Instructions - Parts
Gun Air Shutoff Kit
Automatically shuts off gun atomizing air during purge or color change in ProMix
®
ProMix
2KE, ProMix
systems using gun flush boxes. For professional use only.
Part No. 15V823
®
For use with ProMix
2KS, ProMix
100 psi (0.7 MPa, 7 bar) Maximum Working Pressure
Part No. 234928
®
For use with ProMix
II Electronic Proportioner
100 psi (0.7 MPa, 7 bar) Maximum Working Pressure
Part No. 15V829
®
For use with ProMix
2KS (Second Gun)
Important Safety Instructions
Read all warnings and instructions in this manual.
Save these instructions.
®
PD2K, and ProMix
®
2KE, and ProMix
®
II Proportioning Systems. Not for use in
®
PD2K Electronic Proportioners
310745J
EN
®
2KS,
TI15213a
Advertisement
Table of Contents
Related Manuals for Graco 15V823
Summary of Contents for Graco 15V823
- Page 1 ® ® ProMix 2KE, ProMix PD2K, and ProMix II Proportioning Systems. Not for use in systems using gun flush boxes. For professional use only. Part No. 15V823 ® ® ® For use with ProMix 2KS, ProMix 2KE, and ProMix PD2K Electronic Proportioners 100 psi (0.7 MPa, 7 bar) Maximum Working Pressure...
-
Page 2: Table Of Contents
Technical Data ......17 332562 ProMix PD2K Manual System Operation Graco Standard Warranty ....18 3A2800 ProMix PD2K Manual System Graco Information . -
Page 3: Warnings
Do not alter or modify equipment. • For professional use only. • Use equipment only for its intended purpose. Call your Graco distributor for information. • Route hoses and cables away from traffic areas, sharp edges, moving parts, and hot surfaces. •... -
Page 4: Installation
(13 mm deep NOTE: ProMix 2KS systems can use two guns. Use kit 15V823 for gun 1 and kit 15V829 for gun 2. Kit 15V829 1.375 in. (35 mm) incorporates a shuttle valve to facilitate proper flushing in a two-gun system. -
Page 5: Promix 2Ks Installation
Installation ProMix 2KS Installation Install Solenoid 4. Connect solenoid wires to terminals as shown in . 2-2. 1. Turn off EasyKey™/Control Box power, and shut off 5. Remove air manifold plug from row B (marked on power at main circuit breaker (See your Installation manifold, bottom row) and install tube fitting (4, G1). - Page 6 Installation Install Atomizing Air Shutoff Valve 1. Mount the shutoff valve (2) securely. (See F . 1 on page 4) 2. Install bushing (6) and muffler (9) in the lower port (N/C-Normally Closed). (See F . 3 for steps 2-5.) 3.
-
Page 7: Promix 2Ke Installation
Installation ProMix 2KE Installation Install Solenoid 3. Remove two sealing screws (SS), and install sole- noid valve (3). Tighten screws to secure. 1. Turn off EasyKey™/Control Box power, and shut off (See F . 5-1) power at main circuit breaker. (See your Installation 4. - Page 8 Installation Install Atomizing Air Shutoff Valve 1. Mount the shutoff valve (2) securely. (See F . 1 on page 4.) 2. Install bushing (6) and muffler (9) in the lower port (N/C-Normally Closed). (See F . 6 for steps 2-5.) 3.
-
Page 9: Promix Pd2K Installation
Installation ProMix PD2K Installation Install Solenoid 3. Remove two sealing screws (SS), and install the solenoid valve. Tighten screws to secure. 1. Turn off EasyKey™/Control Box power, and shut off (See F . 7-1) power at main circuit breaker. (See your Installation and Repair-Parts manual in Related Manuals, 4. - Page 10 Installation Install Atomizing Air Shutoff Valve 1. Mount the shutoff valve (2) securely. (See F . 1 on page 4.) 2. Install bushing (6) and muffler (9) in the lower port (N/C-Normally Closed). (See F . 8 for steps 2-5.) 3.
-
Page 11: Promix Ii Installation
Installation ProMix II Installation Install Solenoid 3. Remove Blank Plate (SS), and install solenoid valve (3). Tighten screws to secure. (See F . 9-1) 1. Turn off EasyKey™/Control Box power, and shut off power at main circuit breaker. (See your Installation 4. - Page 12 Installation Install Atomizing Air Shutoff Valve 1. Mount the shutoff valve (2) securely. (See F . 1 on page 4.) 2. Install bushing (6) and muffler (9) in the upper port (N/O-Normally Open). (See F . 10 for steps 2-5.) 3.
-
Page 13: Operation
Operation Operation Operation Sequence Follow the operating instructions in your proportioner’s Operation manual (See Related Manuals, page 2.). ProMix 2KS, ProMix 2KE, and ProMix PD2K: During normal mix mode there is no air supplied to the pilot port. The solenoid (3) supplies an air signal to the pilot port to shut off atomizing air to the gun during purge or If using an electrostatic gun shut off the electrostatics color change mode. - Page 14 Troubleshooting 310745J...
-
Page 15: Parts
Parts Parts Kit No. 15V823, for ProMix 2KS, Kit No. 15V829, for ProMix 2KS ProMix 2KE, and ProMix PD2K (Second Gun) Ref. Part No. Description Qty. 598095 TUBE, nylon, 5/32 in. OD, 10 ft. Ref. (3.05 m) long (not shown; con- Part No. - Page 16 Parts Kit No. 234928, for ProMix II Ref. Part No. Description Qty. 598095 TUBE, nylon, 5/32 in. OD, 50 ft. (15 m) long (not shown; connects solenoid fitting [4] to valve fitting [D]) 570132 VALVE, air safety shutoff 117356 VALVE, solenoid, 12 VDC, IS 114263 FITTING, 1/8 npt x 5/32 tube 112512 FERRULE, wire Order length needed.
-
Page 17: Technical Data
Technical Data Technical Data Kit No. 15V823, for ProMix 2KS, Kit No. 234928, for ProMix II ProMix 2KE, and ProMix PD2K Maximum Working Pressure 100 psi (0.7 MPa, 7 bar) Maximum Working Pressure 100 psi (0.7 MPa, 7 bar) Shutoff Valve Port Fitting Sizes... -
Page 18: Graco Standard Warranty
With the exception of any special, extended, or limited warranty published by Graco, Graco will, for a period of twelve months from the date of sale, repair or replace any part of the equipment determined by Graco to be defective.
