Parts
INSTRUCTIONS–PARTS LIST
INSTRUCTIONS
Preset
PM5t Electronic Metered Dispense Valves
1000 psi (7 MPa, 69 bar) Maximum Working Pressure
5 gpm (18.9 lpm) Maximum Flow Rate
Factory-Set to Measure in Quarts
Model 238511
Model 238512
Model 238515
Factory-Set to Measure in Liters
Model 238513
Model 238514
Model 238516
D This dispense valve is designed to
dispense petroleum-based lubricants and
antifreeze only. Do not dispense
windshield washer solvent with this
dispense valve.
D This dispense valve is designed for indoor
use only.
D This dispense valve is not designed for
in-line installation. Do not install with a
shut-off valve on the outlet side of the
meter. Such installation could result in
damage to the meter housing cover.
Registered Design No. 1025804
This manual contains important
warnings and information.
READ AND KEEP FOR REFERENCE.
75_ bend 3/8-in. rigid tube
3/8-in. coupled flexible hose
90_ offset
75_ bend 3/8-in. rigid tube
3/8-in. coupled flexible hose
90_ offset
CAUTION
GRACO INC. P.O. BOX 1441 MINNEAPOLIS, MN 55440–1441
ECOPYRIGHT 2001, GRACO INC.
Graco Inc. is registered to I.S. EN ISO 9001
309377
First choice when
quality counts.t
TI0327
Model 238511 or 238513 shown
Rev. A
