C4800 / C4070 / C4065 / C4065P - QG No. 01 - Quick Guide Basic Operations Ver. 01.00 Table of Contents Confirmation of Product Configuration Name of Each Component and Control Panel Power-On/Off Paper Feed Route and Paper Jam Processing Replenishment and Replacement of Consumables Cleaning... -
Page 2: Confirmation Of Product Configuration
Confirmation of Product Configuration 1-1. Introduction of Names and Functions of Machines and Options (Including the Controller) This chapter explains the configuration and simple functions of the installed devices. ❖ Paper output system options □ Large Capacity Stacker [LS-507] □ Relay Unit [RU-518m] □... - Page 3 Confirmation of Product Configuration * The photo below shows an example of the product configuration (combination of options). Control Panel ❖ Machine 本体 ❖ Document system options □ C4080 □ Reverse Automatic Document Feeder [DF-713]（ADF） □ C4070 □ Original Cover [OC-511]（Original Cover） □...
-
Page 4: Name Of Each Component
Name of Each Component and Control Panel 2-1. Name of Each Machine Component Front door Sub power switch Main power switch Toner bottle Fusing Conveyance Unit 2-2. Control Panel of Machine ● Reset Press this button to return the setting ●... - Page 5 Name of Each Component and Control Panel 2-3. Control Panel of Option For details about how to use the control panel of each option, view the video. ● Storage button (Output Tray) ● Eject button (Paper in stacker tray) [LS-507] LS-507 operation button ●...
-
Page 6: Power-On/Off
Power-On/Off 3-1. Machine This system has 2 power switches, namely, main power switch and sub power switch. Be careful of the order of turning these 2 power switches on and off. Power-On Approx. minutes and seconds Main power ON Sub Power ON "Please wait"... - Page 7 Power-On/Off "Please wait" "Machine is warming up" "Ready to print" "Now adjusting" "Please wait for a while" *1: The displayed message varies depending on the option you are using. • It takes a certain amount of time from when the main power is turned on until it is ready for printing.
- Page 8 Power-On/Off 3-2. KM Controller Power-ON/OFF Turn the power on/off in the following order. 1. Turn the machine on or off. 2. Turn the controller on or off. • For information about how to turn the machine on, refer to "3-1. Machine".
- Page 9 Power-On/Off 3-5. Recommended Useful Functions This system provides useful functions related to the power supply and job output of the KM and Fiery controllers. ✓: Functions are provided. Name Description Fiery Machine/controller Set whether to synchronize the power supply ✓ ✓...
-
Page 10: Paper Feed Route And
Paper Feed Route and Paper Jam Processing 4-1. 本体通紙経路 Output Tray Output Tray Output Tray * The product configuration (combination of options) is an example. 4-2. How to See the Paper Jam Display • If a paper jam occurs while printing or copying, the message [Paper JAM] and the paper jam location are displayed on the control panel (screen). - Page 11 Paper Feed Route and Paper Jam Processing Main paper feed flow 4-3. Precautions for Clearing Paper Jams • When clearing paper jams, leave the main power switch or sub power switch on. When the power is turned off, you cannot pull out the tray or the conveyance fixing unit.
-
Page 12: Replenishment And Replacement Of Consumables
Replenishment and Replacement of Consumables 5-1. What Are Consumables? Consumables are parts that require processing such as replenishment, disposal, and replacement of this system. The main processing of consumables is as follows: Toner bottle replacement, Waste toner box replacement, Staple needle replenishment/disposal, *Glue pellet replenishment, Humidification tank water supply, Trimming scrap disposal * Staple needle disposal: Dispose of needle scraps generated when staple needles are cut... - Page 13 Replenishment and Replacement of Consumables 5-3. Consumables Replenishment/Replacement Procedure 1. Check the consumables replacement message. A replacement message is displayed on the upper left of the touch panel, and the name of the corresponding consumable item in [Consumable and Scrap Indicators] on the lower left is displayed in yellow.
-
Page 14: Cleaning
Cleaning 6-1. Cleaning Each Component To achieve the stable output, check the following points every day before turning on the machine, and clean them if necessary. IQ-501 cleaning (video) ② PF-707ｍ cleaning (video) Cleaning timing: When a cleaning message Cleaning timing: When paper jams is displayed on the control panel frequently occur or the print paper is dirty... -
Page 15: Usage Environment And Machine Specifications
Usage Environment and Machine Specifications 7-1. Usage Environment In order to maintain the performance of this system and use it comfortably, please protect the usage environment of this system and the storage environment of paper and consumables. [Temperature and humidity] •... - Page 16 Usage Environment and Machine Specifications 7-2. Machine Specifications Name C4080 / C4070 / C4065 / C4065P 6 minutes 30 seconds or less (23 ° C, 50% RH, rated voltage when electric current is Warm-up time running through) C4080 / C4070: Metric area: AC 220 V to 240 V / 25 A, 50/60 Hz Inch Area: AC 208 V to 240 V / 24 A, 60 Hz Australia and New Zealand: AC 220 V to 240 V / 20 A, 50/60 Hz...
