Page 1 This manual deals with the operation and care of your Volvo. Welcome to the world-wide family of Volvo owners. We trust that you will enjoy many years of safe driving in your Volvo, an automobile designed with your safety and comfort in mind. To help ensure your satisfaction with this vehicle, we encourage you to familiarize yourself with the equipment descriptions, operating instructions and maintenance requirements/recommendations in this manual.
Page 2 Chapter 10 - Audio systems Homelink® Universal Transceiver (option) Index Back Cover NOTE: This manual contains information on the Volvo C70 Coupe and C70 Convertible. Unless otherwise stated, the information pertains to both models. General information file:///K|/ownersdocs/2002/2002_C70/02c70c_00.htm (2 of 6)12/30/2006 3:53:41 PM...
Page 3 Volvo reserves the right to make model changes at any time, or to change specifications or design, without notice and without incurring obligation.
Page 4 16). Volvo and the environment Volvo is committed to the well being of our customers. As a natural part of this commitment, we care about the environment in which we all live. Caring for the environment means an everyday involvement in reducing our environmental impact.
Page 5 In addition to continuous environmental refinement of conventional gasoline-powered internal combustion engines, Volvo is actively looking at advanced technology alternative-fuel vehicles. When you drive a Volvo, you become our partner in the work to lessen the car's impact on the environment.
Page 6 2002 Volvo C70 Copue & Convertible · Properly dispose of any vehicle related waste such as used motor oil, used batteries, brake pads, etc. · When cleaning your car, use Volvo's own car care products, all of which have systematically been adapted to the environment For additional information regarding the environmental activities in which Volvo Cars of North America, Inc.
Page 7: Table Of Contents
Occupant safety Not wearing a seat belt is like believing "It'll never happen to me!". Volvo, the inventor of the three- point seat belt, urges you and all adult occupants of your car to wear seat belts and ensure that children are properly restrained, using an infant, car or booster seat determined by age, weight and height.
Page 8: Seat Belts
2002 Volvo C70 Coupe & Convertible Reporting Safety Defects 14 pg. 2 Seat belts Seat belts Always fasten the seat belts before you drive or ride. Two lights above the rear view mirror will be illuminated for 4-8 seconds after the starting (ignition) key is turned to the driving position.
Page 9 For information on securing child seats, please refer to page 11. WARNING! The rear seat of the Volvo C70 is intended for two occupants only. Only two three-point seat belts are provided. The center position should never be used to seat a passenger. WARNING! ·...
Page 10: Volvo Srs
WARNING! · The rear seat of the Volvo C70 is intended for two occupants only. Only two three-point seat belts are provided. The center position should never be used to seat a passenger.
Page 11 As an enhancement to the three-point seat belt system, your Volvo is equipped with a Supplemental Restraint System (SRS). The Volvo SRS consists of an airbag (2) on both the driver's and passenger's sides and seat belt tensioners in both front door pillars (4). The system is designed to supplement the protection provided by the three-point seat belt system.
Page 12 · When installing any optional equipment, make sure that the SRS system is not damaged. Do not attempt to service any component of the SRS yourself. Attempting to do so may result in serious personal injury. If a problem arises, take your car to the nearest authorized Volvo retailer for inspection as soon as possible.
Page 13 (wiring, connectors, etc.) should also be inspected at this time. The SRS decal on your car shows the month and year servicing is due. This service must be performed by an authorized Volvo retailer. Should you have any questions about the SRS system, please contact...
Page 14 Volvo's dual-threshold air bags use special sensors that are integrated with the front seat buckles. The point at which the air bag deploys is determined by whether or not the seat belt is being used, as well as, the severity of the collision.
Page 15 · If the airbags have been deployed, we recommend the following: · Have the car towed to an authorized Volvo retailer. Never drive with the airbags deployed. · Have an authorized Volvo retailer replace the SRS system components.
Page 16 2002 Volvo C70 Coupe & Convertible The heart of the Volvo safety system is the threepoint seat belt (a Volvo invention)! In order for the SRS system to provide the protection intended, seat belts must be worn at all times by everyone in the car.
Page 17: Bag
2002 Volvo C70 Coupe & Convertible pg. 8 Volvo Side Impact Protection System (SIPS) airbag SIPS airbag As an enhancement to the structural Side Impact Protection System built into your car, the car is also equipped with Side Impact Protection System (SIPS) airbags. The SIPS airbag system consists of airbag modules built into the sides of both front seat backrests (1), cables (2) from these modules to the mechanical sensor units (3) and gas generators (4).
Page 18 This may cause airbag deployment which could result in personal injury. Have the car towed to an authorized Volvo retailer for repairs. pg. 9 Whiplash protection System (WHIPS)
Page 19: Whips
· If your car has been involved in a collision, the front seat backrests must be inspected by an authorized Volvo retailer even if the seats appear to be undamaged. Certain components in the WHIPS system may need to be replaced. Do not attempt to service any component in the WHIPS system yourself.
Page 20 Seats belts for all seating positions are equipped with seat belt tensioners. WARNING! The rear seat of the Volvo C70 is intended for two occupants only. Only two three-point seat belts are provided. The center position should never be used to seat a passenger.
Page 21 The rear seat of the Volvo C70 is intended for two occupants only. Only two three-point seat belts are provided. The center position should never be used to seat a passenger.
Page 22 Because of the size of the air bag and its speed of inflation, a child should never be placed in the front seat, even if he or she is properly belted or strapped into a child safety seat. Volvo has been an innovator in safety for over fifty years, and we'll continue to do our part.
Page 23: Child Safety
2002 Volvo C70 Coupe & Convertible · Volvo recommends that ALL occupants (adults and children) shorter than four feet seven inches (140 cm) be seated in the back seat of any vehicle with a front passenger side airbag. Drive safely! * Automatic Locking Retractor/Emergency Locking Retractor pg.
Page 24: Occupant Safety
Volvo Concern for Safety Safety is the cornerstone for Volvo. Our concern dates back to 1927 when the first Volvo rolled off the production line. Threepoint seat belts (a Volvo invention), safety cages, and energyabsorbing impact zones were designed into Volvo cars long before it was fashionable or required by government regulation.
Page 25 However, NHTSA cannot become involved in individual problems between you, your retailer, or Volvo Cars of North America. To contact NHTSA, you may either call the Auto Safety Hotline tollfree at 1-800-424-9393 (or 202-366-0123 in Washington, D.C. area) or write to: NHTSA, U.
Page 26 2002 Volvo C70 Coupe & Convertible Contents Top of Page file:///K|/ownersdocs/2002/2002_C70/02c70c_01b.htm (10 of 10)12/30/2006 3:53:43 PM...
Page 27 2002 Volvo C70 Coupe & Convertible 2 0 0 2 VOLVO C70 Coupe & Convertible Chapter 2 - Instruments, switches and controls pg. 16 Instruments, switches and controls pg. 17 Instruments, switches and controls The pages in this section provide detailed descriptions of the vehicle's instruments and controls. Note...
Page 28 2002 Volvo C70 Coupe & Convertible that vehicles may be equipped differently, depending on special legal requirements. Page 1 Air vents 2 Headlights, parking lights 3 Instrument illumination 4 Rear fog light 5 Front fog lights (optional) 6 Space for additional equipment...
Page 29 2002 Volvo C70 Coupe & Convertible 28 Shiftlock release button (automatic transmission only) 69-71 29 Gear selector shift positions 30 Winter mode selector 31 Parking brake 32 Horn/SRS 33 Trunk open control 34 Power window controls 35 Power mirror controls...
Page 30 2002 Volvo C70 Coupe & Convertible 3 Speedometer 4 Clock, ambient temperature sensor, trip computer (certain models) 5 Odometer 6 Trip odometer NOTE: Digital displays showing Clock, Trip Odometer and Odometer will go off 30 minutes after the ignition has been switched off. To view these displays again, turn the ignition key to position I.
Page 31 2002 Volvo C70 Coupe & Convertible 2 Turn signal, right 3 Cruise control (C70 Coupe) - Roll Over Protection system - ROPS (C70 Convertible) 4 Low washer fluid level If the lamp glows continuously when the engine is running, there is only about 1/2 - 1 US qt. remaining in the washer fluid reservoir.
Page 32 When this happens, please have your car checked by a Volvo retailer as soon as possible. A CHECK ENGINE light may have many causes. Sometimes, you may not notice a change in your car's behavior.
Page 33 If the warning lamp remains on after the engine has started or comes on while you are driving, the ROPS self-diagnostic system has detected a fault. The car should be driven to an authorized Volvo retailer as soon as possible for inspection.
Page 34 If the light comes on (or stays on after the vehicle has started), the SRS diagnostic system has detected a fault. Drive to an authorized Volvo retailer for an inspection of the system. See the SRS section for more information.
Page 35 2002 Volvo C70 Coupe & Convertible This light will come on at 7,500 mile (12,000 km) intervals, after 750 hours of driving or after 12 months, whichever occurs first. It is a reminder to the driver that the service interval has been exceeded.
Page 36 2002 Volvo C70 Coupe & Convertible Headlights and parking lights All lights off * Parking lights on * Headlights and parking lights are on if starting (ignition ) switch is in positions I or II. If the headlight switch is in the position all lights will go out when the starting switch is switched off.
Page 37 2002 Volvo C70 Coupe & Convertible 3 High beam/low beam switch (headlights on). Move the lever towards the steering wheel and release it. Headlight flasher (headlights off). Move the lever towards the steering wheel. The headlight high beam will be on until the lever is released.
Page 38 2002 Volvo C70 Coupe & Convertible 5 Windshield wiper/washer, headlight wiper/washer The wipers will make 23 sweeps across the windshield and headlights (certain models) after the lever is released. O Locked position: Remove the key to lock the steering wheel* WARNING! Never turn the key to position O while driving or when the car is being towed.
Page 39 2002 Volvo C70 Coupe & Convertible 1 - Instrument illumination To increase the brightness: move the thumbwheel up. To decrease the brightness: move the thumbwheel down. 2 - Rear fog light * The rear fog light (located in the driver's side tail light cluster) is considerably brighter than the normal tail lights and should be used only when the atmospheric conditions, such as fog, rain, snow, smoke or dust reduce the daytime or nighttime visibility of other vehicles to less than 500 ft (150 meters).
Page 40 2002 Volvo C70 Coupe & Convertible Contents Top of Page file:///K|/ownersdocs/2002/2002_C70/02c70c_02a.htm (14 of 14)12/30/2006 3:53:45 PM...
Page 41 2002 Volvo C70 Coupe & Convertible pg. 25 STC, Sun roof, Trip computer, Hazard warning flashers, Demister 6 - Stability and Traction control (STC) - option page 79 for more information on this system. 7 - Electrically operated sun roof - option (C70 Coupe)/...
Page 42 2002 Volvo C70 Coupe & Convertible Hazard warning flashers The four-way flasher (located above the ashtray) should be used to indicate that the vehicle has become a traffic hazard. NOTE: Regulations regarding the use of the hazard warning flasher may vary from state to state.
Page 43 2002 Volvo C70 Coupe & Convertible The daytime running lights will also function when the headlight switch is in position and switch A is in this position. All lights off (daytime running light function disabled) NOTE: The daytime running light function may only be disabled (turned off) in the U.S. Canadian law mandates the use of daytime running lights.
Page 44 2002 Volvo C70 Coupe & Convertible Display alternatives If buttons A and B are pressed down simultaneously, it is possible to shift between four different display alternatives: Press 1st time: 12 hour clock and °F Press 2nd time: 24 hour clock and °F Press 3rd time: 12 hour clock and °C...
Page 45 2002 Volvo C70 Coupe & Convertible Trip computer controls Select one of the trip computer's six functions by using control B. The Reset button (C) is used to reset the following functions: · Average speed · Average fuel consumption · Trip meter Rotate the control to the required position and press the button for at least two seconds to reset the selected function.
Page 46 2002 Volvo C70 Coupe & Convertible (Canada: L/100 km) Continuous information on current fuel consumption, calculated once per second. When the car is not moving, the display shows "---". Average fuel consumption Ø mpg (Canada: L/100 km) Average fuel consumption since the function was last reset.
Page 47 2002 Volvo C70 Coupe & Convertible Driving distance on current fuel reserve mile ==> 0 (Canada: km) Shows the approximate distance which can be driven on the fuel remaining in the tank, calculated on the basis of the average fuel consumption during the last 12 miles (20 km) driven and the amount of fuel remaining in the tank at the time of the reading.
Page 48 2002 Volvo C70 Coupe & Convertible Braking This will automatically disengage the cruise control. The previously selected cruise speed is retained in the memory and by momentarily setting the switch to the RESUME position, that speed will be reengaged. If the cruise control is already engaged, the cruising speed can be increased or decreased by depressing the SET button (A) towards either + or -.
Page 49 2002 Volvo C70 Coupe & Convertible Heated front seats The heated front seats can be switched on and off as required. When switched on, the system senses the ambient temperature and regulates the level of heat applied. When the optimum temperature is reached, the heating switches off automatically.
Page 50 2002 Volvo C70 Coupe & Convertible WARNING! Always use the parking brake (hand brake) when parking. On hills, also turn the front wheels toward the curb. The indicator light in the instrument panel will light up even if the parking brake is only applied slightly.
Page 51 2002 Volvo C70 Coupe & Convertible pg. 33 Ashtrays, Auxiliary socket Ashtray Front ashtray (option) To open the front ashtray, press lightly on the panel. To empty the front ashtray: · Put the gear selector (aut. transmission) in position L. To release the gear selector from the (P)ark position, the ignition key must be in position II and the brake pedal must be depressed.
Page 52 This 12 volt socket can be used to plug in certain accessories such as cellular telephones, etc. A cigarette lighter, available as an accessory from your Volvo retailer, may also be used in this socket. The key must be in position I (or higher) for the auxiliary socket to function.
Page 53 A-open, B-closed, C-horizontal air flow, D-vertical air flow Heating and air conditioning Your Volvo is equipped with a heating system combined with air conditioning. Depending on which function you select, warm or cool/cold air is distributed to the different parts of the passenger...
Page 54 CFC-free refrigerant - R134a. This substance will not deplete the ozone layer. The system contains 1.63 lbs (0.75 kg) R134a and uses ZXL 100PG (type PAG) oil. NOTE: All maintenance on the climate control systems should be carried out by an authorized Volvo service technician only.
Page 55 2002 Volvo C70 Coupe & Convertible Function selector AUT Air distribution automatically regulated Air through panel vents Defrost. Air to windshield and side windows. Recirculation will not function regardless of button setting. Air to floor, windshield and side windows. Air through floor vents.
Page 56 2002 Volvo C70 Coupe & Convertible minute period will allow fresh air into the passenger compartment. Press the ON button again for more than 3 seconds to return the button to its original function (i.e., Recirculation will remain on until the OFF button is pressed).
Page 57 2002 Volvo C70 Coupe & Convertible · Water under the vehicle in hot weather can be the result of condensation from the air conditioning system and is quite normal. · The air conditioning is disengaged when the blower is set at 0 and the speed of the vehicle is less than 20 mph (30 km/h).
Page 58 2002 Volvo C70 Coupe & Convertible Faults in the ECC system The RECIRCULATION ON and AC OFF lights will flash for approximately 20 seconds if a fault is detected in the ECC system. If this flashing recurs the next time the system is switched on, the climate control unit should be checked by an authorized Volvo retailer.
Page 59 2002 Volvo C70 Coupe & Convertible WARNING! · Remove the ignition key when children are left unattended in the vehicle. · Make sure that childrens' hands are clear before raising the windows. · Never leave children unattended in the car.
Page 60 2002 Volvo C70 Coupe & Convertible Electrically operated windows - C70 Convertible The electrically operated windows are controlled by buttons on the driver's door armrest. The starting (ignition) switch must be ON (intermediate position I) for the electrically operated windows to function.
Page 61 2002 Volvo C70 Coupe & Convertible This button can be used to raise/lower all windows at the same time. To lower: press the right side of the button. To raise: press the left side of the button. Cut-off function - rear windows To prevent the rear windows from being opened with the buttons in the rear seat, pull up the front edges of both rear window buttons on the driver's door quickly and release them.
Page 62 2002 Volvo C70 Coupe & Convertible 2 0 0 2 VOLVO C70 Coupe & Convertible Chapter 3 - Body and interior pg. 41 Body and interior Page Storage compartments Sun roof Convertible top/wind deflector Keys, doors and locks Remote keyless entry system...
Page 63: Sun Roof
2002 Volvo C70 Coupe & Convertible 1 Glove compartment 2 Shelf under glove compartment 3 Coin holder 4 Compartment in door 5 Pocket on rear of front seat 6 Compartment between front seats 7 Cup holder pg. 43 Sun roof (option) - C70 Coupe...
Page 64 2002 Volvo C70 Coupe & Convertible Electrically operated sun roof The switch for operating the sun roof is located on the instrument panel. The starting (ignition) key must first be turned to the drive position (position II). The sun roof is also equipped with a one-touch, AUTO-open function.
Page 65 2002 Volvo C70 Coupe & Convertible pg. 44 Electrically operated convertible top Electrically operated convertible top Electrically operated convertible top To lower the convertible top: · Start the engine. The car must be at a standstill, the parking brake must be ON and the trunk must be closed when raising/lowering the convertible top.The gear selector must be in position P...
Page 66 · Be sure there is sufficient clearance above the car before raising/lowering the convertible top. · Volvo recommends that you raise the convertible top and close the windows when you leave the car to help deter thefts and to protect the interior from rain, windblown dust, etc.
Page 67: Keys, Doors And Locks
2002 Volvo C70 Coupe & Convertible Wind deflector (option/accessory) Installing the wind deflector: · Fold out the panels on the sides of the wind deflector (1). · Slide the two metal slats on the wind deflector under the rear seat head restraints (2). Slide them carefully to avoid damaging the upholstery.
Page 68 2002 Volvo C70 Coupe & Convertible Doors and locks Your car is equipped with a central locking system. The key, used on the driver's door, the remote control or central locking button, will lock/unlock both doors and the trunk. · Turn the key once to unlock the driver's door only.
Page 69: Remote Keyless Entry System
The car can only be started if a properly coded key is used. If you misplace a key, take the other keys to an authorized Volvo retailer. The existing code in the start inhibitor module and all the keys will be erased as an antitheft measure and a new code will be programmed in.
Page 70 WARNING! Volvo does not recommend using the transmitter to lock the doors from inside the car. On cars equipped with an alarm, the alarm would be activated and would sound when one of the doors is opened. The doors must not be locked using the remote transmitter while the vehicle is occupied. In case of an accident, this may hinder rapid access to the occupants of the vehicle.
Page 71: Alarm
2002 Volvo C70 Coupe & Convertible Canadian 2306104388 Model 504 2927 by Donnelly Operation is subject to the following conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device...
Page 72 2002 Volvo C70 Coupe & Convertible · The battery is disconnected (if the car is equipped with the optional backup battery siren). The alarm will sound for ten 30 second intervals, with a 5 second pause between intervals. This function cannot be...
Page 73 2002 Volvo C70 Coupe & Convertible NOTE: This button will NOT unlock the car. Audible alarm signal An audible alarm signal is given either by a separate alarm horn or by the optional backup siren. One alarm cycle lasts for 30 seconds.
Page 74: Front Seats
Reinstall the cover, making sure it is secured tightly to help protect the transmitter. CAUTION: Do not attempt to service or repair any components of the alarm system yourself. This should only be done by an authorized Volvo retailer. pg. 50 Front seats Electrically operated seats with memory function file:///K|/ownersdocs/2002/2002_C70/02c70c_03a.htm (13 of 17)12/30/2006 3:53:50 PM...
Page 75 2002 Volvo C70 Coupe & Convertible 1 Lumbar support 2 Strap for controlling front seat for rear seat passengers 3 Backrest release control lever 4 Power seat control panel Power seat control panel A-seat front (raise/lower), B-forward/rearward, C-seat rear (raise/lower), D-backrest tilt WARNING! The power seats are operable with the ignition OFF.
Page 76 2002 Volvo C70 Coupe & Convertible Buttons 2 and 3 can be programmed in the same way. To move the seat to a programmed position, depress button 1, 2 or 3 until the seat stops. If the button is released before the seat has reached the programmed position, the seat will stop as a safety precaution.
Page 77 2002 Volvo C70 Coupe & Convertible reaches the forward-most position. Manually operated passenger's seat**: When the backrest has been tilted forward , the seat can be moved forward/rearward without holding the control on the side of the seat. To tilt up the backrest to its normal position: 1.
Page 78 2002 Volvo C70 Coupe & Convertible 2 Forward-rearward seat adjustment Pull the bar upward, then slide the seat forward or rearward to the desired position. Make sure that the seat is properly secured when you release the bar. 3 Backrest tilt Rotate the control counterclockwise to tilt the backrest rearward and clockwise to tilt the backrest forward.
Page 79: Rear/Side View Mirrors
2002 Volvo C70 Coupe & Convertible pg. 53 Rear/side-view mirrors Rear-view mirror A Normal position B Night position, reduces glare from following headlights CAUTION: Never use ice scrapers made of metal as they can easily scratch the mirror surface. Auto-dim function (certain models) A Indicator light file:///K|/ownersdocs/2002/2002_C70/02c70c_03b.htm (1 of 12)12/30/2006 3:53:51 PM...
Page 80 2002 Volvo C70 Coupe & Convertible B Sensor The Auto-dim function reacts to high beams from the car behind you and switches the mirror automatically to "night" position. NOTE: If the right indicator light (see inset illustration above) is on, the Auto-dim function is ON. Press the button (see arrow) to turn the function ON or OFF.
Page 81 2002 Volvo C70 Coupe & Convertible Front courtesy lights The front courtesy lighting consists of two reading lights for the front seat occupants. Front and rear reading lights always on Front and rear reading lights always off Front and rear reading lights come on when a door is opened...
Page 82 2002 Volvo C70 Coupe & Convertible Vanity mirrors - C70 Coupe The light illuminates when the cover is opened. The driver's side vanity mirror will only illuminate if the ignition key is in position I. Vanity mirrors - C70 Convertible Fold down the sun visor and slide the cover to the side to illuminate the mirror.
Page 83 2002 Volvo C70 Coupe & Convertible Reading lights, rear seat - C70 Coupe There are two reading lights for the rear seat passengers. These are turned on/off by using the adjacent switches. Light is on if the front switch is in position Light turns on if any door is opened.
Page 84: Long Load Storage
2002 Volvo C70 Coupe & Convertible pg. 57 Long load storage Long load storage There is a flap located in the panel behind the rear seat which makes is possible to carry long loads such as skis, etc. To open, pull the strap forward, see illustration above.
Page 85 2002 Volvo C70 Coupe & Convertible To open the hood · Pull the lever located under the left side of the dash to release the hood lock. · Lift the hood slightly. · Pull the release control on the inside of the lower edge of the grille toward you and lift the hood.
Page 86: Opening The Trunk
2002 Volvo C70 Coupe & Convertible Opening the trunk The trunk can be opened by: · Pressing the button on the remote control (A) twice within 3 seconds · Using the master key in the trunk lock · Using the trunk control on the driver's door (B) Locking the trunk The trunk lock is incorporated in the central locking system.
Page 87: Trunk Light, Spare Tire, Jack
2002 Volvo C70 Coupe & Convertible NOTE: This handle is not intended to be used to anchor the trunk lid when long loads are being transported. Opening the trunk from the inside WARNING! Keep vehicle doors and trunk locked and keep keys out of a child's reach. Unsupervised children could lock themselves in an open trunk and risk injury.
Page 88: Securing Cargo, Avoiding Battery Drain
2002 Volvo C70 Coupe & Convertible A Light always off B Light is on when the trunk lid is open Spare tire The spare tire is located under the carpet in a special well under the floor of the trunk. The jack is placed inside the wheel rim.
Page 89 2002 Volvo C70 Coupe & Convertible Eyelets in trunk Securing cargo As a safety precaution, your car is equipped with four eyelets to which straps can be attached to secure luggage. WARNING! The eyelets are not to be used as passenger restraints or as anchorages for child restraints. See...
Page 90 2002 Volvo C70 Coupe & Convertible pg. 62 This page left intentionally blank Contents Top of Page file:///K|/ownersdocs/2002/2002_C70/02c70c_03b.htm (12 of 12)12/30/2006 3:53:51 PM...
Page 91 2002 Volvo C70 Coupe & Convertible 2 0 0 2 VOLVO C70 Coupe & Convertible Chapter 4 - Starting and driving pg. 63 Starting and driving Page Fuel requirements, Refueling Driving economy Starting the engine Manual transmission Automatic transmission Points to remember...
Page 92 Unleaded fuel Each Volvo has a three-way catalytic converter and must use only unleaded gasoline. U.S. and Canadian regulations require that pumps delivering unleaded gasoline be labelled "UNLEADED". Only these file:///K|/ownersdocs/2002/2002_C70/02c70c_04a.htm (2 of 11)12/30/2006 3:53:53 PM...
Page 93 (MMT). If such fuels are used, your Emission Control System performance may be affected, and the Malfunction Indicator Lamp located on your instrument panel may light. If this occurs, please return your vehicle to an authorized Volvo retailer for service. Octane rating Volvo engines are designed for optimum performance on unleaded premium gasoline with an octane rating.
Page 94: Fuel Requirements, Refueling
To meet seasonal air quality standards, some areas require the use of "oxygenated" fuel. Volvo allows the use of the following "oxygenated fuels; however, the octane ratings listed on this page must still be met.
Page 95 2002 Volvo C70 Coupe & Convertible Fuel filler door control on driver's door Refueling The fuel tank holds approximately 17.9 US gal. (68 liters) with sufficient volume left over to accommodate possible expansion of the fuel in hot weather. Be aware that the "usable" tank capacity will be somewhat less than the specified maximum.
Page 96: Driving Economy
2002 Volvo C70 Coupe & Convertible Malfunction Indicator Lamp may indicate a fault. However, your vehicle's performance will not be affected. Use only Volvo original or approved fuel filler caps. pg. 67 Driving economy Economical driving conserves natural resources Better driving economy may be obtained by thinking ahead, avoiding rapid starts and stops and adjusting the speed of your vehicle to immediate traffic conditions.
Page 97 2002 Volvo C70 Coupe & Convertible Starting and stopping 1. Fasten the seat belt. WARNING! Before starting, check that the seat, steering wheel and mirrors are adjusted properly. Make sure the brake pedal can be depressed completely. Move the seat closer if necessary. Refer to section "front seats".
Page 98: Manual Transmission
2002 Volvo C70 Coupe & Convertible immediately after selecting a gear will cause harsh engagement and premature transmission wear. NOTE: Selecting P or N (automatic transmission) when idling at a standstill for prolonged periods of time will help prevent overheating of transmission oil.
Page 99: Automatic Transmission
2002 Volvo C70 Coupe & Convertible Depress the clutch pedal completely when changing gears*. Remove your foot from the clutch pedal while driving. Overdrive (5th gear) should be used as often as possible to help improve fuel economy. This gear can be engaged at speeds above approx.
Page 100 2002 Volvo C70 Coupe & Convertible P (Park) Use this position when starting the engine or parking the car. Never use P while the car is in motion. The parking brake should be set whenever the car is parked. The gear selector is mechanically locked in the P position (SHIFTLOCK). To release the gear selector from this position, the engine must be running (or the ignition key must be in position II) and the brake pedal must be depressed.
Page 101 2002 Volvo C70 Coupe & Convertible 4 (Intermediate gear) The transmission will shift automatically between gears 4, 3, 2 or 1 from this position. The transmission cannot shift up to (D) from fourth gear. 3 (Intermediate gear) The transmission will shift automatically between gears 3, 2 and 1 from this position. The transmission cannot shift up to fourth gear of (D)rive from third gear.
Page 102 2002 Volvo C70 Coupe & Convertible pg. 71 Automatic transmission Automatic transmission - shift gate positions The gear selector can be moved freely between N and D. Depressing the selector knob enables you to move the gear selector to positions P, R, N, D, 4, 3 and L.
Page 103: Points To Remember
2002 Volvo C70 Coupe & Convertible pg. 72 Points to remember Special tips automatic transmission For driving down steep hills and when driving for prolonged periods at low speeds, position L should be selected. Avoid, however, repeated changes since this can cause overheating of the transmission oil.
Page 104 Not more than one protective floor covering may be used at one time. * To prevent injury from contact with hot surfaces, do not insect your car's transmission oil yourself. Have your car's transmission fluid level inspected by a qualified Volvo service technician. pg.73 Points to remember Cooling system The risk for engine overheating is greatest, especially in hot weather, when: Towing a trailer up steep inclines for prolonged periods at wide open throttle and low engine rpm.
Page 105 The radio must be turned off before the battery is disconnected. The anti-theft code must be re-entered before the radio will function properly. The electrical system in your car is designed to accommodate Volvo accessories. It also has an accessory connector located beneath the dashboard on the driver's side.
Page 106: Roof/Trunk-Mounted Luggage Racks
Anchor the cargo correctly with appropriate tie-down equipment. Drive carefully. Avoid rapid starts, fast cornering and hard braking. Max. roof load is 220 lbs (100 kg) when Volvo approved removable roof racks are attached to the points indicated in the illustration.
Page 107: Emergency Towing
Avoid single-point loads. Distribute loads evenly. Volvo-approved removable roof racks are designed to carry the maximum roof load allowable for this vehicle: 220 lbs (100 kg.). For Non-Volvo roof racks, check the manufacturer's weight limits for the rack. Never exceed the roof rack manufacturer's weight limits and never exceed the maximum rated roof load of 220 lbs (100 kg).
Page 108: Vehicle Towing Information
2002 Volvo C70 Coupe & Convertible Automatic transmissions only: Gear selector in position N. Check transmission oil level (see section titled "Transmission oil". Maximum speed: 50 mph (80 km/h). Maximum distance with front wheels on ground: 50 miles (80 km).
Page 109 Towing cars with front wheel drive Volvo recommends the use of flat bed equipment. If wheel lift equipment must be used, please use extreme caution to help avoid damage to the car. In this case, the car should be towed with the rear wheels on the ground if at all possible.
Page 110: Jump Starting
2002 Volvo C70 Coupe & Convertible Jump starting If the 12-volt booster battery to be used is in another car, check that the cars are not touching to prevent premature completion of a negative circuit. Note the position of the battery terminals and using jumper cables: First connect the booster battery positive (+) terminal (1) to car battery positive (+) terminal (2).
Page 111 2002 Volvo C70 Coupe & Convertible PROPOSITION 65 WARNING! Battery posts, terminals, and related accessories contain lead and lead compounds, chemicals known to the state of California to cause cancer and reproductive harm. Wash hands after handling. NOTE: Refer to page 126 for information on properly maintaining the battery.
Page 112 If the warning lamp lights up there is a malfunction of the ABS system (the standard braking system will however function) and the vehicle should be driven cautiously to a Volvo retailer for inspection. The Anti-lock Braking System (ABS) helps to improve vehicle control (stopping and steering) during severe braking conditions by limiting brake lock-up.
Page 113 If the BRAKE and ABS warning lights come on at the same time, this could indicate a fault in the brake system. If the brake fluid level is above the MIN mark, drive carefully to an authorized Volvo retailer and have the brake system inspected.
Page 114: Trailer Towing
If the system is temporarily switched off due to high brake temperatures. STC will automatically restart when brake temperature has returned to normal. If a fault is detected in the system. Consult your Volvo retailer if this occurs. pg. 80 Trailer towing...
Page 115: Winter Driving
More frequent vehicle maintenance is required. Remove the ball and drawbar assembly when the hitch is not being used. Volvo recommends the use of synthetic engine oil when towing a trailer over long distances or in mountainous areas. NOTE: Refer to section "Automatic transmission" for additional trailer hauling tips.
Page 116 It is therefore advisable to check the state of charge more frequently and spray an anti-rust oil on the battery posts. Volvo recommends the use of snow tires on all four wheels for winter driving - see section "Wheels and tires".
Page 117 If the fluid level is below the MIN mark in either section of the reservoir: DO NOT DRIVE. Tow the car to a Volvo retailer and have the brake system checked and any leakage repaired. file:///K|/ownersdocs/2002/2002_C70/02c70c_04c.htm (6 of 6)12/30/2006 3:53:56 PM...
Page 118 2002 Volvo C70 Coupe & Convertible 2 0 0 2 VOLVO C70 Coupe & Convertible Chapter 5 - Wheels and tires pg. 83 Wheels and tires Page General information, Wear indicator, Tire economy, Flat spots Snow chains, Snow tires Inflation pressure Uniform tire quality grading pg.
Page 119 2002 Volvo C70 Coupe & Convertible should be noted however that the tires have been developed to give these features on snow/icefree surfaces. Certain models are equipped with "all-season" tires, which provide a somewhat higher degree of road holding on slippery surfaces than tires without the "all-season" rating. However, for optimum road holding on icy or snow covered roads we recommend suitable winter tires on all four wheels.
Page 120 Snow chains can be used on your Volvo with the following restrictions: Snow chains should be installed on front wheels only. Use only Volvo approved snow chains. Snow chains may be mounted on tire dimension 195/65R15. Tire dimension 205/55R16 requires a special type of snow chain.
Page 121 2002 Volvo C70 Coupe & Convertible Do not mix tires of different design as this could also negatively affect overall tire road grip. Volvo recommends 195/65 R15 winter tires on 15" steel wheels on all C 70 models including those equipped with 16", 17"...
Page 122 2002 Volvo C70 Coupe & Convertible *Please note that the tire information label indicates pressure for both comfort and fuel economy. Tire pressure label pg. 87 Wheels and tires Uniform tire quality grading ALL PASSENGER CAR TIRES MUST CONFORM TO FEDERAL SAFETY REQUIREMENTS...
Page 123 2002 Volvo C70 Coupe & Convertible TEMPERATURE The temperature grades are AA (the highest), A, B, and C, representing the tire's resistance to the generation of heat and its ability to dissipate heat when tested under controlled conditions on a specified indoor laboratory test wheel.
Page 124 2002 Volvo C70 Coupe & Convertible 2 0 0 2 VOLVO C70 Coupe & Convertible Chapter 6 - In case of an emergency pg. 89 In case of an emergency Page Wheel changing Spare tire Replacing bulbs Replacing fuses Installation of accessories...
Page 125: Wheel Changing
2002 Volvo C70 Coupe & Convertible The spare wheel is located under the carpet on the trunk floor. The jack and crank are secured in the wheel recess. Engage the parking brake. Put the gear selector in (P)ark (automatic) or in Reverse (manual).
Page 126: Spare Tire
2002 Volvo C70 Coupe & Convertible WARNING! The jack's attachment must engage the bar in the jack attachment (A). The car's weight must not rest on the jack attachment (B). Be sure the jack is on a firm, level, non-slippery surface.
Page 127: Replacing Bulbs
Temporary Spare tire is used on. In the event of damage to this tire, a new one can be purchased from your Volvo retailer. CAUTION: The car must not be driven with wheels of different dimensions or with a spare tire other than the one that came with the car.
Page 128 2002 Volvo C70 Coupe & Convertible Parking light/direction indicator 1. From the front of the car, use a screwdriver to press down on the silver catch (located in the space between the inside of the fender and the headlight unit) to release the lamp housing from the front fender.
Page 129 2002 Volvo C70 Coupe & Convertible 2. Pull out the entire lens/bulb unit. 3. With the lens toward you, turn the bulb holder 1/4 turn (the wires should not be disconnected from the holder) and pull out the bulb holder from the lens unit.
Page 130 2002 Volvo C70 Coupe & Convertible 2. Press the wire catches on the retaining clamp (1 in inset illustration above) together and push out (2) to release the bulb and connector from the headlight housing. 3. Pull the bulb out of the connector.
Page 131 2002 Volvo C70 Coupe & Convertible 3. Let the connector with its wires remain attached to the bulb holder. 4. Remove the bulb by pressing in and turning counterclockwise. 5. Insert a new bulb into the holder and reinstall the holder into the tail light assembly.
Page 132 2002 Volvo C70 Coupe & Convertible Insert the screwdriver and turn gently to loosen the glass lens. Replace the bulb and reinstall the glass lens. Front courtesy lights - C70 Coupe Switch off the ignition. Insert a screwdriver and turn carefully to loosen the glass lens.
Page 133 2002 Volvo C70 Coupe & Convertible Replace the bulb and press the glass lens back into place. Rear reading lights - C70 Coupe only · Switch off the ignition. · Insert a screwdriver and turn to loosen the lamp unit.
Page 134 2002 Volvo C70 Coupe & Convertible Contents Top of Page file:///K|/ownersdocs/2002/2002_C70/02c70c_06a.htm (11 of 11)12/30/2006 3:53:59 PM...
Page 135 2002 Volvo C70 Coupe & Convertible pg. 98 Replacing bulbs Slide upward and pull out lower edge Door warning lights Slide the lamp unit upward and pull out the lower edge. Twist off the bulb holder. Pull the bulb straight out.
Page 136 Press the lamp unit back into place. NOTE: Other bulbs, such as the rear reading lamps, etc, may be difficult for the owner to replace. Let your Volvo retailer replace these bulbs if necessary. Front fog lights in spoiler Front fog lights Switch off the lights Turn the plastic cover counterclockwise to remove it.
Page 137: Replacing Fuses
(written on the fuse). Spare fuses are stored in a compartment in the Supplementary fuse box. If fuses burn out repeatedly, have the electrical system tested at a Volvo retailer. If you find it difficult to remove a fuse, you will find a special fuse tool clipped in the fuse box.
Page 138 Relay/Main fuse box Fuses in the main fuse box protect the entire electrical system. If one of the fuses blows, there is a serious electrical fault. Do not change any of these fuses. Contact your nearest Volvo retailer for a closer analysis.
Page 139 2002 Volvo C70 Coupe & Convertible 3 Starter motor 4 ABS 5 Headlights 6 Fuses in Supplementary fuse box 7 Fuses in Supplementary fuse box 8 Control modules - engine/automatic transmission 9 Electrically operated windows left/right ** Ignition switch, Control modules - engine/automatic...
Page 140 2002 Volvo C70 Coupe & Convertible Courtesy lights, door open warning lights, trunk, seat belt reminder, glove compartment light, power windows 16 Power antenna, electrical connector for trailer, accessories, CD-changer (option) 17 Front fog lights 18 Key reminder 19 Left high beam, accessories...
Page 141: Installation Of Accessories
In order to help avoid interference and damage to your car's electrical system, the car is equipped with an accessory connector located under the instrument panel on the driver's side. Please consult your Volvo retailer if you have any questions before connecting accessory or optional equipment to the vehicle's electrical system.
Page 142: Replacing Wiper Blades
2002 Volvo C70 Coupe & Convertible pg. 103 Replacing wiper blades Replacing wiper blades Lift the wiper arm off the windshield and hold the blade at right angles to the arm. Pinch the end of the plastic clip located at the back of the arm.
Page 143: In Case Of Emergency
2002 Volvo C70 Coupe & Convertible Clean the glass with a suitable cleaning agent. The glass is clean if beads do not form when you rinse it with water. Clean the wiper blade by wiping vigorously with a cloth soaked in full strength windshield washer solvent.
Page 144 2002 Volvo C70 Coupe & Convertible Shiftlock release (automatic transmission only) The gear selector is locked in the (P)ark position. To manually release the shiftlock: Turn the starting (ignition) key to position I Press firmly on the "SHIFTLOCK OVERRIDE" button located to the right of the base of the gear...
Page 145 2002 Volvo C70 Coupe & Convertible Manually raising the convertible top NOTE: The tools needed (A and B in the illustration) are located in the glove compartment. 1. Open the trunk. The trunk must be open during the entire procedure.
Page 146 2002 Volvo C70 Coupe & Convertible NOTE: After manually raising the convertible top, the car should be inspected by an authorized Volvo retailer. Circuit breaker If the automatic circuit breakers have activated, wait at least 20 seconds before attempting to raise the top again using the switch on the instrument panel.
Page 147 Minor scratches can be repaired by using Volvo touchup paint. NOTE: When ordering touchup paint from your Volvo retailer, use the paint code indicated on the model plate. The plate is located in the engine compartment, on the inside of the left front fender.
Page 148 2002 Volvo C70 Coupe & Convertible Minor stone chips and scratches Material: Primer can Paint touchup bottle Brush Masking tape NOTE: When touching up the car, it should be clean and dry. The surface temperature should be above 60° F (15° C).
Page 149 2002 Volvo C70 Coupe & Convertible Deep scratches 1. Place a strip of masking tape over the damaged surface. Pull the tape off so that any loose flakes of paint adhere to it. 2. Thoroughly mix the primer and apply it with a small brush.
Page 150 2002 Volvo C70 Coupe & Convertible A detergent can be used to facilitate the softening of dirt and oil. A water-soluble grease solvent may be used in cases of sticky dirt. However, use a wash place equipped with a drainage separator.
Page 151 See your local Volvo retailer for a complete line of genuine Volvo environmental car care products. * Pay special attention to the drain holes near the base of the windshield in the cowl under the rear edge of the hood.
Page 152 Winter: remove any residue of road salt from the convertible top as soon as possible. Do not use solvents, tar remover or other all-purpose stain removers to clean the convertible top. Use Volvo approved cleaning agents only - consult your Volvo retailer. Polishing and waxing Normally, polishing is not required during the first year after delivery, however, waxing may be beneficial.
Page 153 The plastic in the upholstery can be cleaned with a soft cloth and Volvo plastic-rubber cleaner. Leather upholstery can be cleaned with a soft cloth and mild soap solution. For more difficult spots, Volvo offers a leather care kit.
Page 154 114 Label information 1 Vehicle Emission Control Information Your Volvo is designed to meet all applicable emission standards, as evidenced by the certification label on the underside of the hood. For further information regarding these regulations, please consult your Volvo retailer.
Page 155 6 Federal Motor Vehicle Safety Standards (FMVSS) specifications (USA) and Ministry of Transport (CMVSS) standards (Canada) Your Volvo is designed to meet all applicable safety standards, as evidenced by the certification label on the rear edge of the driver's door. For further information regarding these regulations, please consult your Volvo retailer.
Page 156: Maintenance Service, Warranty
115 Maintenance service, Warranty Maintenance service Volvo advises you to follow the service program which is outlined in the Warranty and Service Records Information Booklet. This maintenance program contains inspections and services necessary for the proper function of your car. The maintenance services contain several checks which require special instruments and tools and therefore must be performed by a qualified technician.
Page 157: Servicing
2002 Volvo C70 Coupe & Convertible Applicable warranties U.S. In accordance with U.S. Federal Regulations, the following list of applicable U.S. warranties is provided. For Canadian specification vehicles, see your separate warranty booklet. New Car Limited Warranty- U.S. New Car Warranty - Canada...
Page 158: Emissions Maintenance
NOTE: If the fuel filler cap is not closed tightly or if the engine is running when the car is refueled, the Check Engine light ("Malfunction indicator") may indicate a fault. However, your vehicle's performance will not be affected. Use only Volvo original or approved fuel filler caps. file:///K|/ownersdocs/2002/2002_C70/02c70c_08a.htm (5 of 8)12/30/2006 3:54:03 PM...
Page 159: Fuel/Emissions Systems
2002 Volvo C70 Coupe & Convertible Timing belt For proper functioning of the vehicle and its emission control systems, the timing belt and belt tensioner must be replaced every 105,000 miles (168,000 km). Engine damage will occur if the belt fails.
Page 160 2002 Volvo C70 Coupe & Convertible oxides of nitrogen (NOx) by a threeway catalytic converter. Crankcase ventilation Crankcase ventilation The engine is provided with positive crankcase ventilation which prevents crankcase gases from being released into the atmosphere. Instead, the crankcase gases are admitted to the intake manifold and cylinders.
Page 161 2002 Volvo C70 Coupe & Convertible Contents Top of Page file:///K|/ownersdocs/2002/2002_C70/02c70c_08a.htm (8 of 8)12/30/2006 3:54:03 PM...
Page 162: Lubrication
To avoid rattles and unnecessary wear, the body should be lubricated at regular service intervals. This should be done by an authorized Volvo retailer. C70 Convertible: Lubrication of the convertible top mechanism should be done by an authorized Volvo retailer.
Page 163 The oil may be very hot. If you change the engine oil and filter yourself, your Volvo retailer can assist you in disposing of the used oil. Engine oil can be harmful to your skin gloves should be worn when performing this work.
Page 164 Meeting minimum ILSAC specification GF-2, including ACEAA1, API SJ, SJ/CF and SJ/Energy Conserving. Your Volvo has been certified to standards using ILSAC oil specification GF-2 5W/30. Volvo recommends use of oil with a quality rating equal to or higher than ILSAC GF-2. Equivalent and better oils include ACEA A1, API SJ, SJ/CF, and SJ/Energy conserving.
Page 165 SAE 5W/30 will provide good fuel economy and engine protection. See the viscosity chart at right. Operation in hot climates When temperatures exceed 86 ¡F in your area, Volvo recommends, for the protection of your engine, that you use a heavier weight oil, such as SAE 10W/30. See the viscosity chart at right.
Page 166 2002 Volvo C70 Coupe & Convertible pg. 122 Power steering fluid, Brake/clutch fluid reservoir Power steering fluid The dipstick has marks for checking hot and cold oil. The oil level when the engine is cold must never be higher than the COLD mark. After the engine has reached normal operating temperature, the level may not be higher than the HOT mark.
Page 167: Washer Fluid Reservoir
15,000 miles (24,000 km) when driving under extremely hard conditions (mountain driving, etc.) Check, without removing the cap, that the level is above the "MIN" mark of the fluid reservoir. Always entrust brake/clutch fluid changing to an authorized Volvo retailer. pg. 123 Washer fluid reservoir Washer fluid reservoir The washer fluid reservoir is located in the engine compartment and holds approx.
Page 168: Engine Compartment
2002 Volvo C70 Coupe & Convertible coolant circulation between the engine and the expansion tank during engine warm up and cooling. Capacity: 7.4 US qts. (7.0 liters) Coolant: Volvo Genuine Coolant/Anti-freeze only. NOTE: Do not top up with water only. Water by itself reduces the rustprotective and antifreeze qualities of the coolant and has a lower boiling point.
Page 169: Battery Maintenance/ Proposition 65 Warning
2002 Volvo C70 Coupe & Convertible WARNING! The coolant fan may start or continue to operate (for up to 6 minutes) after the engine has been switched off. pg. 126 Battery maintenance Correct fluid level Battery maintenance Driving habits and conditions, climate, the number of starts, etc. all affect the service life and function of the battery.
Page 170: Three-Way Catalytic Converter
2002 Volvo C70 Coupe & Convertible * More frequently in warm climates. If necessary, add distilled water to approximately 0.4 in. (10 mm) above the plates in the cell or to the level indicator. See the illustrations above. Check that the battery cables are correctly connected and properly tightened.
Page 171 2002 Volvo C70 Coupe & Convertible Three-way catalytic converter cautions Keep your engine properly tuned. Certain engine malfunctions, particularly involving the electrical, fuel or distributor ignition systems, may cause unusually high three-way catalytic converter temperatures. Do not continue to operate your vehicle if you detect engine misfire, noticeable loss of power or other unusual operating conditions, such as engine overheating or backfiring.
Page 172 2002 Volvo C70 Coupe & Convertible 2 0 0 2 VOLVO C70 Coupe & Convertible Chapter 9 - Specifications pg. 129 Specifications Page Oil/fluids specifications Engine specifications Cooling/fuel/distributor ignition systems Front/rear suspensions Transmission, Capacities, Vehicle loading Electrical system/bulbs Dimensions and weights Service manuals, Road assistance pg.
Page 173 2002 Volvo C70 Coupe & Convertible Quality: AW5. Only Volvo gearbox Automatic transmission fluid oil (1161540-8). Do not mix with Capacity: 8 US qts. (7.5 liters) other oils.. Quality: Volvo synthetic gearbox oil Manual transmission fluid Capacity: 2.2 US qts. (2.1 liters) 1161423 Capacity: 0.95 US qts.
Page 174 2002 Volvo C70 Coupe & Convertible Number of cylinders Bore 3.19" (81 mm) Stroke 3.54" (90 mm) Displacement 2.3 liters Compression ratio 8.5:1 Number of valves Designation: Volvo B 5244 T Output 190 hp at 5100 rpm (142 kw/85 rps) Max torque 199 ft.
Page 175 2002 Volvo C70 Coupe & Convertible The engine is equipped with a multiport fuel injection system. Distributor ignition system Firing order: 12453 Distributor ignition setting: Not adjustable Spark plugs: Champion RC8PYP (or equivalent) Spark plug gap: 0.03" (0.75 mm) Tightening torque: 18.4 ft. lbs. +/ 3.7 ft. lbs. (25 Nm +/ 5 Nm) WARNING! The distributor ignition system operates at very high voltages.
Page 176 2002 Volvo C70 Coupe & Convertible pg. 133 Specifications Power transmission Manual transmission: M 56 H Singledisc dry plate clutch. Allsynchromesh on all gears including reverse; integrated final drive. Operation via a floor mounted gear lever. Final drive 4.00:1 ratio...
Page 177 0.6 US qts (0.6 liters) Vehicle loading The tires on your Volvo should perform to specifications at all normal loads when inflated as recommended on the tire information label. The label is located on the inside of the fuel filler flap. The label lists both tire and vehicle design limits.
Page 178 Capacity 520 A/100 min (certain markets) 420 A/75 min The battery contains corrosive and poisonous acids. It is of the utmost importance that old batteries are disposed of correctly. Your Volvo retailer can assist you in this matter. Generator Rated output 1400 W Max.
Page 179 2002 Volvo C70 Coupe & Convertible gear selector (automatic trans.) 1.2 W W 2x4.6d rear ashtray 1.2 W W 2x4.6d Instrument warning/indicator 1.2 W W 2x4.6d lights Front courtesy lights BA 9s Rear reading lights BA 9s All specifications are subject to change without notice.
Page 180 2002 Volvo C70 Coupe & Convertible C70 Coupe 785 lbs (356 kg) 355 kg C70 Convertible (B5234T3) 765 lbs (347 kg) 350 kg (B5254T) 795 lbs (361 kg) 360 kg Curb weight 3305-3405 lbs (1499-1544 C70 Coupe 1500-1545 kg 3590-3685 lbs (1628-1671...
Page 181 2002 Volvo C70 Coupe & Convertible Volvo On Call Roadside Assistance Your new Volvo comes with a four year On Call Roadside Assistance program.. Additional information, features, and benefits are described in a separate information package in your glove compartment.
Page 182 2002 Volvo C70 Coupe & Convertible 2 0 0 2 VOLVO C70 Coupe & Convertible Chapter 10 - Audio systems pg. 137 Audio systems Page SC-813 SC-816 SC-901 General information pg. 138 Audio system SC-813 (certain models) The following pages describe the use of your SC-813 Cassette radio and CD remote control 1.
Page 183 2002 Volvo C70 Coupe & Convertible · Pause/Mute (push) · Balance (pull) 3. Active Sound Control 4. CD changer selector 5. · Tape mode selector · Tape direction selector PROG 6. Bass control 7. Treble control 8. Fader control 9. · Preset buttons ·...
Page 184 2002 Volvo C70 Coupe & Convertible · TP-fast forward/Rewind · CD-Music searchUP/DOWN 18. RND button 19. Cassette slot 20. Display 21. Waveband selector (AM) 22. Waveband selectors (FM) 23. Anti-theft LED TP = Applicable only in Tape Mode CD = Applicable only when in CD mode and connected to a CD changer.
Page 185 2002 Volvo C70 Coupe & Convertible To enter the code After installation or when the set has been disconnected from power, the set displays "COdE" when it is switched on. Enter the 4-digit code using the preset buttons. If the correct code is entered, "on" is displayed and the set is ready to use.
Page 186 2002 Volvo C70 Coupe & Convertible · the unit must be turned on Make sure the headlights are turned off to help prevent battery drain (please refer to page 22 information on turning the headlights off). Enter the code again once this time has elapsed.
Page 187 2002 Volvo C70 Coupe & Convertible The radio can be used in most parts of the world by changing the frequency selection intervals as follows: Depress and hold preset button 5 and turn the radio ON. "USA" will flash on the display.
Page 188 2002 Volvo C70 Coupe & Convertible comes on again (approx. 2 seconds). 3. The frequency is now stored on this preset button. C - Preset buttons To select a pre-programed radio frequency, depress the preset button. The set frequency will be displayed.
Page 189 2002 Volvo C70 Coupe & Convertible Adjust the bass by sliding the control up or down (up to increase, down to decrease). A "detent" indicates "equalized" bass. C - Treble control Adjust the treble by sliding the control up or down (up to increase, down to decrease).
Page 190 2002 Volvo C70 Coupe & Convertible clockwise. D - Scan Press this button to listen to each station for five seconds. Press it again to stop scanning. "Scan" will be displayed during scanning. E - Active sound control (ASC) The ASC function automatically adjusts the volume level of the audio system according to driving speed.
Page 191 2002 Volvo C70 Coupe & Convertible The side of the tape being played will be displayed. C - Fast winding The tape is advanced with " " and rewound with " ". Fast winding can be stopped by pressing either the selected button or the fast wind button again or by pressing the "TAPE"...
Page 192 2002 Volvo C70 Coupe & Convertible There must be a gap (no audio sound) of approx. 5 seconds between songs for this function to operate. C - Pause If you press the "volume" knob the tape is stopped, the unit is silent and "PAUSE" is displayed. To restart the tape press the knob again.
Page 193 2002 Volvo C70 Coupe & Convertible pg. 146 Cassette deck A - Cassette eject If the button is pressed the tape will stop and the cassette will be ejected. The radio will be automatically engaged. The radio or CD changer will engage automatically (depending on which mode was activated before the tape was played).
Page 194 *The functions pertaining to the CD-changer are only applicable if the unit has been connected to the Volvo CD-changer, which is sold separately as an accessory. If no CD-changer is connected to the unit "EEEE" will be displayed if you happen to choose CHGR mode.
Page 195 2002 Volvo C70 Coupe & Convertible A - Changing the selected track number Press " " for forward selection or " " for backward selection. The chosen disc number and track number will be displayed. B - Playing-time display When the "CHGR" button is pressed the playing time for the current track is displayed for 5 seconds.
Page 196 2002 Volvo C70 Coupe & Convertible Press "RND" to actuate the random mode. From a disc chosen at random, 4 tracks will be played (also chosen at random)*. A new disc will then be played in the same way. "RND" will be displayed when this function is engaged.
Page 197 2002 Volvo C70 Coupe & Convertible Frequency) front and end automatic wide band gain control. Electronic suppression circuitry (noise killer). This Radio is equipped with FM-Diversity. Frequency range: AM 530 1710 kHz FM 87.9 107.9 MHz Sensitivity: AM 20µV FM 1.1µV...
Page 198 2002 Volvo C70 Coupe & Convertible Dolby noise reduction manufactured under license from Dolby Laboratories Licensing Corporation. pg. 151 Audio system SC-816 (certain models) The following pages describe the use of your SC-816 1. On/off (push) 2. · Volume (turn) ·...
Page 199 2002 Volvo C70 Coupe & Convertible · CD-Disc No. selector 10. Dolby B NR button 11. CD-random play 12. Cassette eject 13. Remote control window 14. Auto seek memory 15. Scan 16. · Seek tuning up/down · TP-Next/Previous song · CD-Next UP/Previous DOWN track 17.
Page 200 2002 Volvo C70 Coupe & Convertible · Disc in LED (single) TP = Applicable only in Tape Mode pg. 152 Anti-theft code Anti-theft code The radio features anti-theft circuitry. If the set is removed from the vehicle or if the battery power is disconnected, a special code must be entered to enable operation of the set.
Page 201 2002 Volvo C70 Coupe & Convertible If you enter an incorrect code you must enter the correct code again from the beginning. Incorrect code If an incorrect code has been entered "EEEE" is displayed. Enter the correct code. After three unsuccessful coding attempts the set will lock and remain locked for two hours.
Page 202 2002 Volvo C70 Coupe & Convertible A - On/off switch Push the button to switch on the radio. Press the button to turn the radio off. B - Volume control Turn the button clockwise to increase the volume. The volume control is electronic and has no end stop.
Page 203 2002 Volvo C70 Coupe & Convertible Press the left side tune button to tune to lower frequencies and the right side to tune to higher frequencies. The tuned frequency is displayed. ST will be displayed to indicate stereo FM reception.
Page 204 2002 Volvo C70 Coupe & Convertible Contents Top of Page file:///K|/ownersdocs/2002/2002_C70/02c70c_10b.htm (12 of 12)12/30/2006 3:54:08 PM...
Page 205 2002 Volvo C70 Coupe & Convertible pg. 155 Radio SC-816 A - Automatic programming (Auto) Please note that this function will not interfere with pre-stored stations on buttons 1-6. This function automatically seeks and stores up to 8 strong AM or FM stations.
Page 206 2002 Volvo C70 Coupe & Convertible Adjust the treble by sliding the control up or down (up to increase, down to decrease). A "detent" indicates "equalized" treble. pg. 156 Radio SC-816 A - Fader control Adjust front/rear speaker balance by sliding the control up or down.
Page 207 2002 Volvo C70 Coupe & Convertible E - Active sound control (ASC) The ASC function automatically adjusts the volume level of the audio system according to driving speed. To deactivate ASC depress the "CD" button until "ASC" is no longer displayed.
Page 208 2002 Volvo C70 Coupe & Convertible Fast winding can be stopped by pressing the tuning button or the TAPE button again. D - Dolby B NR button Press this button when you use tapes recorded with the Dolby B noise reduction system.
Page 209 2002 Volvo C70 Coupe & Convertible D - Scan Press this button to listen to the first five seconds of each song. Press it again to stop scanning. "SCAN" will be displayed. There must be a gap (no audio sound) of approx. 5 seconds between songs for this function to operate.
Page 210 2002 Volvo C70 Coupe & Convertible If the CD function has been disconnected and the CD has not been ejected, the CD mode can be re- entered by pressing the "CD" button. E - To re-enter Tape mode If the Tape function has been disconnected and the cassette has not been ejected, the Tape mode can be re-entered by pressing the "TAPE"...
Page 211 2002 Volvo C70 Coupe & Convertible If the button is pressed the CD will stop and the disc will be ejected. The radio will be automatically engaged. The radio, tape or CD changer will engage automatically (depending on which mode was activated before the CD was played).
Page 212 2002 Volvo C70 Coupe & Convertible pg. 162 CD - Single A - Random choice Press "RND" to actuate the random mode. From a disc, tracks will be played at random*. "RND" will be displayed when this function is engaged.
Page 213 " button to search within a track. While the button is depressed the playing time for this track will be displayed. *The functions pertaining to the CD-changer are only applicable if the unit has been connected to the Volvo CD-changer, which is sold separately as an accessory. file:///K|/ownersdocs/2002/2002_C70/02c70c_10c.htm (9 of 10)12/30/2006 3:54:10 PM...
Page 214 2002 Volvo C70 Coupe & Convertible If no CD-changer is connected to the unit "EEEE" will be displayed if you happen to choose CHGR mode. pg. 164 CD - Changer (retailer option) A - Changing the selected track number Press "...
Page 215 2002 Volvo C70 Coupe & Convertible pg. 165 CD - Changer (retailer option) A - Random choice Press "RND" to actuate the random mode. From a disc chosen at random, 4 tracks will be played (also chosen at random). A new disc will then be played in the same way. "RND" will be displayed when this function is engaged.
Page 216 2002 Volvo C70 Coupe & Convertible F - To re-enter CD changer mode If the CD changer function has been disconnected, the CD changer mode can be re-entered by pressing the "CHGR" button. pg. 166 Technical specifications SC-816 Power output: 4 x 60 W (10% dist.)
Page 217 2002 Volvo C70 Coupe & Convertible 4track, 2 channel stereo Full logic electronic tape transport Tape speed: 4.76 cm/sec. Channel 53 dB separation Frequency range 3015000 hz S/N (120 µV) 56 dB without Dolby B NR S/N (120 µV) 66 dB with Dolby B NR Wow and Flutter <...
Page 218 2002 Volvo C70 Coupe & Convertible 2. CD player - on/off 3. CD mode selector - on/off 4. Cassette deck - on/off 5. · Bass control · Volume control - sound effects (pull and turn) 6. Treble control 7. · Balance control front/rear (fader) ·...
Page 219 2002 Volvo C70 Coupe & Convertible 14. Traffic information selector 15. · Manual tuning knob · Track selector - CD · Scanning 16. Pro Logic Surround Sound 17. Cassette slot 18. Display 19. CD slot 20. Fast forward · CD - forward search ·...
Page 220 2002 Volvo C70 Coupe & Convertible · Radio - next station (seek down) 24. · CD - open 25. · Anti-Theft indicator · CD - warning indicator 26. Cassette eject 27. PROG - reversing the tape pg. 168 Anti-theft code Anti-theft code The radio features anti-theft circuitry.
Page 221 2002 Volvo C70 Coupe & Convertible Anti-theft light (LED) To enter the code After installation or when power has been disconnected, `CODE' appears in the display when the set is switched on. Enter the 4-digit code using the preset buttons. If the correct code is entered, the set is ready to use.
Page 222 2002 Volvo C70 Coupe & Convertible A - On/off switch Press the button to switch the radio on/off. B - Volume control Turn this knob clockwise to increase the volume. The volume control is electronic and has no stop point.
Page 223 2002 Volvo C70 Coupe & Convertible A - Automatic programming of stations Please note that this function will not interfere with pre-stored stations on buttons 1-6. This function automatically seeks and stores up to 10 strong AM or FM stations in a separate memory.
Page 224 2002 Volvo C70 Coupe & Convertible pg. 171 Radio SC-901 A - Bass control Adjust the bass by pressing the button to extend the control and then turning it to the left (less bass) or to the right (more bass). A "detent" indicates "equalized" bass. Press the button back in when you have set the level.
Page 225 Volvo was among the first to pioneer this technology throughout Europe and it is slowly making its way to North America. Coverage by local broadcasters may be limited at this time, but as the technology and benefits grow, you will find the SC-901 radio ready to take advantage of this system.
Page 226 2002 Volvo C70 Coupe & Convertible `AF Switch ON'- Automatic station tracking is activated `AF Switch OFF'- Automatic station tracking is deactivated A - Station seek up/down Press the left side of the station seek button to seek for lower frequencies and the right side for higher frequencies.
Page 227 2002 Volvo C70 Coupe & Convertible the RDS information on page 172. By pressing the TP button, RDS stations broadcasting traffic information can be heard. `TP' is displayed when this function is switched on. If the unit is in tape or CD mode when the radio receives traffic information, the respective function will be interrupted and the announcement is received at the volume selected for traffic information.
Page 228 2002 Volvo C70 Coupe & Convertible NEWS This feature may not apply in your area and only functions with FM broadcasts. Please refer to the RDS information on page 172. Press the NEWS button to seek a station broadcasting news programs.
Page 229 2002 Volvo C70 Coupe & Convertible pg. 175 Program type - PTY Program type The `PTY' function enables you to select different types of program. If you want to search for a specific program type: 1. Press the PTY button for less than 1 second. The program type of the currently selected radio station will be displayed.
Page 230 2002 Volvo C70 Coupe & Convertible PTY preset buttons Program types are factory-preset as follows: Button 1 - Top 40 Button 2 - Classical Button 3 - News Button 4 - Rock Button 5 - R&B Button 6 - Country These settings can be reprogrammed according to your preferences.
Page 231 2002 Volvo C70 Coupe & Convertible Press one of the preset buttons to select a program type. The program type stored on that button will be displayed and a station broadcasting that type of program will be selected. Press the same button again to select a new station broadcasting the same type of program.
Page 232 2002 Volvo C70 Coupe & Convertible Certain RDS stations broadcast general information on programs, music, weather, etc. in text form. This information can be displayed by pressing the NEWS button for approximately 2 seconds. If no text information is available, "No radio text" will be displayed.
Page 233 2002 Volvo C70 Coupe & Convertible C - Fast winding The tape is advanced with `FF' and rewound with `REW'. `FF' (fast forward) or `REW' (rewind) appear in the display when fast winding. Fast winding can be stopped by pressing the button again.
Page 234 2002 Volvo C70 Coupe & Convertible If you press the `TAPE' button, the tape will stop, the sound will cut off and `PAUSE' will appear in the display. Press the `TAPE' button to restart the tape. B - Dolby B noise reduction Press this button if you are playing a tape which has been recorded with the Dolby B noise reduction system.
Page 235 2002 Volvo C70 Coupe & Convertible C - To return to the tape mode If the cassette deck has been switched off, but the cassette has not been ejected, you can return to tape mode by pressing the `TAPE' button.
Page 236 2002 Volvo C70 Coupe & Convertible · Remove the discs from the cartridge by pulling the lock tab for the disc you wish to remove (1). Carefully pull the disc out of the cartridge (2). B - CD 3 player mode - on Press the CD 3 button to activate the CD player.
Page 237 2002 Volvo C70 Coupe & Convertible A - Music search Press the `FF' or `REW' buttons to search within a track. While the button is pressed, the playing time for this track is displayed. B - Changing tracks Press `NXT' to move forward to the next track, `RPT' to repeat the previous track or turn the manual tuning knob.
Page 238 2002 Volvo C70 Coupe & Convertible A - Random choice Press `RND' to activate the random function. The unit will play the tracks on the disc in a random* order. `RND' (random) appears in the display while the function is on.
Page 239 2002 Volvo C70 Coupe & Convertible If the CD 6 changer has been switched off, you can return to the CD changer mode by pressing the CD 6 button. pg. 184 CD 6 changer (dealer option) CD 6 changer The CD 6 changer, which is available separately, is loaded with a cartridge which can accommodate 6 discs.
Page 240 2002 Volvo C70 Coupe & Convertible A - CD 6 changer - on Press the `CD 6' button to activate the CD 6 mode. The CD 6 changer will start playing the last disc and track to be played. If the CD 6 changer cartridge is empty, `No Disc' will appear in the display. If a selected disc does not exist, the disc number and `CD X-00' (X is the disc number) will appear in the display, and the next disc will automatically be selected.
Page 241 2002 Volvo C70 Coupe & Convertible pg. 185 CD 6 Changer (retailer option) A - Changing the selected track number Press `NXT' to move forward to the next track, `RPT' to repeat the previous track or turn the manual tuning knob. The selected disc number and track number will be displayed.
Page 242 2002 Volvo C70 Coupe & Convertible A - Random choice Press `RND' to activate the random function. Randomly selected tracks will play from randomly selected discs. `RND' (random) appears in the display while the function is on. B - Pause If you press the CD 6 button, the sound is switched off and `Pause' appears in the display.
Page 243 2002 Volvo C70 Coupe & Convertible Dolby Pro Logic Surround Sound Together with a center speaker mounted at the center of the dash, Dolby Pro Logic Surround Sound offers much clearer and more realistic sound. Through a connection to a special decoder (optional on certain models), as well as a center speaker (option), the normal left-right stereo channels are divided into left-center-right.
Page 244 2002 Volvo C70 Coupe & Convertible C - Surround effect volume control First press the button in slightly to pop it out, then pull the button out completely and turn it to adjust the volume level from the rear speakers (Dolby Pro Logic only).
Page 245 2002 Volvo C70 Coupe & Convertible B - Setting the internal equalizer To select the frequency correction: · Switch off the radio. · Hold down preset button 2 (B). · Switch the radio on again. · Press button 2 until the desired curve appears : S70-V70-S40-V40-Custom.
Page 246 4 Ohms System voltage: 12 V, negative ground Radio Volvo's SC-900 stereo system contains a microprocessor-controlled radio receiver with PLL (Phase Lock Loop), designed for RDS (Radio Data System). The SC-900 must be connected to a separate power amplifier. Frequency range: 530 - 1710 kHz 87.9 - 107.9 MHz...
Page 247 2002 Volvo C70 Coupe & Convertible Full logic electronic tape transport Tape speed: 4.76 cm/sec. Channel 40 dB separation: Frequency range: 30 - 15,000 Hz S/N (120 µV): 50 dB Wow and Flutter: < 0.07% Pinch-off Alert `Alert!' will be displayed when emergency information is broadcast. This function is used to warn drivers in the event of a serious accident or disaster siuation.
Page 248 · Take up slack using a pen or a pencil before inserting a cassette in the cassette slot. Cassette cleaning We recommend the use of the Volvo Cleaning Cassette available as a genuine Volvo accessory. Regular use improves sound quality, cleans vital parts and prevents tape tangle.
Page 249 2002 Volvo C70 Coupe & Convertible Sending signals The FM waves do not follow the earth's surface nor do they bounce off the atmosphere. For this reason their range is limited. The AM waves follow the earth's surface and reflect against the atmosphere, giving them a wide range.
Page 250 2002 Volvo C70 Coupe & Convertible Static The reason why FM but not AM is audible in covered parking areas, under bridges, etc, is that FM signals reflect against solid objects such as buildings. Because these waves are very reflective, static can result.
Page 251 2002 Volvo C70 Coupe & Convertible FM - reasons for distortion FM is affected by the electrical systems of nearby vehicles, especially those without suppression. The distortion increases if the station is weak or poorly set. The FM reception is not as sensitive to electrical disturbance as AM.
Page 252 Reception conditions are not always optimum and this is, of course, beyond our control. However, we have endeavored to make the Volvo Audio System of a quality that will enable you to enjoy the best possible reception no matter what the reception conditions may be.
Page 253 2002 Volvo C70 Coupe & Convertible 2 0 0 2 VOLVO C70 Coupe & Convertible INDEX pg. 197 - 199 Index Air conditioning Air filter- engine Air mix Air vents Airbag (SIPS) Airbag (SRS) Alarm Ambient temperature sensor 19,78 Anti-lock Brake System (ABS)
Page 254 2002 Volvo C70 Coupe & Convertible Automatic transmission fluid 81,134 Battery Battery drain - avoiding Battery maintenance Booster cushion 19, 20 Brake failure warning light 122,130 Brake fluid Brake fluid warning light 78, 79 Brake system Brake warning light 19,21...
Page 255 2002 Volvo C70 Coupe & Convertible Coolant - checking/changing Coolant level sensor Coolant level warning light 73,132 Cooling system Courtesy lights - exterior Courtesy lights - front Cruise control Daytime running lights Demister - rear window Dimensions Distributor ignition system...
Page 256 2002 Volvo C70 Coupe & Convertible Engine air filter Engine compartment 120, 121,130 Engine oil Engine oil - checking/changing Engine oil pressure Exterior courtesy lights 19,24 Fog light - rear Fog lights - front Front courtesy lights Front fog lights...
Page 257 Additionally, your authorized Volvo retailer knows where accessories may and may not be safely installed in your Volvo. In all cases, please consult your authorized Volvo retailer before installing any accessory in or on your car.
Page 258 2002 Volvo C70 Coupe & Convertible Never use these devices or any feature of your vehicle in a way that distracts you from the task of driving safely. Distraction can lead to a serious accident. In addition to this general warning, we offer the following guidance regarding specific newer features that may be found in your vehicles: Never use a hand-held cellular telephone while driving.
Page 259 2002 Volvo C70 Coupe & Convertible 4 Engine oil level should be between the dipstick marks. The distance between the marks represents approx. 1.6 US qts (1.5 liters). See page 120. 5 Brake fluid - check, without removing the cap, that the level is above the MIN mark. Use brake fluid DOT 4+.
Page 260 2002 Volvo C70 Coupe & Convertible Contents Top of Page file:///K|/ownersdocs/2002/2002_C70/02c70c_12.htm (4 of 4)12/30/2006 3:54:16 PM...
Page 261 2002 Volvo C70 Coupe & Convertible 2 0 0 2 VOLVO C70 Coupe & Convertible INDEX pg. 194 HomeLink® Universal Transceiver (option) HomeLink® Universal Transceiver HomeLink® is an advanced system that can be programmed to learn the codes of three different remote controlled-devices (e.g., garage door openers, remote lighting, entry door lock).
Page 262 2002 Volvo C70 Coupe & Convertible 2. Begin by erasing all 3 factory default channels. Hold down the two outside buttons (buttons 1 and 3 in the illustration) on the HomeLink® Universal Transceiver for about 20 seconds, until HomeLink® 's indicator light begins to flash.
Page 263 2002 Volvo C70 Coupe & Convertible that the button has been successfully programmed. Determining if your garage door uses a rolling code Determining if your garage door uses a rolling code Determine, in one of the following ways, if your garage door uses a rolling code system and is manufactured after 1996: Refer to the garage door opener owner's manual for verification.
Page 264 2002 Volvo C70 Coupe & Convertible Erasing programmed buttons Individual buttons cannot be erased. To erase all three programmed buttons: 1. 1. Turn the ignition key to the "accessory" position (II). 2. Hold down the two outside buttons on the HomeLink® Universal Transceiver for about 20 seconds, until HomeLink®...
Page 265 2002 Volvo C70 Coupe & Convertible Contents Top of Page file:///K|/ownersdocs/2002/2002_C70/02c70c_13.htm (5 of 5)12/30/2006 3:54:17 PM...
