CBS-1261 and CBS-1262 Extractor Plus Brewing System
CBS-1261 Single 3 gallon brewer and CBS-1262 Dual 3 gallon Extractor Plus Brewers shown with FETCO 3 Gallon TPD-30 dispensers (sold separately)
CONTACT INFORMATION
FETCO® FOOD EQUIPMENT TECHNOLOGIES COMPANY
600 ROSE ROAD
LAKE ZURICH • IL • 60047-0429 • USA
ON THE WEB: fetco.cofee
©2020-2021 FETCO
PATENTS:https://www.fetco.com/pl,pages,patents,74.html
Coffee Brewer: CBS-1260 series
TABLE OF CONTENTS
Electrical Configurations ................................................ 3
Electrical and Output Specifications .............................. 3
Enter Programming ........................................................ 4
Programing Menu Layout ............................................... 4
Starting The Brew .......................................................... 5
A Program ...................................................................... 6
B General ....................................................................... 7
C Service Inputs ............................................................. 8
D Service Outputs .......................................................... 9
User's Guide and Operator Instructions
FETCO PLUS
Commercial Beverage Equipment
®
fetco.com
PHONE: (800) 338-2699 (US & CANADA)
(847) 719-3000 (All Countries)
FAX: (847) 719-3001
EMAIL:sales@fetco.com
orders@fetco.com (to order parts and equipment)
techsupport@fetco.com (all service queries)
P214
E Calibration ................................................................ 10
E10 Calibration Procedure - Automatic ....................... 11
F Service Menu ............................................................ 12
F Error Codes .............................................................. 13
G Counters ................................................................... 14
H Save & Exit ............................................................... 15
Operator Training ......................................................... 16
Modular Brew Head and Bypass Valves ................... 27
Wiring Diagrams .......................................................... 28
September 2023
Advertisement
Table of Contents
Related Manuals for Fetco CBS-1261
Summary of Contents for Fetco CBS-1261
-
Page 1: Table Of Contents
FETCO PLUS Commercial Beverage Equipment ® CBS-1261 Single 3 gallon brewer and CBS-1262 Dual 3 gallon Extractor Plus Brewers shown with FETCO 3 Gallon TPD-30 dispensers (sold separately) PHONE: (800) 338-2699 (US & CANADA) CONTACT INFORMATION (847) 719-3000 (All Countries) FETCO®... - Page 2 Brewers have unique construction only available for these models. 1260 Water Requirements: Coffee Filter Size: 20” X 8”– standard FETCO # F004 CBS-2260 20-75 psig, (138-517kPa) 1½ gpm/(5.7 lpm) 18” X 7½” - optional half batch FETCO # F005 Water inlet fitting: 3/8 inch male flare.
-
Page 3: Electrical Configurations
220/380-240/415 3 X 5.0kW 3L/N/G 12.7-15.1 19.3-21.0 30.0 gal/114 L CBS-1261 NOM (Mexico In Spanish) Single-Voltage. With cUL/UL & NSF-4 Certification Electrical and Output Specifications All brewers use terminal block electrical connection for 50Hz or 60Hz Professional installation is required E1261NM-3B350-MM110 208-240 3 X 5.0kW... -
Page 4: Enter Programming
Copy Batch: From PASTE: To Top and middle batches are permanent SEE BOX on the following page for all “A” menus Go to fetco.com for the latest versions of all information User Guide & Operator instructions P214 September 2023 Page 4... -
Page 5: Starting The Brew
The “A” menu is the most accessed menu. It is for programming the batch volumes, brewing parameters, enabling or disabling brew buttons. The “A” menu moves through the six positions(CBS-1262-) or three positions(CBS-1261+) by entering the menu and pressing the left stop button. (only the left side is active for programming the CBS-1262+) The A menus [A1-3 or A1-6] correspond to batch buttons [3 or 6] on the touch panel Access the A menus to PROGRAM &... -
Page 6: A Program
Copy To Batch? A91.1 (1-6) PULSE BREW note. FETCO CBS-1200V+ brewers are factory programmed to pulse 2 cycles per minute brew time Changing the brew time only will increase the pulses but will not change the volume of brew water delivered Go to fetco.com for the latest versions of all information... -
Page 7: B General
(Not recommended) Unit will operate at lower temperature Allows brewing at any temperature above 77°C/170°F Below 70°C/170°F The brewer will display “HEATING” Go to fetco.com for the latest versions of all information User Guide & Operator instructions P214 September 2023... -
Page 8: C Service Inputs
USB Drive (not in use) Checks buttons Follow directions on the Keyboard Test Calibrate under membrane YES/NO touch screen cover Go to fetco.com for the latest versions of all information User Guide & Operator instructions P214 September 2023 Page 8... -
Page 9: D Service Outputs
LEDs under buttons Adjust LED button LED Brightness Brightness=60% 20-100% brightness only-Not for the screen display LCD Go to fetco.com for the latest versions of all information User Guide & Operator instructions P214 September 2023 Page 9... -
Page 10: E Calibration
(134) the new flow rate is 122.8 (rounded to 129). Enter , save and test brew to verify the new volume 3.00 Go to fetco.com for the latest versions of all information User Guide & Operator instructions... -
Page 11: E10 Calibration Procedure - Automatic
Brewer will continue Press top button to when at temperature scroll through valves Press top button when complete. Go to fetco.com for the latest versions of all information User Guide & Operator instructions P214 September 2023 Page 11... -
Page 12: F Service Menu
Override Lt BBL NO/YES YES or NO lock Toggle +/- Disables brew basket Override Rt BBL NO/YES YES or NO lock Go to fetco.com for the latest versions of all information User Guide & Operator instructions P214 September 2023 Page 12... -
Page 13: F Error Codes
Brew basket must be in place BSKT Insert brew basket into brewer rails to This is a enable brewer SAFETY FEATURE Insert Brew Basket Go to fetco.com for the latest versions of all information User Guide & Operator instructions P214 September 2023 Page 13... -
Page 14: G Counters
Batch 60 Cycles [LT] Menu button selection Total brews-right side bottom button Count and activation count CBS-1251&CBS-1252 Batch 60 Cycles Go to fetco.com for the latest versions of all information User Guide & Operator instructions P214 September 2023 Page 14... -
Page 15: H Save & Exit
3) When setting brewer model The software sets equipment to brewer defaults 4) When loading from USB (Reprograms settings) (SETTING F9) 5) When restoring defaults (Reloads to defaults ) (SETTING E10) Go to fetco.com for the latest versions of all information User Guide & Operator instructions P214 September 2023 Page 15... -
Page 16: Operator Training
5. Do not attempt to move hot beverage equipment once it is filled. Drain equipment before moving. 6. FETCO commercial coffee brewers prepare large amounts of coffee or tea in a single batch using very hot water 7. Commercial coffee brewers provide very hot water from the spray head, brew basket and faucet when it is pulled. - Page 17 Damage to inlet valve from improper installation will void the warranty NOTE: DO NOT PLUMB TANK DRAIN. DRAIN IS FOR SERVICE AND MAINTENANCE. Go to fetco.com for the latest versions of all information User Guide & Operator instructions P214 September 2023...
- Page 18 4. Brewers in this series wire differently in regard to a neutral wire. Review the wire diagrams. 5. The electrical diagram is located in the User’s Guide and online at www.fetco.com. 6. Make sure of the tight grounding of the equipment and use the external ground bolt.
- Page 19 Do not operate if unit has been submerged or saturated with water. Labels and warnings for hot beverage equipment For BACK PANEL of equipment (1046.00035.00) Go to fetco.com for the latest versions of all information User Guide & Operator instructions P214 September 2023 Page 19...
- Page 20 QUICK CONNECT SPRAYHEAD ASSEMBLY, LARGE, RETROFIT (SEE PAGE 27) 1083.00010.00 WASHER, #12 SCREW W/NEOPRENE-BONDED SEAL Parts list continued on next page Go to fetco.com for the latest versions of all information User Guide & Operator instructions P214 September 2023 Page 20...
- Page 21 PART NO DESCRIPTION Continued from previous page Drawing 1101.00576.00 CBS-1261-Parts Page 1/2 1084.00006.00 NUT, 8-32 18-8 HEX MACHINE SCREW 1025.00144.00 TUBE, SILICONE, 3/4" OD X 1/2" ID X 6.625" LG, BREW 1102.00113.00 SWITCH, REED, ASSEMBLY 1029.00006.00 NUT, FINGER KNURLED, #4-40 1023.00396.00...
- Page 22 WASHER, #12 SCREW W/NEOPRENE-BONDED SEAL 1084.00006.00 NUT, 8-32 18-8 HEX MACHINE SCREW 1102.00113.00 SWITCH, REED, ASSEMBLY Parts list continued on next page Go to fetco.com for the latest versions of all information User Guide & Operator instructions P214 September 2023 Page 22...
- Page 23 NUT, HEX, #6-32 MACHINE SCREW 1025.00144.00 TUBE, SILICONE, 3/4" OD X 1/2" ID X 6.625" LG, BREW 1024.00050.00 GROMMET, SILICONE, 11.4mm ID Go to fetco.com for the latest versions of all information User Guide & Operator instructions P214 September 2023 Page 23...
- Page 24 CBS-1261 Hot Water Tank three heater drawings 1104.00199.00, 1104.00200.00, 1104.00201.00 PART NO DESCRIPTION 1114.00174.00 WELDMENT TANK, CBS-2261. LASER 1024.00115.00 TANK GASKET - NG HEATER PLATE, ONE ELEMENT 1024.00114.00 TANK GASKET - NG HEATER PLATE, TWO ELEMENT 1114.00181.00 WELDMENT TANK HEATER BRACKET, NG-2232 1114.00176.00...
- Page 25 1081.00042.00 STANDOFF, 1/4" HEX 1044.00004.00 LABEL, DANGER, HIGH VOLTAGE 1022.00033.00 INSULATION, TANK, BACK, CBS-2062e 1022.00086.00 INSULATION TANK FRONT, CBS-2162 XTS Go to fetco.com for the latest versions of all information User Guide & Operator instructions P214 September 2023 Page 25...
- Page 26 1044.00004.00 LABEL, DANGER, HIGH VOLTAGE 20 1 1022.00033.00 INSULATION, TANK, BACK, CBS-2062e 21 1 1022.00086.00 INSULATION TANK FRONT, CBS-2162 XTS Go to fetco.com for the latest versions of all information User Guide & Operator instructions P214 September 2023 Page 26...
-
Page 27: Modular Brew Head And Bypass Valves
INSULATION, 5/8" ID X 3/8" TH, 11"LG 1025.00138.00 TUBE, SILICONE, 3/4" OD X 1/2" ID X 1-1/2" LG, HOT WATER Go to fetco.com for the latest versions of all information User Guide & Operator instructions P214 September 2023 Page 27... -
Page 28: Wiring Diagrams
Wiring Diagrams Go to fetco.com for the latest versions of all information User Guide & Operator instructions P214 September 2023 Page 28... - Page 29 Go to fetco.com for the latest versions of all information User Guide & Operator instructions P214 September 2023 Page 29...
- Page 30 Go to fetco.com for the latest versions of all information User Guide & Operator instructions P214 September 2023 Page 30...
- Page 31 1104.00199.00 TANKASSEMBLY,CBS-2261,3X3KW/240VAC 1104.00200.00 TANKASSEMBLY,CBS-2261,3X4KW/240VAC 1104.00201.00 TANKASSEMBLY,CBS-2261,3X5KW/240VAC 1104.00202.00 TANKASSEMBLY,CBS-2261,3X4KW/480VAC 1104.00192.00 TANKASSEMBLY,CBS2262,3X3KW/240VAC 1104.00193.00 TANKASSEMBLY,CBS2262,6X3KW/240VAC 1104.00194.00 TANKASSEMBLY,CBS2262,3X4KW/240VAC 1104.00195.00 TANKASSEMBLY,CBS2262,6X4KW/240VAC 1104.00196.00 TANKASSEMBLY,CBS2262,3X5KW/240VAC 1104.00197.00 TANKASSEMBLY,CBS2262,6X3KW/480VAC Go to fetco.com for the latest versions of all information User Guide & Operator instructions P214 September 2023 Page 31...
- Page 32 End of section notes...
