- Page 1 Questo manuale d’istruzione è fornito da trovaprezzi.it. Scopri tutte le offerte per AsRock 760GM 760GM-HDV o cerca il tuo prodotto tra le migliori offerte di Schede Madri...
- Page 2 (including damages for loss of profits, loss of business, loss of data, interruption of business and the like), even if ASRock has been advised of the possibility of such damages arising from any defect or error in the documentation or product.
- Page 3 If you require assistance please call ASRock Tel : +886-2-28965588 ext.123 (Standard International call charges apply) The terms HDMI™...
-
Page 4: Table Of Contents
Expansion Slots (PCI and PCI Express Slots) Jumpers Setup Onboard Headers and Connectors Chapter 3 Software and Utilities Operation Installing Drivers ASRock Live Update & APP Shop 3.2.1 UI Overview 3.2.2 Apps 3.2.3 BIOS & Drivers 3.2.4 Setting Chapter 4 BIOS SETUP UTILITY Introduction 4.1.1... - Page 5 4.1.2 Navigation Keys Main Screen OC Tweaker Screen Advanced Screen 4.4.1 CPU Configuration 4.4.2 Chipset Configuration 4.4.3 ACPI Configuration 4.4.4 Storage Configuration 4.4.5 PCIPnP Configuration 4.4.6 USB Configuration Hardware Health Event Monitoring Screen Boot Screen 4.6.1 Boot Settings Configuration. Security Screen Exit Screen...
-
Page 6: Chapter 1 Introduction
If you require technical support related to this motherboard, please visit our website for specific information about the model you are using. You may find the latest VGA cards and CPU support list on ASRock’s website as well. ASRock website http://www.asrock.com. -
Page 7: Specifications
1.2 Specifications Platform • Micro ATX Form Factor • Solid Capacitor design • Supports Socket AM3+ processors • Supports Socket AM3 processors: AMD Phenom II X6 / X4 / X3 / X2 (except 920 / 940) / Athlon II X4 / X3 / X2 / Sempron processors • Supports 8-Core CPU • Supports AMD OverDrive... - Page 8 760GM-HDV • Supports DVI-D with max. resolution up to 1920x1200 @ 75Hz • Supports D-Sub with max. resolution up to 2048x1536 @ 60Hz • Supports HDCP with DVI-D and HDMI Ports • Supports Full HD 1080p Blu-ray (BD) / HD-DVD playback...
- Page 9 • ErP/EuP ready (ErP/EuP ready power supply is required) * For detailed product information, please visit our website: http://www.asrock.com Please realize that there is a certain risk involved with overclocking, including adjusting the setting in the BIOS, applying Untied Overclocking Technology, or using third-party overclocking tools.
- Page 10 CPU you adopt. If you want to adopt DDR3 1800/1600 memory module on this motherboard, please refer to the memory support list on our website for the compatible memory modules. ASRock website: http://www.asrock.com 2. Due to the operating system limitation, the actual memory size may be less than 4GB for the reservation for system usage under Windows®...
-
Page 11: Motherboard Layout
CPU_FAN1 ATX12V1 HDMI2 USB 2.0 T: USB2 B: USB3 RoHS 760G USB 2.0 Top: T: USB0 RJ-45 Chipset B: USB1 PCIE1 CHA_FAN2 SB710 PCIE2 CMOS BATTERY Chipset USB6_7 USB4_5 PANEL 1 CLRMOS1 PCI1 HD_AUDIO2 SATAII_1 (PORT 1) SPK_CI1 760GM-HDV CHA_FAN1... - Page 12 760GM-HDV No. Description ATX 12V Power Connector (ATX12V1) CPU Fan Connector (CPU_FAN1) CPU Socket CPU Heatsink Retention Module 2 x 240-pin DDR3 DIMM Slots (DDR3_A1, DDR3_B1) ATX Power Connector (ATXPWR1) SATA2 Connector (SATAII_4 (PORT4)) Chassis Fan Connector (CHA_FAN2) System Panel Header (PANEL1)
-
Page 13: I/O Panel
1.4 I/O Panel No. Description No. Description PS/2 Mouse Port USB 2.0 Ports (USB23) LAN RJ-45 Port* HDMI Port Line In (Light Blue)** DVI-D Port Front Speaker (Lime)** D-Sub Port Microphone (Pink)** PS/2 Keyboard Port USB 2.0 Ports (USB01) * There are two LEDs on the LAN port. Please refer to the table below for the LAN port LED indications. ACT/LINK LED SPEED LED LAN Port... - Page 14 760GM-HDV ** To configure 7.1 CH HD Audio, it is required to use an HD front panel audio module and enable the multi- channel audio feature through the audio driver. Please set Speaker Configuration to “7.1 Speaker”in the Realtek HD Audio Manager.
-
Page 15: Chapter 2 Installation
Chapter 2 Installation This is a Micro ATX form factor motherboard. Before you install the motherboard, study the configuration of your chassis to ensure that the motherboard fits into it. Pre-installation Precautions Take note of the following precautions before you install motherboard components or change any motherboard settings. -
Page 16: Installing The Cpu
760GM-HDV 2.1 Installing the CPU Unplug all power cables before installing the CPU. -
Page 18: Installing The Cpu Fan And Heatsink
760GM-HDV 2.2 Installing the CPU Fan and Heatsink After you install the CPU into this motherboard, it is necessary to install a larger heatsink and cooling fan to dissipate heat. You also need to spray thermal grease between the CPU and the heatsink to improve heat dissipation. Make sure that the CPU and the heatsink are securely fastened and in good contact with each other. -
Page 19: Installing Memory Modules (Dimm)
2.3 Installing Memory Modules (DIMM) This motherboard provides two 240-pin DDR3 (Double Data Rate 3) DIMM slots, and supports Dual Channel Memory Technology. 1. For dual channel configuration, you always need to install identical (the same brand, speed, size and chip-type) DDR3 DIMM pairs. 2. - Page 20 760GM-HDV...
-
Page 21: Expansion Slots (Pci And Pci Express Slots)
2.4 Expansion Slots (PCI and PCI Express Slots) There is 1 PCI slot and 2 PCI Express slots on the motherboard. Before installing an expansion card, please make sure that the power supply is switched off or the power cord is unplugged. Please read the documentation of the expansion card and make necessary hardware settings for the card before you start the installation. -
Page 22: Jumpers Setup
760GM-HDV 2.5 Jumpers Setup The illustration shows how jumpers are setup. When the jumper cap is placed on the pins, the jumper is “Short”. If no jumper cap is placed on the pins, the jumper is “Open”. Clear CMOS Jumper... -
Page 23: Onboard Headers And Connectors
2.6 Onboard Headers and Connectors Onboard headers and connectors are NOT jumpers. Do NOT place jumper caps over these headers and connectors. Placing jumper caps over the headers and connectors will cause permanent damage to the motherboard. System Panel Header Connect the power (9-pin PANEL1) switch, reset switch and... - Page 24 760GM-HDV Chassis Intrusion and Please connect the SPEAKER DUMMY Speaker Header chassis intrusion and the DUMMY (7-pin SPK_CI1) chassis speaker to this (see p.6, No. 15) header. SIGNAL DUMMY Serial ATA2 Connectors These four SATA2 (SATAII_1 (PORT1): connectors support SATA see p.6, No.
- Page 25 1. High Definition Audio supports Jack Sensing, but the panel wire on the chassis must support HDA to function correctly. Please follow the instructions in our manual and chassis manual to install your system. 2. If you use an AC’97 audio panel, please install it to the front panel audio header by the steps below: A.
- Page 26 760GM-HDV ATX 12V Power This motherboard pro- Connector vides an 8-pin ATX 12V (8-pin ATX12V1) power connector. To use a (see p.6, No. 1) 4-pin ATX power supply, please plug it along Pin 1 and Pin 5.
-
Page 27: Chapter 3 Software And Utilities Operation
Chapter 3 Software and Utilities Operation 3.1 Installing Drivers The Support CD that comes with the motherboard contains necessary drivers and useful utilities that enhance the motherboard’s features. Running The Support CD To begin using the support CD, insert the CD into your CD-ROM drive. The CD automatically displays the Main Menu if “AUTORUN”... -
Page 28: Asrock Live Update & App Shop
Double-click on your desktop to access ASRock Live Update & APP Shop utility. *You need to be connected to the Internet to download apps from the ASRock Live Update & APP Shop. 3.2.1 UI Overview Category Panel Hot News... -
Page 29: Apps
3.2.2 Apps When the "Apps" tab is selected, you will see all the available apps on screen for you to download. Installing an App Step 1 Find the app you want to install. The most recommended app appears on the left side of the screen. The other various apps are shown on the right. - Page 30 760GM-HDV Step 3 If you want to install the app, click on the red icon to start downloading. Step 4 When installation completes, you can find the green "Installed" icon appears on the upper right corner. To uninstall it, simply click on the trash can icon...
- Page 31 Upgrading an App You can only upgrade the apps you have already installed. When there is an available new version for your app, you will find the mark of "New Version" appears below the installed app icon. Step 1 Click on the app icon to see more details. Step 2 Click on the yellow icon to start upgrading.
-
Page 32: Bios & Drivers
760GM-HDV 3.2.3 BIOS & Drivers Installing BIOS or Drivers When the "BIOS & Drivers" tab is selected, you will see a list of recommended or critical updates for the BIOS or drivers. Please update them all soon. Step 1 Please check the item information before update. Click on to see more details. -
Page 33: Setting
3.2.4 Setting In the "Setting" page, you can change the language, select the server location, and determine if you want to automatically run the ASRock Live Update & APP Shop on Windows startup. -
Page 34: Chapter 4 Bios Setup Utility
760GM-HDV Chapter 4 BIOS SETUP UTILITY 4.1 Introduction This section explains how to use the BIOS SETUP UTILITY to configure your system. You may run the BIOS SETUP UTILITY by pressing <F2> or <Del> right after you power on the computer, otherwise, the Power-On-Self-Test (POST) will continue with its test routines. -
Page 35: Navigation Keys
4.1.2 Navigation Keys Use < > key or < > key to choose among the selections on the menu bar, and use < > key or < > key to move the cursor up or down to select items, then press <Enter>... -
Page 36: Main Screen
Use [Enter], [TAB] System Time [ :00:09] or [SHIFT-TAB] to System Date [Wed 11/14/2012] select a field. BIOS Version : 760GM-HDV P1.00 Use [+] or [-] to : AMD FX(tm)-8100 Eight-Core Processor Type configure system Time. Processor (64bit) Processor Speed... -
Page 37: Oc Tweaker Screen
4.3 OC Tweaker Screen In the OC Tweaker screen, you can set up overclocking features. BIOS SETUP UTILITY Main OC Tweaker Advanced H/W Monitor Boot Security Exit CPU Configuration Overclocking may cause damage to your CPU and motherboard. Overclock Mode [Auto] It should be done at CPU Frequency (MHz) - Page 38 760GM-HDV Boot Failure Guard Count Configure the number of attempts to boot until the system automatically restores the default settings. CPU Active Core Control This allows you to adjust CPU Active Core Control feature. The configuration options depend on the CPU core you adopt. The default value is [Disabled].
- Page 39 BIOS SETUP UTILITY Main OC Tweaker Advanced H/W Monitor Boot Security Exit CPU Configuration Overclocking may cause damage to your CPU and motherboard. Overclock Mode [Auto] It should be done at CPU Frequency (MHz) [200] your own risk and PCIE Frequency (MHz) [100] expense.
- Page 40 760GM-HDV Memory Timing BIOS SETUP UTILITY OC Tweaker Memory Timing [Enabled] Power Down Enable Bank Interleaving [Auto] Channel Interleaving [Auto] CAS Latency (CL) [Auto] TRCD [Auto] [Auto] TRAS [Auto] [Auto] Command Rate [Auto] Select Screen Select Screen [Auto] Select Item...
- Page 41 Use this item to change Command Rate Auto/Manual setting. The default is [Auto]. Use this item to change TRC Auto/Manual setting. The default is [Auto]. Use this item to change TWR Auto/Manual setting. The default is [Auto]. TRFC Use this item to change TRFC Auto/Manual setting. The default is [Auto]. TRRD Use this item to change TRRD Auto/Manual setting.
- Page 42 760GM-HDV Use this to configure +2.5V Voltage. The default value is [Auto]. VCORE Offset Voltage Use this to configure Vcore offset Voltage. The default value is [Auto]. VCORE Droop Voltage Use this to configure Vcore droop Voltage. The default value is [Auto].
-
Page 43: Advanced Screen
4.4 Advanced Screen In this section, you may set the configurations for the following items: CPU Configuration, Chipset Configuration, ACPI Configuratio, Storage Configuration, PCIPnP Configuration and USB Configuration. BIOS SETUP UTILITY Main OC Tweaker H/W Monitor Boot Security Exit Advanced Advanced Settings Options for CPU WARNING : Setting wrong values in below sections... -
Page 44: Cpu Configuration
760GM-HDV 4.4.1 CPU Configuration BIOS SETUP UTILITY Advanced CPU Configuration Cool' n' Quiet [Enabled] [Enabled] Secure Virtual Machine Enhanced Halt State(C1E) [Disabled] CPU Thermal Throttle [Auto] Select Screen Select Screen Select Item Select Item Change Option Change Option General Help... -
Page 45: Chipset Configuration
4.4.2 Chipset Configuration BIOS SETUP UTILITY Advanced Chipset Settings Onboard HD Audio [Auto] Front Panel [Auto] Onboard Lan [Enabled] Internal Graphics Mode [UMA] Share Memory [Auto] Onboard HDMI HD Audio [Enabled] Surround View [Auto] Select Screen Select Item Change Option General Help Load Defaults Save and Exit... -
Page 46: Acpi Configuration
760GM-HDV 4.4.3 ACPI Configuration BIOS SETUP UTILITY Advanced ACPI Settings Select auto-detect or disable the STR feature. Suspend To RAM [Auto] Check Ready Bit [Auto] Away Mode Support [Disabled] Restore on AC / Power Loss [Power Off] PCI Devices Power On... - Page 47 Allow the system to be waked up by the real time clock alarm. Set it to By OS to let it be handled by your operating system. ACPI HPET table Use this item to enable or disable ACPI HPET Table. The default value is [Enabled]. Please set this option to [Enabled] if you plan to use this motherboard to submit Windows®...
-
Page 48: Storage Configuration
760GM-HDV 4.4.4 Storage Configuration BIOS SETUP UTILITY Advanced Configure onboard Storage Configuration serial ATA controller. Onboard SATA Controller [Enabled] SATA Operation Mode [AHCI] [Enabled] SATA IDE Combined Mode [Hard Disk] SATAII_1 SATAII_2 [Not Detected] SATAII_3 [Not Detected] SATAII_4 [Not Detected]... -
Page 49: Pcipnp Configuration
4.4.5 PCIPnP Configuration BIOS SETUP UTILITY Advanced Value in units of PCI Advanced PCI / PnP Settings clocks for PCI device latency timer PCI Latency Timer [32] register. [Enabled] PCI IDE BusMaster Select Screen Select Item Change Option General Help Load Defaults Save and Exit Exit... -
Page 50: Usb Configuration
760GM-HDV 4.4.6 USB Configuration BIOS SETUP UTILITY Advanced USB Configuration To enable or disable the onboard USB controllers. [Enabled] USB Controller USB 2.0 Support [Enabled] Legacy USB Support [Enabled] USB Keyboard/Remote Power On [Disabled] USB Mouse Power On [Disabled] Select Screen... -
Page 51: Hardware Health Event Monitoring Screen
4.5 Hardware Health Event Monitoring Screen This section allows you to monitor the status of the hardware on your system, including the parameters of the CPU temperature, motherboard temperature, fan speed and voltage. BIOS SETUP UTILITY Main OC Tweaker Advanced H/W Monitor Boot Security... -
Page 52: Boot Screen
760GM-HDV 4.6 Boot Screen This section displays the available devices on your system for you to configure the boot settings and the boot priority. BIOS SETUP UTILITY Main OC Tweaker Advanced H/W Monitor Boot Security Exit Boot Settings Configure Settings during System Boot. -
Page 53: Boot Settings Configuration
4.6.1 Boot Screen BIOS SETUP UTILITY Boot Boot Settings Configuration Disabled: Displays normal POST messages. Full Screen Logo [Enabled] Enabled: Displays OEM AddOn ROM Display [Enabled] Logo instead of POST Boot From Onboard LAN [Disabled] messages. Bootup Num-Lock [ON] Select Screen Select Item Change Option General Help... -
Page 54: Security Screen
760GM-HDV 4.7 Security Screen In this section you may set or change the supervisor/user password for the system. You may also clear the user password. BIOS SETUP UTILITY Security Exit Main OC Tweaker Advanced H/W Monitor Boot Security Settings Install or Change the password. -
Page 55: Exit Screen
4.8 Exit Screen BIOS SETUP UTILITY Main OC Tweaker Advanced H/W Monitor Boot Security Exit Exit Options Exit system setup after saving the Save Changes and Exit changes. Discard Changes and Exit Discard Changes F10 key can be used for this operation. Load BIOS Defaults Load Performance Setup Default Load Power Saving Setup Default... - Page 56 Contact Information If you need to contact ASRock or want to know more about ASRock, you’re welcome to visit ASRock’s website at http://www.asrock.com; or you may contact your dealer for further information. For technical questions, please submit a support request form at https://event.asrock.com/tsd.asp...
- Page 57 DECLARATION OF CONFORMITY Per FCC Part 2 Section 2.1077(a) Responsible Party Name: ASRock Incorporation Address: 13848 Magnolia Ave, Chino, CA91710 Phone/Fax No: +1-909-590-8308/+1-909-590-1026 hereby declares that the product Product Name : Motherboard 760GM-HDV Model Number : Conforms to the following speci cations:...
- Page 58 EU Declaration of Conformity For the following equipment: Motherboard (Product Name) 760GM-HDV / ASRock (Model Designation / Trade Name) ASRock Incorporation (Manufacturer Name) 2F., No.37, Sec. 2, Jhongyang S. Rd., Beitou District, Taipei City 112, Taiwan (R.O.C.) (Manufacturer Address) EMC —Directive 2014/30/EU (from April 20th, 2016)
