ASROCK 760GM-GS3 Manual
Hide thumbs Also See for 760GM-GS3:

Advertisement

Copyright Notice:
Copyright Notice:
Copyright Notice:
Copyright Notice:
Copyright Notice:
No part of this installation guide may be reproduced, transcribed, transmitted, or trans-
lated in any language, in any form or by any means, except duplication of documen-
tation by the purchaser for backup purpose, without written consent of ASRock Inc.
Products and corporate names appearing in this guide may or may not be registered
trademarks or copyrights of their respective companies, and are used only for identifica-
tion or explanation and to the owners' benefit, without intent to infringe.
Disclaimer:
Disclaimer:
Disclaimer:
Disclaimer:
Disclaimer:
Specifications and information contained in this guide are furnished for informational
use only and subject to change without notice, and should not be constructed as a
commitment by ASRock. ASRock assumes no responsibility for any errors or omissions
that may appear in this guide.
With respect to the contents of this guide, ASRock does not provide warranty of any kind,
either expressed or implied, including but not limited to the implied warranties or
conditions of merchantability or fitness for a particular purpose. In no event shall
ASRock, its directors, officers, employees, or agents be liable for any indirect, special,
incidental, or consequential damages (including damages for loss of profits, loss of
business, loss of data, interruption of business and the like), even if ASRock has been
advised of the possibility of such damages arising from any defect or error in the guide
or product.
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that
may cause undesired operation.
CALIFORNIA, USA ONLY
The Lithium battery adopted on this motherboard contains Perchlorate, a toxic
substance controlled in Perchlorate Best Management Practices (BMP) regulations
passed by the California Legislature. When you discard the Lithium battery in
California, USA, please follow the related regulations in advance.
"Perchlorate Material-special handling may apply, see
www.dtsc.ca.gov/hazardouswaste/perchlorate"
ASRock Website: http://www.asrock.com
Copyright©2010 ASRock INC. All rights reserved.
ASRock
760GM-GS3 / 760GM-S3
Published September 2010
Motherboard
1 1 1 1 1

Advertisement

Table of Contents
loading

Summary of Contents for ASROCK 760GM-GS3

  • Page 1 ASRock. ASRock assumes no responsibility for any errors or omissions that may appear in this guide. With respect to the contents of this guide, ASRock does not provide warranty of any kind, either expressed or implied, including but not limited to the implied warranties or conditions of merchantability or fitness for a particular purpose.
  • Page 2: Motherboard Layout

    PCI Slots (PCI1- 2) Southbridge Controller SPI Flash Memory (8Mb) Third SATAII Connector (SATAII_3 (PORT 2)) PCI Express 2.0 x16 Slot (PCIE2; Blue) Fourth SATAII Connector (SATAII_4 (PORT 3)) PCI Express 2.0 x1 Slot (PCIE1; Blue) Power Fan Connector (PWR_FAN1)
  • Page 3 Line In (Light Blue) COM Port Line Out (Lime) PS/2 Keyboard Port (Purple) * There are two LED next to the LAN port. Please refer to the table below for the LAN port LED indications. LAN Port LED Indications ACT/LINK...
  • Page 4 Line In (Light Blue) COM Port Line Out (Lime) PS/2 Keyboard Port (Purple) * There are two LED next to the LAN port. Please refer to the table below for the LAN port LED indications. LAN Port LED Indications ACT/LINK...
  • Page 5: Package Contents

    ASRock’s commit- ment to quality and endurance. In this manual, chapter 1 and 2 contain introduction of the motherboard and step-by-step guide to the hardware installation. Chapter 3 and 4 contain the configuration guide to BIOS setup and information of the Support CD.
  • Page 6: Specifications

    - Micro ATX Form Factor: 9.6-in x 7.2-in, 24.4 cm x 18.3 cm - Support for Socket AM3 processors: AMD Phenom II X6 / X4 / X3 / X2 (except 920 / 940) / Athlon II X4 / X3 / X2 / Sempron processors - Six-Core CPU Ready...
  • Page 7 - 4 x Ready-to-Use USB 2.0 Ports - 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED LED) - HD Audio Jack: Line in / Front Speaker / Microphone Connector - 4 x Serial ATAII 3.0Gb/s connectors, support RAID (RAID 0, RAID 1, RAID 10 and JBOD), NCQ, AHCI and “Hot Plug”...
  • Page 8 Overclocking may affect your system stability, or even cause damage to the components and devices of your system. It should be done at your own risk and expense. We are not responsible for possible damage caused by overclocking.
  • Page 9 USB flash drive or hard drive must use FAT32/16/12 file system. 10. The software name itself – OC DNA literally tells you what it is capable of. OC DNA, an exclusive utility developed by ASRock, provides a conve- nient way for the user to record the OC settings and share with others.
  • Page 10 15. EuP, stands for Energy Using Product, was a provision regulated by European Union to define the power consumption for the completed system. According to EuP, the total AC power of the completed system shall be under 1.00W in off mode condition. To meet EuP standard, an EuP ready motherboard and an EuP ready power supply are required.
  • Page 11: Pre-Installation Precautions

    Installation Installation Installation This is a Micro ATX form factor (9.6-in x 7.2-in, 24.4 cm x 18.3 cm) motherboard. Before you install the motherboard, study the configuration of your chassis to ensure that the motherboard fits into it. Pre-installation Precautions...
  • Page 12: Installation Of Cpu Fan And Heatsink

    Step 4. When the CPU is in place, press it firmly on the socket while you push down the socket lever to secure the CPU. The lever clicks on the side tab to indicate that it is locked.
  • Page 13: Installation Of Memory Modules (Dimm)

    Unlock a DIMM slot by pressing the retaining clips outward. Step 2. Align a DIMM on the slot such that the notch on the DIMM matches the break on the slot. The DIMM only fits in one correct orientation. It will cause permanent damage to the motherboard and the DIMM if you force the DIMM into the slot at incorrect orientation.
  • Page 14: Installing An Expansion Card

    2.4 Expansion Slots (PCI and PCI Express Slots) 2.4 Expansion Slots (PCI and PCI Express Slots) There are 2 PCI slots and 2 PCI Express slots on this motherboard. PCI slots: PCI slots are used to install expansion cards that have the 32-bit PCI interface. PCIE slots: PCIE1 (PCIE x1 slot;...
  • Page 15: Multi Monitor Feature

    [512MB] to enable the function of VGA. Please make sure that the value you select is less than the total capability of the system memory. If you do not adjust the BIOS setup, the default value of “Share Memory”, [Auto], will disable VGA function when the add-on VGA card is inserted to this motherboard.
  • Page 16 F. Set the “Screen Resolution” and “Color Quality” as appropriate for the second monitor. Click “Apply” or “OK” to apply these new values. G. Repeat steps C through E for the diaplay icon identified by the number one, two and three.
  • Page 17: Jumpers Setup

    After waiting for 15 seconds, use a jumper cap to short pin2 and pin3 on CLRCMOS1 for 5 seconds. However, please do not clear the CMOS right after you update the BIOS.
  • Page 18: Onboard Headers And Connectors

    Floppy Connector (33-pin FLOPPY1) (see p.2 No. 21) the red-striped side to Pin1 Note: Make sure the red-striped side of the cable is plugged into Pin1 side of the connector. Primary IDE connector (Blue) (39-pin IDE1, see p.2 No. 10)
  • Page 19 HDA to function correctly. Please follow the instruction in our manual and chassis manual to install your system. 2. If you use AC’97 audio panel, please install it to the front panel audio header as below: A.
  • Page 20 Though this motherboard provides 4-Pin CPU fan (Quiet Fan) support, the 3-Pin CPU fan still can work successfully even without the fan speed control function. If you plan to connect the 3-Pin CPU fan to the CPU fan connector on this motherboard, please connect it to Pin 1-3.
  • Page 21: Installing Windows Functions

    Driver Installation Guide Driver Installation Guide To install the drivers to your system, please insert the support CD to your optical drive first. Then, the drivers compatible to your system can be auto-detected and listed on the support CD driver page. Please follow the order from up to bottom side to install those required drivers.
  • Page 22: Installing Windows Vista

    Untied Overclocking function, please enter “Overclock Mode” option of BIOS setup to set the selection from [Auto] to [Manual]. Therefore, CPU FSB is untied during overclocking, but PCI / PCIE buses are in the fixed mode so that FSB can operate under a more stable overclocking environment.
  • Page 23: Bios Information

    BIOS Setup utility; otherwise, POST continues with its test routines. If you wish to enter BIOS Setup after POST, please restart the system by pressing <Ctl> + <Alt> + <Delete>, or pressing the reset button on the system chassis. The BIOS Setup program is designed to be user-friendly.
  • Page 24 1. Einführung 1. Einführung 1. Einführung Wir danken Ihnen für den Kauf des ASRock 760GM-GS3 / 760GM-S3 Motherboard, ein zuverlässiges Produkt, welches unter den ständigen, strengen Qualitätskontrollen von ASRock gefertigt wurde. Es bietet Ihnen exzellente Leistung und robustes Design, gemäß der Verpflichtung von ASRock zu Qualität und Halbarkeit.
  • Page 25: Spezifikationen

    - Micro ATX-Formfaktor: 24.4 cm x 18.3 cm; 9.6 Zoll x 7.2 Zoll - Unterstützung von Socket AM3-Prozessoren: AMD Phenom II X6 / X4 / X3 / X2 (außer 920 / 940) / Athlon X4 / X3 / X2 / Sempron-Prozessor - Sechs-Kern-CPU-bereit - Unterstützt AMD OverDrive...
  • Page 26 - 1 x Serieller port: COM 1 - 1 x VGA Port - 4 x Ready-to-Use USB 2.0 Ports - 1 x RJ-45 LAN Port mit LED (ACT/LINK LED und SPEED LED) - Audioanschlüsse: Line In / Line Out / Mikrofon Anschlüsse - 4 x SATAII-Anschlüsse, unterstützt bis 3.0 Gb/s...
  • Page 27 Beachten Sie bitte, dass Overclocking, einschließlich der Einstellung im BIOS, Anwenden der Untied Overclocking-Technologie oder Verwenden von Overclocking-Werkzeugen von Dritten, mit einem gewissen Risiko behaftet ist. Overclocking kann sich nachteilig auf die Stabilität Ihres Systems auswirken oder sogar Komponenten und Geräte Ihres Systems beschädigen.
  • Page 28 USB-Flash-Laufwerk oder die Festplatte das Dateisystem FAT32/16/12 benutzen muss. 10. Allein der Name – OC DNA* – beschreibt es wörtlich, was die Software zu leisten vermag. OC DNA ist ein von ASRock exklusiv entwickeltes Dienstprogramm, das Nutzern eine bequeme Möglichkeit bietet, Übertaktungseinstellungen aufzuzeichnen und sie Anderen mitzuteilen.
  • Page 29 Charger. Installieren Sie einfach den ASRock APP Charger-Treiber; dadurch lädt sich Ihr iPhone wesentlich schneller über einen Computer auf – genaugenommen bis zu 40 % schneller als zuvor. Der ASRock APP Charger ermöglicht Ihnen die schnelle Aufladung mehrerer Apple- Geräte gleichzeitig; der Ladevorgang wird sogar dann fortgesetzt, wenn der PC den Ruhezustand (S1), Suspend to RAM-Modus (S3) oder Tiefschlafmodus (S4) aufruft oder ausgeschaltet wird (S5).
  • Page 30 Shutdown durch. Bevor Sie das System neu starten, prüfen Sie bitte, ob der CPU-Lüfter am Motherboard richtig funktioniert, und stecken Sie bitte den Stromkabelstecker aus und dann wieder ein. Um die Wärmeableitung zu verbessern, bitte nicht vergessen, etwas Wärmeleitpaste zwischen CPU und Kühlkörper zu sprühen.
  • Page 31: Einstellung Der Jumper

    Überbrücken Sie Pin2, Pin3, um +5VSB (Standby) zu setzen (siehe S.2, No. 1) und die PS/2 oder USB- Weckfunktionen zu aktivieren. Hinweis: Um +5VSB nutzen zu können, muss das Netzteil auf dieser Leitung 2A oder mehr leisten können. CMOS löschen (CLRCMOS1, 3-Pin jumper) Default- CMOS (siehe S.2, No.
  • Page 32 (33-Pin FLOPPY1) die rotgestreifte Seite auf Stift 1 (siehe S.2, No. 21) Hinweis: Achten Sie darauf, dass die rotgestreifte Seite des Kabel mit der Stift 1- Seite des Anschlusses verbunden wird. Primärer IDE-Anschluss (blau) (39-pin IDE1, siehe S.2, No. 10)
  • Page 33 Geräte), wobei jedoch die Bildschirmverdrahtung am Gehäuse HDA unterstützen muss, um richtig zu funktionieren. Beachten Sie bei der Installation im System die Anweisungen in unserem Handbuch und im Gehäusehandbuch. 2. Wenn Sie die AC’97-Audioleiste verwenden, installieren Sie diese wie nachstehend beschrieben an der Front-Audioanschlussleiste: A.
  • Page 34 ® Bei den Betriebssystemen Windows XP / XP 64 Bit: Wählen Sie „Mixer“. Wählen Sie „Recorder“ (Rekorder). Klicken Sie dann auf „FrontMic“ (Vorderes Mikrofon). ® Bei den Betriebssystemen Windows 7 / 7 64 Bit / Vista / Vista 64 Bit: Wählen Sie im Realtek-Bedienfeld die „FrontMic“...
  • Page 35 Obwohl dieses Motherboard einen 24-pol. ATX-Stromanschluss bietet, kann es auch mit einem modifizierten traditionellen 20-pol. ATX-Netzteil verwendet werden. Um ein 20-pol. ATX-Netzteil zu verwenden, stecken Sie den Stecker mit Pin 1 und Pin 13 ein. Installation eines 20-pol. ATX-Netzteils Anschluss für...
  • Page 36 Erscheint der Wilkommensbildschirm nicht, so “doppelklicken” Sie bitte auf das File ASSETUP.EXE im BIN-Verzeichnis der Support-CD, um die Menüs aufzurufen. Das Setup-Programm soll es Ihnen so leicht wie möglich machen. Es ist menügesteuert, d.h. Sie können in den verschiedenen Untermenüs Ihre Auswahl treffen und die Programme werden dann automatisch installiert.
  • Page 37: Contenu Du Paquet

    Contenu du paquet Contenu du paquet Carte mère ASRock 760GM-GS3 / 760GM-S3 (Facteur de forme Micro ATX: 9.6 pouces x 7.2 pouces, 24.4 cm x 18.3 cm) Guide d’installation rapide ASRock 760GM-GS3 / 760GM-S3 CD de soutien ASRock 760GM-GS3 / 760GM-S3 Deux câble de données Serial ATA (SATA) (Optionnelle)
  • Page 38: Spécifications

    9.6 pouces x 7.2 pouces, 24.4 cm x 18.3 cm - Prise en charge des processeurs sur socket AM3: Processeur Phenom II X6 / X4 / X3 / X2 (sauf 920 / 940) / Athlon II X4 / X3 / X2 / Sempron d’AMD - Prêt pour processeurs Six-Core - Prise en charge d’AMD OverDrive...
  • Page 39 - Connecteur pour ventilateur de CPU/Châssis/Ventilateur - br. 24 connecteur d’alimentation ATX - br. 4 connecteur d’alimentation 12V ATX - Connecteur audio panneau avant - 2 x En-tête USB 2.0 (prendre en charge 4 ports USB 2.0 supplémentaires) BIOS - 8Mb BIOS AMI - BIOS AMI - Support du “Plug and Play”...
  • Page 40 - FCC, CE, WHQL - Prêt pour ErP/EuP (alimentation Prêt pour ErP/EuP requise) (voir ATTENTION 15) * Pour de plus amples informations sur les produits, s’il vous plaît visitez notre site web: http://www.asrock.com ATTENTION Il est important que vous réalisiez qu’il y a un certain risque à effectuer l’overclocking, y compris ajuster les réglages du BIOS, appliquer la technologie Untied Overclocking, ou...
  • Page 41 Avant d’installer le disque dur SATAII au connecteur SATAII, veuillez lire le Guide « Installation du disque dur SATAII » à la page 25 du « Manuel de l’utilisateur » qui se trouve sur le CD de support pour régler votre lecteur de disque dur SATAII au mode SATAII.
  • Page 42 10. Le nom même du logiciel – OC DNA vous indique littéralement ce dont il est capable. OC DNA, utilitaire exclusif développé par ASRock, offre une façon pratique pour l’utilisateur d’enregistrer les paramètres d’overclockage et de les partager avec d’autres. Il vous aide à...
  • Page 43 EuP sont requises. Selon les suggestions d’Intel’, l’alimentation électrique EuP doit correspondre à la norme, qui est que l’efficacité électrique de 5v en mode de veille doit être supérieure à 50% pour 100 mA de consommation de courant. Pour choisir une alimentation électrique conforme à...
  • Page 44 Toutefois, veuillez ne pas effacer la CMOS tout de suite après avoir mis le BIOS à jour. Si vous avez besoin d’effacer la CMOS lorsque vous avez fini de mettre le BIOS à jour, vous devez d’abord initialiser le système, puis le mettre hors tension avant de procéder à...
  • Page 45 (voir p.2 fig. 21) Broche1 Note: Assurez-vous que le côté avec fil rouge du câble est bien branché sur le côté Broche1 du connecteur. Connecteur IDE primaire (bleu) (IDE1 br. 39, voir p.2 No. 10)
  • Page 46 1. L’audio à haute définition (HDA) prend en charge la détection de fiche, mais le fil de panneau sur le châssis doit prendre en charge le HDA pour fonctionner correctement. Veuillez suivre les instructions dans notre manuel et le manuel de châssis afin installer votre système.
  • Page 47 (voir p.2 fig. 6) ien que cette carte mère offre un support de (Ventilateur silencieux) ventilateur de CPU à 4 broches , le ventilateur de CPU à 3 broches peut bien fonctionner même sans la fonction de commande de vitesse du ventilateur.
  • Page 48 (voir p.2 fig. 7) Bien que cette carte mère fournisse un connecteur de courant ATX 24 broches, elle peut encore fonctionner si vous adopter une alimentation traditionnelle ATX 20 broches. Pour utiliser une alimentation ATX 20 broches, branchez à...
  • Page 49: Informations Sur Le Cd De Support

    BIOS après le POST, veuillez redémarrer le système en pressant <Ctl> + <Alt> + <Suppr>, ou en pressant le bouton de reset sur le boîtier du système. Vous pouvez également redémarrer en éteignant le système et en le rallumant.
  • Page 50 1. Introduzione Grazie per aver scelto una scheda madre ASRock 760GM-GS3 / 760GM-S3, una scheda madre affidabile prodotta secondo i severi criteri di qualità ASRock. Le prestazioni eccellenti e il design robusto si conformano all’impegno di ASRock nella ricerca della qualità e della resistenza. Questa Guida Rapida all’Installazione contiene l’introduzione alla motherboard e la guida passo-passo all’installazione.
  • Page 51 Processore - Supporto di processori Socket AM3: AMD Phenom II X6 / X4 / X3 / X2 (fatta eccezione per 920 / 940) / Athlon II X4 / X3 / X2 / Sempron - CPU Six-Core Ready - Supporta AMD OverDrive...
  • Page 52 - 1 x Porta COM - 1 x Porta VGA - 4 x porte USB 2.0 già integrate - 1 x porte LAN RJ-45 con LED (LED azione/collegamento e LED velocità) - Audio Jack: Line In / Line Out / Microfono Connettori - 4 x connettori SATAII 3.0Go/s, sopporta RAID (RAID 0, RAID 1,...
  • Page 53 * Per ulteriori informazioni, prego visitare il nostro sito internet: http://www.asrock.com AVVISO Si prega di prendere atto che la procedura di overclocking implica dei rischi, come anche la regolazione delle impostazioni del BIOS, l’applicazione della tecnologia Untied Overclocking Technology, oppure l’uso di strumenti di overclocking forniti da terzi. L’overclocking può...
  • Page 54 (dischi floppy) o altre complicate utilità Flash. Si prega di notare che l’unità Flash USB o il disco rigido devono usare il File System FAT32/16/ 10. Il nome stesso del software – OC DNA – dice di cosa è capace. OC DNA, una utilità esclusiva sviluppata da ASRock, fornisce un modo comodo per registrare le impostazioni OC e condividerle con gli altri.
  • Page 55 CD ASRock fornito in dotazione, e scaricare gratuitamente AIWI Lite dall’App Store sull’iPhone/iPod touch. Collegare il PC ed i dispositivi Apple usando Bluetooth o la rete WiFi e poi si può iniziare a divertirsi con i giochi controllati dal movimento. Non scordare di vistare regolarmente il...
  • Page 56 Quando il ponticello è posizionato sui pin, il jumper è “CORTOCIRCUITATO”. Se sui pin non ci sono ponticelli, il jumper è “APERTO”. L’illustrazione mostra un jumper a 3 pin in cui il pin1 e il pin2 sono “CORTOCIRCUITATI” quando il ponticello è CORTOCIRCUITATO APERTO posizionato su questi pin.
  • Page 57 (33-pin FLOPPY1) (vedi p.2 item 21) Lato del Pin1 con la striscia rossa Nota: Assicurarsi che il lato del cavo con la striscia rossa sia inserito nel lato Pin1 del connettore. Connettore IDE primario (blu) (39-pin IDE1, vedi p.2 Nr. 10)
  • Page 58 1. La caratteristica HDA (High Definition Audio) supporta il rilevamento dei connettori, però il pannello dei cavi sul telaio deve supportare la funzione HDA (High Definition Audio) per far sì che questa operi in modo corretto. Attenersi alle istruzioni del nostro manuale e del manuale del telaio per installare il sistema.
  • Page 59 Sebbene la presente scheda madre disponga di un supporto per ventola CPU a 4 piedini (ventola silenziosa), la ventola CPU a 3 piedini è in grado di funzionare anche senza la funzione di controllo della velocità della ventola. Se si intende collegare la ventola CPU a 3 piedini al connettore della ventola CPU su questa scheda madre, collegarla ai piedini 1-3.
  • Page 60 ATX a 24 pin, ma può funzionare lo stesso se si adotta un alimentatore ATX a 20 pin. Per usare l’alimentatore ATX a 20 pin, collegare l’alimentatore con il Pin 1 e il Pin 13. Installazione dell’alimentatore ATX a 20 pin Connettore ATX 12V È...
  • Page 61 BIOS; altrimenti, POST continua con i suoi test di routine. Per entrare il BIOS Setup dopo il POST, riavvia il sistema premendo <Ctl> + <Alt> + <Delete>, o premi il tasto di reset sullo chassis del sistema. El BIOS Setup Utility es diseñádo “user-friendly”.
  • Page 62 ASRock. Esta Guía rápida de instalación contiene una introducción a la placa base y una guía de instalación paso a paso. Puede encontrar una información más detallada sobre la placa base en el manual de usuario incluido en el CD de soporte.
  • Page 63 Especificación Especificación Especificación Especificación Plataforma - Factor forma Micro ATX: 24,4 cm x 18,3 cm, 9,6” x 7,2” Procesador - Compatibilidad con procesadores con conector AM3: procesador AMD Phenom II X6 / X4 / X3 / X2 (excepto 920 / 940) / Athlon II X4 / X3 / X2 / Sempron - Compatible con CPU de séxtuple núcleo...
  • Page 64 - 1 x puerto serial: COM1 - 1 x Puerto VGA - 4 x puertos USB 2.0 predeterminados - 1 x Puerto LAN RJ-45 con LED (LED de ACCIÓN/ENLACE y LED de VELOCIDAD) - Audio Jack: Line In / Line Out / Micrófono...
  • Page 65 ADVERTENCIA Tenga en cuenta que hay un cierto riesgo implícito en las operaciones de aumento de la velocidad del reloj, incluido el ajuste del BIOS, aplicando la tecnología de aumento de velocidad liberada o utilizando las herramientas de aumento de velocidad de otros fabricantes.
  • Page 66 Antes de instalar un disco duro SATAII en el conector SATAII, consulte la sección “Guía de instalación de discos duros SATAII” en la página 25 del “Manual de usuario” que se incluye en el CD de soporte para configurar su disco duro SATAII en modo SATAII. También puede conectar un disco duro SATA directamente al conector SATAII.
  • Page 67 PC. Tan solo tiene que instalar la utilidad ASRock AIWI desde el sitio web oficial de ASRock AIWI, o bien mediante el CD de soporte de software de ASRock en su placa base, y también descargarse gratis AIWI Lite de la tienda de aplicaciones de su iPhone o iPod touch.
  • Page 68 Unión Europea para establecer el consumo total de energía de un sistema. Según la disposición EuP, la alimentación de CA total para el sistema completo ha de ser inferior a 1,00W en modo apagado. Para cumplir con el estándar EuP, se requieren una placa base y una fuente de alimentación que cumplan con...
  • Page 69 3 para habilitar +5VSB (vea p.2, No. 1) (standby) para PS/2 o USB wake up events. Atención: Para elegir +5VSB, se necesita corriente mas que 2 Amp proveida por la fuente de electricidad. Limpiar CMOS (CLRCMOS1, jumper de 3 pins) (ver p.2, No.
  • Page 70 1 Atención: Asegúrese que la banda roja del cable queda situado en el mismo lado que el contacto 1 de la conexión. IDE conector primario (azul) (39-pin IDE1, vea p.2, No. 10)
  • Page 71 2. Si utiliza el panel de sonido AC’97, instálelo en la cabecera de sonido del panel frontal de la siguiente manera: A. Conecte Mic_IN (MIC) a MIC2_L.
  • Page 72 Si pretende enchufar el ventilador de procesador de 3 contactos en el conector del ventilador de procesador de esta placa base, conéctelo al contacto 1-3. Contacto 1-3 conectado Instalación del ventilador de 3 contactos...
  • Page 73 ATX de 24 pins, ésta puede funcionar incluso si utiliza una fuente de alimentación ATX de 20 pins tradicional. Para usar una fuente de alimentación ATX de 20 pins, por favor, conecte su fuente de alimentación usando los Pins 1 y 13.
  • Page 74 / Vista / Vista 64 bits / XP / XP Media Center / XP 64 bits El CD de instalación que acompaña la placa-base trae todos los drivers y programas utilitarios para instalar y configurar la placa-base. Para iniciar la instalación, ponga el CD en el lector de CD y se desplegará...
  • Page 75 ASRock. ASRock Micro ATX: 9,6 x 7,2 / 24,4 x 18,3 ASRock ASRock Serial ATA (SATA) ( ASRock 760GM-GS3 / 760GM-S3 Motherboard...
  • Page 76 Micro ATX: 9,6 x 7,2 / 24,4 x 18,3 ASRock 760GM-GS3 / 760GM-S3 Motherboard...
  • Page 77 Hot-Plug ASRock 760GM-GS3 / 760GM-S3 Motherboard...
  • Page 78 ASRock 760GM-GS3 / 760GM-S3 Motherboard...
  • Page 79 ASRock 760GM-GS3 / 760GM-S3 Motherboard...
  • Page 80 ASRock 760GM-GS3 / 760GM-S3 Motherboard...
  • Page 81 Short Open CMOS CMOS ASRock 760GM-GS3 / 760GM-S3 Motherboard...
  • Page 82 1 SATAII_3 SATAII_4 (PORT 2) (PORT 3) SATAII_1 SATAII_2 (PORT 0) (PORT 1) ASRock 760GM-GS3 / 760GM-S3 Motherboard...
  • Page 83 ASRock 760GM-GS3 / 760GM-S3 Motherboard...
  • Page 84 PANEL1) ASRock 760GM-GS3 / 760GM-S3 Motherboard...
  • Page 85 ATX. 12V-ATX ATX 12 ASRock 760GM-GS3 / 760GM-S3 Motherboard...
  • Page 86 BIOS Setup Power-On-Self-Test – POST POST BIOS Setup POST Ctrl> + <Alt> + <Delete BIOS Setup ASRock 760GM-GS3 / 760GM-S3 Motherboard...
  • Page 87 é dotada de um projeto robusto que atende a ASRock de compromisso com a qualidade e durabilidade. Este Guia de Instalação Rápida apresenta a placa-mãe e o guia de instalação passo a passo. Mais informações detalhadas sobre a placa-mãe podem ser encontradas no manual do usuário do CD de suporte.
  • Page 88 - Formato Micro ATX: 9,6 pol. x 7,2 pol., 24,4 cm x 18,3 cm - Suporte para processadores AM3: Processador AMD Phenom II X6 / X4 / X3 / X2 (exceto 920 / 940) / Athlon II X4 / X3 / X2 / Sempron - Preparado para CPU de seis núcleos...
  • Page 89 - 1 x porta COM1 - 1 x porta VGA - 4 x portas USB 2.0 padrão - 1 x porta LAN RJ-45 com LED (LED ACT/LIG e LED VELOCIDADE) - Áudio Jack: saída / entrada de linha / microfone + porta...
  • Page 90 - Microsoft Windows 7 / 7 de 64 bits / Vista Operacional Vista de 64 bits / XP / Centro de multimedia XP / XP de 64 bits Certificações - FCC, CE, WHQL - “ErP/EuP Ready” (é necessária alimentação eléctrica “ErP/ EuP Ready”) (veja o AVISO 15)
  • Page 91 O máximo tamanho de memória compartilhada é definido por vendedor de chipset e é sujeito a mudar. Verifique o AMD website para a última informação. Antes de instalar o disco duro SATAII no conector SATAII, por favor leia o “Guia de Instalação do Disco duro SATAII” na página 25 do Manual do Usuário no CD de suporte, para definir a sua unidade de disco duro...
  • Page 92 11. Os jogos controlados por movimento intuitivo deixaram de ser um exclusivo da Wii. O utilitário ASRock AIWI apresenta uma nova forma de jogar jogos no PC. O ASRock AIWI é o primeiro utilitário a nível mundial a transformar o seu iPhone/iPod touch num joystick para controlar os seus jogos.
  • Page 93 (veja a folha 2, No. 1) para PS/2 ou eventos de wake up na USB. Nota: Para escolher +5VSB, é preciso uma corrente de stand by de 2 A ou mais. Restaurar CMOS (CLRCMOS1, jumper de 3 pinos) (veja a folha 2, No. 9) Limpar o CMOS Configuração-...
  • Page 94 (veja a folha 2, No. 21) o lado com listras vermelhas para o Pino 1 Nota: Certifique-se de que o lado com listras vermelhas no cabo seja conectado ao lado Pino 1 do conector. Conector primário (Azul) (IDE1 de 39 pinos, veja a folha 2, No. 10)
  • Page 95 Siga s instruções que aparecem no manual e no manual do chassis para instalar o sistema. 2. Se utilizar o painel de áudio AC’97, instale-o no cabeçalho de áudio do painel frontal, como a figura abaixo mostra: A. Ligue o Mic_IN (MIC) ao MIC2_L.
  • Page 96 (CPU_FAN1 de 4 pinos) (veja a folha 2, No. 6) Apesar de esta placa-mãe possuir 4 apoios para uma ventoinha de CPU (Ventoinha silenciosa), uma ventoinha de 3 pinos para CPU poderá funcionar mesmo sem a função de controlo de velocidade da ventoinha. Se pretender ligar uma ventoinha de 3 pinos para CPU ao conector de ventoinha do CPU nesta placa-mãe, por favor, ligue-a aos pinos 1-3.
  • Page 97 20 pinos. Para usar a fonte de alimentação de 29 pinos, por favor ligue a sua fonte de alimentação com o Pino 1 e o Pino 13. Instalação da Fonte de alimentação ATX de 20 Pinos Conector ATX 12 V Note que é...
  • Page 98 64 bits / Win7. O CD de instalação que acompanha a placa Mãe contem: drivers e utilitários necessários para um melhor desempenho da placa Mãe. Para começar a usar o CD de instalação, introduza o CD na leitora de CD-ROM do computador. Automaticamente iniciará o menu principal, casa o “AUTORUN”...
  • Page 99 ASRock 760GM-GS3 / 760GM-S3 Motherboard...
  • Page 100 1 0 0 1 0 0 1 0 0 1 0 0 1 0 0 ASRock 760GM-GS3 / 760GM-S3 Motherboard...
  • Page 101 1 0 1 1 0 1 1 0 1 1 0 1 1 0 1 ASRock 760GM-GS3 / 760GM-S3 Motherboard...
  • Page 102 1 0 2 1 0 2 1 0 2 1 0 2 1 0 2 ASRock 760GM-GS3 / 760GM-S3 Motherboard...
  • Page 103 1 0 3 1 0 3 1 0 3 1 0 3 1 0 3 ASRock 760GM-GS3 / 760GM-S3 Motherboard...
  • Page 104 1 0 4 1 0 4 1 0 4 1 0 4 1 0 4 ASRock 760GM-GS3 / 760GM-S3 Motherboard...
  • Page 105 Short Open Default Clear CMOS 1 0 5 1 0 5 1 0 5 1 0 5 1 0 5 ASRock 760GM-GS3 / 760GM-S3 Motherboard...
  • Page 106 SATAII_3 SATAII_4 (PORT 2) (PORT 3) SATAII_1 SATAII_2 (PORT 0) (PORT 1) 1 0 6 1 0 6 1 0 6 1 0 6 1 0 6 ASRock 760GM-GS3 / 760GM-S3 Motherboard...
  • Page 107 1 0 7 1 0 7 1 0 7 1 0 7 1 0 7 ASRock 760GM-GS3 / 760GM-S3 Motherboard...
  • Page 108 1 0 8 1 0 8 1 0 8 1 0 8 1 0 8 ASRock 760GM-GS3 / 760GM-S3 Motherboard...
  • Page 109 1 0 9 1 0 9 1 0 9 1 0 9 1 0 9 ASRock 760GM-GS3 / 760GM-S3 Motherboard...
  • Page 110 1 1 0 1 1 0 1 1 0 1 1 0 1 1 0 ASRock 760GM-GS3 / 760GM-S3 Motherboard...
  • Page 111 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 ASRock 760GM-GS3 / 760GM-S3 Motherboard...
  • Page 112 ‘ ’ 1 1 2 1 1 2 1 1 2 1 1 2 1 1 2 ASRock 760GM-GS3 / 760GM-S3 Motherboard...
  • Page 113 1 1 3 1 1 3 1 1 3 1 1 3 1 1 3 ASRock 760GM-GS3 / 760GM-S3 Motherboard...
  • Page 114 ® “ ” ® ® “ ” “ ” ® 1 1 4 1 1 4 1 1 4 1 1 4 1 1 4 ASRock 760GM-GS3 / 760GM-S3 Motherboard...
  • Page 115 ® 1 1 5 1 1 5 1 1 5 1 1 5 1 1 5 ASRock 760GM-GS3 / 760GM-S3 Motherboard...
  • Page 116 1 1 6 1 1 6 1 1 6 1 1 6 1 1 6 ASRock 760GM-GS3 / 760GM-S3 Motherboard...
  • Page 117 “ ” “ ” “ ” “ ” 1 1 7 1 1 7 1 1 7 1 1 7 1 1 7 ASRock 760GM-GS3 / 760GM-S3 Motherboard...
  • Page 118 SATAII_3 SATAII_4 (PORT 2) (PORT 3) SATAII_1 SATAII_2 (PORT 0) (PORT 1) 1 1 8 1 1 8 1 1 8 1 1 8 1 1 8 ASRock 760GM-GS3 / 760GM-S3 Motherboard...
  • Page 119 ® “ ” “ ” “ ” 1 1 9 1 1 9 1 1 9 1 1 9 1 1 9 ASRock 760GM-GS3 / 760GM-S3 Motherboard...
  • Page 120 ® “ ” “ ” 1 2 0 1 2 0 1 2 0 1 2 0 1 2 0 ASRock 760GM-GS3 / 760GM-S3 Motherboard...
  • Page 121 1 2 1 1 2 1 1 2 1 1 2 1 1 2 1 ASRock 760GM-GS3 / 760GM-S3 Motherboard...
  • Page 122 “ ” “ ” 1 2 2 1 2 2 1 2 2 1 2 2 1 2 2 ASRock 760GM-GS3 / 760GM-S3 Motherboard...
  • Page 123 1 2 3 1 2 3 1 2 3 1 2 3 1 2 3 ASRock 760GM-GS3 / 760GM-S3 Motherboard...
  • Page 124 ‘ ’ 1 2 4 1 2 4 1 2 4 1 2 4 1 2 4 ASRock 760GM-GS3 / 760GM-S3 Motherboard...
  • Page 125 1 2 5 1 2 5 1 2 5 1 2 5 1 2 5 ASRock 760GM-GS3 / 760GM-S3 Motherboard...
  • Page 126 ® ® ® “ ” ® ® 1 2 6 1 2 6 1 2 6 1 2 6 1 2 6 ASRock 760GM-GS3 / 760GM-S3 Motherboard...
  • Page 127 ® ® – 1 2 7 1 2 7 1 2 7 1 2 7 1 2 7 ASRock 760GM-GS3 / 760GM-S3 Motherboard...
  • Page 128 1 2 8 1 2 8 1 2 8 1 2 8 1 2 8 ASRock 760GM-GS3 / 760GM-S3 Motherboard...
  • Page 129 1 2 9 1 2 9 1 2 9 1 2 9 1 2 9 ASRock 760GM-GS3 / 760GM-S3 Motherboard...
  • Page 130 SATAII_3 SATAII_4 (PORT 2) (PORT 3) SATAII_1 SATAII_2 (PORT 0) (PORT 1) 1 3 0 1 3 0 1 3 0 1 3 0 1 3 0 ASRock 760GM-GS3 / 760GM-S3 Motherboard...
  • Page 131 ® “ ” “ ” “ ” ® “ ” “ ” 1 3 1 1 3 1 1 3 1 1 3 1 1 3 1 ASRock 760GM-GS3 / 760GM-S3 Motherboard...
  • Page 132 1 3 2 1 3 2 1 3 2 1 3 2 1 3 2 ASRock 760GM-GS3 / 760GM-S3 Motherboard...
  • Page 133 1 3 3 1 3 3 1 3 3 1 3 3 1 3 3 ASRock 760GM-GS3 / 760GM-S3 Motherboard...
  • Page 134 ® ® 1 3 4 1 3 4 1 3 4 1 3 4 1 3 4 ASRock 760GM-GS3 / 760GM-S3 Motherboard...
  • Page 135 1 3 5 1 3 5 1 3 5 1 3 5 1 3 5 ASRock 760GM-GS3 / 760GM-S3 Motherboard...
  • Page 136 ™ ‘ ’ 1 3 6 1 3 6 1 3 6 1 3 6 1 3 6 ASRock 760GM-GS3 / 760GM-S3 Motherboard...
  • Page 137 ® ® 1 3 7 1 3 7 1 3 7 1 3 7 1 3 7 ASRock 760GM-GS3 / 760GM-S3 Motherboard...
  • Page 138 ® ® ® ® 1 3 8 1 3 8 1 3 8 1 3 8 1 3 8 ASRock 760GM-GS3 / 760GM-S3 Motherboard...
  • Page 139 ® 1 3 9 1 3 9 1 3 9 1 3 9 1 3 9 ASRock 760GM-GS3 / 760GM-S3 Motherboard...
  • Page 140 1 4 0 1 4 0 1 4 0 1 4 0 1 4 0 ASRock 760GM-GS3 / 760GM-S3 Motherboard...
  • Page 141 SATAII_3 SATAII_4 (PORT 2) (PORT 3) SATAII_1 SATAII_2 (PORT 0) (PORT 1) 1 4 1 1 4 1 1 4 1 1 4 1 1 4 1 ASRock 760GM-GS3 / 760GM-S3 Motherboard...
  • Page 142 ® ® 1 4 2 1 4 2 1 4 2 1 4 2 1 4 2 ASRock 760GM-GS3 / 760GM-S3 Motherboard...
  • Page 143 1 4 3 1 4 3 1 4 3 1 4 3 1 4 3 ASRock 760GM-GS3 / 760GM-S3 Motherboard...
  • Page 144 ® ® 1 4 4 1 4 4 1 4 4 1 4 4 1 4 4 ASRock 760GM-GS3 / 760GM-S3 Motherboard...
  • Page 145 1 4 5 1 4 5 1 4 5 1 4 5 1 4 5 ASRock 760GM-GS3 / 760GM-S3 Motherboard...
  • Page 146 1 4 6 1 4 6 1 4 6 1 4 6 1 4 6 ASRock 760GM-GS3 / 760GM-S3 Motherboard...
  • Page 147 1 4 7 1 4 7 1 4 7 1 4 7 1 4 7 ASRock 760GM-GS3 / 760GM-S3 Motherboard...
  • Page 148 1 4 8 1 4 8 1 4 8 1 4 8 1 4 8 ASRock 760GM-GS3 / 760GM-S3 Motherboard...
  • Page 149 ® ® ® ® ® 1 4 9 1 4 9 1 4 9 1 4 9 1 4 9 ASRock 760GM-GS3 / 760GM-S3 Motherboard...
  • Page 150 ® ® 1 5 0 1 5 0 1 5 0 1 5 0 1 5 0 ASRock 760GM-GS3 / 760GM-S3 Motherboard...
  • Page 151 1 5 1 1 5 1 1 5 1 1 5 1 1 5 1 ASRock 760GM-GS3 / 760GM-S3 Motherboard...
  • Page 152 SATAII_3 SATAII_4 (PORT 2) (PORT 3) SATAII_1 SATAII_2 (PORT 0) (PORT 1) 1 5 2 1 5 2 1 5 2 1 5 2 1 5 2 ASRock 760GM-GS3 / 760GM-S3 Motherboard...
  • Page 153 ® ® 1 5 3 1 5 3 1 5 3 1 5 3 1 5 3 ASRock 760GM-GS3 / 760GM-S3 Motherboard...
  • Page 154 1 5 4 1 5 4 1 5 4 1 5 4 1 5 4 ASRock 760GM-GS3 / 760GM-S3 Motherboard...
  • Page 155 ® ® ® 1 5 5 1 5 5 1 5 5 1 5 5 1 5 5 ASRock 760GM-GS3 / 760GM-S3 Motherboard...

This manual is also suitable for:

760gm-s37680gm-gs3

Table of Contents
