Follow the steps below to mount the thermostat:
1.
Open the thermostat:
Important: Do NOT press on the display screen when
removing the front part.
Press your ngers under the side of the front part and
pull toward you:
2.
Connect the thermostat according to the connection
diagram.
The screen of the heating cable must be connected to
the earth conductor of the power supply cable
by using a separate connector.
Note: Always install the oor sensor in a conduit in the
oor.
10
L
NTC
O
L
A
D
Maximum
Load 16 (1) A
Dtouch
Standby maximum 0.4W
DEVIreg™ Touch
L
L
N
O
N
A
D
Mains
220-240V
50-60 Hz
IP21
T30
Installation Guide
