Step 4: Connect ribbon cables, cabinet wires, and power
supply

Step4-1:I/O Back Panel Introduction

PS/2 Keyboard and PS/2 Mouse Connector
PS/2 Mouse Connector
(6 pin Female)
PS/2 Keyboard Connector
(6 pin Female)
USB & LAN Connector
LAN*
USB 0
USB 1
"*" Only for GA-7VTXH.
This connector supports standard PS/2 keyboard
and PS/2 mouse.
Before you connect your device(s) into USB
connector(s), please make sure your device(s)
such as USB keyboard,mouse, scanner, zip,
speaker..etc. Have a standard USB interface. Also
make sure your OS (Win 95 with USB supplement,
Win98, Windows 2000, Windows ME, Win NT
with SP 6) supports USB controller. If your OS
does not support USB controller, please contact
OS vendor for possible patch or driver upgrade.
For more information please contact your OS or
device(s) vendors.
