GA-7VTXE/GA-7VTXH AMD Socket A Processor Motherboard USER’S MANUAL ™ ™ ™ AMD Athlon / Athlon XP / Duron Socket A Processor Motherboard Rev. 1.0 Third Edition 12ME-7VTXE-1003...
WARNING! ....................7 Chapter 1 Introduction ................8 Summary of Features .................. 8 GA-7VTXE/GA-7VTXH Motherboard Layout ..........10 Chapter 2 Hardware Installation Process ..........11 Step 1: Install the Central Processing Unit (CPU)........12 Step1-1: CPU Speed Setup .................... 12 Step1-2: CPU Installation ....................
Revision Revision Note Date Initial release of the GA-7VTXE/GA-7VTXH motherboard user's manual. Sep.2001 Second release of the GA-7VTXE/GA-7VTXH motherboard user's manual. Oct .2001 Third release of the GA-7VTXE/GA-7VTXH motherboard user's manual. Nov.2001 Item Checklist The GA-7VTXE/GA-7VTXH motherboard IDE cable x 1/ Floppy cable x 1 CD for motherboard driver &...
WARNING! WARNING! Computer motherboards and expansion cards contain very delicate Integrated Circuit (IC) chips. To protect them against damage from static electricity, you should follow some precautions whenever you work on your computer. Unplug your computer when working on the inside. Use a grounded wrist strap before handling computer components.
GA-7VTXE/GA-7VTXH Motherboard Chapter 1 Introduction Summary of Features Form Factor 30.4cm x 20.5cm ATX size form factor, 4 layers PCB. Motherboard GA-7VTXE/GA-7VTXH Motherboard Socket A processor AMD Athlon /Athlon XP/ Duron (K7) 128K L1 & 256K/64K L2 cache on die 200/266MHz FSB and DDR bus speeds (PCI 33MHz) Supports 1.4GHz and faster...
Page 9
CPU, chipset and most of the peripherals. Whether your system can run under these specific bus frequencies properly will depend on your hardware configurations, including CPU, Chipsets,SDRAM,Cards….etc. "*" Only for GA-7VTXH. "**" Only for GA-7VTXE.
8.5x 9.5x 10.5x 11.5x >=12.5x CK_RATIO* The system bus frequency can be switched at 100/ CLK_JP CPU AGP PCI 133MHz by adjusting system jumper (CLK_JP). 2-3 close (The internal frequency depend on CPU.) 1-2 close "*" CK_RATIO only for GA-7VTXH.
Hardware Installation Process Step1-2: CPU Installation CPU Top View CPU Bottom View Socket Actuation Lever Pin1 indicator 2. Locate Pin 1 in the socket and look 1. Pull up the CPU socket level for a (golden) cut edge on the CPU and up to 90-degree angle.
GA-7VTXE/GA-7VTXH Motherboard Step1-3:CPU Heat Sink Installation 2. Use qualified fan approved by AMD. 1. Press down the CPU socket lever and finish CPU installation. 3. Fasten the heatsink supporting-base 4. Make sure the CPU fan is onto the CPU socket on the main- plugged to the CPU fan connector, board.
Hardware Installation Process Step 2: Install memory modules The motherboard has 3 dual inline memory module (DIMM) sockets. The BIOS will automatically detects memory type and size. To install the memory module, just push it vertically into the DIMM Slot. The DIMM module can only fit in one direction due to the notch.
GA-7VTXE/GA-7VTXH Motherboard 1. The DIMM slot has a notch, so the DIMM memory module can only fit in one direction. 2. Insert the DIMM memory module verticallyinto the DIMM slot. Then push it down. 3. Close the plastic clip at both edges of theDIMM slots to lock the DIMM module.
Hardware Installation Process Step 3: Install expension cards 1. Read the related expansion card’s instruction document before install the expansion card into the computer. 2. Remove your computer’s chassis cover, necessary screws and slot bracket from the computer. 3. Press the expansion card firmly into expansion slot in motherboard. 4.
Win98, Windows 2000, Windows ME, Win NT with SP 6) supports USB controller. If your OS does not support USB controller, please contact OS vendor for possible patch or driver upgrade. For more information please contact your OS or device(s) vendors. "*" Only for GA-7VTXH.
Hardware Installation Process Parallel Port , Serial Ports (COMA / COMB) Parallel Port (25 pin Female) This connector supports 2 standard COM ports ,1 Parallel port . Device like printer can be con nected to Parallel port ; mouse and modem etc can be connected to Serial ports.
GA-7VTXE/GA-7VTXH Motherboard Step4-2: Connectors Introduction A) CPU FAN F) F_Panel B) SYS FAN G) USB1 C) ATX H) WOL** D) Floppy/IDE1/IDE2 I) IR E) Battery J) CD_IN "**" Only for GA-7VTXE.
Page 21
Hardware Installation Process A) CPU_FAN (CPU_FAN Connector) B) SYS_FAN (SYS_FAN Connector) The CPU fan connector supports Max. current up to 600 mA . C) ATX (ATX Power) +12V 5V SB (Stand by +5V) Power Good PS-ON(Soft On/Off) 3.3V -12V 3.3V 3.3V AC power cord should only be connected to your power supply unit after ATX power cable and other related devices are firmly connected to the mainboard.
Page 22
GA-7VTXE/GA-7VTXH Motherboard G) USB1 I) IR Be careful with the polarity of the IR connector while you connect the IR. Please contact you nearest dealer for optional IR device. Be careful with the polarity of the front panel USB connector. Check the pin assignment while you connect the front panel USB cable.
Page 23
Hardware Installation Process F) F_PANEL (2x7 pins jumper) HD (IDE Hard Disk Active LED) Pin 1: LED anode(+) Pin 2: LED cathode(-) SPK (Speaker Connector) Pin 1: VCC(+) Pin 2- Pin 3: NC Pin 4: Data(-) RST (Reset Switch) Open: Normal Operation Close: Reset Hardware System PD+/PD_G/PD_Y(Power LED) Pin 1: LED anode(+)
GA-7VTXE/GA-7VTXH Motherboard Chapter 3 BIOS Setup BIOS Setup is an overview of the BIOS Setup Program. The program that allows users to modify the basic system configuration. This type of information is stored in battery-backed CMOS RAM so that it retains the Setup information when the power is turned off.
BIOS Setup GETTING HELP Main Menu The on-line description of the highlighted setup function is displayed at the bottom of the screen. Status Page Setup Menu / Option Page Setup Menu Press F1 to pop up a small help window that describes the appropriate keys to use and the possible selections for the highlighted item.
GA-7VTXE/GA-7VTXH Motherboard Power Management Setup This setup page includes all the adjustable items of Green function features. PNP/PCI Configurations This setup page includes all the adjustable configurations of PCI & PnP ISA resources. Load Fail-Safe Defaults Load Fail-Safe Defaults option loads preset system parameter values to set the system in its most stable configurations.
BIOS Setup Standard CMOS Features AMIBIOS SETUP - STANDARD CMOS SETUP ( C ) 1999 American Megatrends, Inc. All Rights Reserved Date (mm/dd/yyyy) : Fri Mar 16, 2001 Time (hh/mm/ss) : 14:44:35 TYPE SIZE CYLS HEAD PRECOMP LANDZ SECTOR MODE Pri Master : Auto Pri Slave : Auto...
Page 28
GA-7VTXE/GA-7VTXH Motherboard Time The times format in <hour> <minute> <second>. The time is calculated base on the 24-hour military- time clock. For example, 1 p.m. is 13:00:00. Primary Master, Slave / Secondary Master, Slave The category identifies the types of hard disk from drive C to F that has been installed in the computer.
BIOS Setup Boot Sector Virus Protection If it is set to enable, the category will flash on the screen when there is any attempt to write to the boot sector or partition table of the hard disk drive. The system will halt and the following error message will appear in the mean time.
GA-7VTXE/GA-7VTXH Motherboard BIOS Features Setup AMIBIOS SETUP - BIOS FEATURES SETUP ( C ) 1999 American Megatrends, Inc. All Rights Reserved 1st Boot Device : Floppy 2nd Boot Device : IDE-0 3rd Boot Device : CDROM S.M.A.R.T. for Hard Disks...
BIOS Setup S.M.A.R.T. for Hard Disks Enabled Enable HDD S.M.A.R.T. Capability. Disabled Disable HDD S.M.A.R.T. Capability. (Default value) Boot Up Num-Lock Keypad is number keys. (Default value) Keypad is arrow keys. Floppy Drive Seek During POST, BIOS will determine the floppy disk drive installed is 40 or 80 tracks. 360 K type is 40 tracks 720 K, 1.2 M and 1.44 M are all 80 tracks.
GA-7VTXE/GA-7VTXH Motherboard Chipset Features Setup AMIBIOS SETUP - CHIPSET FEATURES SETUP ( C ) 1999 American Megatrends, Inc. All Rights Reserved Top Performance :Disabled Configure SDRAM by SPD :Enabled DRAM Frequency :100 SDRAM CAS# Latency SDRAM Command Rate :2T Command AGP Mode AGP Comp.
BIOS Setup DRAM Frequency 100MHz Set DRAM Frequency is 100MHz. (Default Value). 133MHz Set DRAM Frequency is 133MHz. Auto Set DRAM Frequency is Auto. SDRAM CAS# Latency For Fastest SDRAM DIMM module. (Default Value). For Slower SDRAM DIMM module. SDRAM Command Rate 2T Command Set SDRAM Command Rate to 2T Command.
BIOS Setup VCore Voltage Normal Normal Function.(Default Value) +5.0% Set VCore voltage to +5.0%. +7.5% Set VCore voltage to +7.5%. +10.0% Set VCore voltage to +10.0%.
GA-7VTXE/GA-7VTXH Motherboard Power Management Setup AMIBIOS SETUP - POWER MANAGEMENT SETUP ( C ) 1999 American Megatrends, Inc. All Rights Reserved ACPI Standby State :S1/POS RTC Alarm Date USB Dev Wakeup From S3-S5 :Disabled RTC Alarm Hour Suspend Time Out(Minute)
Page 37
BIOS Setup Suspend Time Out (Minute.) Disabled Disabled Suspend Time Out Function. (Default Value) Enabled Suspend Time Out after 1min. Enabled Suspend Time Out after 2min. Enabled Suspend Time Out after 4min. Enabled Suspend Time Out after 8min. Enabled Suspend Time Out after 10min. Enabled Suspend Time Out after 20min.
GA-7VTXE/GA-7VTXH Motherboard Modem Ring On/Wake On LAN Disabled Disabled Resume On Ring / LAN. Enabled Enabled Resume On Ring / LAN. (Default Value) PME Event Wake Up Disabled Disable PME Event Wake Up. Enabled Enabled PME Event Wake Up. (Default Value) Keyboard Wakeup From S1(Suspend) Keyboard is able to Wakeup the system from S1(Suspend) state.
BIOS Setup PNP/PCI Configuration AMIBIOS SETUP - PNP/PCI CONFIGURATION ( C ) 1999 American Megatrends, Inc. All Rights Reserved VGA Boot From : AGP PCI Slot 1/5 IRQ Priority : Auto PCI Slot 2 IRQ Priority : Auto PCI Slot 3 IRQ Priority : Auto PCI Slot 4 IRQ Priority : Auto...
Page 40
GA-7VTXE/GA-7VTXH Motherboard The system will reserved IRQ7 for PCI slot 1/5, 2, 3, 4 device if no legacy ISA device using IRQ7. The system will reserved IRQ9 for PCI slot 1/5, 2, 3, 4 device if no legacy ISA device using IRQ9.
GA-7VTXE/GA-7VTXH Motherboard Load Optimized Defaults AMIBIOS SIMPLE SETUP UTILITY - VERSION 1.24e (C) 1999 American Megatrends, Inc. All Rights Reserved STANDARD CMOS SETUP INTEGRATED PERIPHERALS BIOS FEATURES SETUP HARDWARE MONITOR & MISC SETUP CHIPSET FEATURES SETUP SUPERVISOR PASSWORD POWER MANAGEMENT SETUP...
BIOS Setup Integrated Peripherals AMIBIOS SETUP - INTEGRATED PERIPHERALS ( C ) 1999 American Megatrends, Inc. All Rights Reserved OnBoard FDC :Auto OnBoard Serial Port 1 :Auto OnBoard Serial Port 2 :Auto Serial Port2 Mode :Normal OnBoard Parallel Port :Auto Parallel Port Mode :ECP Parallel Port IRQ...
GA-7VTXE/GA-7VTXH Motherboard Onboard Serial Port 2 Auto BIOS will automatically setup the port 2 address (Default Value). 3F8/COM1 Enable onboard Serial port 2 and address is 3F8. 2F8/COM2 Enable onboard Serial port 2 and address is 2F8. 3E8/COM3 Enable onboard Serial port 2 and address is 3E8.
BIOS Setup Parallel Port IRQ Set Parallel Port IRQ is 7. Auto Set Auto to parallel Port IRQ DMA Channel. . (Default Value). Set Parallel Port IRQ is 5. Parallel Port DMA Auto Set Auto to parallel port mode DMA Channel. . (Default Value). Set Parallel Port DMA is 3.
BIOS Setup Set Supervisor / User Password When you select this function, the following message will appear at the center of the screen to assist you in creating a password. AMIBIOS SIMPLE SETUP UTILITY - VERSION 1.24e (C) 1999 American Megatrends, Inc. All Rights Reserved STANDARD CMOS SETUP INTEGRATED PERIPHERALS BIOS FEATURES SETUP...
GA-7VTXE/GA-7VTXH Motherboard IDE HDD Auto Detection AMIBIOS SETUP - STANDARD CMOS SETUP ( C ) 1999 American Megatrends, Inc. All Rights Reserved Date (mm/dd/yyyy) : Fri Mar 16, 2001 Time (hh/mm/ss) : 14:44:35 TYPE SIZE CYLS HEAD PRECOMP LANDZ SECTOR MODE...
BIOS Setup Save & Exit Setup AMIBIOS SIMPLE SETUP UTILITY - VERSION 1.24e (C) 1999 American Megatrends, Inc. All Rights Reserved STANDARD CMOS SETUP INTEGRATED PERIPHERALS BIOS FEATURES SETUP HARDWARE MONITOR & MISC SETUP CHIPSET FEATURES SETUP SUPERVISOR PASSWORD POWER MANAGEMENT SETUP USER PASSWORD Save to CMOS and EXIT (Y/N)? Y PNP / PCI CONFIGURATION...
GA-7VTXE/GA-7VTXH Motherboard Exit Without Saving AMIBIOS SIMPLE SETUP UTILITY - VERSION 1.24e (C) 1999 American Megatrends, Inc. All Rights Reserved STANDARD CMOS SETUP INTEGRATED PERIPHERALS BIOS FEATURES SETUP HARDWARE MONITOR & MISC SETUP CHIPSET FEATURES SETUP SUPERVISOR PASSWORD POWER MANAGEMENT SETUP...
GA-7VTXE/GA-7VTXH Motherboard Dual BIOS Introduction A. What is Dual BIOS Technology? Dual BIOS means that there are two system BIOS (ROM) on the motherboard, one is the Main BIOS and the other is Backup BIOS. Under the normal circumstances, the system works on the Main BIOS.
Page 53
Technical Reference b. AMI Dual BIOS Flash ROM Programming Utility AMI Dual BIOS Flash ROM Programming Utility V1.02 Boot From..........Main BIOS Main ROM Type..........SST 39SF020 Backup ROM Type..........SST 39SF020 Wide Range Protection Disable Boot From MainBIOS Auto Recovery Enable Halt On Error Disable Copy Main ROM Data to Backup Load Default Settings...
Page 54
GA-7VTXE/GA-7VTXH Motherboard Boot From : Main BIOS (Default), Backup BIOS Status 1: The user can set to boot from main BIOS or Backup BIOS. Auto Recovery : Enabled(Default), Disabled When one of the Main BIOS or Backup BIOS occurs checksum failure, the working BIOS will automatically recover the BIOS of checksum failure.
Page 55
Technical Reference D. How to use Q-Flash? Load BIOS From Floppy In the A:drive, insert the "BIOS" diskette, then Press Enter to Run. Input BIOS file name in the text box. Press "Enter". Load XXXX.XX Where XXX.XX is name of the BIOS file. Are you sure to COPY BIOS? [Enter] to Continue Or [Esc] to abort..
Page 56
DualBIOS Technology FAQ GIGABYTE Technology is pleased to introduce DualBIOS technology, a hot spare for your system BIOS. This newest “Value-added” feature, in a long series of innovations from GIGABYTE, is available on this motherboard. Future GIGABYTE motherboards will also incorporate this innovation.
Page 57
Technical Reference I. Q: What is DualBIOS technology? Answer: DualBIOS technology is a patented technology from Giga-Byte Technology. The concept of this technology is based on the redundancy and fault tolerance theory. DualBIOS technology simply means there are two system BIOSes (ROM) integrated onto the motherboard. One is a main BIOS, and the other is a backup BIOS.
Page 58
GA-7VTXE/GA-7VTXH Motherboard III. Q: How does DualBIOS technology work? Answer: DualBIOS technology provides a wide range of protection during the boot up procedure. It protects your BIOS during system POST, ESCD update, and even all the way to PNP detection/assignment.
Page 59
Technical Reference 2. During or after a BIOS upgrade, if DualBIOS detects that the main BIOS is corrupt, the backup BIOS will take over the boot-up process automatically. Moreover, it will verify the main and backup BIOS checksums when booting-up. DualBIOS technology examines the checksum of the main and backup BIOS while the system is powered on to guarantee your BIOS operates properly.
GA-7VTXE/GA-7VTXH Motherboard Four Speaker & SPDIF Introduction(For GA-7VTXH Only) Four Speaker Introduction A. What is Four Speaker? The Creative CT5880 audio chip can support up to 4 speaker output. If you select “Four speaker out”, Line In will be reconfigured as another line out to support a second pair of speakers.
Page 61
Technical Reference Microsoft Windows Me setup procedure: Go to “Control Panel” and double click “Sounds and Multimedia”. Select “Audio” Page, and click “Advanced” button. Select “Quadraphonic Speakers” and click ok. C. Four Speaker Application The four speaker function will only be supported in application softwares that use Microsoft DirectX and Creative EAX, for example, the game titles, software DVD player and MP3 player.
GA-7VTXE/GA-7VTXH Motherboard SPDIF Introduction A. What is SPDIF? The SPDIF output is capable of providing digital signal to AC3 decoder which can support upto 5.1 speakers. B. How to use SPDIF? Click your mouse right button in “My Computer” and select the “Properties” item.
Page 63
Technical Reference Click “Settings” item and select the “Output Mode” item. Click “Digital” item, Line Out will be reconfigure to SPDIF Out. Recommend you to select “Autosense”, It will automatically detect the type (mono or stereo) of the audio connector that you plug into Line Out audio jack, then configure Line Out to either SPDIF or Speaker accordingly.
GA-7VTXE/GA-7VTXH Motherboard @ BIOS Introduction Gigabyte announces @ BIOS Windows BIOS live update utility Have you ever updated BIOS by yourself? Or like many other people, you just know what BIOS is, but always hesitate to update it? Because you think updating newest BIOS is unnecessary and actually you don’t know how to update it.
Technical Reference Easy TuneIII Introduction Gigabyte announces EasyTuneIII Windows overdrive utility “Overdrive” might be one of the most common issues in computer field. But have many users ever tried it? The answer is probably “no”. Because “overdrive” is thought to be very difficult and includes a lot of technical know-how, sometimes “over- drive”...
GA-7VTXE/GA-7VTXH Motherboard Revision History Chapter 5 Appendix Picture below are shown in Windows ME (VUCD driver version 1.81) Appendix A: VIA 4 in 1 Service Pack Driver Installation A. VIA 4 in 1 Service Pack Driver Utility: Insert the driver CD-title that came with your motherboard into your CD-ROM driver, the driver CD-title will auto start and show the installation guide.
Page 68
Appendix B: AC97 Sound Chipset Driver Revision History "AC'97 Audio Driver" under Windows ME will auto install. Appendix C: Creative CT5880 Chipset Driver Installation (Only for GA-7VTXH) Revision History Insert the driver CD-title that came with your motherboard into your CD-ROM driver, the driver CD-title will auto start and show the installation guide.
Page 71
Appendix Please base on your actual requirement, select “Yes” or “No” accordingly. 5.Click "Next". 6.Click "Finish" to restart computer.
Page 72
GA-7VTXE/GA-7VTXH Motherboard Appendix D: RealTek 8139/8100 Network Driver (Only for GA-7VTXH) Revision History "RealTek 8139/8100 Network Driver" under Windows ME will auto install. If you would like to install LAN driver, please refer to attached README.txt file for detail instruction. Please install the driver through CD-ROM by the path D:\Network\Rtl (This manual assumes that your CD-ROM device drive letter is D:).
Page 73
Appendix Appendix E: EasyTuneIII Utilities Installation Revision History Insert the driver CD-title that came with your motherboard into your CD-ROM driver, the driver CD-title will auto start and show the installation guide. If not, please double click the CD-ROM device icon in "My computer", and execute the setup.exe.
Page 75
Appendix Appendix F: BIOS Flash Procedure BIOS update procedure: If your OS is Win9X, we recommend that you used Gigabyte @BIOS Program to flash BIOS. 2.Click "@BIOS Writer Utility Press "Tools" icon. v1.08e". 1.Click "Gigabyte Utilities". Click here. Click " ". Methods and steps: I.
Page 76
GA-7VTXE/GA-7VTXH Motherboard II. Update BIOS NOT through Internet: a. Do not click "Internet Update" icon b. Click "Update New BIOS" c. Please select "All Files" in dialog box while opening the old file. d. Please search for BIOS unzip file, downloading from internet or any other methods (such as: 8ITXR.F3).
Page 77
Appendix We use GA-8ITXR motherboard and Flash841 BIOS flash utility as example. Please flash the BIOS according to the following procedures if you are now under the DOS mode. Flash BIOS Procedure: STEP 1: (1) Please make sure you have set "Auto" for BIOS Setup (BIOS Flash Protection). For more detail please refer to page 31.
Page 78
GA-7VTXE/GA-7VTXH Motherboard (2) Select the "Quick (erase)" for Format Type, and pick both "Display summary when finished" and "Copy system files", after that press "Start". That will format the floppy and transfer the needed system files to it. Beware: This procedure will erase all the prior data on that floppy, so please proceed accordingly.
Page 79
Appendix STEP 3: Download BIOS and BIOS utility program. (1) Please go to Gigabyte website http://www.gigabyte.com.tw/chinese-web/index.html, and click "Support". (2) From Support zone, click the "Motherboards BIOS & Drivers".
Page 80
GA-7VTXE/GA-7VTXH Motherboard (3) Choose an appropriate model name in accordance with this user's manual. Please select GA- 8ITXR by Model or Chipset optional menu to obtain BIOS flash files. (4) Select an appropriate BIOS version (For example: F3), and click to download the file. It will pop...
Page 81
Appendix (5) At this time the screen shows the following picture, please click "Extract" button to unzip the files. (6) Please extract the download files into the clean bootable floppy disk A mentioned in STEP 2, and press "Extract".
Page 82
GA-7VTXE/GA-7VTXH Motherboard STEP 4: Make sure the system will boot from the floppy disk. (1) Insert the floppy disk (contains bootable program and unzip file) into the floppy drive A. Then, restart the system. The system will boot from the floppy disk. Please press <DEL> key to enter BIOS setup main menu when system is boot up.
Page 83
Appendix (3) Press "Enter" to enter "BIOS FEATURES SETUP" menu. Use the arrows to highlight the item "1st Boot Device", and then use the "Page Up" and "Page Down" keys to select "Floppy". AMIBIOS SETUP - BIOS FEATURES SETUP ( C ) 2001 American Megatrends, Inc. All Rights Reserved BIOS Flash Protection : Auto 1st Boot Device...
Page 84
GA-7VTXE/GA-7VTXH Motherboard STEP 5: BIOS flashing. (1) After the system boot from floppy disk, type "A:\> dir/w" and press "Enter" to check the entire files in floppy A. Then type the "BIOS flash utility" and "BIOS file" after A:\>. In this case you have to type "A:\>...
Page 85
Appendix (3) It will pop up a screen and asks "Are you sure to flash the BIOS?" Press [Enter] to continue the procedure, or press [ESC] to quit. Beware: Please do not turn off the system while you are upgrading BIOS. It will render your BIOS corrupted and system totally inoperative.
Page 86
GA-7VTXE/GA-7VTXH Motherboard STEP 6: Load BIOS defaults. Normally the system redetects all devices after BIOS has been upgraded. Therefore, we highly recommend reloading the BIOS defaults after BIOS has been upgraded. This important step resets everything after the flash. (1) Take out the floppy diskette from floppy drive, and then restart the system. The boot up screen will indicate your motherboard model and current BIOS version.
Page 87
Appendix (3) Use the arrows to highlight the item "SAVE & EXIT SETUP" and press "Enter". System will ask "SAVE to CMOS and EXIT (Y/N)?" Press "Y" and "Enter" keys to confirm. Now the system will reboot automatically, the new BIOS setting will be taken effect next boot-up. AMIBIOS SIMPLE SETUP UTILITY - VERSION 2.00 (C) 2001 American Megatrends, Inc.
Page 88
GA-7VTXE/GA-7VTXH Motherboard Appendix G: Acronyms Acronyms Meaning ACPI Advanced Configuration and Power Interface Advanced Power Management Accelerated Graphics Port Audio Modem Riser Advanced Communications Riser BIOS Basic Input / Output System Central Processing Unit CMOS Complementary Metal Oxide Semiconductor CRIMM...
Page 89
Appendix Acronyms Meaning Logical Block Addressing Light Emitting Diode Megahertz MIDI Musical Interface Digital Interface Memory Translator Hub Memory Protocol Translator Network Interface Card Operating System Original Equipment Manufacturer PCI A.G.P. Controller POST Power-On Self Test Peripheral Component Interconnect RIMM Rambus in-line Memory Module Special Circumstance Instructions SECC...
Puent, CA 91744 Phone/Fax No: (818) 854-9338/ (818) 854-9339 hereby declares that the product Product Name: Motherboard GA-7VTXE/GA-7VTXH Model Number: Conforms to the following specifications: FCC Part 15, Subpart B, Section 15.107(a) and Section 15.109(a), Class B Digital Device Supplementary Information: This device complies with part 15 of the FCC Rules.
Page 92
Ausschlager Weg 41, 1F, 20537 Hamburg, Germany declare that the product ( description of the apparatus, system, installation to which it refers) Mother Board GA-7VTXE/GA-7VTXH is in conformity with (reference to the specification under which conformity is declared) in accordance with 89/336 EEC-EMC Directive...
