Gigabyte GA-7VTX-P User Manual

Amd athlon/duron socket a processor motherboard

Advertisement

Quick Links

DECLARATION OF CONFORMITY
Per FCC Part 2 Section 2. 1077(a)
Responsible Party Name: G.B.T. INC.
Address: 18305 Valley Blvd., Suite#A
LA Puent, CA 91744
Phone/Fax No: (818) 854-9338/ (818) 854-9339
hereby declares that the product
Product Name:
Mother Board
Model Number:
GA-7VTX-P
Conforms to the following specifications:
FCC Part 15, Subpart B, Section 15.107(a) and Section 15.109(a),
Class B Digital Device
Supplementary Information:
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions:
(1)
This device may not cause harmful
and
(2)
this device must accept any inference received, including
that may cause undesired operation.
Representative Person's Name:
ERIC LU
Eric Lu
Signature:
Date:
Sep. 26, 2001
determined by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:
-Reorient or relocate the receiving antenna
-Move the equipment away from the receiver
-Plug the equipment into an outlet on a circuit different from that to which
the receiver is connected
-Consult the dealer or an experienced radio/television technician for
additional suggestions
You are cautioned that any change or modifications to the equipment not
expressly approve by the party responsible for compliance could void Your
authority to operate such equipment.
This device complies with Part 15 of the FCC Rules. Operation is subjected to
the following two conditions 1) this device may not cause harmful interference
and 2) this device must accept any interference received, including interference
that may cause undesired operation.
FCC Compliance Statement:
This equipment has been tested and found to
comply with limits for a Class B digital device ,
pursuant to Part 15 of the FCC rules. These
limits are designed to provide reasonable
protection
against
harmful
residential
installations.
generates,
uses,
and
frequency energy, and if not installed and used
in accordance with the instructions, may cause
harmful interference to radio communications.
However, there is no guarantee that interference
will not occur in a particular installation. If this
equipment does cause interference to radio or
television equipment reception, which can be
interference
in
This
equipment
can
radiate
radio

Advertisement

Table of Contents
loading

Summary of Contents for Gigabyte GA-7VTX-P

  • Page 1 Product Name: Mother Board generates, Model Number: GA-7VTX-P frequency energy, and if not installed and used Conforms to the following specifications: FCC Part 15, Subpart B, Section 15.107(a) and Section 15.109(a), in accordance with the instructions, may cause...
  • Page 2: Declaration Of Conformity

    EN 60335 Safety of household and similar electrical appliances Manufacturer/Importer Date : Sep. 26, 2001 (Stamp) (full address) GA-7VTX-P EN 61000-3-2* Disturbances in supply systems caused EN60555-2 by household appliances and similar electrical equipment “Harmonics” EN61000-3-3* Disturbances in supply systems caused...
  • Page 3 7VTX-P AMD Athlon /Duron Socket A Processor Motherboard USER'S MANUAL AMD Athlon /Duron Socket A Processor Motherboard REV. 1.0 First Edition 12ME-7VTXP-1001...
  • Page 5 How This Manual Is Organized This manual is divided into the following sections: 1) Revision History 2) Item Checklist 3) Features 4) Installation Guide 5) Block Diagram 6) Suspend to RAM & Dual BIOS 7) Four Speaker & SPDIF 8) @BIOS &...
  • Page 7: Table Of Contents

    Table Of Content Revision History Item Checklist Summary of Features 7VTX-P Motherboard Layout Installation Guide Page Index for CPU Speed Setup / Connectors / Panel and Jumper Definition Block Diagram Suspend to RAM Installation Dual BIOS Introduction Four Speaker & SPDIF Introduction @BIOS Introduction EasyTuneIII...
  • Page 8: Revision History

    7VTX-P Motherboard Revision History Revision Revision Note Initial release of the 7VTX-P motherboard user’s manual. The author assumes no responsibility for any errors or omissions that may appear in this document nor does the author make a commitment to update the information contained herein. Third-party brands and names are the property of their respective owners.
  • Page 9: Item Checklist

    Item Checklist Item Checklist The 7VTX-P motherboard Cable for IDE / floppy device Diskettes or CD for motherboard driver & utility 7VTX-P user’s manual...
  • Page 10: Summary Of Features

    7VTX-P Motherboard Summary Of Features Form Factor 31.1 cm x 25.3 cm ATX size form factor, 4 layers PCB. AMD Athlon 128K L1 & 256K/64K L2 cache on die Supports 500MHz ~ 1.2GHz+ and faster Chipset VIA Chipset consisting of: KT266A Memory/AGP/PCI Controller(PAC) VT8233 Integrated Peripheral Controller (PSIPC) Clock Generator...
  • Page 11: Mouse Interface

    Hardware Monitor CPU/System fan revolution detect CPU/System temperature detect System voltage detect (Vcore,VDD ,Vcc,+12V)  PS/2 Connector PS/2 BIOS Licensed AMI BIOS, 2M bit flash ROM Support Dual BIOS Additional Features Support Wake-On-LAN (WOL)/ Wake-On-Ring (WOR) Support Internal / External Modem Ring On Support PS/2, KB/Mouse Power On.
  • Page 12: 7Vtx-P Motherboard Layout

    7VTX-P Motherboard 7VTX-P Motherboard Layout KBMS_ PS/2 CK_RATIO Socket A RUSB_ON NB FAN TELE AGP_OV FMIC_EN AGP PRO AMR_EN1 AMR_EN2 PCI 1 PCI 2 IT8705 PCI 3 PCI 4 CT5880 PCI 5 CPU_FAN KT266A 7VTX-P APG_12V AMR_USB2 AMR_USB1 AGP_USB1 AGP_USB2 VT8233 CLK SW Main...
  • Page 13: Installation Guide

    Installation Guide Getting Started WARNING! Computer motherboards and expansion cards contain very delicate Integrated Circuit (IC) chips. To protect them against damage from static electricity, you should follow some precautions whenever you work on your computer. Unplug your computer when working on the inside.
  • Page 14 7VTX-P Motherboard To set up your computer, you must complete the following steps: Step 1 - Set system jumpers Step 2- Install the Central Processing Unit (CPU) Step 3-Install memory modules Step 4-Install expansion cards Step 5-Connect ribbon cables, cabinet wires, and power supply Step 6-Set up BIOS software Step 7-Install supporting software tools STEP 1...
  • Page 15 CPU Speed Setup The CPU frequency can be switched by adjusting CLK_SW. (The frequency ratio depend on CPU). CLK_SW Select the CPU Speed 100MHz -170MHz by below table. *We recommend you to setup your system speed by your CPU type. CK_RATIO: Frequency Override O:ON, X:OFF *We recommend you to setup your system speed by Auto.
  • Page 16 7VTX-P Motherboard CPU Installation Please make sure the CPU should be supported to the motherboard. CPU Top View Socket Actuation Lever 1.Pull the lever out and lift it up. CPU Heat Sink Installation: Beware: Please check that the heat sink is in good contact with the CPU before you turn on your system.
  • Page 17 Installation Guide 3.Align CPU and insert it 4.Use compliant fan approved by AMD. (Please refer to your heatsink installation manual for application of thermal grease to provide better heat conduction between your CPU and heatsink.) 5.Hook one end of the cooler bracket to the CPU socket. 6.
  • Page 18 7VTX-P Motherboard Memory Installation The motherboard has 3 dual DDR inline memory module (DIMM) sockets. The BIOS will automatically detects memory type and size. To install the memory module, just push it vertically into the DIMM Slot .The DIMM module can only fit in one direction due to the notch. Memory size can vary between sockets.
  • Page 19 Total Memory Sizes With Unbuffered DDR DIMMS Devices used on 1 DIMM DIMM x64/x72 64 Mbit 128 MBytes (2Mx8x4 banks) 64 Mbit 64 MBytes (1Mx16x4 banks) 128 Mbit 256 MBytes (4Mx8x4 banks) 128 Mbit 128 MBytes (2Mx16x4 banks) 256 Mbit 512 MBytes (8Mx8x4 banks) 256 Mbit...
  • Page 20: Ddr Introduction

    7VTX-P Motherboard DDR Introduction Established on the existing SDRAM industry infrastructure, DDR (Double Date Rate) memory is a high performance and cost-effective solution that allows easy adoption for memory vendors, OEMs and system integrators. DDR memory is a sensible evolutionary solution for the PC industry that builds on the existing SDRAM infrastructure, yet makes awesome advances in solving the system performance bottleneck by doubling the memory bandwidth.
  • Page 21: Page Index For Cpu Speed Setup / Connectors / Panel And Jumper

    Page Index for CPU Speed Setup / Connectors / Panel and Jumper Definition CPU Speed Setup Connectors ATX Power COM A / COM B / LPT Port PS/2 Keyboard & PS/2 Mouse Connector) USB (USB Connector) Front USB2/USB3(Front USB2/USB3 Connector) Floppy Port Game &...
  • Page 22 7VTX-P Motherboard AGP_OV(AGP Voltage Override AGP_12V(Power for AGP Pro) CI(Case Open) AMR_USB1/AMR_USB2(AMR_USB)[Optional] AGP_USB1/AGP_USB2(AGP_USB)[Optional] STR_EN(STR Selection) RAM_OV(RAM Over voltage) S_IRQ(Serial IRQ) BAT1(Battery) P.33 P.33 P.34 P.34 P.35 P.35 P.36 P.36 P.37...
  • Page 23: Lpt Port

    Connectors ATX Power Please note: AC power cord should only be connected to your power supply unit after ATX power cable and other related devices are firmly connected to the mainboard. COM A / COM B / LPT Port Please note: This mainboard supports 2 standard COM ports and 1 LPT port.
  • Page 24: Definition

    7VTX-P Motherboard PS/2 Keyboard & PS/2 Mouse Connector PS/2 Keyboard Please note: This mainboard supports standard PS/2 keyboard and PS/2 mouse interface connector. USB : USB Connector Please note: Before you connect your device(s) into USB connector(s), please make sure your device(s) has a standard USB interface, like USB keyboard, mouse, scanner, zip, buzzer…...
  • Page 25: Floppy Port

    Front USB 2 / USB 3: USB 2 / USB 3 Connector USB 2 Please note: Be careful with the polarity of the front panel USB connector. Check the pin assignment while you connect the front panel USB cable. Please contact your nearest dealer for optional front panel USB cable.
  • Page 26 7VTX-P Motherboard Game & Audio Port Please note: Line Out 1: Line Out or SPDIF (The SPDIF output is capable of providing digital audio to external speakers or compressed AC3 data to an external Dolby digital decoder). To enable SPDIF, simply insert SPDIF connector into Line Out1.
  • Page 27 CD_IN: CD Audio Line In AUX _IN: AUXIN (Optional) Connectors Pin No. Definition CD-L CD-R Pin No. Definition AUX-L AUX-R...
  • Page 28 7VTX-P Motherboard TELE: TEL (The connector is for internal modem card with voice connector) (Optional) WOR: Ring Power On (Internal Modem Card Wake Up) Pin No. Definition Signal-In Signal-Out Pin No. Definition Signal...
  • Page 29 SMB: External SMBUS Device Connector (Optional) SYS_FAN: System Fan Connector Pin No. Definition SMB CLK SMB DATA Pin No. Definition Control +12V SENSE Connectors...
  • Page 30 7VTX-P Motherboard PWR_FAN: Power Fan Connector CPU_FAN: CPU Fan Connector Please note: A proper installation of the CPU cooler is essential to prevent the CPU from running under abnormal condition or damaged by overheating. Pin No. Definition Control +12V SENSE Pin No.
  • Page 31 WOL: Wake On LAN RAM LED Conn. & LED1: RAM LED Connector & LED1 (RAM LED Connector is Optional) Please note: Do not remove memory modules while RAM LED is on. It might cause short or other unexpected damages due to the 2.5V stand by voltage. Remove memory modules only when STR function is disabled by jumper and AC Power cord is disconnected.
  • Page 32 7VTX-P Motherboard IR / CIR Connector Please note: Please make sure that pin 1 on the IR device is align with pin 1 of the connector. To enable the IR/CIR function on the board, you are required to purchase an option IR/CIR module. For detail information please contact your authorized Giga-Byte distributor.
  • Page 33 SCR: Smart Card Reader Header (Optional) Please note: This MB supports smart card reader. To enable smart card reader function an optional smart card reader box is required. Please contact your autherized distributor. Remove Floppy B before you plug smart card reader cable, you can not use smart card reader and Floppy B simultaneously.
  • Page 34 7VTX-P Motherboard Panel and Jumper Definition F_ Panel: 2x11 Pins Jumper GN (Green Switch) Open: Normal Operation Close: Entering Green Mode GD (Green LED) Pin 1: LED anode(+) Pin 2: LED cathode( ) HD (IDE Hard Disk Active LED) Pin 1: LED anode(+) Pin 2: LED cathode( ) SPK (Speaker Connector) Pin 1: VCC(+)
  • Page 35 CLR_CMOS : Clear CMOS Function Please note: You may clear the CMOS data to its default values by this jumper. BUZ_EN: Internal Buzzer Connector (Optional) Panel and Jumper Definition Clear CMOS Disable (Default) Pin No. Definition 1-2 Close Enable Clear CMOS Function 2-3 Close Disable Clear CMOS Function (Default)
  • Page 36 7VTX-P Motherboard BIOS_WP: BIOS Write Protect Function (Optional) Please note: To flash/upgrade BIOS on this MB BIOS_WP jumper must be set to 2-3 close, We recommend BIOS_WP jumper to be set to 1-2 close”, whenever user is not try to flash/upgrade the BIOS. KBMS_ON : Keyboard Power On Selection Please Note: PS/2 keyboard power on, enable user to power on his computer by press the any key/keys on the PS/2 keyboard.
  • Page 37 Guardian: FAN Detect (Optional) FUSB_ON: Front USB Wake Up USB 3 USB 2 Please note: (If you want to use “USB Dev Wakeup From S3~S5” function, you have to set the BIOS setting “USB Dev Wakeup from S3~S5” enabled, and the jumper “FUSB_ON &...
  • Page 38 7VTX-P Motherboard RUSB_ON: Rear USB Wake Up USB 1 Please note: (If you want to use “USB Dev Wakeup From S3~S5” function, you have to set the BIOS setting “USB Dev Wakeup From S3~S5” enabled, and the jumper “RUSB_ON & STR_EN “enabled) *(Power on the computer and as soon as memory counting starts, press <Del>.
  • Page 39 AMR_EN1 & AMR_EN2: AMR Selection (Optional) Please note: 7VTX: If M/B has hardware audio (CT5880), your modem riser has been set to “Primary” automatically. No Jumpers AMR_EN1 & AMR_EN2 for 7VTX. 7VTX: AMR_EN1 & AMR_EN2: 2-3 close: If you don’t use onboard software audio, your audio/modem riser must be “Primary”.
  • Page 40 7VTX-P Motherboard AGP_OV: AGP Voltage Override AGP_12V: Power for AGP Pro 1.5V (Default) 1.6V 1.7V Pin No. Definition +12V...
  • Page 41 CI: Case Open AMR_USB1, AMR_USB2 : AMR_USB (Optional) Panel and Jumper Definition Pin No. Definition Signal AMR_USB2 AMR_USB1 USB Select AMR_USB1 AMR_USB2 AMR_USB 1-2 close 1-2 close USB Port5 2-3 close 2-3 close (Default)
  • Page 42 7VTX-P Motherboard AGP_USB1, AGP_USB2: AGP_USB (Optional) STR_EN: STR Selection 1-2 close 2-3 close STR Disabled (Default) AGP_USB1 AGP_USB2 USB Select AGP_USB1 AGP_USB2 AGP_USB 1-2 close 1-2 close USB Port4 2-3 close 2-3 close (Default) Disabled Enabled (Default) Pin No. Definition STR Enabled...
  • Page 43 RAM_OV: RAM Overvoltage S_IRQ: Serial IRQ (Optional) Panel and Jumper Definition O:ON, X:OFF 2.5V (Default) 2.6V 2.7V Pin No. Definition Signal...
  • Page 44 7VTX-P Motherboard BAT1 : Battery CAUTION Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type recommended by the manufacturer. Dispose of used batteries according to the manufacturer’s instructions.
  • Page 45: Block Diagram

    Block Diagram AMD-K7 AGP Pro 2X/4X AGPCLK (66MHz) KT266A PCI Bus 33MHz Game Port CT5880 VT8233 AC97 CODEC ITE 8705F L-OUT L-IN 5 PCI PS/2 Floppy PCI (33MHz) AGPCLK (66MHz) PCI (33MHz) 48MHz 14.318MHz 33MHz Block Diagram CPUCLK (100 /133 MHz) System Bus 100/133MHz 2.5V DDR SDRAM 100 / 133MHz...
  • Page 46: Suspend To Ram Installation

    7VTX-P Motherboard Suspend To RAM Installation A.1 Introduce STR function: Suspend-to-RAM (STR) is a Windows 98 ACPI sleep mode function. When recovering from STR (S3) sleep mode, the system is able, in just a few seconds, to retrieve the last “state” of the system before it went to sleep and recover to that state.
  • Page 47 Step 2: (If you want to use STR Function, please set jumper to 1-2 closed.) 1-2 close 2-3 close STR Disabled (Default) Step 3: Power on the computer and as soon as memory counting starts, press <Del>. You will enter BIOS Setup.
  • Page 48 7VTX-P Motherboard A.3 How to put your system into STR mode? There are two ways to accomplish this: Choose the “Stand by” item in the “Shut Down Windows” area. A. Press the “Start” button and then select “Shut Down” B. Choose the “Stand by” item and press “OK”...
  • Page 49 Suspend To RAM Installation Define the system ”power on” button to initiate STR sleep mode: A. Double click “My Computer” and then “Control Panel” B. Double click the “ Power Management” item.
  • Page 50 7VTX-P Motherboard C. Select the “Advanced” tab and “Standby” mode in Power Buttons. Step 4: Restart your computer to complete setup. Now when you want to enter STR sleep mode, just momentarily press the “Power on” button. A.4 How to recover from the STR sleep mode? There are five ways to “wake up”...
  • Page 51 A.5 Notices : In order for STR to function properly, several hardware and software requirements must be satisfied: Your ATX power supply must comply with the ATX 2.01 specification (provide more than 720 mA 5V Stand-By current). Your DDR must be PC-200 compliant. Jumper is provided to connect to the STR LED in your system chassis.
  • Page 52: Dual Bios Introduction

    7VTX-P Motherboard Dual BIOS Introduction What is Dual BIOS Technology? Dual BIOS means that there are two system BIOS (ROM) on the motherboard, one is the Main BIOS and the other is Backup BIOS. Under the normal circumstances, the system works on the Main BIOS.
  • Page 53 b. AMI Dual BIOS Flash ROM Programming Utility AMI Dual BIOS Flash ROM Programming Utility Boot From……………………….. Main BIOS Main ROM Type………………… SST 39SF020 Backup ROM Type……………… SST 39SF020 Wide Range Protection Boot From Auto Recovery Halt On Error Copy Main ROM Data to Backup Load Default Settings Save Settings to CMOS PgDn/PgUp:Modify(Enter:Run)
  • Page 54 7VTX-P Motherboard Boot From: Main BIOS (Default), Backup BIOS Status 1: The user can set to boot from main BIOS or Backup BIOS. Auto Recovery: Enabled (Default), Disabled When one of the Main BIOS or Backup BIOS occurs checksum failure, the working BIOS will automatically recover the BIOS of checksum failure.
  • Page 55 DualBIOS Technology FAQ GIGABYTE Technology is pleased to introduce DualBIOS technology, a hot spare for your system BIOS. This newest “Value-added” feature, in a long series of innovations from GIGABYTE, is available on GA-7VTX-P motherboard. Future GIGABYTE motherboards will also incorporate this innovation.
  • Page 56 7VTX-P Motherboard I. Q: What is DualBIOS technology? Answer: DualBIOS technology is a patented technology from Giga-Byte Technology. The concept of this technology is based on the redundancy and fault tolerance theory. DualBIOS simply means there are two system BIOSes (ROM) integrated onto the motherboard. One is a main BIOS, and the other is a backup BIOS.
  • Page 57 III. Q: How does DualBIOS technology work? Answer: 1. DualBIOS technology provides a wide range of protection during the boot up procedure. It protects your BIOS during system POST, ESCD update, and even all the way to PNP detection/assignment. 2. DualBIOS provides automatic recovery for the BIOS.
  • Page 58 7VTX-P Motherboard 2. During or after a BIOS upgrade, if DualBIOS backup BIOS will take over the boot-up process automatically. Moreover, it will verify the main and backup BIOS checksums when booting-up. DualBIOS checksum of the main and backup BIOS while the system is powered on to guarantee your BIOS operates properly.
  • Page 59: Four Speaker & Spdif Introduction

    Four Speaker & SPDIF Introduction Four Speaker Introduction What is Four Speaker? The Creative CT5880 audio chip can support up to 4 speaker output. If you select “Four speaker out”, Line In will be reconfigured as another line out to support a second pair of speakers.
  • Page 60 7VTX-P Motherboard c. Select “Four speaker” item. Microsoft Windows Me setup procedure: a. Go to “Control Panel” Double click “Sounds and Multimedia”.
  • Page 61 b. Select “Audio” Page, and click “Advanced” button. c. Select “Quadraphonic Speakers” and click ok. Click “Quadraphonic Speakers”. Four Speaker Application The four speaker function will only be supported in application softwares that use Microsoft DirectX and Creative EAX, for example, the game titles, software DVD player and MP3 player. Four Speaker &...
  • Page 62 7VTX-P Motherboard SPDIF Introduction What is SPDIF? The SPDIF output is capable of providing digital audio to external speakers or compressed AC3 data to an external Dolby digital decoder. How to use SPDIF? a. Click your mouse right button in “My Computer” and select the “Properties” item. b.
  • Page 63 Four Speaker & SPDIF Introduction c. Click “Sound, video and game controllers” item and select the “Creative Sound Blaster PCI128” item. d. Click “Settings” item and select the “Output Mode” item.
  • Page 64 7VTX-P Motherboard e. Click “Digital” item, Line Out will be reconfigure to SPDIF Out. f. Recommend you to select “Autosense”, It will automatically detect the type (mono or stereo) of the audio connector that you plug into Line Out audio jack, then configure Line Out to either SPDIF or Speaker accordingly.
  • Page 65: Bios Tm Introduction

    BIOS, just choose “Save Current BIOS” to save it first. You make a wise choice to use Gigabyte, and @BIOS update your BIOS smartly. You are now worry free from updating wrong BIOS, and capable to maintain and manage your BIOS easily.
  • Page 66 Click “Advanced Mode” to enjoy “sport drive” class overclocking. In “Advanced Mode”, one can change the system bus speed in small increments to get ultimate system performance. And no matter which mainboard is used, if it’s a Gigabyte’s product*, EasyTuneIII helps to perform the best of system.
  • Page 67: Page Index For Bios Setup

    Page Index for BIOS Setup The Main Menu Standard CMOS Setup BIOS Features Setup Chipset Features Setup Power Management Setup PNP/ PCI Configuration Load BIOS Defaults Load Setup Defaults Integrated Peripherals Hardware Monitor & MISC Setup Supervisor Password / User Password IDE HDD Auto Detection Save &...
  • Page 68: Entering Setup

    7VTX-P Motherboard BIOS Setup BIOS Setup is an overview of the BIOS Setup Program. The program that allows users to modify the basic system configuration. This type of information is stored in battery-backed CMOS RAM so that it retains the Setup information when the power is turned off. ENTERING SETUP Power ON the computer and press <Del>...
  • Page 69: Getting Help

    GETTING HELP Main Menu The on-line description of the highlighted setup function is displayed at the bottom of the screen. Status Page Setup Menu / Option Page Setup Menu Press F1 to pop up a small help window that describes the appropriate keys to use and the possible selections for the highlighted item.
  • Page 70 7VTX-P Motherboard Chipset Features Setup This setup page includes all the items of chipset special features. Power Management Setup This setup page includes all the items of Green function features. PnP/PCI Configurations This setup page includes all the configurations of PCI & PnP ISA resources. Load BIOS Defaults Bios Defaults indicates the value of the system parameter which the system would be in the safe configuration.
  • Page 71: Standard Cmos Setup

    Standard CMOS Setup The items in Standard CMOS Features Menu (Figure 2) are divided into 9 categories. Each category includes no, one or more than one setup items. Use the arrows to highlight the item and then use the <PgUp> or <PgDn> keys to select the value you want in each item. AMIBIOS SETUP –...
  • Page 72 7VTX-P Motherboard Time The times format in <hour> <minute> <second>. The time is calculated base on the 24-hour military-time clock. For example, 1 p.m. is 13:00:00. IDE Primary Master, Slave / Secondary Master, Slave The category identifies the types of hard disk from drive C to F that has been installed in the computer.
  • Page 73 Boot Sector Virus Protection If it is set to enable, the category will flash on the screen when there is any attempt to write to the boot sector or partition table of the hard disk drive. The system will halt and the following error message will appear in the mean time.
  • Page 74: Bios Features Setup

    7VTX-P Motherboard BIOS Features Setup AMIBIOS SETUP – BIOS FEATURES CMOS SETUP ( C ) 1999 American Megatrends, Inc. All Rights Reserved 1st Boot Device :Floppy 2nd Boot Device :IDE-0 3rd Boot Device :CDROM S.M.A.R.T for Hard Disks :Disabled BootUp Num-Lock Floppy Drive Seek :Disabled Password Check...
  • Page 75 S.M.A.R.T. for Hard Disks Enable Enable S.M.A.R.T. Hard for Disks. Disable Disable S.M.A.R.T. Hard for Disks. (Default Value) Boot Up Num-Lock Keypad is number keys. (Default Value) Keypad is arrow keys. Floppy Drive Seek During POST, BIOS will determine if the floppy disk drive installed is 40 or 80 tracks. 360 type is 40 tracks while 720 , 1.2 and 1.44 are all 80 tracks.
  • Page 76: Chipset Features Setup

    7VTX-P Motherboard Chipset Features Setup AMIBIOS SETUP –CHIPSET FEATURE CMOS SETUP ( C ) 1999 American Megatrends, Inc. All Rights Reserved Top Performance :Disabled Configure SDRAM by SPD :Enabled DRAM Frequency :100 SDRAM CAS# Latency SDRAM Command Rate :2T Command AGP Mode AGP Comp.
  • Page 77 SDRAM Command Rate 2T Command Set SDRAM Command Rate to 2T Command. (Default Value) 1T Command Set SDRAM Command Rate to 1T Command. AGP Mode Set AGP Mode is 4X. (Default Value) Set AGP Mode is 1X. Set AGP Mode is 2X. AGP Comp.
  • Page 78 7VTX-P Motherboard USB Controller Disabled Disable USB Controller function. USB Port 1&2 Enabled USB Port 1&2. USB Port 2&3 Enabled USB Port 2&3. Enabled USB Port 1&3. USB Port 1&3 USB1 Enabled USB Port 1. USB2 Enabled USB Port 2. USB3 Enabled USB Port 3.
  • Page 79: Power Management Setup

    Power Management Setup AMIBIOS SETUP –POWER MANAGEMENT SETUP ( C ) 1999 American Megatrends, Inc. All Rights Reserved ACPI Sleep Type :S1/POS USB Dev Wakeup From S3-S5 :Disabled Suspend Time Out(Minute) :Disabled IRQ3 :Monitor IRQ 4 :Monitor IRQ 5 :Ignore IRQ 7 :Monitor IRQ 9...
  • Page 80 7VTX-P Motherboard Suspend Time Out (Minute.) Disabled Disabled Suspend Time Out Function. (Default Value) Enabled Suspend Time Out after 1min. Enabled Suspend Time Out after 2min. Enabled Suspend Time Out after 4min. Enabled Suspend Time Out after 8min. Enabled Suspend Time Out after 10min. Enabled Suspend Time Out after 20min.
  • Page 81 Resume On KBC S1(Suspend) Keyboard is able to Wakeup the system from S1(Suspend) state. (Default value) S1/S3 Keyboard is able to Wakeup the system from S1/S3 state. S1/S3/S4/S5 Keyboard is able to Wakeup the system from S1/S3/S4/S5 state. Disabled Disabled Resume On KBC. Resume On PS/2 Mouse S1(Suspend) PS/2 Mouse is able to Wakeup the system from S1(Suspend) state.
  • Page 82 7VTX-P Motherboard PnP/PCI Configurations AMIBIOS SETUP –PNP/PCI CONFIGURATION SETUP ( C ) 1999 American Megatrends, Inc. All Rights Reserved VGA Boot From :PCI PCI Slot 1/5 IRQ Priority :Auto PCI Slot 2 IRQ Priority :Auto PCI Slot 3 IRQ Priority :Auto PCI Slot 4 IRQ Priority :Auto...
  • Page 83 The system will reserved IRQ7 for PCI slot 1 & 5 device if no legacy ISA device using IRQ7. The system will reserved IRQ9 for PCI slot 1 & 5 device if no legacy ISA device using IRQ9. The system will reserved IRQ10 for PCI slot 1 & 5 device if no legacy ISA device using IRQ10.
  • Page 84: Load Bios Defaults

    7VTX-P Motherboard Load BIOS Defaults AMIBIOS SIMPLE SETUP UTILITY-VERSION 1.24b ( C ) 1999 American Megatrends, Inc. All Rights Reserved STANDARD CMOS SETUP BIOS FEATURES SETUP CHIPSET FEATURES SETUP POWER MANAGEMENT SETUP PNP/PCI CONFIGURATION Load BIOS Defaults (Y/N) ? N LOAD BIOS DEFAULTS LOAD SETUP DEFAULTS ESC : Quit...
  • Page 85: Load Setup Defaults

    Load Setup Defaults AMIBIOS SIMPLE SETUP UTILITY-VERSION 1.24b ( C ) 1999 American Megatrends, Inc. All Rights Reserved STANDARD CMOS SETUP BIOS FEATURES SETUP CHIPSET FEATURES SETUP Load SETUP Defaults (Y/N) ? N POWER MANAGEMENT SETUP PNP/PCI CONFIGURATION LOAD BIOS DEFAULTS LOAD SETUP DEFAULTS ESC : Quit : Select Item...
  • Page 86: Integrated Peripherals

    7VTX-P Motherboard Integrated Peripherals AMIBIOS SETUP –INTEGRATED PERIPHERAL ( C ) 1999 American Megatrends, Inc. All Rights Reserved OnBoard FDC :Auto OnBoard Serial Port 1 :Auto OnBoard Serial Port 2 :Auto Serial Port2 Mode :Normal OnBoard CIR Port :Disabled CIR Port IRQ :N/A OnBoard Parallel Port :Auto...
  • Page 87 Onboard Serial Port 2 Auto BIOS will automatically setup the port 2 address (Default Value). 3F8/COM1 Enable onboard Serial port 2 and address is 3F8. 2F8/COM2 Enable onboard Serial port 2 and address is 2F8. 3E8/COM3 Enable onboard Serial port 2 and address is 3E8. 2E8/COM4 Enable onboard Serial port 2 and address is 2E8.
  • Page 88 7VTX-P Motherboard Parallel Port IRQ Set Parallel Port IRQ is 7. Auto Set Auto to parallel Port IRQ DMA Channel. . (Default Value). Set Parallel Port IRQ is 5. Parallel Port DMA Auto Set Auto to parallel port mode DMA Channel. . (Default Value). Set Parallel Port DMA is 3.
  • Page 89 Hardware Monitor& MISC Setup AMIBIOS SETUP –HARDWARE MONITOR & MISC Setup ( C ) 1999 American Megatrends, Inc. All Rights Reserved CPU Host Clock (Mhz) :By Jumper Reset Case Open Status Case Status :Open CPU Temp. :64°C/147°F :35°C/95°F System Temp. CPU Fan Speed :4560 RPM System Fan Speed...
  • Page 90: Set Supervisor / User Password

    7VTX-P Motherboard Set Supervisor / User Password When you select this function, the following message will appear at the center of the screen to assist you in creating a password. AMIBIOS SIMPLE SETUP UTILITY-VERSION 1.24b ( C ) 1999 American Megatrends, Inc. All Rights Reserved STANDARD CMOS SETUP BIOS FEATURES SETUP CHIPSET FEATURES SETUP...
  • Page 91: Ide Hdd Auto Detection

    IDE HDD AUTO Detection AMIBIOS SETUP – STANDARD CMOS SETUP ( C ) 1999 American Megatrends, Inc. All Rights Reserved Date (mm/dd/yyyy) : Tue Jan 25, 2000 Time (hh/mm/ss) : 10:36:24 TYPE SIZE CYLS HEAD PRECOMP LANDZ SECTOR MODE Pri Master : Not Installed Pri Slave : Not Installed Sec Master : Not Installed...
  • Page 92: Save & Exit Setup

    7VTX-P Motherboard Save & Exit Setup AMIBIOS SIMPLE SETUP UTILITY-VERSION 1.24b ( C ) 1999 American Megatrends, Inc. All Rights Reserved STANDARD CMOS SETUP BIOS FEATURES SETUP CHIPSET FEATURES SETUP POWER MANAGEMENT SETUP SAVE to CMOS and EXIT(Y/N)? Y PNP/PCI CONFIGURATION LOAD BIOS DEFAULTS LOAD SETUP DEFAULTS ESC : Quit...
  • Page 93: Exit Without Saving

    Exit Without Saving AMIBIOS SIMPLE SETUP UTILITY-VERSION 1.24b ( C ) 1999 American Megatrends, Inc. All Rights Reserved STANDARD CMOS SETUP BIOS FEATURES SETUP CHIPSET FEATURES SETUP POWER MANAGEMENT SETUP PNP/PCI CONFIGURATION Quit without Saving (Y/N)? N LOAD BIOS DEFAULTS LOAD SETUP DEFAULTS ESC : Quit : Select Item...
  • Page 94: Technical Support /Rma Sheet

    7VTX-P Motherboard Technical Support /RMA Sheet Customer/Country: Company: Contact Person: E-mail Add. : Model name/Lot Number: BIOS version: O.S./A.S.: Hardware Mfs. Model name Size: Configuration Memory Brand Video Card Audio Card CD-ROM / DVD-ROM Modem Network AMR / CNR Keyboard Mouse Power supply Other Device...
  • Page 95: Appendix

    Appendix Appendix A: VIA KT266A Chipsets Driver Installation Insert the support CD that came with your motherboard into your CD-ROM driver or double –click the CD driver icon in My Computer to bring up the screen. 1.Click “VIA 4in 1 Service Pack Driver”...
  • Page 96 7VTX-P Motherboard Appendix B: Creative Sound Driver Installation Insert the support CD that came with your motherboard into your CD-ROM driver or double –click the CD driver icon in My Computer to bring up the screen. Press “Audio” icon. 1.Click “Creative 5880 Sound Driver”. 3.Click “Yes”.
  • Page 97 5.Click “Next”. 7.Click”Next”. 8.Click “Finish” to complete setup. Appendix 6.Click here.
  • Page 98 7VTX-P Motherboard Appendix C: BIOS Flash Procedure BIOS update procedure: If your OS is Win9X, we recommend that you used Gigabyte @BIOS Program to flash BIOS. Press “Tools” icon. 1.Click “Gigabyte Utilities”. Click Here. Click “ ”. Methods and steps: I.
  • Page 99 In method I, if the BIOS file you need cannot be found in @BIOS server, please go onto Gigabyte's web site for downloading and updating it according to method II. d. Please note that any intercorruption during updating will cause system unbooted...
  • Page 100 Format a bootable system floppy diskette by the command “format a:/s” in command mode. Visit the Gigabyte website at http:// need and download it to your bootable floppy diskette. Insert the bootable diskette containing the BIOS file into the floppy diskette driver.
  • Page 101 Appendix D: Acronyms Acronyms Meaning ACPI Advanced Configuration and Power Interface Advanced Power Management Accelerated Graphics Port Audio Modem Riser Advanced Communications Riser BIOS Basic Input / Output System Central Processing Unit CMOS Complementary Metal Oxide Semiconductor CRIMM Continuity RIMM Communication and Networking Riser Direct Memory Access Desktop Management Interface...
  • Page 102 7VTX-P Motherboard Acronyms Meaning Original Equipment Manufacturer PCI A.G.P. Controller POST Power-On Self Test Peripheral Component Interconnect RIMM Rambus in-line Memory Module Special Circumstance Instructions SECC Single Edge Contact Cartridge SRAM Static Random Access Memory Symmetric Multi-Processing System Management Interrupt Universal Serial Bus Voltage ID...
