Tsf Turbo Commercial Storage Fan Heaters - Creda Heating Solution Brochure

TSF Turbo
Commercial storage fan heaters
"
Creda TSF Turbo storage
fan heaters provide
controlled output space
heating with maximum
economy and flexibility.
The heater retains up to 40% of its total
stored heat after 17 hours, allowing the
thermostatically controlled 2-speed
centrifugal fan to deliver rapid and
uniform heat.
Key features
• Smooth, rounded, modern appearance, compatible
with today's home and office décor
• TSF Turbo uses economy tariff electricity,
operating particularly well on special daytime
economy periods
• Available in 3.6kW, 4.8kW and 5.7kW models
• More controllable, providing heat quickly
when required
• In-built direct element for out of season heating
using day rate electricity
• Fanned heat is faster and more even in distribution,
particularly near ground level
• Easy to use manual controls for room thermostat
and economy charge
• Single or 3 phase installation capability
Product Selector
Model Reference
TSF24K 70369KS
TSF32K 70379KS
TSF42K 70389KS
"
User controls
• Charge input control
• Neon switch for fan
• Neon switch for direct acting element
• Heat output control
Rating Direct Acting
Element Load
3.6kW 0.7kW
4.8kW 1.1kW
5.7kW 1.5kW
+44 (0) 1733 456789
Electric storage
heating
Technical Specification
• Insulation - opacified silicaceous aerogel and
mineral fibre mat
• Storage Core - high density iron oxide compound
• Storage Elements - mineral insulated stainless
steel sheathed
• Protection - two level thermal safety overheat
• Supply - 230/240V AC single phase
Dimensions
Model
TSF24K
TSF32K
TSF42K
Charge Charge
Acceptance (7hrs) Acceptance (8hrs)
25.2kWh 28.8kWh
33.6kWh 38.4kWh
39.9kWh 45.6kWh
www.creda-heating.co.uk
Height A Width B Depth C
672mm 776mm 250mm
672mm 926mm 250mm
672mm 1076mm 250mm
Weight Number of
Core Bricks
137kg 18
176kg 24
215kg 30
25
