TPRIII NC
'No controls panel heaters'
TPRIII Thermostatic panel heater ranges
TPRIII M mechanical thermostat without timer
(500W - 2000W models).
TPRIII MT mechanical thermostat with 24hr timer
(500W - 2000W models).
TPRIII MT7 mechanical thermostat with 7 day timer
(available in 2000W model only).
Product Selector
Model Reference
No controls models
TPRIII 500NC 75 774300
TPRIII 750NC 75 774301
TPRIII 1000NC 75 774302
TPRIII 1250NC 75 774303
TPRIII 1500NC 75 774304
TPRIII 2000NC 75 774305
Advanced control
heating systems
TPRIII No controls panel heater range
TPRIII NC a range of panel heaters without any integral controls for use in applications
where external control of temperature and time programming is required.
Technical Specification
• Element - mineral-filled sheathed type
• Finish - white powder coated steel
• Protection - auto reset thermal cut-out
• IP rating - IPX4 (splashproof)
• Supply - 230/240V AC single phase
Dimensions
Loading Height A
0.5kW 430mm
0.75kW 430mm
1kW 430mm
1.25kW 430mm
1.5kW 430mm
2kW 430mm
+44 (0) 1733 456789 www.creda-heating.co.uk
Width B Depth C
450mm 108mm
620mm 108mm
620mm 108mm
690mm 108mm
690mm 108mm
860mm 108mm
Weight
4.8kg
6.2kg
6.2kg
6.6kg
6.6kg
8.0kg
