LIA 0608BWCF M
LIA 0911BWCF M
LIA 1316BWCF
LIA 1316BWCF M
Installation and
Operating Instruction
Split air-to-water heat
pump with Hydrotower
Order no.: 452172.66.10-EN
Glen
Dimplex
Deutschland
Dimplex
EN · FD 0311

Advertisement

Table of Contents
loading

Related Manuals for Dimplex LIA 0608BWCF M

Summary of Contents for Dimplex LIA 0608BWCF M

  • Page 1 Glen Dimplex Deutschland Dimplex LIA 0608BWCF M LIA 0911BWCF M LIA 1316BWCF LIA 1316BWCF M Installation and Operating Instruction Split air-to-water heat pump with Hydrotower Order no.: 452172.66.10-EN EN · FD 0311...

  • Page 3: Table Of Contents

    11 Faults / troubleshooting ......................... EN-30 12 Decommissioning / disposal ......................... EN-30 13 Device information ..........................EN-31 14 Performance values..........................EN-35 14.1 Performance values, heating LIA 0608BWCF M....................EN-35 14.2 Performance values, heating LIA 0911BWCF M....................EN-36 www.dimplex.de 452172.66.10-EN · FD 0311...
  • Page 4 17.1 Operating limits diagram heating ..........................EN-49 17.2 Operating limits diagram cooling ..........................EN-50 18 Circuit diagrams ............................EN-51 18.1 Circuit diagram LIA 0608BWCF M / LIA 0911BWCF M .................. EN-51 18.2 Circuit diagram LIA 1316BWCF M 1-phase......................EN-52 18.3 Circuit diagram LIA 1316BWCF 3-phase......................EN-53 18.4 Legend ....................................

  • Page 5: Safety Notes

    LIA 0608BWCF M - LIA 1316BWCF M English 1.3 General safety notes Safety notes CAUTION! 1.1 Symbols and markings Work on the heat pump must only be performed by authorised and qualified specialist personnel. Particularly important information in these instructions is marked with CAUTION! and NOTE.

  • Page 6: Legal Regulations And Directives

    English LIA 0608BWCF M - LIA 1316BWCF M 1.5 Legal regulations and directives Purpose This heat pump is designed for use in a domestic environment 2.1 Area of application according to Article 1, Paragraph 2 k) of EU directive 2006/42/...

  • Page 7: Scope Of Supply

    LIA 0608BWCF M - LIA 1316BWCF M English 3.2 Heat pump manager Scope of supply The integrated heat pump manager is a convenient electronic 3.1 Indoor unit regulating and control device. It controls and monitors the en- tire heating system based on the outside temperature, as well as domestic hot water preparation and safety systems.

  • Page 8: Outdoor Unit

    English LIA 0608BWCF M - LIA 1316BWCF M 3.3 Outdoor unit Transport and storage During transport and storage, the unit must be kept in a dry 3.3.1 Outdoor unit 6 kW place and must not be exposed to temperatures below freez- ing.

  • Page 9: Transporting The Indoor Unit

    LIA 0608BWCF M - LIA 1316BWCF M English 4.1 Transporting the indoor unit Installation A pallet should be used for transportation to the final installa- 5.1 Indoor unit tion location. Due to the high tare weight of the indoor unit, it should be The unit should always be installed indoors on a level, smooth transported by means of a lift truck, hand truck, or similar.

  • Page 10: Outdoor Unit

    English LIA 0608BWCF M - LIA 1316BWCF M 5.2 Outdoor unit CAUTION! The device must not be installed or operated near a naked  It is advisable to install the outdoor unit close to a wall, on a flame, gas-powered devices, electric heaters or any other foundation separate from the building with a minimum comparable source of ignition.
  • Page 11 LIA 0608BWCF M - LIA 1316BWCF M English 5.2.1 Wall opening, split lines and electric Wall or obstacle wires Air inlet Maintenance Please proceed as follows when laying split lines and electric area >300 wires: Drill a 70 mm opening for the pipework using a core drill.

  • Page 12: Heat Pump Installation Conditions

    English LIA 0608BWCF M - LIA 1316BWCF M 5.3 Heat pump installation 5.3.2 Minimum installation space requirements: conditions: The heat pump described in this manual is a refrigerant-filled The refrigerating system described in this manual is filled with device that must be installed in accordance with the require- R32.
  • Page 13 LIA 0608BWCF M - LIA 1316BWCF M English 5.3.3 Toxicity and flammability limit values: stallation conditions. It should be noted here that, in contrast to the toxicity limit value, this relates to the room area. If the refrigerant fill quantity is below 1.842 kg, the toxicity limit Calculation of the maximum permissible refrigerant fill quantity value is the determining factor for the installation conditions.

  • Page 14: Installation In Coastal Areas

    English LIA 0608BWCF M - LIA 1316BWCF M 5.4 Installation in coastal areas NOTE The use of heat pumps is safe from a distance of 12 km from If the unit is installed close to the sea, the high salt concentra- the sea with a maximum salt content of 3.5%...

  • Page 15: Assembly Indoor Unit

    LIA 0608BWCF M - LIA 1316BWCF M English NOTE Assembly indoor unit When removing the unit cover, it must be taken into account that the length of the connecting cable between the control 6.1 General panel in the unit cover and the controller on the contact plate is only 1.5 m.

  • Page 16: Water Quality In Heating Systems

    English LIA 0608BWCF M - LIA 1316BWCF M NOTE If necessary, for example in bivalent systems, the specifications listed in the table below must also be observed, or the precise Pump units with check valves maintain the specified flow guidelines for filling water and supplementary water and the directions.
  • Page 17 LIA 0608BWCF M - LIA 1316BWCF M English 6.4.2 Corrosion Saturation Index < -0.2 -0.2 - 0.1 The VDI 2035 recommends the use of partially demineralised water or demineralised water in systems with larger-than-aver- 0.1 - 0.2 age specific system volumes of 50 l/kW.
  • Page 18 English LIA 0608BWCF M - LIA 1316BWCF M Hot water outlet approx. 18° - 20° The hot water outlet connection supplies domestic hot water through the entire building and must be distributed to different water-consuming outlets as required. The connection on the indoor unit is a 1 inch external thread pipe connection.

  • Page 19: Connecting The Pipework And Cables To The Outdoor Unit

    LIA 0608BWCF M - LIA 1316BWCF M English CAUTION! Connecting the pipework Only equipment and tools intended for the product, pressure and cables to the outdoor and temperatures may be used for work on the unit. unit CAUTION! When working on the device, the use of spark-generating This chapter describes the refrigerant pipe connections and the machines should be avoided.
  • Page 20 English LIA 0608BWCF M - LIA 1316BWCF M 7.1.2 Preparation for pipework NOTE If the indoor unit is mounted 4 m or more metres higher or The preparation of the pipework takes place in five steps. One lower than the outdoor unit, a cooling technology specialist main cause of refrigerant leaks is incorrect flanging.
  • Page 21 LIA 0608BWCF M - LIA 1316BWCF M English Step 5: Checks Step 2: Fastening Compare the flanging with the figure. Align the centre of the pipes and tighten the screw nuts by   hand. If the flanging is visibly damaged, cut the relevant section ...

  • Page 22: Electrical Connections

    English LIA 0608BWCF M - LIA 1316BWCF M 7.2 Electrical connections 7.2.2 Indoor unit Two supply cables must be connected to the indoor unit: The 7.2.1 Outdoor unit power supply for the electric heating element and the control voltage for the integrated heat pump manager. (Load: 3~; 1x 5- NOTE core;...

  • Page 23: Final Work

    LIA 0608BWCF M - LIA 1316BWCF M English 7.3 Final work Connecting electronically regulated circulating pumps Once the pipes and electric cables have been connected, the Electronically regulated circulating pumps may have high start- pipes must be bent and a leak test must be carried out. The leak...

  • Page 24: Leak Test And Evacuation

    English LIA 0608BWCF M - LIA 1316BWCF M 7.4.2 Leakage tightness test Connect the multi-way valve (with pressure gauges) and  dry nitrogen gas cylinder with the filling hoses on this Seal small gaps around maintenance connection. the pipe, e.g. with silicon.

  • Page 25: Commissioning

    LIA 0608BWCF M - LIA 1316BWCF M English 7.4.3 Evacuation Commissioning Connect the end of the filling hose mentioned above to the vacuum pump to pump the pipework and indoor unit 8.1 General empty. The levers "Lo" and "Hi" on the multi-way valve must be open.

  • Page 26: Commissioning Procedure

    English LIA 0608BWCF M - LIA 1316BWCF M Special notes for the integration of heat pumps in At heating water temperatures under 7 °C, commissioning is existing systems (renovations): not possible. The water in the buffer tank must be heated with the 2nd heat generator to at least 18 °C.

  • Page 27: Test Points, Maintenance And Troubleshooting

    LIA 0608BWCF M - LIA 1316BWCF M English CAUTION! Test points, maintenance Always wear adequate personal protective equipment and troubleshooting (protective gloves, safety glasses, etc.) when working with refrigerant. If no faults have occurred up to this point, the unit can now be put into operation.

  • Page 28: Maintenance

    English LIA 0608BWCF M - LIA 1316BWCF M 9.2 Maintenance CAUTION! For cleaning and maintenance, especially when removing To maintain an optimal output on the split heat pump, regular covers, the entire system must be disconnected from the checks and maintenance work should be carried out on the power supply beforehand.

  • Page 29: Troubleshooting

    LIA 0608BWCF M - LIA 1316BWCF M English 9.3 Troubleshooting CAUTION! Before opening the device, ensure that all electric circuits are If the split heat pump is experiencing problems during opera- disconnected from the power supply. tion or is not working at all, check the following points.

  • Page 30: Characteristic Curve Temperature Sensor Outdoor Unit

    English LIA 0608BWCF M - LIA 1316BWCF M If the system needs to be completely refilled due to a fault or Evacuate the system and make sure that there is no oxygen leakage, please proceed as follows: or nitrogen in the pipe system.

  • Page 31: Characteristic Curve Temperature Sensor Indoor Unit

    LIA 0608BWCF M - LIA 1316BWCF M English 9.5 Characteristic curve 9.5.2 Mounting the outside temperature sensor temperature sensor indoor unit The outside temperature is measured via the heat source inlet sensor on the outdoor unit. Optionally, a separate outdoor tem- 9.5.1 Sensor characteristic curves...

  • Page 32: Cleaning / Maintenance

    English LIA 0608BWCF M - LIA 1316BWCF M 10 Cleaning / maintenance 11 Faults / troubleshooting This heat pump is a quality product and is designed for trouble- 10.1 Care free operation. Should a fault occur, however, it will be indi- cated on the heat pump manager display.

  • Page 33: Device Information

    LIA 0608BWCF M - LIA 1316BWCF M English 13 Device information Type and order code LIA 0608BWCF M LIA 0911BWCF M Design Heat source Version Universal with hydrotower Universal with hydrotower Controller WPM Touch WPM Touch Thermal energy metering Installation location...
  • Page 34 English LIA 0608BWCF M - LIA 1316BWCF M for circulation pipe inches 3/4" external thread 3/4" external thread unmixed heating circuit inches 1 1/4" external thread 1 1/4" external thread Anode diameter Anode length Anode connection thread inches 1 1/4" internal thread 1 1/4"...
  • Page 35 LIA 0608BWCF M - LIA 1316BWCF M English Type and order code LIA 1316BWCF M LIA 1316BWCF Design Heat source Version Universal with hydrotower Universal with hydrotower Controller WPM Touch WPM Touch Thermal energy metering Installation location Indoors/outdoors Indoors/outdoors Performance level...
  • Page 36 English LIA 0608BWCF M - LIA 1316BWCF M unmixed heating circuit inches 1 1/4" external thread 1 1/4" external thread Anode diameter Anode length Anode connection thread inches 1 1/4" internal thread 1 1/4" internal thread Electrical connection Supply voltage / fusing...

  • Page 37: Performance Values

    LIA 0608BWCF M - LIA 1316BWCF M English 14 Performance values 14.1 Performance values, heating LIA 0608BWCF M Maximum 2.57 1.49 1.72 2.25 1.53 1.46 2.14 1.67 1.28 1.91 1.64 1.17 1.71 1.57 1.09 3.64 1.56 2.34 3.34 1.86 1.80 2.88...

  • Page 38: Performance Values, Heating Lia 0911Bwcf M

    English LIA 0608BWCF M - LIA 1316BWCF M 14.2 Performance values, heating LIA 0911BWCF M Maximum 4.68 2.06 2.27 4.21 2.12 1.98 3.78 2.28 1.66 3.52 2.24 1.57 2.96 2.26 1.31 5.98 2.12 2.82 5.35 2.24 2.39 4.98 2.34 2.13 4.55...

  • Page 39: Performance Values, Heating Lia 1316Bwcf (M

    LIA 0608BWCF M - LIA 1316BWCF M English 14.3 Performance values, heating LIA 1316BWCF (M) Maximum 6.60 3.09 2.14 6.76 3.20 2.11 5.43 3.18 1.71 4.89 3.35 1.46 4.47 3.47 1.29 8.26 3.22 2.57 8.30 3.30 2.52 7.79 3.58 2.18 6.89...

  • Page 40: Performance Values, Cooling Lia 0608Bwcf M

    English LIA 0608BWCF M - LIA 1316BWCF M 14.4 Performance values, cooling LIA 0608BWCF M Maximum 5.27 0.59 8.93 6.38 0.55 11.53 6.77 0.64 10.62 5.05 0.69 7.28 6.16 0.66 9.39 6.55 0.74 8.85 4.55 0.79 5.74 5.66 0.76 7.48 6.05...

  • Page 41: Performance Values, Cooling Lia 0911Bwcf M

    LIA 0608BWCF M - LIA 1316BWCF M English 14.5 Performance values, cooling LIA 0911BWCF M Maximum 6.83 0.69 9.92 8.79 0.82 10.66 9.35 0.77 12.13 6.61 0.77 8.56 7.76 0.81 9.61 8.30 0.76 10.88 6.38 0.89 7.19 6.74 0.79 8.56 7.25...

  • Page 42: Performance Values, Cooling Lia 1316Bwcf (M

    English LIA 0608BWCF M - LIA 1316BWCF M 14.6 Performance values, cooling LIA 1316BWCF (M) Maximum 10.0 1.32 7.57 10.9 1.47 7.44 12.0 1.42 8.43 9.80 1.67 5.87 11.4 1.58 7.24 12.5 1.59 7.84 9.57 1.76 5.44 12.0 1.61 7.43 13.0...
  • Page 43 Regulation (EU) No 813/ 2013, Annex II, Table 2 Information requirements for heat pump space heaters and heat pump combination heaters Model Dimplex LIA 0608BWCF M (LIA 0608 M + LIA BW) Air-to-water heat pump Water-to-water heat pump Brine-to-water heat pump...
  • Page 44 English LIA 0608BWCF M - LIA 1316BWCF M Information requirements for heat pump space heaters and heat pump combination heaters Model Dimplex LIA 0911BWCF M (LIA 0911 M + LIA BW) Air-to-water heat pump Water-to-water heat pump Brine-to-water heat pump...
  • Page 45 Contact details Glen Dimplex Deutschland GmbH, Am Goldenen Feld 18, 95326 Kulmbach (*) For heat pump space heaters and heat pump combination heaters, the rated output Prated is equal to the design load for heating Pdesignh , and the rated heat output of a supplementary capacity for heating sup(Tj ).
  • Page 46 English LIA 0608BWCF M - LIA 1316BWCF M Information requirements for heat pump space heaters and heat pump combination heaters Model Dimplex LIA 1316BWCF M (LIA 1316 M + LIA BW14) Air-to-water heat pump Water-to-water heat pump Brine-to-water heat pump...

  • Page 47: Dimension Drawings

    LIA 0608BWCF M - LIA 1316BWCF M English 16 Dimension drawings 16.1 Dimension drawing outdoor unit LIA 0608BWCF M 1008 www.dimplex.de 452172.66.10-EN · FD 0311 EN-45...

  • Page 48: Dimension Drawing Outdoor Unit Lia 0911Bwcf M / Lia 1316Bwcf M / Lia 1316Bwcf

    English LIA 0608BWCF M - LIA 1316BWCF M 16.2 Dimension drawing outdoor unit LIA 0911BWCF M / LIA 1316BWCF M / LIA 1316BWCF 1118 EN-46 452172.66.10-EN · FD 0311 www.dimplex.de...

  • Page 49: Foundation Plan Lia 0608Bwcf M

    LIA 0608BWCF M - LIA 1316BWCF M English 16.3 Foundation plan LIA 0608BWCF M Foundation > 80 ca. 1000 16.4 Foundation plan LIA 0911BWCF M / LIA 1316BWCF M / LIA 1316BWCF Foundation > 80 ca. 1110 www.dimplex.de 452172.66.10-EN · FD 0311...

  • Page 50: Dimension Drawing Indoor Unit

    English LIA 0608BWCF M - LIA 1316BWCF M 16.5 Dimension drawing indoor unit EN-48 452172.66.10-EN · FD 0311 www.dimplex.de...

  • Page 51: Diagrams

    LIA 0608BWCF M - LIA 1316BWCF M English 17 Diagrams 17.1 Operating limits diagram heating Heat source inlet temperature [°C] www.dimplex.de 452172.66.10-EN · FD 0311 EN-49...

  • Page 52: Operating Limits Diagram Cooling

    English LIA 0608BWCF M - LIA 1316BWCF M 17.2 Operating limits diagram cooling Heatsink inlet temperature [°C] EN-50 452172.66.10-EN · FD 0311 www.dimplex.de...

  • Page 53: Circuit Diagrams

    LIA 0608BWCF M - LIA 1316BWCF M English 18 Circuit diagrams 18.1 Circuit diagram LIA 0608BWCF M / LIA 0911BWCF M FACTORY SETTINGS blue black PCB A, Inverter board for 1-phase brown blue blue brown PCB B, Main control board...

  • Page 54: Circuit Diagram Lia 1316Bwcf M 1-Phase

    English LIA 0608BWCF M - LIA 1316BWCF M 18.2 Circuit diagram LIA 1316BWCF M 1-phase FACTORY SETTINGS blue PCB A, Inverter board black for 1-phase blue brown blue brown PCB B, Main control board for 1-ph brown brown To heater band...

  • Page 55: Circuit Diagram Lia 1316Bwcf 3-Phase

    LIA 0608BWCF M - LIA 1316BWCF M English 18.3 Circuit diagram LIA 1316BWCF 3-phase black black black brown brown brown grey Inverter board grey Ferrite core grey black Ferrite core blue white black Address Ferrite core grey brown black To heater...

  • Page 56: Legend

    English LIA 0608BWCF M - LIA 1316BWCF M 18.4 Legend Inverter board for 3-phase Input connection P_in for IPM module PCB A, inverter board for 1-phase Communication connection for PCB C Connection for fan CN19 Input connection P_out for IPM module...
  • Page 57 LIA 0608BWCF M - LIA 1316BWCF M English Communication connection for power meter CN26 Connection for 2-way valve 6 CN27 Communication connection for XYE CN28 Connection for low pressure switch and quick check CN29 Connection for fan 15 VDC power supply...

  • Page 58: Hydraulic Integration Diagrams

    English LIA 0608BWCF M - LIA 1316BWCF M 19 Hydraulic integration diagrams 19.1 Mono energy system with one heating circuit NOTE The hydraulic integration diagram is an example and intended only as an aid. The system requires professional and safety- approved layout by a specialist planner.

  • Page 59: Mono Energy System With One Heating Circuit And Domestic Hot Water Preparation

    LIA 0608BWCF M - LIA 1316BWCF M English 19.2 Mono energy system with one heating circuit and domestic hot water preparation NOTE The hydraulic integration diagram is an example and intended only as an aid. The system requires professional and safety- approved layout by a specialist planner.

  • Page 60: Legend

    English LIA 0608BWCF M - LIA 1316BWCF M 19.3 Legend Isolating valve Overflow valve Check valve Circulating pump Room-temperature controlled valve Isolating valve with check valve Heat consumer Temperature sensor Three-way mixer Dirt trap Outdoor unit Indoor unit Buffer tank...

  • Page 61: Declaration Of Conformity

    LIA 0608BWCF M - LIA 1316BWCF M English 20 Declaration of conformity You can find the current CE declaration of conformity to down- load https://dimplex.de/lia0608bwcfm https://dimplex.de/lia0911bwcfm https://dimplex.de/lia1316bwcf https://dimplex.de/lia1316bwcfm www.dimplex.de 452172.66.10-EN · FD 0311 EN-59...
  • Page 62 English LIA 0608BWCF M - LIA 1316BWCF M EN-60 452172.66.10-EN · FD 0311 www.dimplex.de...
  • Page 63 LIA 0608BWCF M - LIA 1316BWCF M English www.dimplex.de 452172.66.10-EN · FD 0311 EN-61...
  • Page 64 Glen Dimplex Deutschland On site service Head office After-sales service, technical support and Glen Dimplex Deutschland GmbH spare partsl. Assistance before and Am Goldenen Feld 18 after installation of your equipment D-95326 Kulmbach T +49 9221 709-545 T +49 9221 709-101...
