L6TBN62K
USER
MANUAL
EN
User Manual
Washing Machine

Advertisement

Table of Contents
loading

Related Manuals for AEG L6TBN62K

Summary of Contents for AEG L6TBN62K

  • Page 1 L6TBN62K User Manual Washing Machine USER MANUAL...

  • Page 2: Table Of Contents

    16. QUICK GUIDE....................31 FOR PERFECT RESULTS Thank you for choosing this AEG product. We have created it to give you impeccable performance for many years, with innovative technologies that help make life simpler – features you might not find on ordinary appliances. Please spend a few minutes reading to get the very best from it.

  • Page 3: Safety Information

    ENGLISH SAFETY INFORMATION Before the installation and use of the appliance, carefully read the supplied instructions. The manufacturer is not responsible for any injuries or damage that are the result of incorrect installation or usage. Always keep the instructions in a safe and accessible location for future reference.

  • Page 4: Safety Instructions

    – working environments; by clients in hotels, motels, bed & breakfast and – other residential type environments; areas for communal use in blocks of flats or in – launderettes. The appliance maximum load is 6 kg. Do not exceed •...
  • Page 5 ENGLISH • Follow the installation instructions • Do not touch the mains cable or the supplied with the appliance. mains plug with wet hands. • Do not install or use a damaged • Do not pull the mains cable to appliance.

  • Page 6: Product Description

    • Make sure that all metal objects are repairers, and that not all spare parts removed from the laundry. are relevant for all models. • Concerning the lamp(s) inside this 2.5 Service product and spare part lamps sold separately: These lamps are intended •...
  • Page 7 ENGLISH 3.2 Appliance overview 10 11 Control panel Drain hose Mains cable Lid handle Transit bolts Drain pump filter Hose support Lever to move the appliance Rating plate Feet for levelling the appliance Inlet hose Information for register product. The rating plate reports the model name The info label reports the model name (A), (A) , product number (B), electrical product number (B ) and serial number (C).

  • Page 8: Technical Data

    4. TECHNICAL DATA Dimension Width/ Height/ Total depth 39,7 cm /90,3 cm /59,9 cm Electrical connection Voltage 230 V Overall power 2200 W Fuse 10 A Frequency 50 Hz Level of protection against ingress of solid particles and IPX4 moisture ensured by the protective cover, except where the low voltage equipment has no protection against mois‐...
  • Page 9 ENGLISH We recommend that you keep the packaging and the transit bolts for any transport of the appliance. Adjust the appliance correctly to prevent vibration, noise and movement of the appliance when it operates. WARNING! Do not put cardboard, wood or equivalent materials below the appliance feet to adjust the level.
  • Page 10 5.3 Water drainage min.600 mm max.1000 mm The drain hose should stay at a height of no less than 600 mm and not more than 1000 mm. You can extend the drain hose to maximum 4000 mm. Contact the authorised service centre for the other drain hose and the extension.

  • Page 11: Control Panel

    ENGLISH 6. CONTROL PANEL 6.1 Control panel description Aan/Uit touch button Opties touch button • Vlekken option Programme dial • Voorwas option Display TPM reduction touch button Startuitstel touch button Temp. °C touch button Tijd Besparen touch button Start/Pauze touch button 6.2 Display...

  • Page 12: Programme Chart

    The digital indicator can show: • Programme duration (e. g. • Delay time (e. g. • Cycle end ( ). • Warning code ( Extra rinse indicator. It lights on when this option is se‐ lected . indicator blink during the laundry load detec‐...
  • Page 13 ENGLISH Pro‐ Default Refer‐ Programme description gramme temper‐ ence im‐ ature spin Tem‐ speed load pera‐ Spin ture speed range range 40 °C 800 rpm Single synthetic blanket, padded clothes, du‐ 60 °C - 800-800 2 kg vets, down jackets and similar items. Dekbed Cold All fabrics, except woollens and delicate fab‐...
  • Page 14 Pro‐ Default Refer‐ Programme description gramme temper‐ ence im‐ ature spin Tem‐ speed load pera‐ Spin ture speed range range Cotton and synthetic items lightly soiled or 30 °C 1200 rpm once worn. 40 °C - 1200-800 3 kg 20 min.
  • Page 15 ENGLISH OPTIONS ■ ■ ■ ■ ■ ■ ■ Tijd Besparen ■ ■ ■ ■ ■ ■ ■ ■ ■ ■ Extra Spoelen 1) This option is not available with temperature lower than 40 °C. 2) If you set the shortest duration, we recommend that you decrease the load size. It is possible to fully load the appliance, however the washing results can be less satisfactory.

  • Page 16: Options

    Universal Liquid Uni‐ Liquid for Delicates Programme Special versal coloureds woollens powder ▲ ▲ 20 min. - 3 kg 1) At temperature higher than 60 °C the use of powder detergent is recommended. ▲ = Recommended -- = Not recommended 7.1 Woolmark Apparel Care - Blue...
  • Page 17 ENGLISH be added in the appropriate phase of The indicator = cold water of the set the washing programme. temperature comes on (the appliance does not heat the water). This option can increase the programme duration. 8.4 TPM This option is not available with a When you set a programme, the temperature lower than...

  • Page 18: Settings

    9. SETTINGS 9.1 Acoustic signals • After you touch the Start/Pauze button: all the buttons and the To deactivate the acoustic signals when programme dial are deactivated the programme is completed touch the (except Aan/Uit button ). Startuitstel and the Tijd Besparen •...
  • Page 19 ENGLISH 2. Push the button A. 2. Put the detergent and the fabric conditioner into the proper compartments. Always follow the instructions that you find on the packaging of the detergent products, but we recommend that you do not exceed the maximum indicated level.
  • Page 20 11.6 Starting a programme • The indicator of Start/Pauze flashes. Touch the Start/Pauze button to start the • The display shows the programme. programme duration. The related indicator stops flashing and 2. If necessary, change the stays on. temperature, the spin speed, the The programme starts, the lid is locked.
  • Page 21 ENGLISH 1. Press the button Aan/Uit for some If the ProSense phase is seconds to deactivate the appliance. already carried out and the 2. Wait for some minutes and then open water filling is already carefully the lid. started, the new programme 3.

  • Page 22: Hints And Tips

    11.14 Draining water out after 11.15 AUTO Stand-by option end of cycle The AUTO Stand-by function automatically deactivates the appliance The washing programme is to decrease the energy consumption completed, but there is water in the when: drum: • You do not use the appliance for 5...
  • Page 23 ENGLISH (delicates, woollens, cottons, etc), the colour of clothes, size of the load, degree of soiling, wash temperature and hardness of the water used. • Follow the instructions that you find on packaging of the detergents or other treatments without exceeding the indicated maximum level ( •...

  • Page 24: Care And Cleaning

    This will hardness is soft it is not necessary to use save energy during drying! a water softener. To find out the water hardness in your 12.5 Water hardness area, contact your local water authority.
  • Page 25 ENGLISH Regularly examine the drum to check for For a thorough clean: limescale. 1. Remove all laundry from the drum. Regular detergents already contain water 2. Run a Katoen programme with the softening agents, but we recommend to highest temperature. run a cycle with an empty drum and a 3.
  • Page 26 13.9 Cleaning the drain filter WARNING! • Disconnect the mains Regularly check the drain pump filter and plug from the mains make sure that it is clean. socket. Clean the drain pump if: • Do not remove the filter while the appliance •...

  • Page 27: Troubleshooting

    ENGLISH 13.11 Emergency drain 1. Disconnect the mains plug from the mains socket. If the appliance cannot drain the water, 2. Close the water tap. carry out the same procedure, described 3. Put the two ends of the inlet hose in in 'Cleaning the drain pump' paragraph.
  • Page 28 • Make sure that the sink spigot is not clogged. • Make sure that the drain hose has no kinks or bends. The appliance does • Make sure that the drain filter is not clogged. Clean the filter, if not drain the water.

  • Page 29: Consumption Values

    ENGLISH Problem Possible solution • Make sure that the couplings of the water hoses are tight and there is not water leakages. There is water on the • Make sure that the water inlet hose and the drain hose have floor.
  • Page 30 The QR code on the energy label supplied with the appliance provides a web link to the information related to the performance of the appliance in the EU EPREL database. Keep the energy label for reference together with the user manual and all other documents provided with this appliance.

  • Page 31: Quick Guide

    ENGLISH 15.4 Common programmes These values are indicative only. Programme Litres h:mm °C Katoen 2.60 3:25 1200 95°C Katoen 1.85 3:25 1200 60°C Katoen 20° 0.40 2:45 1200 20°C Synthetica 0.65 2:10 1200 40°C Fijne Was 0.35 1:00 1200 30°C Wol/Zijde 0.20 1:10...
  • Page 32 2. Set the desired options (1) by means Push the Aan/Uit button to turn the of the corresponding touch buttons. appliance off. To start the programme, touch the Start/Pauze (2) button. 3. The appliance starts. At the end of the programme, remove the laundry.
  • Page 33 ENGLISH Programmes Load Product description 3 kg Denim clothing and jersey items. Jeans 6 kg Mixed fabrics. Cotton and synthetic items. Katoen 20° 2,5 kg Synthetic items requiring a gentle wash. Sport Cotton and synthetic lightly soiled or once worn 3 kg 20 min.
  • Page 36 www.aeg.com/shop...
