AEG L6TBE60278 User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
L6TBE60278
USER
MANUAL
EN
User Manual
Washing Machine

Advertisement

Table of Contents
loading

Related Manuals for AEG L6TBE60278

Summary of Contents for AEG L6TBE60278

  • Page 1 L6TBE60278 User Manual Washing Machine USER MANUAL...

  • Page 2: Table Of Contents

    17. ENVIRONMENTAL CONCERNS..............35 FOR PERFECT RESULTS Thank you for choosing this AEG product. We have created it to give you impeccable performance for many years, with innovative technologies that help make life simpler – features you might not find on ordinary appliances. Please spend a few minutes reading to get the very best from it.

  • Page 3: Safety Information

    ENGLISH SAFETY INFORMATION Before the installation and use of the appliance, carefully read the supplied instructions. The manufacturer is not responsible for any injuries or damage that are the result of incorrect installation or usage. Always keep the instructions in a safe and accessible location for future reference.

  • Page 4: Safety Instructions

    This appliance is intended to be used in household • and similar applications such as: staff kitchen areas in shops, offices and other – working environments; by clients in hotels, motels, bed & breakfast and – other residential type environments;...
  • Page 5 ENGLISH future they must be reattached to lock be replaced, this must be carried out the drum to prevent an internal by our Authorised Service Centre. damage. • Connect the mains plug to the mains • Always take care when moving the socket only at the end of the appliance as it is heavy.

  • Page 6: Product Description

    • Do not wash fabrics which are heavily such as detergent dispensers. Please soiled with oil, grease or other greasy note that some of these spare parts substances. It can damage rubber are only available to professional parts of the washing machine.
  • Page 7 ENGLISH 3.2 Appliance overview 10 11 Control panel Drain hose Mains cable Lid push handle Transit bolts Drain pump filter Hose support Lever to move the appliance Rating plate Feet for levelling the appliance Inlet hose Information for register product. The rating plate reports the model name The info label reports the model name (A), (A) , product number (B), electrical...

  • Page 8: Technical Data

    4. TECHNICAL DATA Dimension Width/ Height/ Total depth 39,7 cm /90,3 cm /59,9 cm Electrical connection Voltage 230 V Overall power 2200 W Fuse 10 A Frequency 50 Hz Level of protection against ingress of solid particles and IPX4 moisture ensured by the protective cover, except where the low voltage equipment has no protection against mois‐...
  • Page 9 ENGLISH We recommend that you keep the packaging and the transit bolts for any transport of the appliance. Adjust the appliance correctly to prevent vibration, noise and movement of the appliance when it operates. WARNING! Do not put cardboard, wood or equivalent materials below the appliance feet to adjust the level.
  • Page 10 5.3 Water drainage min.600 mm max.1000 mm The drain hose should stay at a height of no less than 600 mm and not more than 1000 mm. You can extend the drain hose to maximum 4000 mm. Contact the authorised service centre for the other drain hose and the extension.

  • Page 11: Control Panel

    ENGLISH 6. CONTROL PANEL 6.1 Control panel description 12 11 Flecken/Vorwäsche skipping touch Ein/Aus push button button Programme dial • Flecken option Display • Vorwäsche option Zeitvorwahl touch button Anti-Allergie touch button Zeit Sparen touch button Flüssig Dosierung touch button Spülen skipping touch button Schleudern reduction touch button •...
  • Page 12 Maximum laundry indicator. It flashes when the laundry load exceeds the maximum declared load of the selected programme. Lid locked indicator. Delay start indicator. The digital indicator can show: • Programme duration (e. g. • Delay time (e. g.

  • Page 13: Programme Chart

    ENGLISH 7. PROGRAMME CHART Washing programmes Programme Default Reference Maxi‐ Programme description tempera‐ spin speed ture Spin speed load Tempera‐ range ture range White cotton and fast-coloured cotton. Normally soiled items. The 1200 rpm energy consumption decreases and Eco 40-60 1200-400 7 kg 40 °C...
  • Page 14 Programme Default Reference Maxi‐ Programme description tempera‐ spin speed ture Spin speed load Tempera‐ range ture range Do not us fabric soft‐ ener and make sure there is no softener residue in the deter‐ gent dispenser. Outdoor clothing, technical, sport fabrics, waterproof and breatha‐...
  • Page 15 ENGLISH Programme Default Reference Maxi‐ Programme description tempera‐ spin speed ture Spin speed load Tempera‐ range ture range All fabrics, except woollens and 1200 rpm delicate fabrics. To spin the laun‐ Schleudern/ 1200 rpm - 7 kg dry and to drain the water in the Abpumpen 400 rpm drum.
  • Page 16 OPTIONS Extra Spülen ■ ■ ■ ■ ■ ■ Nur Spülen ■ ■ ■ ■ ■ ■ ■ ■ ■ Anti-Allergie ■ ■ ■ ■ ■ ■ Zeit Sparen Zeitvorwahl ■ ■ ■ ■ ■ ■ ■ ■ ■...

  • Page 17: Options

    ENGLISH ▲ = Recommended -- = Not recommended 7.1 Woolmark Apparel Care - Green The wool wash cycle of this machine has been approved by The Woolmark Company for the washing of wool garments labelled as «hand wash» provided that the garments are washed according to the instructions issued by the manufacturer of this washing machine.
  • Page 18 8.6 Spülen • Activate the Extra Silent option. The intermediate and the final With this button you can select one of the spinning phases are suppressed and following options: the programme ends with water in the drum. This helps to reduce creasing.

  • Page 19: Settings

    ENGLISH and pollens/allergenic items, making it Touch the button repeatedly to set the suitable for delicate and sensitive skins. required delay. The time increases by steps of 30 minutes up to 90' and from 2 8.9 Flüssig Dosierung hours up to 20 h. After touching the Start/Pause button, Press this button to adapt the cycle if you use a liquid detergent.

  • Page 20: Before First Use

    10. BEFORE FIRST USE 2. Open the water tap. During installation or before 3. Put 2 litre of water in the detergent first use you may observe compartment for washing phase. some water in the appliance. This activates the drain system.
  • Page 21 ENGLISH Detergent compartment for prewash phase. The marks MAX are the maximum levels of the quantity of detergent (powder or liquid). When you set a programme with a stain, add detergent (powder or liquid). Detergent compartment for washing phase. The marks MAX are the maximum levels of the quantity of detergent (powder or liquid).
  • Page 22 11.7 Cycle time recalculation When you use the liquid detergent: After approximately 15 • Do not use gelatinous or minutes from the start of the thick liquid detergents. programme: • Do not put more liquid • The appliance adjusts then the maximum level.
  • Page 23 ENGLISH 3. Press the button Start/Pause again. Once removed the exceeding garments, The programme continues. touch the Start/Pause button to start the programme again. The ProSense phase 11.11 Cancelling a running can be repeated up to three times (see point 1). programme Important! If the laundry amount will not 1.

  • Page 24: Hints And Tips

    11.14 Opening the Lid when 2. Remove the laundry from the appliance. the delay start is active 3. Make sure that the drum is empty. 4. Keep the door ajar, to prevent mildew While the delay start operates, the and odours appliance lid is locked.
  • Page 25 ENGLISH a. interrupt the programme and • Use only detergents and other open the door (refer to "Daily treatments specially made for Use" chapter); washing machines. First, follow these b. manually redistribute the load so generic rules: that the items are spaced evenly –...

  • Page 26: Care And Cleaning

    • Loading the appliance to the laundry in a tumble dryer. This will maximum capacity indicated for save energy during drying! each programmes helps to reduce 12.5 Water hardness energy and water consumption. • With adequate pre-treatment, stains If the water hardness in your area is high and limited soiling can be removed;...
  • Page 27 ENGLISH 13.6 Lid seal CAUTION! Do not clean the metal Regularly examine the seal and remove surfaces with chlorine-based all objects from the inner part. Clean it detergent. when needed, using ammonia cream cleanser agent without scratching the 13.4 Descaling seal surface.
  • Page 28 Always keep a rag nearby to dry up any WARNING! water spillages when removing the filter. • Disconnect the mains plug from the mains socket. • Do not remove the filter while the appliance operates. • Do not clean the pump if the water in the appliance is hot.

  • Page 29: Troubleshooting

    ENGLISH 13.11 Emergency drain 1. Disconnect the mains plug from the mains socket. If the appliance cannot drain the water, 2. Close the water tap. carry out the same procedure, described 3. Put the two ends of the inlet hose in in 'Cleaning the drain pump' paragraph.
  • Page 30 • Make sure that the sink spigot is not clogged. • Make sure that the drain hose has no kinks or bends. The appliance does • Make sure that the drain filter is not clogged. Clean the filter, if not drain the water.
  • Page 31 ENGLISH Problem Possible solution • Make sure that the couplings of the water hoses are tight and there is not water leakages. There is water on the • Make sure that the water inlet hose and the drain hose have floor.

  • Page 32: Consumption Values

    15. CONSUMPTION VALUES 15.1 Introduction See the web link www.theenergylabel.eu for detailed information about Energy Label. The QR code on the energy label supplied with the appliance provides a web link to the information related to the performance of the appliance in the EU EPREL database.
  • Page 33 ENGLISH Eco 40-60 pro‐ Litres h:mm °C gramme Quarter load 0.265 2:40 1151 1) Maximum spin speed. Power consumption in different modes Off (W) Stand-by (W) Delay start (W) 0.50 0.50 4.00 Time to Off/Standby mode is 15 minutes maximum. 15.4 Common programmes These values are indicative only.

  • Page 34: Quick Guide

    16. QUICK GUIDE 16.1 Daily use Connect the mains plug to the mains 2. Set the desired options (1) by means socket. of the corresponding touch buttons. To start the programme, touch the Open the water tap. Start/Pause (2) button.

  • Page 35: Environmental Concerns

    ENGLISH Programmes Load Product description 3 kg Synthetic items or mixed fabric items. Pflegeleicht Delicate fabrics such as acrylics, viscose, poly‐ 2 kg Feinwäsche ester items. Machine washable wool, hand washable wool 1.5 kg and delicates. Wolle/Seide Cotton and synthetic lightly soiled items or once 3 kg 20 Min.
  • Page 36 www.aeg.com/shop...
