We advise you to read this manual carefully, which contains all the instructions for maintaining the
appliance's aesthetic and functional qualities. For further information on the product: www.smeg.com
PRECAUTIONS
General safety instructions
Risk of personal injury
• WARNING: During use the
appliance and its accessible
parts become very hot. Keep
children well away from the
appliance.
• Protect your hands by wearing
oven gloves when moving food
inside the oven.
• Never try to put out a fire or
flames with water: Turn off the
appliance and smother the
flames with a fire blanket or
other appropriate cover.
• This appliance may only be
91477A899/A
3
3
7
8
8
8
8
8
9
9
9
9
9
10
10
10
10
11
11
12
12
used by children aged 8 years
and over, and by people of
reduced physical, sensory or
mental capacity, or lacking in
experience in the use of
electrical appliances, provided
that they are supervised or
have been given instructions on
the safe use of the appliance
and of the hazards associated
with it.
• Children must not play with the
appliance.
• Keep children under the age of
eight at a safe distance unless
they are constantly supervised.
• Keep children under the age of
12
12
13
13
14
15
15
16
16
16
18
18
19
20
20
23
23
25
26
PRECAUTIONS - 3
Advertisement
Table of Contents
Related Manuals for Smeg SSA60MX2
Summary of Contents for Smeg SSA60MX2
-
Page 1: Table Of Contents
Instructions for the installer Preliminary operations We advise you to read this manual carefully, which contains all the instructions for maintaining the appliance’s aesthetic and functional qualities. For further information on the product: www.smeg.com PRECAUTIONS General safety instructions used by children aged 8 years... - Page 2 8 away from the appliance hot during use. Take care never when it is in use. to touch the heating elements • Cleaning and maintenance inside the oven(s). must not be carried out by • Do not insert pointed metal unsupervised children.
- Page 3 • DO NOT USE AEROSOLS IN for it to be replaced in order to THE VICINITY OF THIS avoid possible hazards. APPLIANCE WHILST IT IS IN • WARNING: A gas cooking USE. appliance produces heat, • DO NOT MODIFY THIS humidity and combustion APPLIANCE.
- Page 4 prevent them from being • If you wish to use greaseproof removed must face downwards paper, place it so that it will not and towards the back of the interfere with the hot air oven. circulation inside the oven. • Do not use the open door to rest pans or trays on the internal glass pane.
-
Page 5: Installation
when fitting. are shown on the gas setting • Avoid exerting too much label. pressure on the door when • Have the gas connection open. performed by authorised • Take care that no objects are personnel. stuck in the doors. •... -
Page 6: Appliance Purpose
• The tightening torque of the Manufacturer’s liability screws of the terminal supply The manufacturer declines all liability for damage to persons or property caused by: wires must be 1.5 - 2 Nm. • use of the appliance other than that •... -
Page 7: Information For European Control Bodies
Information for European Control for use in high temperature applications such as ovens. Bodies • This appliance contains light sources of Fan forced mode efficiency class "G". the ECO function used to define the energy How to read the user manual efficiency class complies with the specifications This user manual uses the following reading of European standard EN 60350-1. -
Page 8: Description
DESCRIPTION General description 1 Upstand 2 Hob 3 Control panel 4 Oven light 5 Seal 6 Door 7 Fan 8 Storage compartment Frame shelf AUX = Auxiliary Burner SR = Semi-rapid Burner UR-3c = Ultra-rapid Burner Control panel 9 Temperature knob maximum setting. -
Page 9: Other Parts
reaches the set temperature. It flashes regularly function. to indicate that the temperature set inside the oven is kept constant. When the door is open, it is not possible to turn off the interior lighting. 11 Function knob The oven’s various functions are suitable for Accessories different cooking modes. -
Page 10: Use
Preliminary operations devices are located together on the front panel. The burner controlled by each knob is shown next to the knob. The appliance is equipped See General safety instructions. with an electronic ignition device. Simply press the knob and turn it anti-clockwise to the •... -
Page 11: Using The Storage Compartment (Where Present)
CIRCULAIRE over. The heat is distributed quickly and Burner Pan diameter uniformly. Suitable for all dishes, ideal 12 - 14 cm for cooking on multiple levels without mixing smells or flavours. 16 - 24 cm The ECO symbol indicates that this function UR-3c 18 - 28 cm gives the least energy consumption. -
Page 12: Cooking Information Table
you wish to change the effect of the be obtained from Authorised Assistance cooking. Centres). • With the Fan with grill function (if present), • To facilitate the flow of air, place the we recommend that you preheat the oven moulds/ovenware at the centre of the racks before grilling. -
Page 13: Cleaning And Maintenance
Weight Temp. Time Food Function Shelf (Kg) (°C) (minutes) surface 2 surface Pork chops FAN WITH GRILL Spare ribs FAN WITH GRILL Bacon GRILL Pork fillet FAN WITH GRILL Beef fillet GRILL Salmon trout TURBO/CIRCULAIRE 150 - 160 35 - 40 Monkfish TURBO/CIRCULAIRE 60 - 65... -
Page 14: Cleaning The Hob
Use normal, non-abrasive products and a Knobs wooden or plastic tool, if necessary. Rinse Do not use aggressive products thoroughly and dry with a soft cloth or a containing alcohol or products for microfibre cloth. cleaning steel and glass when cleaning Do not allow residues of sugary foods (such as the knobs, as these products could jam) to set inside the oven. - Page 15 that grooved sections A are resting 5. Remove the intermediate glass unit by lifting completely in the slots. it upwards. N.B.: in some models, the intermediate glass unit 4. Lower the door and once it is in place consists of two glasses. remove the pins from the holes in the hinges.
-
Page 16: Cleaning The Oven Cavity
9. Be sure to fit the 4 pins of the inner glass well slide it out of the seats B at the back. into their seats on the door. • When cleaning is complete, repeat the above procedures to put the rack/tray Cleaning the oven cavity support frames back in. -
Page 17: Extraordinary Maintenance
Vapor Clean cycle setting 2. Remove the rack/tray support frames. 3. Use a tool (e.g. a spoon) to remove the bulb 1. Turn the functions knob to symbol cover. (where present). 2. Turn the temperature knob to the symbol. 3. Allow the cleaning cycle to run for 18 minutes. -
Page 18: Installation
INSTALLATION (serigraphed on the hose itself). The appliance must be installed by a qualified technician and according to Connection using a rubber hose the regulations in force. complying with current standards is only permitted if the hose can be inspected along its entire length. - Page 19 comply with the applicable standard. comply with the applicable standard. Carefully screw the connector 3 to the gas Carefully screw the hose connector 3 to the connector 1 of the appliance, placing the seal 2 appliance’s gas connector 1 (½” thread ISO between them.
- Page 20 Extraction of the combustion products Replacing nozzles The combustion products may be extracted by means of hoods connected to a natural draught chimney whose efficiency is certain or via forced extraction. An efficient extraction system requires precision planning by a specialist qualified in this area and must comply with the positions and clearances indicated by the applicable standards.
-
Page 21: Burner And Nozzle Characteristics Tables
spindle clockwise all the way. Lubricating the gas cocks Over time the gas cocks may become difficult to Following adjustment to a gas other turn and get blocked. Clean them internally and than the one originally set in the factory, replace the lubrication grease. - Page 22 Assembling the upstand (on some models 600 mm only) Minimum distance from side walls or other flammable material. Minimum cabinet width (=A) Appliance dimensions The upstand must always be positioned and secured correctly on the appliance. 1. Unscrew the two nuts (B) on the back of the hob.
-
Page 23: Electrical Connection
1. Screw the wall fastening plate to the rear of 6. Consider a distance of 50 mm from the side the appliance. of the appliance to the bracket holes. 2. Adjust the height of the 4 legs. 3. Assemble the fastening bracket. 7. -
Page 24: Instructions For The Installer
data, serial number and brand name is visibly valve, burner and ignition are working positioned on the appliance. properly. Do not remove this plate for any reason. • Turn the burner knobs to the minimum position and check that the flame is stable The appliance must be connected to ground for each individual burner and all the using a wire that is at least 20 mm longer than...
