INSTALLATION MANUAL
R-410A OUTDOOR SPLIT-SYSTEM
HEAT PUMP
MODELS: 16 SEER -
YHG, CH6B, TH6B, RHP16L SERIES
1.5 TO 5 TONS - 1 PHASE
GENERAL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
SAFETY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
UNIT INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
INDOOR EXPANSION DEVICE . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
EVACUATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
SYSTEM CHARGE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Typical Installation Clearances . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Alternative Installation Clearances . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Installation of Vapor Line . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Underground Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Heat Protection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
TXV Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
TXV Bulb and Equalizer Line Installations . . . . . . . . . . . . . . . . . . . . . 6
Proper Bulb Location . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Outdoor Unit Swing Away Control Box . . . . . . . . . . . . . . . . . . . . . . 13
Maximum / Minimum Operating Limit Conditions . . . . . . . . . . . . . . . . 2
R-410A Saturation Properties . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
1.5 Ton Subcooling Charging Chart for Coils
CF/CM/CU30, AE30, AVC30, RFCX30BE . . . . . . . . . . . . . . . . . . . . . 8
1.5 Ton Subcooling Charging Chart for Coils
CF/CM/CU24, AP24, AE24, AVC24, RFCX24BP/BE . . . . . . . . . . . . 8
for all Approved Coils . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
for all Approved Coils . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
3 Ton Subcooling Charging Chart
for all Approved Coils . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
3.5 Ton Subcooling Charging Chart for Coils
AE/AVC60C, AP60(C,D), RFCX60(CE,CP,DP) . . . . . . . . . . . . . . . . . 9
CF/CM/CU48, AP37, AE/AVC42, AP/AE/AVC48,
RFCX37, RFCX48, RFCX42CE . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
4 Ton Subcooling Charging Chart for Coils
CF/CM/CU64, AE60D, AVC60D,RFCX60DE . . . . . . . . . . . . . . . . . 10
5 Ton Subcooling Charging Chart for Coils
CF/CM/CU64, AE60D, AVC60D,RFCX60DE . . . . . . . . . . . . . . . . . 10
AE/AVC30, RFCX30BE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
AP/AE/AVC24, RFCX24(BP,BE) . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
SECTION I: GENERAL
The outdoor units are designed to be connected to a matching indoor
coil with sweat connect lines. Sweat connect units are factory charged
with refrigerant for a nominal sized matching indoor coil plus 15 feet of
field-supplied lines.
Johnson Controls Ducted Systems
LIST OF SECTIONS
ELECTRICAL CONNECTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
SYSTEM START-UP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
SYSTEM OPERATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
INSTRUCTING THE OWNER . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
WIRING DIAGRAM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
START UP SHEET . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
LIST OF FIGURES
Outdoor Unit Control Box (208/230V Single Phase) . . . . . . . . . . . . . 14
(Single and Three-Phase) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Heat Pump Flow Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Demand Defrost Control Module . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Defrost Operation Curves . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
(Demand Defrost) ECM Fan Motor . . . . . . . . . . . . . . . . . . . . . . . . . . 19
(Demand Defrost) PSC Fan Motor . . . . . . . . . . . . . . . . . . . . . . . . . . 20
LIST OF TABLES
AE/AVC36, RFCX30BP, RFCX36(BE,CE) . . . . . . . . . . . . . . . . . . . . 11
AE/AVC30, RFCX30(BP,BE) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
2.5 Ton Heating Charts for Coils CF/CM/CU36, AP30B,
AP36B, AE/AVC36, RFCX30BP, RFCX36(BE,BP,CE) . . . . . . . . . . 11
2.5 Ton Heating Charts for Coils CF/CM/CU30,
AE/AVC30, RFCX30BE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
AVC48, RFCX37CP, RFCX42CE, RFCX48(CE,CP,DE,DP) . . . . . . 12
AE/AVC36, RFCX30BP, RFCX36(BE,BP,CE) . . . . . . . . . . . . . . . . . 12
CF/CM/CU60, AP60, AE/AVC60C, RFCX60(CE,CP,DP) . . . . . . . . 12
AP48, AE42, AVC42, AE48, AVC48, RFCX37CP,
RFCX42CE, RFCX48(CE,CP,DE,DP) . . . . . . . . . . . . . . . . . . . . . . . 12
4 Ton Heating Charts for Coils CF/CM50, CF/CM61 . . . . . . . . . . . . 12
AE/AVC60D, RFCX60DE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
5 Ton Heating Charts for Coils CF/CM/CU64,
AE/AVC60D, RFCX60DE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
TEST Input Functionality with Y . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
TEST Input Functionality without Y . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Status Code Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Status . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Matching indoor coils can be used with a thermostatic expansion valve
(TXV). Refer to the Tabular Data Sheet or to the Technical Guide for
the proper selection.
® ® ® ®
5878890-UIM-A-0220
