For model N400X - a 4.5 cu. ft., 2-way or 3-way, refrigerator.
For model N510X - a 5.5 cu. ft., 2-way or 3-way, refrigerator.
The model numbers of 3-way refrigerators include ".3". The model numbers of 2-way mod-
els do not.
The letter "X" in the model number above, stands for a letter or a numeral which means a
refrigerator option.
WARNING:
Improper installation, adjustment, alteration, service or maintenance
can cause injury or property damage. Refer to this manual. For
assistance or additional information, contact a qualified installer,
service agency, or the gas supplier.
FOR YOUR SAFETY
Do not store or use gasoline or other flammable vapors and liquid in the
vicinity of this or any other appliance.
FOR YOUR SAFETY
If you smell gas:
NORCOLD, Inc.
P.O. Box 4248
Sidney, OH 45365-4248
Owner's Manual
1. Open windows.
2. Don't touch electrical switches.
3. Extinguish any open flame.
4. Immediately call your gas supplier.
English
French
Norcold Customer Support Dept.
Telephone: 800-543-1219
Web Site: www.norcold.com
Part No. 623669E (7-04)
Fax: 937-497-3183
Advertisement
Table of Contents
Related Manuals for Norcold N400
Summary of Contents for Norcold N400
- Page 1 For model N400X - a 4.5 cu. ft., 2-way or 3-way, refrigerator. For model N510X - a 5.5 cu. ft., 2-way or 3-way, refrigerator. The model numbers of 3-way refrigerators include “.3”. The model numbers of 2-way mod- els do not.
-
Page 2: Table Of Contents
Ignition - propane gas operation ... 6 Do a test of the gas safety valve ... 6 Start up - AC operation ... 6 Start up - DC operation (N400.3 models) ... 6 Shut down ... 6 Operating the Refrigerator Controls (N510 models) ... 6 Control Panel ... -
Page 3: Gas Absorption Warranty Information
What will the refrigerator owner do? To obtain warranty service, the refrigerator owner responsibilities are: - To use, service, and maintain the refrigerator as specified in the Installation/Owner’s Manuals. - To deliver the warranted product to an authorized Norcold Service Center for warranty repair. -
Page 4: Safety Awareness
Food compartment: Ignite or start up the refrigerator and let it cool for eight hours before loading with food. If the refrigerator does not start to cool down after about two hours, contact your dealer or an authorized Norcold Service Center. -
Page 5: Flip-Up Shelf
[2] of the latch plate [3]. Temperature control system (N510 models): Although the refrigerator is not frost -free, it is made to limit frost on the cooling fins. At regular intervals, the temperature control system automatically melts most of the frost from the cooling fins. -
Page 6: Ignition - Propane Gas Operation
- Turn the selector switch to the AC position ( - Turn the thermostat to the temperature setting that you wish. Start up - DC operation (3-way model N400.3): - Make sure that 12 volts DC is available. - Turn the selector switch to the DC position (... -
Page 7: Automatic Mode Operation
To remove the air from the propane gas supply lines: - Make sure that all of the gas valves are open. - Push the ON / OFF button to turn the refrigerator on. - Push and hold the MODE button until the light bar beside LP GAS shows. -
Page 8: Set The Controls To Manual Mode Operation
You can reset the controls and remove this fault code one time. To reset the controls, shut off and then start the refrigerator. - To turn off the refrigerator, push the ON / OFF button for two seconds and then release. -
Page 9: Backup Operating System
For the refrigerator to operate correctly on DC power, the battery must be maintained in a fully charged condition. For the battery to be fully charged at all times during refrigerator operation on DC, the vehicle engine must be running and the battery charging system must be in good operating condition. -
Page 10: Refrigerator Care Checklist
- with any air leakage into the refrigerator. N510 models only: Although the refrigerator is not frost -free, it is made to limit frost on the cooling fins. At regular intervals, the temperature control system automatically melts most of the frost from the cooling fins. -
Page 11: Door Sealing
10.5 - 15.4 volts. - Make sure the thermocouple tip is clean and secure. - Make sure the area at the rear of the refrigerator is free of any combustible materials, gasoline, and other flammable vapors and liquids. -
Page 12: Refrigerator Maintenance
While in propane gas operation, examine the appearance of the gas flame: - On N400 models, turn the thermostat to the 5 position. - On N510 models, push and hold temperature setting button until the “9” shows and then release. -
Page 13: Reinstall The Refrigerator
7 ... Thermocouple interrupter 8 ... Flame meter 9 ... AC heater 10 ... -12 VDC Power supply (model N400.3) 11 ... +12 VDC Power supply (model N400.3) 12 ... 25 Amp fuse (model N400.3) 13 ... DC heater (model N400.3) -
Page 14: Wiring Diagram (N400 Models)
6 ... Gas safety valve 7 ... Thermocouple interrupter 8 ... Flame meter 9 ... AC heater 10 ... -12 VDC Com (model N400.3) 11 ... +12 VDC (model N400.3) 12 ... 25 Amp fuse (model N400.3) 13 ... DC heater (model N400.3) 14 ... -
Page 15: Fault Codes (N510 Models)
Fault Codes (N510 models) t l u t l u a t l a l i " " F a t l " " A a l i a t l " " " " n t i n a l f t l u "... - Page 16 Owner’s Manual 16...
- Page 17 Art01114...
- Page 18 Wiring pictorial (N400 models only) Schéma de câblage (modèles N400 seulement) Wiring pictorial (N510 models only) Schéma de câblage (modèles N510 seulement)
- Page 19 Wiring diagram (N400 models only) Schéma électrique (modèles N400 seulement) Wiring diagram (N510 models only) Schéma électrique (modèles N510 seulement)
