Norcold N300 Installation And Owner's Manual

2.7 cu. ft., 2-way or 3-way, refrigerator
Hide thumbs Also See for N300:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Service Manual, Installation & Owner's Manual
Installation and Owner's Manual
For model N300 - a 2.7 cu. ft., 2-way or 3-way, refrigerator.
WARNING:
nance can cause injury or property damage. Refer to this manual.
For assistance or additional information, contact a qualified in-
staller, service agency, or the gas supplier.
FOR YOUR SAFETY
Do not store or use gasoline or other flammable vapors and liquid in
the vicinity of this or any other appliance.
FOR YOUR SAFETY
If you smell gas:
WARNING:
DO NOT install this refrigerator in below deck
marine applications. Do not install this refrigerator in fixed
indoor cabin or other dwelling applications. This refrigerator
must use only NORCOLD designed and approved outside air
intake and exhaust ventilation for correct and safe operation.
Any other ventilation could cause lethal combustion exhaust
fumes and/or explosive propane gas fumes to be in the living
area and/or to be below deck.
NORCOLD, Inc.
P.O. Box 4248
Sidney, OH 45365-4248
Improper installation, adjustment, alteration, service or mainte-
1. Open windows.
2. Don't touch electrical switches.
3. Extinguish any open flame.
4. Immediately call your gas supplier.
English
French
Norcold Customer Support Dept.
Telephone: 800-543-1219
Web Site: www.norcold.com
Part No. 620840F (11-01)
Fax: 937-497-3183

Advertisement

Table of Contents
loading

Related Manuals for Norcold N300

Summary of Contents for Norcold N300

  • Page 1 Installation and Owner’s Manual For model N300 - a 2.7 cu. ft., 2-way or 3-way, refrigerator. WARNING: Improper installation, adjustment, alteration, service or mainte- nance can cause injury or property damage. Refer to this manual. For assistance or additional information, contact a qualified in- staller, service agency, or the gas supplier.

  • Page 2: Table Of Contents

    Table of Contents Warranty Policy Owner’s Manual ................ 2 Norcold • P.O. Box 4248 • Sidney, OH • USA • 45365-4248 Gas Absorption 3 Year Limited Warranty Policy ....2 Provided it is properly installed, properly maintained and placed Gas Absorption Warranty Information ......... 3 under normal service and use, Norcold, Inc.

  • Page 3: Gas Absorption Warranty Information

    Norcold Service Centers. If a problem occurs with your refrigerator, contact any of the Norcold has the option of replacing the defective parts or the service centers throughout the United States and Canada. To entire refrigerator.

  • Page 4: Safety Awareness

    Norcold authorized service center. before loading with food. If the refrigerator does not start to cool down after about two hours, contact your dealer or a Norcold - Disconnect both the AC and DC power sources before authorized service center.

  • Page 5: Freezer Compartment

    Freezer compartment: - Put foods that are more likely to freeze on the upper shelf. The freezer compartment is made to keep pre-frozen food The selector switch [2] changes the energy source of the frozen and not to quick freeze food. Keep pre-frozen foods in refrigerator between propane gas ( ), AC electric ( ), DC...

  • Page 6: Start Up - Dc Operation (3-Way Models Only)

    - Be aware of any cooling changes that are not because of Start up - DC operation (3-way models only): weather, loading, or gas control changes. If changes occur, contact your dealer or service center. - Make sure that 12 volts DC is available. - Make sure the gas supply is propane gas only and not - Turn the selector switch to the DC position ( butane or a butane mixture.

  • Page 7: Door Sealing

    - Close the burner box door. Norcold authorized service center. Remove and clean the burner orifice: Have a qualified RV dealer or a Norcold authorized service center do these annual safety and maintenance checks: NOTE: Your dealer or Norcold authorized service center must - Examine the gas supply lines for leaks.

  • Page 8: Remove The Refrigerator

    Do not try to remove the orifice [3] from the orifice adapter [4] when cleaning. Removal will damage the orifice and seal of the orifice and can NOTE: Your dealer or Norcold authorized service center must cause a propane gas leak. Leaking propane gas can do this procedure.

  • Page 9: Wiring Pictorial

    You may purchase replacement parts through your local RV supply system. Do not use an open flame to examine dealer or authorized Norcold Service Center. the gas supply piping or fittings for leaks. - To avoid possible propane gas leaks, always use two wrenches to tighten or loosen the gas suppy line connections.

  • Page 10: Certification And Code Requirements

    Propane Appliances and Equipment. refrigerator will not cool correctly. - Current CSA Z240.4.2 Installation Requirement for Propane Each NORCOLD model is certified by AGA and CGA for correct Appliances and Equipment in Recreational Vehicles. ventilation. - Current CSA Z240.6.2/C22.2 No. 148 Electrical Requirement for Recreational Vehicles.

  • Page 11: Assemble The Enclosure

    - Make sure the baffle is the full width of the inside of Assemble the Enclosure the enclosure. - If the construction of the vehicle does not allow the - Make sure the enclosure is 29 3/4 inches high x 20 1/2 distance [4] to be 37 inches, the distance (optional inches wide x 21 3/8 inches deep.

  • Page 12: Install The Refrigerator

    - Turn out and save the upper hinge pin [1]. Install the Refrigerator - Open the door a small amount and pull the top of the door 1. Make sure the clearance at the rear of the refrigerator is away from the upper hinge of the refrigerator. correct: - Lift the door off of the lower hinge pin [2].

  • Page 13: Connect The Electrical Components

    This refrigerator operates on propane gas at a pressure of 11 inches Water Column Propane. 1. For the best performance, Norcold recommends that you use the following wire and fuse sizes: Connect the propane gas supply system:...

  • Page 14: Examine The Gas Supply System For Leaks

    - Do not use an open flame to examine for leaks. - Do not connect the refrigerator to the gas tank without a pressure regulator between them. - To avoid an propane gas leak, always use two wrenches to tighten or loosen the gas supply line connections.
