- Page 1 ERK-135EL MODEL # SMART COFFEE TABLE WITH ALL-IN-ONE REFRIGERATOR DRAWERS In case you might need to return this product, please keep all the packaging materials and return only in its original packaging and in excellent condition. 如需退货请保留好所有包装材料，并按原包装包好退回。...
- Page 2 PARTS & FEATURES/各部件名称 Tempered Glass Top 钢化玻璃台面 Wireless Charger 无线充电模块 Control Panel 电子温控操作界面 TYPE C PET Tray TYPE C 插口 塑料托盘 Left Refrigerator Drawer 左冷藏室 Partition 隔板 USB插口 Right Refrigerator Drawer 右冷藏室 110V Socket Water Inlet 110V插座 冰水上水接口 Bluetooth Speaker 蓝牙音响...
- Page 3 SPECIFICATIONS/技术参数 17.9" 51" 27.7" Consumption Packing Size 160kWh/year 55.9'' x 32.3'' x 22.4'' 耗电量 包装尺寸 Noise Level Temp Control Electronic Control 36db 噪音 控温方式 电子控温 Voltage Refrigeration Mode Compressor 110V-120V/60HZ 输入电压 制冷方式 压缩机／直冷 Net Weight Refrigerant/Wt 122.5 lbs R600a /25g 净重...
- Page 4 NOTICE/安全注意事项 NOTICE ELECTRIC WARNINGS / 电气方面 1. After powering on the unit, please install the cable cover to prevent any damage of the cable. Do not step on the cable, otherwise it will raise the risk for electric leakage. 2. The power cord should be kept in firm contact with the power source. Failure to do so may result in property damage, personal injury or fire.
- Page 5 WIRELESS CHARGER / 无线充电装置 1. If the device is equipped with a thick protective shell or a metal protective shell, the charging efficiency may be affected. Remove the shell and try again. 2. The wireless charger may generate heat when charging. If the battery overheats, the software may limit the charging. It will begin to charge once the temperature drops.
- Page 6 重复： 静置2个小时后再插电使用。 Use proper lifting technique! Exercise caution! If you have a history of back pain or injury, do not attempt to lift table. Eureka, LLC will not accept responsibility for any injury that may occur during set up process.
- Page 7 FUNCTION AND FEATURES/主要功能及特点 Left Refrigerator Drawer 37.4°F-46.4°F Right Refrigerator Drawe 42.8°F-53.6°F 左冷藏室 3℃-8℃ 右冷藏室 6℃-12℃ REFRIGERATOR DRAWERS / 冷藏存储室 The Smart Coffee table is designed with two drawers that can be independently controlled for the temperatures. Each refrigerator drawer comes with two partitions and one tray to organize all your favorite beverages and snacks. 冰箱茶几有两个抽屉，...
- Page 8 PARTITION STORAGE / 分区存储 To make better use of the storage space, there are two partitions and a tray in the refrigerator drawer, which facilitate the classification and storage of food. 为了更有效地利用存储空间， 每个抽屉里有两个隔板和可以左右滑动的盒子， 方便食物分区存放。 REMOVABLE DOOR SEAL / 可拆卸门封条 The removable door seal will ensure the long-term sealing of the Smart Coffee Table, making it easy for daily cleaning and maintenance, and reducing energy consumption.
- Page 9 USER GUIDE/使用说明 REFRIGERATOR DRAWER / 冷藏室 NOTE / 注意事项 1. Fill this refrigerator only with fresh food. 2. Do not store food that requires the refrigerator to outperform its designed temperature range. 3. Do not store food while it is hot. This would drive up the drawer temperature, thus affecting all other items inside. 4.
- Page 10 CONTROL PANEL INSTRUCTION / 控制区说明 The display area is divided into two parts. The refrigerator control area is above the horizontal line, the speaker operation area is below the horizontal line. Double-click the “Refri Unlock” button on the refrigerator, allowing you to use other fridge buttons.
- Page 11 REFRIGERATOR OPERATION / 冰箱模式操作 Display Area Eco Mode Left Door Temp.Adjust Right Door Temp.Adjust Refri.Unlock Light Circle Temp./Mode Display 智能模式 左冷藏温度调节 右冷藏温度调节 冰箱解锁 光圈 数码显示管 After the initial power-up, the refrigerator automatically enters unlock mode. If there is no operation in 10 s, the buttons will be locked. 初次上电，...
- Page 12 SPEAKER INSTRUCTION / 音响操作 DISPLAY 音响显示 Start Speaker Mute Switch 启动音响 静音切换 Light Circle 光圈 Music Mute Speaker Unlock Volume Down Volume Up Lamp Switch Sound Effects Play/Stop Switch 减音量 加音量 氛围灯开关 音效模式 音响解锁 音乐静音切换 暂停/播放 SPEAKER / 音响的开启： In off mode, click the unlock button , and the buzzer rings and the white aperture will be on, which means the speaker is switched on.
- Page 13 SPEAKER OFF / 音响的关闭: Press and hold “ ” for 6s, during which , the nixie tube will display OFF for 1s, and the circle will light up in 3s. The aperture nixie tube and the speaker will turn off, and there will be a prompt note when the speaker turn off. 长按...
- Page 14 Voltage / 输入电压 12V Input/12V输入 Output / 输入功率 15W (max) Sensing Distance / 感应距离 ≤4mm Work Frequency / 工作频率 105K-205K Hz Work Temperature / 工作温度 14℉-149℉ Work Humidity / 工作湿度 10%RH-75%RH USB-A AND TYPE C CHARGING / 手机充电插口 There are two USB-A and one TYPE C chargers that can connect devices to the speaker and charge device. 冰箱茶几有2个USB和1个type C 充电插口，...
- Page 15 DAILY MAINTENANCE/日常保养与维护 CLEANING / 清洁 Clean the Smart Coffee Table regularly to avoid dust accumulation. Wipe the surface of the table with the microfiber cloth. Do not store expired food in the drawers. 1.Before cleaning the Smart Coffee Table, please make sure to turn off the power and remove the plug.
- Page 16 DISASSEMBLY AND CLEANING OF THE REFRIGERATOR DRAWER / 冷藏保鲜抽屉的拆卸清洁 Before dismantling the refrigerator drawer, please take out the PET tray, drawer partition and all items inside from the refrigerator. Fully pull the door and the drawer, lift up the whole drawer and pull out the sets. You can use water to wash the drawer, PET tray, partition, and then use soft cloth to dry them.
- Page 17 DELIVERY AND OUTAGE / 搬运和停用 TRANSPORTATION / 冰箱茶几的搬运 1. Unplug the product. 2. Take out all the items inside the Smart Coffee Table. 3. Use adhesive tape to secure the partition and PET tray inside the Smart Coffee Table. 4. Close the drawer and use adhesive tape to secure it. 1.
- Page 18 NON-FAILURE / 非故障现象 Foggy condensation on the surface: In rainy season with high humidity, condensation may occur on the surface of the refrigerator, which is not a malfunction, please dry it with a clean cloth. 冰箱茶几外表面出现雾状凝露： 在湿度非常大的季节， 如雨季等， 可能在箱外发生凝露现象， 这和冰水注入玻璃杯使其外侧发生凝露现象 相同，...
- Page 19 TROUBLE SHOOTING / 故障排除 Fault / 故障现象 Causes / 产生原因 Solutions / 排除方法 Power light is on, compressor is working but making Power Voltage is lower than 90V. "humming" sound. 电源电压低于90V 电源指示灯亮， 压缩机不正常工作， 只有嗡嗡声 Stop powering on the refrigerator and wait the voltage to get back to normal.
- Page 20 PRECAUTION BEFORE USE ‒ UNPACKING/使用前注意事项 For better heat dissipation, remove the foam base, peel off the adhesive tape and the transparent film from the surface of the table. Failure to do so may result in personal injury or property damage. 拆除泡沫底座及固定用的胶带并将冰箱茶几表面的透明覆膜撕掉，...
