Revoria Press SC180
Revoria Press SC170
User's Manual
Before using the machine, please read this manual thoroughly. Be sure to keep this manual for future reference.
This manual may not be edited, modified or copied in whole or part without the written consent of the publisher.
■
Some parts of this manual are subject to change without prior notice.
■
The screen shots and the illustrations in this manual are used as examples. They may differ from yours depending
■
on the model, the software, or the OS
Control Panel
„ Features of Control Panel
Pressing the Home button displays the Home screen.
1.
Power/Power Saving button
The power switches on.
Note
When Please wait...
"
■
chine is warming up. The use of machine is
not available during this time.
If the power does not switch on, confirm
■
that the power plug is inserted.
2. NFC touch area
This is an area for you to hold up your NFC-supported
mobile devices over. To communicate interactively, the
NFC function of this machine needs to be enabled.
3. Data indicator
This indicator blinks while data is being sent from the
machine or data is being received from the client com-
puter.
Also, this indicator lights up when documents are saved
in the machine.
4. Status display lamp
The lamp lights up in green at an instant of operation
reception. When an error occurs, the lamp blinks in
orange.
5. Login
The user is authenticated when the user enters the
User ID and logs in.
When the user is logged in with the administrator
rights, [Administrator] is shown in this area. While the
user is authenticated, tapping on the authentication
information display area logs out the user, and the state
becomes as unauthenticated.
The PDF manual is available by clicking
the help of Internet Services.
https://product1.iotconnectup.com/webui_help/global/revoria_press_sc180/en/top.html
.
Home Button
is displayed, the ma-
"
[Apps]
5
1
6
[Pause]
2
3
4
6. Opening menu
Tap this to open the menu for change and check of the
settings of the machine.
Tap on [<] to close the menu.
7.
Home Screen
Apps/Pins/Address Screens can be displayed.
• [Apps]
: You can tap on any of the application icons
and use its functions.
• [Pins]
: You can execute a job again using Job Direc-
tion History and the job direction history of which pin
is created with [Create Pin] by user. If you create a
pin of the job direction history, you can also directly
activate a job without opening an application.
• [Address]
: You can register addresses and other
information. You can activate an application from a
registered address.
After activating an application, the selected address
is set as the destination of the application.
PDF Manuals on
" "
June 2023 GM1829E5-2 Edition 1
[Pins] [Address]
7
