Dear Customer,
Thank you for choosing this quality product from ASKO.
We hope it will meet your expectations and fulfi l your needs for many years to
come.
Scandinavian design combines clean lines, everyday functionality and high
quality. These are key characteristics of all our products and the reason they are
greatly appreciated throughout the world.
To get the most out of your new machine, we recommend that you read the
operating instructions before using the machine. The operating instructions also
include information on how you can help protect the environment.
Operating Instructions
Washing Machine
ASKO W6564W-NOR
WARNING: Read the instructions before using the machine.
Advertisement
Table of Contents
Related Manuals for Asko W6564W-NOR
Summary of Contents for Asko W6564W-NOR
- Page 1 Dear Customer, Thank you for choosing this quality product from ASKO. We hope it will meet your expectations and fulfi l your needs for many years to come. Scandinavian design combines clean lines, everyday functionality and high quality. These are key characteristics of all our products and the reason they are greatly appreciated throughout the world.
-
Page 2: Table Of Contents
Contents Before using your machine for the High water level fi rst time Economy and effi ciency Transport protection Detergents Packing material Dyeing fabrics Washer door Washing Checking water hardness Sort your laundry Safety instructions Turn on the main power switch General Open the washer door and load the washing... - Page 3 Contents Troubleshooting The washer door will not open The machine will not start After power failure Wet washing still in the machine Error messages Technical information Information on energy labelling Information for test institute Technical data Transport protection Installation Positioning the washing machine Adjusting the feet Connection to water supply Drainage connection...
-
Page 4: Before Using Your Machine For The Fi Rst Time
Before using your machine for the fi rst time Transport protection Remove any transport protection devices before installing the machine. See the "Transport protection" chapter. Packing material Please sort waste materials in accordance with local guidelines. Washer door • The washer door cannot be opened until the machine is connected to the electricity supply. -
Page 5: Safety Instructions
Safety instructions they do not play with the machine. General • The emergency door opening tool is • Read the operating instructions and attached to the rear of the detergent keep them in a safe place. compartment. Remove the detergent •... -
Page 6: Recycling
Recycling This machine is manufactured and labelled for recycling. In order to prevent injuries, the machine must be made unusable once the decision has been taken to dispose of it. Contact your local authority for information about where and how your machine can be recycled correctly. -
Page 7: Child Safety
Child safety Keep an eye on children! • Always close the washer door and start the programme immediately after you have added detergent. • Do not allow small children to use or play with the washing machine. • Store detergent and fabric softener out of the reach of children. -
Page 8: Description Of The Washing Machine
Description of the washing machine 1. Main power switch 2. Dispenser 3. Programme panel 4. Serial number plate (on inside of washer door) 5. Drainage pump cover 6. Drainage pump (behind cover) 7. Washer door... -
Page 9: Dispenser
Dispenser 1. Pre-wash 2. Main wash with liquid detergent. Use the separator (A). 3. Main wash with powder detergent. Do not use the separator. 4. Fabric softener 5. Release button 6. Child safety catch... -
Page 10: Advice And Tips Before Washing
Advice and tips before washing Here are some tips that may help you before washing. Sorting your laundry Sort items according to: • how soiled they are • colour • material Clothing 1. Do up zips and close Velcro straps so that they don’t harm fabrics. -
Page 11: Wool
Advice and tips before washing Wool • Select Quick if you just need to freshen up These fabrics are labelled either machine wash shirts or exercise clothes, for example. This or hand wash. The Wool/hand wash programme will save both water and energy. is at least as gentle as washing by hand. -
Page 12: Washing
Washing Sort your laundry Powder detergent See the "Advice and tips before washing" Pour the powder into the compartment for the chapter. Place underwired bras in a main wash, and pre-wash as well if desired. laundry net. Empty pockets. Coins, nails and the like can Liquid detergent cause damage to the machine and fabrics. -
Page 13: Select The Programme
Washing Select the programme 4. Eco (Everyday wash) You select a programme by turning A standard programme for lightly to moderately the programme selector. An LED lights soiled laundry. The temperature can be selected up beside the selected programme and the freely, so follow the washing instructions for estimated programme time is shown on the each garment. - Page 14 Washing 8. Wool/hand wash A gentle laundry programme for wool, silk and garments that should be washed by hand. The highest temperature is 30°C. This programme has a short spin. The maximum spin speed is 800 rpm. 9. Rinse This program performs one cold rinse cycle + spin.
- Page 15 Washing Programme chart Program 1. Auto 2. Heavy 1600 2:45 1600 2:40 1600 2:55 40 °C 60 °C 3. Standard cotton 1600 8/4** 1,10/0,87** 2:50/2:20** 1600 8/4** 0,67/0,52** 2:40/2:10** 4. Eco (Everyday wash) 1600 1:40 5. Quick 1600 0:45 6. Easy Care 1200 1:40 7.
-
Page 16: Select Options
Washing 40° 95° 1600 30° 60° 1200 20° 50° Select options machine. The washing will remain covered You can select options to adjust the by the water from the fi nal rinse, stopping it wash programme to suit your own from getting creased. - Page 17 Washing Super rinse Use the Super Rinse option if you want to increase the number of rinses. The maximum number of rinses is seven, and the number of rinses varies depending on the selected programme. Recommended for persons with extremely sensitive skin and/or in areas with very soft water.
-
Page 18: Close The Washer Door And Press The Start/Stop Button
Washing Close the washer door and Once the program has fi nished press the Start/Stop button The text "End" is shown on the display for 2 minutes. The machine then turns off . The washer door opens automatically once the programme has fi nished. If you want to deactivate the automatic door opening function, see the "Selecting settings"... -
Page 19: Settings
Settings You can change the following settings: • Automatic door opening. • Extra rinses. Door opening If you choose Automatic door opening the Washer door will open once the programme has fi nished. 1. Turn off the machine using the main power switch. -
Page 20: Care And Cleaning
Care and cleaning Cleaning the trap and the drainage Cleaning the detergent compartment pump Pull out the detergent compartment using the The washing machine has a trap where smaller release button. objects such as coins and hairpins can collect. To clean the trap and the drainage pump, do as follows: 1. -
Page 21: Cleaning The Inside Of The Machine To Avoid Unpleasant Smells
Care and cleaning Cleaning the inside of the machine to 5. Place the agitator in the mounting hole with avoid unpleasant smells the F-mark towards you. Ensure that all the Modern detergents often allow clothes to be agitator fasteners are in their holes in the washed at low temperatures. -
Page 22: Troubleshooting
Troubleshooting The washer door will not open D Push the tool upwards to open the washer 1. Check that the main power switch is on. door. 2. Is there power? Check your home’s fuses (circuit breakers). The washer door cannot be opened with the door opening button (with the key symbol) if power is off... -
Page 23: Error Messages
Troubleshooting Error messages F12 Water inlet fault If an error occurs during the programme a Check: message is shown on the display. To exit the • that the tap on the water pipe is open. message after taking measures, turn the •... -
Page 24: Technical Information
Technical information Information on energy labelling Information sheet, in compliance with Commission Delegated Regulation (EU) No. 1061/2010 ASKO Model designation: W6564W-NOR Max. washing capacity: 8 kg Energy effi ciency class: A+++ Annual energy consumption (AE 196 kWh per year Energy consumption Standard cotton 60 °C with full load (E... -
Page 25: Information For Test Institute
Technical information Information for test institute Program Max. load Temp. °C Auto 2) 3) Standard cotton 40 °C 60 °C Easy Care 1) Short programme for test institutes, max. 1/2 load. 2) Test programme for cold water connection in accordance with EN 60456. 3) 40°C programme for test institutes. -
Page 26: Transport Protection
Transport protection Remove the three transport bolts and the plastic 3. Remove the plastic covers from the plugs. plugs for locking the machine for transport Push the plastic covers into the three holes before using the machine. that contained the plugs. Save the plastic plugs in case the machine is moved in the future. -
Page 27: Installation
Installation Positioning the washing machine Connection to water supply The washing machine can be installed as a Water connection should be carried out by an built-in or freestanding unit. Place the machine appropriately qualifi ed person. Connect the on a fi rm surface with easy access to the plug. machine using the accompanying supply hose. -
Page 28: Drainage Connection
Installation Drainage connection Electrical installation The machine is supplied with a drainage hose Connect the machine by plugging it into an attached, which must be connected to a drain. earthed wall socket. The electrical wall socket See the examples below. The height must be must be placed outside of the installation area 600-900 mm above fl... -
Page 29: Service
Service Before contacting the service division Model designation Before you contact the service division, make sure that you know the model designation, type designation and serial number. The model designation can be found on the panel. The type designation and serial number Type plate can be found on the type plate on the inside of the washer door. - Page 30 Your notes...
- Page 31 Your notes...
-
Page 32: Quick Guide
CLOSE THE WASHER DOOR AND PRESS THE START BUTTON The time remaining is shown in hours and minutes. We reserve the right to make changes. Gorenje, Partizanska 12, 3320 Velenje, Slovenija www.asko.com WM70.1 W6564W-NOR en (11-16)
