DIGITAL MULTIFUNCTIONAL SYSTEM
Safety Guide
Safety Guide
Safety Guide
Before installing this product, be sure to read the
"CAUTIONS" and "INSTALLATION
REQUIREMENTS" sections.
Keep this manual close at hand for reference
whenever needed.
MODEL:
CAUTIONS
INSTALLATION REQUIREMENTS
SUPPLIES
SPECIFICATIONS
TO THE ADMINISTRATOR OF THE MACHINE
MX-M283N
MX-M363N
MX-M453N
MX-M503N

Advertisement

Table of Contents
loading

Related Manuals for Sharp MX-M503

Summary of Contents for Sharp MX-M503

  • Page 1 DIGITAL MULTIFUNCTIONAL SYSTEM Safety Guide Safety Guide Safety Guide Before installing this product, be sure to read the "CAUTIONS" and "INSTALLATION REQUIREMENTS" sections. Keep this manual close at hand for reference whenever needed. MODEL: MX-M283N MX-M363N MX-M453N MX-M503N CAUTIONS INSTALLATION REQUIREMENTS SUPPLIES SPECIFICATIONS TO THE ADMINISTRATOR OF THE MACHINE...
  • Page 2 Model Number Serial Number Date of Purchase Place of Purchase Authorized Sharp Printer Service Department Number Notice for Users in U.S.A. EMC (this machine and peripheral devices) WARNING: FCC Regulations state that any unauthorized changes or modifications to this equipment not expressly approved by the manufacturer could void the user's authority to operate this equipment.

  • Page 3: Table Of Contents

    SHARP Service Department. • Aside from instances provided for by law, SHARP is not responsible for failures occurring during the use of the product or its options, or failures due to incorrect operation of the product and its options, or other failures, or for any damage that occurs due to use of the product.

  • Page 4: Cautions

    If a piece of metal or water enters the machine, switch off the main power and remove the power plug from the power outlet. Contact your dealer or nearest SHARP Service Department. Using the machine in this condition may result in electrical shock or fire.
  • Page 5 To prevent the loss of important documents in the unlikely event of a hard drive failure, keep the originals of important documents or store the original data elsewhere. With the exception of instances provided for by law, Sharp Corporation bears no responsibility for any damages or loss due to the loss of stored document data.

  • Page 6: Laser Information

    KLASS 1 LASERAPPARAT THIS PRODUCT CONTAINS A LITHIUM PRIMARY MEMORY BACK-UP BATTERY THAT MUST BE DISPOSED OF PROPERLY. PLEASE CONTACT YOUR LOCAL SHARP DEALER OR AUTHORIZED SERVICE REPRESENTATIVE FOR ASSISTANCE IN DISPOSING OF THIS BATTERY. This product utilizes a CR coin Lithium battery which contains a Perchlorate material. Special handling for this material may apply, California residents, See www.dtsc.ca.gov/hazardouswaste/perchlorate/...

  • Page 7: Installation Requirements

    INSTALLATION REQUIREMENTS The performance of the machine is affected by the ambient conditions of the installation location. Do not install in the following locations: CAUTION: Do not install the machine in a location with poor air circulation. A small amount of ozone is created inside the machine during printing.

  • Page 8: Supplies

    Standard supplies for this product that can replaced by the user include paper, toner cartridges, and staple cartridges for the finisher. Be sure to use only SHARP-specified products for the toner cartridges, finisher staple cartridge, saddle stitch finisher staple cartridge, and transparency film.

  • Page 9: Specifications

    Plain paper (16 lbs. to 28 lbs. (60 g/m 110 lbs. index (106 g/m to 209 g/m )) 500 sheets, heavy paper 200 sheets SHARP-recommended plain paper, recycled paper, colored paper, and heavy paper to 105 g/m )), heavy paper (28 lbs. bond to...
  • Page 10 Paper weight: Plain paper (16 lbs. to 28 lbs. (60 g/m Paper types: SHARP-recommended plain paper, recycled paper, colored paper, and heavy paper Output method: Face-down output (12" x 18" and A3W paper can be output to right tray, finisher, or Output capacity: 400 sheets (using SHARP-recommended 8-1/2"...

  • Page 11: Continuous Copying Speeds

    Continuous copying speeds* Model Copy ratio 11" x 17", A3, 8K 8-1/2" x 14", 8-1/2" x 13-1/2", 8-1/2" x 13-2/5", 8-1/2" x 13", 8-1/2" x 11", A4, B5, 16K 8-1/2" x 11"R, 7-1/4" x 10-1/2"R, A4R, B5R, 16KR * Copy speed during output of the second copy and following copies when performing continuous one-sided copying of the same page (excluding offset output) using plain one-sided paper from a tray other than the bypass tray.

  • Page 12: Acoustic Noise Emission (Measurement According To Iso7779)

    SPECIFICATIONS Acoustic noise emission (measurement according to ISO7779) Sound power level L Printing mode (continuous printing) Standby mode Sound pressure level L (actual measurement) Bystander positions Printing mode Operator positions Bystander positions Standby mode Operator positions Emission concentration (measurement according to RAL-UZ122: Edition Jun. 2006) Measured substance Machine state Ozone...

  • Page 13: Exit Tray Unit (Right Tray) Specifications

    Output method Face-down output Output capacity* 100 sheets (using SHARP-recommended 8-1/2" x 11" or A4 paper) When tray is folded up: 12-23/64" (W) x 15-61/64" (D) x 2-3/64" (H) (314 mm (W) x 405 mm (D) x 52 mm (H))

  • Page 14: Stand/2X500 Sheet Paper Drawer Specifications

    Paper capacity 500 sheets (21 lbs. (80 g/m Paper types SHARP-recommended plain paper, recycled paper, and colored paper When "Auto-Inch" detection is selected: Automatic paper size 11" x 17", 8-1/2" x 14", 8-1/2" x 11", 8-1/2" x 11"R, 7-1/4" x 10-1/2"R detection When "Auto-AB"...

  • Page 15: Note

    Finisher specifications Model MX-FNX9 12" x 18", 11" x 17", 8-1/2" x 14", 8-1/2" x 13-1/2", 8-1/2" x 13-2/5", 8-1/2" x 13", 8-1/2" x 11", Paper sizes 8-1/2" x 11"R, 7-1/4" x 10-1/2"R, 5-1/2" x 8-1/2"R, envelopes, A3W, A3, B4, A4, A4R, B5, B5R, A5R, 8K, 16K, 16KR Thin paper (15 lbs.

  • Page 16: Finisher (Large Stacker) Specifications

    SPECIFICATIONS Finisher (large stacker) specifications* Model MX-FN11 12" x 18", 11" x 17", 8-1/2" x 14", 8-1/2" x 13-1/2", 8-1/2" x 13-2/5", 8-1/2" x 13", 8-1/2" x 11", Paper sizes 8-1/2" x 11"R, 7-1/4" x 10-1/2"R, 5-1/2" x 8-1/2"R, envelopes, A3W, A3, B4, A4, A4R, B5, B5R, A5R, 8K, 16K, 16KR Thin paper (15 lbs.

  • Page 17: Saddle Stitch Finisher Specifications

    Saddle stitch finisher specifications* Model MX-FN10 12" x 18", 11" x 17", 8-1/2" x 14", 8-1/2" x 13-1/2", 8-1/2" x 13-2/5", 8-1/2" x 13", 8-1/2" x 11", 8-1/2" x 11"R, Paper sizes 7-1/4" x 10-1/2"R, 5-1/2" x 8-1/2"R, envelopes, A3W, A3, B4, A4, A4R, B5, B5R, A5R, 8K, 16K, 16KR Thin paper (15 lbs.

  • Page 18: Punch Module Specifications (For Finisher)

    SPECIFICATIONS Punch module specifications (for finisher) Model MX-PNX1B Hole punching 3 holes or 2 holes 3 holes: Allowed paper sizes for 11" x 17", 8-1/2" x 11", A3, A4 punching 2 holes: 8-1/2" x 14", 8-1/2" x 13-1/2", 8-1/2" x 13-2/5", 8-1/2" x 13", 8-1/2" x 11"R, 7-1/4" x 10-1/2" Punchable paper weights 15 lbs.

  • Page 19: Printer Specifications

    Printer specifications Type Built-in Same as continuous copying speed (When printing same document continuously on 8-1/2" x 11" Continuous printing speed (A4) plain paper in non-offset mode, excluding processing time.) Printing resolution 600 x 600 dpi / 1200 x 1200 dpi Printer driver type PCL5e, PCL6, PostScript 3 compatible* Supported protocols...

  • Page 20: Network Scanner / Internet Fax Specifications

    SPECIFICATIONS Network scanner / Internet Fax* Type Built-in 100 x 100, 200 x 200, 300 x 300, 400 x 400, 600 x 600 Scanning resolution (dpi) Internet Fax: 200 x 100, 200 x 200, 200 x 400, 400 x 400, 600 x 600 (200 x 100, 200 x 200 when file type is TIFF-S) Halftone can be selected for resolutions other than 200 x 100 dpi.

  • Page 21: Pull Scan Function (Twain) Specifications

    Pull scan function (TWAIN) specifications Supported protocol TCP/IP (IPv4) Supported client PC Windows 98 / Me / 2000 / XP / Server 2003 / Vista/ Server 2008 operating systems Color modes Full Color, Grayscale, Mono Diffusion, Mono 2 gradation 75 dpi, 100 dpi, 150 dpi, 200 dpi, 300 dpi, 400 dpi, 600 dpi Resolution settings (The resolution can be specified by entering a numerical value from 50 to 9600 dpi.

  • Page 22: Facsimile Specifications

    SPECIFICATIONS Facsimile specifications Model MX-FXX2 Applicable telephone line Public switched telephone network, PBX Scanning resolution 8 x 3.85 lines/mm (Standard), 8 x 7.7 lines/mm (Fine, Fine-Halftone), 8 x 15.4 lines/mm (Super Fine, Super Fine - Halftone), 16 x 15.4 lines/mm (Ultra Fine, Ultra Fine - Halftone) (supports ITU-T standards) Transmission speed...
  • Page 23 Information that the administrator of the machine requires is printed on the back of this page. (Separate this page from the manual and keep it in a safe place. In addition, fill in the name of the administrator and the administrator's contact information in the left hand margin.)

  • Page 24: To The Administrator Of The Machine

    TO THE ADMINISTRATOR OF THE MACHINE (Separate this page from the manual and keep it in a safe place.) Factory default passwords When accessing the system settings, the administrator password is required to log in with administrator rights. The system settings can be configured in the Web pages as well as on the operation panel. To access the system settings using the Web pages, a password is also required.

  • Page 25: For The Users Of The Fax Function

    For the users of the fax function ABOUT THE TELEPHONE CONSUMER PROTECTION ACT OF 1991 The Telephone Consumer Protection Act of 1991 makes it unlawful for any person to use a computer or other electronic device, including FAX machines, to send any message unless such message clearly contains in a margin at the top or bottom of each transmitted page or on the first page of the transmission, the date and time it is sent and an identification of the business or other entity, or other individual sending the message and the telephone number of the sending machine or such business, other entity, or individual.
  • Page 26 This equipment may not be used on coin service provided by the telephone company. Connection to party lines service is subject to state tariffs. Contact your state's public utility commission, public service commission or corporation commission for more information. Sharp Electronics Corporation 1 Sharp Plaza, Mahwah, NJ 07495...
  • Page 27 Sharp. You should be aware, however, that Sharp does not itself extend any warranties, either express or implied, directly to you, the end-user, and no one is authorized to make any representations or warranties on behalf of Sharp.
  • Page 28 5. L'indice d'équivalence de la sonnerie (IES) de cet équipement est indiqué sur le kit d'extension télécopieur. Sharp Electronics of Canada Ltd. 335 Britannia Road East, Mississauga, Ontario, L4Z 1W9 Canada...

  • Page 29: Trademark Acknowledgments

    • IBM, PC/AT, and PowerPC are trademarks of International Business Machines Corporation. • Sharpdesk is a trademark of Sharp Corporation. • Sharp OSA is a trademark of Sharp Corporation. • RealVNC is a trademark of RealVNC Limited. • All other trademarks and copyrights are the property of their respective owners.
  • Page 32 SHARP ELECTRONICS CORPORATION 1 Sharp Plaza, Mahwah, New Jersey 07495-1163. www.sharpusa.com SHARP ELECTRONICS OF CANADA LTD. 335 Britannia Road East, Mississauga, Ontario, L4Z 1W9 PRINTED IN CHINA This manual has been printed using a vegetable-based soy oil ink 2009E to help protect the environment.
