Poly TRIO C60 Manual Reconfiguration Procedure
WARNING: THIS PROCEDURE DESCRIBES HOW TO MANUALLY RECONFIGURE A POLY TRIO C60 IP DEVICE
TO WORK ON THE BROADSOFT BROADCLOUD PBX NETWORK. ONCE THIS PROCEDURE HAS BEEN
COMPLETED, ANY PRIOR CONFIGURATION SETTINGS ON THE DEVICE WILL BE OVERRIDDEN, INCLUDING
THE ADMINISTRATOR PASSWORD, AND THE DEVICE WILL ONLY BE USABLE ON THE BROADSOFT
BROADCLOUD PBX NETWORK. THE DEVICE MUST BE RETURNED TO THE POLYCOM FACTORY DEFAULT
CONFIGURATION BEFORE IT CAN BE USED ON ANY NETWORK OTHER THAN BROADSOFT BROADCLOUD
PBX.
Reset the phone to Factory Defaults before continuing.
1. Touch the Home icon on the touchscreen
2. Select "Settings" by touching the corresponding icon on the screen
3. Select "Advanced" by touching the corresponding icon on the screen
4. At the password prompt, enter key in 456 then press the green Enter tick icon.
Note:
• If the password is a known value other than 456, then enter that value instead
• If the password is not 456 and the actual password is not known, then the remainder of
this procedure cannot be performed, and the device cannot be modified for use in the
BroadSoft BroadCloud PBX network.
5. On the touchscreen, select "Administration Setting"
6. On the touchscreen, select "Network Configuration"
7. On the touchscreen, select "Provisioning Server"
8. On the touchscreen, select "DHCP Menu"
9. On the touchscreen, select "Boot Server"
10. On the touchscreen, select "Static"
11. Touch "Return" arrow to return to the "Provisioning Server" menu
13. On the touchscreen, select "Server Type:"
14. On the touchscreen, select "HTTPS" and back to "Provisioning Server" menu
15. On the touchscreen, select "Server Address:"
