www.ti.com
4
Bill of Materials, PCB Layout, and Schematics
This section contains the MUX36D04EVM-PDK
4.1
Bill of Materials
Table 5
lists the MUX36D04EVM-PDK BOM.
Manufacturer Part Number
Qty
Reference Designators
PA020
1
PCB1
C3216X5R1E476M160AC
2
C1, C4
GMK316AB7106KL
2
C2, C5
C3216X7R1H105K
2
C3, C6
GRM188R72A104KA35D
2
C7, C10
C1608C0G2A101J
2
C8, C9
N/A
3
FID1, FID2, FID3
SJ-5303 (CLEAR)
4
H1, H2, H3, H4
TSM-102-01-L-SV
2
J1, J13
J2, J6, J7, J8, J9, J10, J11,
5-1814832-1
10
J12, J14, J15
TSM-103-01-L-SV
3
J3, J4, J5
OSTTE100161
1
J16
39357-0003
1
J18
THT-14-423-10
1
LBL1
R1, R2, R3, R4, R5, R6, R7,
ERJ-6GEY0R00V
8
R8
SH-J1, SH-J3, SH-J4, SH-J5,
969102-0000-DA
5
SH-J13
5005
3
TP1, TP10, TP11
TP2, TP3, TP4, TP5, TP6,
5006
7
TP7, TP8
5008
3
TP9, TP21, TP22
TP12, TP14, TP18, TP20,
5122
8
TP23, TP24, TP25, TP26
5009
3
TP13, TP15, TP16
5007
2
TP17, TP19
MUX36D04IPWR
1
U1
SBAU255A – January 2016 – Revised March 2016
Submit Documentation Feedback
bill of materials
(BOM),
PCB
layout, and
Table 5. Bill of Materials
Manufacturer
Any
Printed Circuit Board
TDK
CAP, CERM, 47 µF, 25 V, +/- 20%, X5R, 1206
Taiyo Yuden
CAP, CERM, 10 µF, 35 V, +/- 10%, X7R, 1206
TDK
CAP, CERM, 1 µF, 50 V, +/- 10%, X7R, 1206
MuRata
CAP, CERM, 0.1 µF, 100 V, +/- 10%, X7R, 0603
TDK
CAP, CERM, 100 pF, 100 V, +/- 5%, C0G/NP0, 0603
N/A
Fiducial mark. There is nothing to buy or mount.
3M
Bumpon, Hemisphere, 0.44 X 0.20, Clear
Samtec
Header, 100mil, 2x1, Gold with Tin Tail, SMT
TE Connectivity
SMA Straight PCB Socket Die Cast, 50 Ohm, TH
Samtec
Header, 100mil, 3x1, Gold, SMT
On-Shore Technology
Terminal Block, 3.5mm, 10x1, Tin, Blue, TH
Molex
Terminal Block, 3.5 mm, 3x1, Tin, TH
Brady
Thermal Transfer Printable Labels, 0.650" W x 0.200" H - 10,000 per roll
Panasonic
RES, 0, 5%, 0.125 W, 0805
3M
Shunt, 100mil, Gold plated, Black
Keystone
Test Point, Compact, Red, TH
Keystone
Test Point, Compact, Black, TH
Keystone
Test Point, Compact, Orange, TH
Keystone
Test Point, Compact, Blue, TH
Keystone
Test Point, Compact, Yellow, TH
Keystone
Test Point, Compact, White, TH
Texas Instruments
Fault-Protected, 8-Channel, Single-Ended and 4-Channel, Differential Multiplexer, PW0016A
Copyright © 2016, Texas Instruments Incorporated
Bill of Materials, PCB Layout, and Schematics
EVM
schematics.
Description
7
MUX36D04EVM-PDK
