- Page 1 RS232 User Manual Planar PS Series 4K Displays PS5074K │ PS5074K-N PS5074KT │ PS5074KT-N PS5574K │ PS5574K-N PS5574KT │ PS5574KT-N PS6574K │ PS6574K-N PS6574KT │ PS6574KT-N Planar PS Series 4K Displays RS232 User Manual Page | 1 020-1389-00C...
- Page 2 Copyright © March 2021 by Planar Systems, Inc. All rights reserved. This document may not be copied in any form without permission from Planar. Information in this document is subject to change without notice. Trademark Credits Windows™ is a trademark of Microsoft Corp.
-
Page 3: Table Of Contents
Table of Contents RS232 Codes ........................... 4 RS232 Command Format ....................4 Connection Setting ......................6 Command Tables ......................7 Example .......................... 18 Accessing Planar’s Technical Support Website ............19 Planar PS Series 4K Displays RS232 User Manual Page | 3 020-1389-00C... -
Page 4: Rs232 Codes
Integer value: Any positive or negative number (example: 100) o String value: Any string surrounded by double quotes (example: “This is a string”) ● “[CR]” is the ASCII carriage return key (0x0D). Planar PS Series 4K Displays RS232 User Manual Page | 4 020-1389-00C... - Page 5 ● String value: Any string surrounded by double quotes (example: “This is a string”) ● “[CR]” is the ASCII carriage return key (0x0D). ● “[LF]” is the ASCII line feed character (0x0A). Planar PS Series 4K Displays RS232 User Manual Page | 5 020-1389-00C...
-
Page 6: Connection Setting
Wake-on-LAN magic packet. Other serial commands are not recognized in standby. If full LAN serial command support is required in standby, use the Wake on All or Always On settings. Consult the Planar PS Series 4K Displays User Manual for more information. -
Page 7: Command Tables
(SHP-) 0~100 (TNT?) (TNT=50) (TNT+) (TNT-) Saturation 0~100 (CLR?) (CLR=50) (CLR+) (CLR-) Scheme Standard (MMP?) (MMP=1) (MMP+) (MMP-) Soft (MMP=2) User (MMP=3) Vivid (MMP=7) Natural (MMP=8) Sports (MMP=9) Planar PS Series 4K Displays RS232 User Manual Page | 7 020-1389-00C... - Page 8 (GMS?) (GMS=0) (GMS+) (GMS-) 1.85 (GMS=1) (GMS=2) 1.95 (GMS=3) (GMS=4) 2.05 (GMS=5) (GMS=6) 2.15 (GMS=7) (GMS=8) 2.25 (GMS=9) (GMS=10) 2.35 (GMS=11) (GMS=12) 2.45 (GMS=13) (GMS=14) 2.55 (GMS=15) (GMS=16) Planar PS Series 4K Displays RS232 User Manual Page | 8 020-1389-00C...
- Page 9 Minute Timer Mode (TMS?) (TMS=0) (TMS+) (TMS-) Everyday Mode (TMS=1) Workday Mode (TMS=2) User Mode Alarm Enable Sunday (AEN?) (AEN=1) (AEN+) (AEN+) Monday (AEN=2) Tuesday (AEN=4) Wednesday (AEN=8) Planar PS Series 4K Displays RS232 User Manual Page | 9 020-1389-00C...
- Page 10 (DNH+) (DNH-) On Hour Wednesday 0~59 (DNM?) (DNM=59) (DNM+) (DNM-) On Minute Wednesday 0~23 (DFH?) (DFH=23) (DFH+) (DFH-) Off Hour Wednesday 0~59 (DFM?) (DFM=59) (DFM+) (DFM-) Off Minute Planar PS Series 4K Displays RS232 User Manual Page | 10 020-1389-00C...
- Page 11 Speakers (SPK?) (SPK=1) (SPK+) (SPK-) Mute (MUT?) (MUT=0) (MUT+) (MUT-) (MUT?) (MUT=1) (MUT+) (MUT-) 0~10 (TSP?) (TSP=10) (TSP+) (TSP-) Transparency OSD H 0~100 (OSD?) (OSD=100) (OSD+) (OSD-) Position Planar PS Series 4K Displays RS232 User Manual Page | 11 020-1389-00C...
- Page 12 HDMI 1 EDID HDMI1.4 (EH1?) (EH1=1) (EH1+) (EH1-) HDMI2.0 (EH1=2) HDMI 2 EDID HDMI1.4 (EH2?) (EH2=1) (EH2+) (EH2-) HDMI2.0 (EH2=2) DP EDID 4K30Hz (ED1?) (ED1=1) (ED1+) (ED1-) 4K60Hz (ED1=2) Planar PS Series 4K Displays RS232 User Manual Page | 12 020-1389-00C...
- Page 13 (SBL?) (SBL=0) (SBL+) (SBL-) (SBL=1) RGB Color 0~255 (CLS?) (CLS=2) (CLS+) (CLS-) Range 16~235 (CLS=3) Auto (CLS=4) Touch Control Auto (TUC?) (TUC=0) (TUC+) (TUC-) Internal (TUC=1) External (TUC=2) Planar PS Series 4K Displays RS232 User Manual Page | 13 020-1389-00C...
- Page 14 Picture Mode (KEY=14) Sound Mode (KEY=15) Input source (KEY=16) Auto (KEY=17) (KEY=18) Down (KEY=19) Left (KEY=20) Right (KEY=21) Enter (KEY=22) Exit (KEY=23) Menu (KEY=24) Volume+ (KEY=25) Volume- (KEY=26) Planar PS Series 4K Displays RS232 User Manual Page | 14 020-1389-00C...
- Page 15 Address 1 Static IP 0~255 (IP2?) (IP2=255) (IP2+) (IP2-) Address 2 Static IP 0~255 (IP3?) (IP3=255) (IP3+) (IP3-) Address 3 Static IP 0~255 (IP4?) (IP4=255) (IP4+) (IP4-) Address 4 Planar PS Series 4K Displays RS232 User Manual Page | 15 020-1389-00C...
- Page 16 MAC Address WiFi MAC (MA2?) (MA2=0) (MA2+) (MA2-) CEC Enable (CEC?) (CEC=0) (CEC+) (CEC-) (CEC=1) Auto Standby (CAS?) (CAS=1) (CAS+) (CAS-) (CAS=0) Control Over (CTE?) (CTE=0) (CTE+) (CTE-) (CTE=1) Planar PS Series 4K Displays RS232 User Manual Page | 16 020-1389-00C...
- Page 17 (SSR=1) Use Network (UNT?) (UNT=0) (UNT+) (UNT-) Time (UNT=1) WiFi Hotspot Disable (WHE?) (WHE=0) (WHE+) (WHE-) Enable Enable (WHE=1) WLAN Save (WSS?) (WSS=1) (WSS+) (WSS-) Static IP Settings Planar PS Series 4K Displays RS232 User Manual Page | 17 020-1389-00C...
-
Page 18: Example
[Command] : (ZZZ=0) [CR] [Response] : (1;ZZZ=0) [CR] [LF] Invalid parameter (string instead of int) [CMD: CON] [Command] : (CON=”Some string”) [CR] [Response] : (9;CON=”Some string”) [CR] [LF] Planar PS Series 4K Displays RS232 User Manual Page | 18 020-1389-00C... -
Page 19: Accessing Planar's Technical Support Website
• User Guide • RS232 User Manual • Touchscreen drivers • Standard warranties • Planar support hotline number and email Planar PS Series 4K Displays RS232 User Manual Page | 19 020-1389-00C...
