Summary of Contents for Planar PS5562
- Page 1 Planar PS Series RS232 User Guide PS4662T PS5562 PS5562T PS6562...
- Page 2 Planar employees. When you purchase a Planar product, you get more than a display, you get the service and support you need to maximize your investment. To find the latest warranty and service information regarding your Planar product, please visit http://www.planar.com/support...
- Page 3 Baud rate 19200 is the default setting. Explanation of symbols ▲ : Valid command in standby mode. Note: The Wake Up from Sleep setting must be set to Wake on All for these commands to work in standby. Planar PS Series RS232 User Guide...
- Page 4 Off (Backlight) 42 4C 43 On (Backlight) 0~100 Contrast 43 4F 4E Sharpness 53 48 41 0~100 48 55 45 0~100 Saturation 53 41 54 Scheme User 53 43 4D Sport Game Cinema Vivid Planar PS Series RS232 User Guide...
- Page 5 47 41 43 1.85 (Gamma) 1.9 (Gamma) 1.95 (Gamma) 2.0 (Gamma) 2.05 (Gamma) 2.15 (Gamma) 2.15 (Gamma) 2.2 (Gamma) 2.25 (Gamma) 2.3 (Gamma) 2.35 (Gamma) 2.4 (Gamma) 2.45 (Gamma) 2.5 (Gamma) 2.55 (Gamma) 2.6 (Gamma) Planar PS Series RS232 User Guide...
- Page 6 52 54 59 Adjustment 1~12 Month 52 54 4D 1~31 52 54 44 0~23 Hour 52 54 48 0~59 Minute 52 54 4E Timer Mode Everyday Mode 54 4D 53 Workday Mode User Mode Planar PS Series RS232 User Guide...
- Page 7 Set bit6 to 1: Saturday Disable In Everyday Mode: Set any bit0~6 to 1: Mon.~Sun. Disable In Workday Mode: Set bit0 to 1: Sunday Disable Set any bit1~5 to 1: Mon.~Fri. Disable Set bit6 to 1: Saturday Disable Planar PS Series RS232 User Guide...
- Page 8 Thursday Off Minute 55 46 4D Friday 0~23 Friday On Hour 49 4E 48 0~59 Friday On Minute 49 4E 4D 0~23 Friday Off Hour 49 46 48 0~59 Friday Off Minute 49 46 4D Planar PS Series RS232 User Guide...
- Page 9 Portrait OSD Language OSL English 4F 53 4C Chinese OSD Timeout 5~120 OSD Timeout. The value 4F 43 4F increments by five (5, 10, 15, 20..., 115, 120 seconds). Splash Screen 53 50 53 Planar PS Series RS232 User Guide...
- Page 10 Wake on VGA 57 46 53 Config Wake on All Never Sleep Auto Scan 41 54 53 Main Pixel Orbit 49 52 46 Smart Light 53 4C 43 Control Light Sensor Power LED 4C 45 44 Planar PS Series RS232 User Guide...
- Page 11 LEFT Key RIGHT Key ENTER Key EXIT Key VGA Key HDMI1 Key HDMI2 Key DISPLAYPORT Key SOURCE Key SCALING Key 52 43 55 MUTE Key BRIGHT Key CONTRAST Key AUTO Key VOLUME+ Key VOLUME- Key Planar PS Series RS232 User Guide...
- Page 12 E-Mail Alert Off (Power Status Alert) 50 53 41 On (Power Status Alert) Off (Source Status Alert) 53 53 41 On (Source Status Alert) Off (Signal Lost Alert) 53 4C 41 On (Signal Lost Alert) Planar PS Series RS232 User Guide...
- Page 13 DNS Address 2 46 44 32 0~255 DNS Address 3 46 44 33 0~255 DNS Address 4 46 44 34 Save Static IP Settings 53 4E 53 Querying MAC ID #0~#5 4D 41 43 Planar PS Series RS232 User Guide...
-
Page 14: Power Control And Input Source
Read Contrast from monitor [CMD: CON] (If the monitor contrast setting is 50) [Transmit] : PC → 07 0101 43 4F 4E 08 → Monitor [Return] : Monitor → 07 01 00 43 4F 4E 32 08 → Monitor Planar PS Series RS232 User Guide... -
Page 15: Scaling Adjustment
[Transmit] : PC → 07 01 01 47 56 45 08 → Monitor [Return] : Monitor → 07 01 00 47 56 45 S(0) … S(5) 08 → PC , S(0) ~ S(5): firmware version in ASCII Planar PS Series RS232 User Guide... -
Page 16: Accessing Planar's Technical Support Website
Technical Support Website Go to www.planar.com/support to locate the following support documents and resources: • User Guide • RS232 User Manual • Touchscreen drivers • Standard warranties • Planar support hotline number and email Planar PS Series RS232 User Guide...
