  6. Operator's manual

Cornelius R-404A Operator's Manual

Post-mix dispenser with v4 features (r-404a refrigerant)
Hide thumbs Also See for R-404A:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Service Manual
Operator's Manual
Part No 312030002
May 8, 1996
Control Code A
THIS DOCUMENT CONTAINS IMPORTANT INFORMATION
This Manual must be read and understood before installing or operating this equipment
IMI CORNELIUS INC; 1996
FCB POST-MIX DISPENSER
WITH V4 FEATURES
(R-404A REFRIGERANT)
PRINTED IN U.S.A

Advertisement

Table of Contents
loading

Related Manuals for Cornelius R-404A

Summary of Contents for Cornelius R-404A

  • Page 1 Part No 312030002 May 8, 1996 Control Code A THIS DOCUMENT CONTAINS IMPORTANT INFORMATION This Manual must be read and understood before installing or operating this equipment IMI CORNELIUS INC; 1996 FCB POST-MIX DISPENSER WITH V4 FEATURES (R-404A REFRIGERANT) PRINTED IN U.S.A...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS SAFETY INFORMATION ........... RECOGNIZE SAFETY INFORMATION UNDERSTAND SIGNAL WORDS FOLLOW SAFETY INSTRUCTIONS...
  • Page 3 TABLE OF CONTENTS (cont’d) BAG–IN–BOX SYSTEM SYRUP FLAVOR CHANGE REPLENISHING CO2 SUPPLY CLEANING AND SANITIZING DAILY CLEANING OF UNIT SANITIZING SYRUP SYSTEMS CLEANING CONDENSER COIL UNIT WITH AIR-COOLED REFRIGERATION SYSTEM UNIT WITH REMOTE CONDENSING REFRIGERATION TROUBLESHOOTING ........... . . TROUBLESHOOTING CONTROL PANEL SWITCHES AND FAULT MESSAGES .
  • Page 4 TABLE OF CONTENTS (cont’d) CYLINDER FREEZE-UP. WARRANTY ............. . FIGURE 1.
  • Page 5 THIS PAGE LEFT BLANK INTENTIONALLY 312030002...

  • Page 6: Safety Information

    SAFETY INFORMATION Recognize Safety Information This is the safety-alert symbol. When you see this symbol on our machine or in this manual, be alert to the potentially of personal injury. Follow recommended precautions and safe operating practices. Understand Signal Words A signal word - DANGER, WARNING, OR CAUTION is used with the safety-alert symbol.
  • Page 7 THIS PAGE LEFT BLANK INTENTIONALLY 312030002...

  • Page 8: Operator's Instructions

    OPERATOR’S INSTRUCTIONS This section describes operating controls and indicators, dispensed product conditions, operating characteris- tics, Unit operation, replenishing syrup supply, product flavor change, checking CO cleaning of Unit, and sanitizing requirements. SOUND BAFFLE/DRIP TRAY ASS’Y PROVIDED ONLY WITH 3 H.P. UNIT. TWO-FLAVOR DISPENSER FIGURE 1.

  • Page 9: Syrup Prime'' Switches

    Side 1 Side 2 FIGURE 2. CONTROL PANEL SWITCH IDENTIFICATION ‘‘SYRUP PRIME’’ Switches. The ‘‘SYRUP PRIME’’ switches, located on the control panel, are touch-type switches and require only pressing to activate. The ‘‘SYRUP PRIME’’ switches are used only when filling the syrup systems sold-out floats during syrup replenishing, syrup flavor changeover, or sanitizing the syrup systems.
  • Page 10 TOP PANEL CONTROL PANEL (2) (SEE FIGURE 2) FACEPLATE RELIEF VALVE (4) BACK PANEL CUP REST FACEPLATE (4) DRIP TRAY DISPENSING VALVE (4) SIDE PANEL (2) CONDENSER COIL ACCESS PANEL VENTILATION LOUVERS NOTE: Two-flavor Unit- The No. 1 freeze cylinder is the left-hand cylinder facing the front of the Unit.

  • Page 11: Control Panel Display Messages

    CONTROL PANEL DISPLAY MESSAGES ‘‘FILL 1’’ and ‘‘FILL 2’’ Fault Messages. ‘‘FILL 1’’ and ‘‘FILL 2’’ fault messages will appear on the message display only after the “SYRUP PRIME” switches have been pressed and the syrup systems sold-out floats have been filled with product. ‘‘FILL 1’’ and ‘‘FILL 2’’...

  • Page 12: Defrost Systems

    DEFROST SYSTEMS NOTE: The automatic defrost, “SLEEP” (SLEEP TIME), and “WAKE UP” (WAKE UP TIME) should be programmed into the Unit electronics by a qualified Service Person. UNITS EQUIPPED WITH HOT-GAS DEFROST SYSTEMS The Unit is equipped with both manual and automatic hot-gas defrost systems. The automatic defrost system may be programmed into the Unit to occur up to nine different times a day with a minimum of two hours be- tween defrost time settings or the system may be completely turned off.

  • Page 13: Sleep'' (Sleep Time)

    Automatic Electric Defrost System. The automatic electric defrost system may be programmed into the Unit to occur up to nine different times a day with a minimum of two hours between defrost settings. At start of each automatic electric defrost cycle, the re- frigeration compressor will operate for a short time.

  • Page 14: Dispensed Product Conditions

    DISPENSED PRODUCT CONDITIONS ‘‘OVERRUN’’, AS APPLIED TO FROZEN CARBONATED BEVERAGES Overrun Defined. Overrun is product expansion that takes place in the frozen carbonated drink. It is caused primarily by CO breakout and secondary by freezing. Low Dispensing Volume Affects Overrun. When the Unit sits idle for a period of time and no drinks are dispensed, CO gas in the system takes a ‘‘set’’.

  • Page 15: Operating Characteristics

    Freezing Affects Overrun. Freezing causes approximately a 10 percent expansion in a dispensed frozen carbonated drink. The degree of freezing is limited because the finished drink is intended to be sipped through a straw. This is not possible if the product is too ‘‘solid’’.

  • Page 16: Secondary Co2 Regulators

    SECONDARY CO REGULATORS The secondary CO regulators, located inside the Unit, control CO product blender tanks. If adjustment of these CO Person to make the adjustments. ADJUSTING BRIX (WATER-TO-SYRUP “RATIO”) OF DISPENSED PRODUCT BRIX is the Water-to-Syrup “Ratio” of the dispensed product and should be periodically checked and if neces- sary, be adjusted by a qualified Service Person.

  • Page 17: Bag-In-Box System

    8. If freeze cylinder is not full of product, repeatedly pull and release the faceplate relief valve to slowly bleed from the freeze cylinder and allow product to fill the cylinder. Do not relieve freeze cylinder pressure too fast or the product will foam excessively in the cylinder and lose carbonation. BAG–IN–BOX SYSTEM 1.

  • Page 18: Cleaning And Sanitizing

    3. Unfasten safety chain and remove empty CO 4. Position full CO cylinder and secure with safety chain. WARNING: To avoid personal injury and/or property damage, always secure CO in an upright position with safety chain to prevent it from falling over. Should the shutoff valve become accidentally broken off, CO 5.
  • Page 19 10. Syrup Tank Syrup System. Disconnect syrup tank containing syrup from No. 1 syrup system. Bag-in-Box Syrup System. Disconnect No. 1 syrup pump syrup inlet line from bag-in-box containing syrup. Cut connector from empty bag-in-box container, then connect connector to No. 1 syrup pump syrup inlet line.
  • Page 20 Bag-in-Box Syrup System. A. Remove end of No. 1 syrup pump syrup inlet line from pail of sanitizing solution. B. Remove empty bag-in-box connector from No. 1 syrup pump syrup inlet line. C. Connect No. 1 syrup pump syrup inlet line to bag-in-box containing syrup. 22.

  • Page 21: Cleaning Condenser Coil

    32. After carbonator water pump cycles off, intermittently pull and release the No. 1 freeze cylinder faceplate relief valve. This bleeds CO from the freeze cylinder and allows product to enter and fill the cylinder. 33. Open No. 2 product blender tank product shutoff valve. CLEANING CONDENSER COIL UNIT WITH AIR-COOLED REFRIGERATION SYSTEM Circulating air, required to to cool the refrigeration system condenser coil, is drawn in through louvers on front...

  • Page 22: Troubleshooting

    IMPORTANT: Only qualified personnel should service internal components or electrical wiring. WARNING: If repairs are to be made to a product system, remove quick disconnects from the applicable product tank, then relieve the system pressure before proceeding. If repairs are to be made to the CO system pressure before proceeding.

  • Page 23: Co2 Out'' Fault Message Goes On During Operation

    Trouble ‘‘CO OUT’’ FAULT MESSAGE GOES ON DURING OPERATION. ‘‘H O OUT’’ FAULT MESSAGE GOES ON DURING OPERATION. ‘‘SYRUP 1’’ OR ‘‘SYRUP 2’’ FAULT MESSAGE GOES ON DURING OPERATION. ‘‘ERROR 1’’ OR ‘‘ERROR 2’’ FAULT MESSAGE GOES ON DURING OPERATION. FREEZE CYLINDER AUTOMATIC DEFROST CYCLE DOES NOT...

  • Page 24: Carbonator Water Pump Will Not Shut Off

    Trouble CARBONATOR WATER PUMP WILL NOT SHUT OFF. ERRATIC CARBONATOR WATER PUMP CYCLING. TROUBLESHOOTING DISPENSED PRODUCT BRIX (WATER-TO-SYRUP) ‘‘RATIO’’ OF DISPENSED PRODUCT TOO LOW. BRIX (WATER-TO-SYRUP) ‘‘RATIO’’ OF DISPENSED PRODUCT TOO HIGH. IMPROPER PRODUCT DISPENSED. PRODUCT WILL NOT DISPENSE OUT OF DISPENSING VALVE, IN ONLY SMALL AMOUNTS, OR ONLY LIQUID.
  • Page 25 Trouble FROZEN PRODUCT CONSISTENCY VARIES EXCESSIVELY (CONT’D). CYLINDER FREEZE-UP. 312030002 Probable Cause Cylinder freeze-up causing ice formation in center of cylinder and liquid product channels around ice formation. NOTE: DEFROST AFFECTED FREEZE CYLINDER AS INSTRUCTED. Dispensed product BRIX too low. Viscosity of dispensed product not properly adjusted.
  • Page 26 IMI Cornelius Inc. warrants that all equipment and parts are free from defects in material and workmanship un- der normal use and service. For a copy of the warranty applicable to your Cornelius, Remcor or Wilshire prod- uct, in your country, please write, fax or telephone the IMI Cornelius office nearest you. Please provide the equipment model number, serial number and the date of purchase.
  • Page 28 IMI CORNELIUS INC. CORPORATE HEADQUARTERS: One Cornelius Place Anoka, Minnesota 55303-6234 (612) 421-6120 (800) 238-3600...
