BEFORE YOU BEGIN
HOW TO USE THESE INSTRUCTIONS
Please read these instructions carefully to familiarize
yourself with the required tools, materials, and installation
sequences. Follow the sections that pertain to your partic-
ular installation. This will aid you in avoiding the unneces-
sary expense associated with improper installation. In
addition to proper installation, read all operating and safe-
ty instructions.
NOTES
S
Seat post holes on 5-1/2" centers.
S
Water depth from rim is 6-3/4".
S
1-3/4" passageway.
S
Ensure that the new toilet has the correct
roughing-in dimension. The K-3420 and K-3421
have a 12" roughing-in dimension. See Fig. #1.
S
Be very careful while working with vitreous china
products. Vitreous china can break and chip if
you overtighten bolts and nuts or carelessly
handle the product.
S
Carefully inspect new fixture for any sign of
damage.
S
Observe all local plumbing and building codes.
S
Shut off hot and cold water supplies.
S
For new construction, refer to the dimensions in
Fig. #1 and Fig. #4 for locating the shut-off valve.
S
Fixture dimensions are nominal and conform to
tolerances by ANSI Standards (A112.19.2).
WARNING: Risk of external leakage. The fill
valve nut has been factory-tightened to design
specifications. If re-tightening is required, wrench
tighten one turn past finger tight.
CA
112375-2-
(B)
R
1 1
WELLWORTH LITE
VITREOUS CHINA
REVERSE TRAP TOILETS
All information in these instructions is based on the latest
product information available at the time of publication.
Kohler Co. reserves the right to make changes in product
characteristics, packaging, or availability at any time with-
out notice.
These instructions contain important care, cleaning, and
warranty information - please leave instructions for the
consumer.
ORDERING INFORMATION
Wellworth Lite Toilet (elongated)
Wellworth Lite Toilet (round front)
Bowl K-4236/K-4237
Tank K-4512
When specified:
3/8" supply
. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Floor bolts (pr.)
. . . . . . . . . . . . . . . . . . . . . . . . .
Recommended elongated seat
Recommended round front seat
. . . . . . . . . . .
K-3420
. . . . . . . . . .
K-3421
K-7638
21401
. . . . . . . . . . .
K-4652
. . . . . . . . . .
K-4662
E1998 Kohler Co.
Advertisement
Table of Contents
Related Manuals for Kohler WELLWORTH LITE K-3420
Summary of Contents for Kohler WELLWORTH LITE K-3420
- Page 1 Follow the sections that pertain to your partic- Kohler Co. reserves the right to make changes in product ular installation. This will aid you in avoiding the unneces- characteristics, packaging, or availability at any time with- sary expense associated with improper installation.
-
Page 2: Tools And Materials Required
FRONT OF BOWL 15-5/8” K-3420-EB 29-1/2” 1” 19-3/4” K-3421-PB 27-1/2” 6-1/8” 9-1/2” 31-7/8” K-4236-ET BASE FRONT OF BOWL 3-5/8” 15” 9” 14-1/8” 4-1/8” C L OF OUTLET 12” 6-3/16” 3/8” N.P.T. SUPPLY 9-3/4” K-4237-PT BASE Fig. #1 Kohler Co., Kohler, WI 112375-2-... -
Page 3: Installation
4-1/8” to the left of the centerline of the closet flange. 9” Centerline of supply shut-off outlet should extend 4” from finished wall. Install the supply shut-off valve with outlet vertical. 12” Fig. #4 Kohler Co., Kohler, WI 112375-2-... - Page 4 CAUTION: Overtightening may cause breakage or chipping. Washer Alternately tighten the three brass hex nuts so that the top of the tank is level with the top of the bowl and a watertight seal is obtained. Fig. #7 Kohler Co., Kohler, WI 112375-2-...
- Page 5 Adjust float by sliding it up or down on float rod until water level is at the marked water line on the flush valve over- flow. Float Check all connections for leaks for several days. Float Rod Fig. #10 Kohler Co., Kohler, WI 112375-2-...
-
Page 6: Troubleshooting Chart
B. Soil pipe or vent is obstructed. B. Clear obstruction from soil pipe or vent pipe. 7. Toilet does A. Chain is not connected to lift rod or flush valve. A. Reconnect the chain. activate. Kohler Co., Kohler, WI 112375-2-... -
Page 7: Important Consumer Information
Kohler Company shall not be responsible or liable for any Most toilet bowl cleansers are not harmful to the vitreous damage to these tank fittings caused by the use of china surface of the toilet bowl. - Page 8 Kohler Co., Kohler, WI 112375-2-...
