Kohler WELLWORTH K-3432 Installation Instructions Manual

BEFORE YOU BEGIN
HOW TO USE THESE INSTRUCTIONS
Please read these instructions carefully to familiarize
yourself with the required tools, materials, and installation
sequences. Follow the sections that pertain to your partic-
ular installation. This will help you avoid costly mistakes.
In addition to proper installation, read all operating and
safety instructions.
ORDERING INFORMATION
Wellworth Toilet . . . . . . . . . . . . . . . . . . . . .
Bowl . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Tank . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
When specified:
3/8" supply . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Floor bolts (pair) . . . . . . . . . . . . . . . . . . . . . . . .
NOTES
S
Observe all local plumbing and building codes.
S
Shut off the water supply.
S
Seat post holes are on 5-1/2" centers.
S
2" passageway.
S
Water depth from the rim is 6".
S
Ensure that the new toilet has the correct
roughing-in dimension. The K-3433 and K-3438
have a 14" roughing-in dimension. See Fig. #1.
TOOLS AND MATERIALS REQUIRED
S
10" adjustable wrench
S
12" pipe wrench
S
Metal file (file cut)
S
Tape measure
S
Tubing cutter
S
Level
S
Hacksaw
CA
114503-2- (-)
R
K-3433/3438
K-4277/4276
K-4621
K-7637
21401
1 1
VITREOUS CHINA
REVERSE TRAP TOILET
All information in these instructions is based upon the lat-
est product information available at the time of publica-
tion. Kohler Co. reserves the right to make changes in
product characteristics, packaging, or availability at any
time without notice.
These instructions contain important care, cleaning, and
warranty information – please leave instructions for the
consumer.
S
Be very careful while working with vitreous china
products. Vitreous china can break or chip if the
bolts and nuts are overtightened, or if carelessly
handled.
S
Carefully inspect the new fixture for any sign of
damage.
S
For new construction, refer to the dimensions in
Fig. #1 and Fig. #4 for locating the shut-off valve.
S
Fixture dimensions are nominal and conform to
tolerances established by ANSI Standards
(A112.19.2).
WARNING: Risk of external leakage. The fill
valve nut has been factory-tightened to design
specifications. If re-tightening is required, wrench
tighten one turn past finger tight.
S
Putty knife
S
Screwdriver
S
Toilet gasket (wax seal)
S
Toilet T-bolts (2), 5/16" diameter
S
Toilet supply shut-off valve, 3/8" recommended
NOTICE: If the existing toilet does not have a supply
shut-off valve below the tank, install one before installing
the new toilet.
WELLWORTH
