Provisioning
Table 5. H4TU-C-231 List 1 Standard Config Screen Options (Continued)
Screen
Standard Config
Display
Screen Options
Code
Alarm Pattern ALMP
See "Alarm
Pattern (ALMP)
Option." on
page 22.
H4TU-R TLOS TLOS
Loopback
Network NLBP
Loopback Pattern
Power Back Off - PBON
Network
See "Power Back
Off (PBON and
PBOC) Options"
on page 22.
Power Back Off - PBOC
Customer
See "Power Back
Off (PBON and
PBOC) Options"
on page 22.
Screen
ADC Config Menu
Display
Options
Code
Line Power Feed PWRF
Remote RTPV
Provisioning
Bipolar Violation BPVT
Transparency
(See "Bipolar
Violation
Transparency
(BPVT) Option"
on page 22.)
20
Selection Description
AIS Enables the HDSL4 system to output an AIS payload at its DS1 ports for
LOSW and LOS DS1. For priority resolution, see
LOS Enables the HDSL4 system to output an LOS condition at its DS1 ports for
LOSW and LOS DS1.
ENA Enables a logic loopback at the H4TU-R when an LOS occurs at its DS1 input.
For priority resolution, see
DIS Disables TLOS logic loopback.
AIS Enables the H4TU-R to transmit AIS towards the CI for any network loopback.
For priority resolution, see
LOS Enables the H4TU-R to transmit LOS towards the CI for any network
loopback.
DEF Configures the power output levels of the H4TU-C network unit toward the
customer to comply with the Default template as defined in Section 6.1.4.2 of
ANSI T1.418.
ENH Configures the power output levels of the H4TU-C network unit toward the
customer to comply with the Enhanced template as defined in Section 6.1.4.2
of ANSI T1.418.
DEF Configures the power output levels of the H4TU-R customer unit toward the
network to comply with the Default template as defined in Section 6.1.4.2 of
ANSI T1.418.
ENH Configures the power output levels of the H4TU-R customer unit toward the
network to comply with the Enhanced template as defined in Section 6.1.4.2
of ANSI T1.418.
Table 6. H4TU-C-231 List 1 ADC Config Screen Options
Selection Description
OFF Disables powering to the HDSL4 pair.
LOW Keeps the HDSL4 line voltage at nominal -185 Vdc.
HIGH Keeps the HDSL4 line voltage at nominal ±123 Vdc.
AUTO Keeps the HDSL4 line voltage at -185 Vdc when line powering up to two
devices (one doubler and one remote unit or two doubler units). When line
powering of more than two devices is required, the line unit automatically
switches to ±123 Vdc.
ENA Enables remote provisioning.
DIS Disables remote provisioning.
ENA Enables BPVs and HDSL4 CRC errors at the DS1 input to be converted into
DS1 BPVs at the DS1 output at the distant end. This makes HDSL4
transparent to BPVs.
DIS Disables BPV Transparency.
September 12, 2003
LTPH-UM-1138-02, Issue 2
Figure 27 on page
Figure 27 on page 46.
Figure 27 on page 46.
46.
Continued
H4TU-C-231 List 1
