Porter-Cable PORTA-BAND 7724 Instruction Manual

Variable speed band saw
Hide thumbs Also See for PORTA-BAND 7724:
Table of Contents

Advertisement

Quick Links

Download this manual
Instruction
manual
To learn more about Porter-Cable
visit our website at:
http://www.porter-cable.com
Copyright © 2005 Porter-Cable Corporation
ESPAÑOL: PÁGINA 15
FRANÇAISE : PAGE 29
Variable Speed
PORTA-BAND
Band Saw
MODEL 7724
IMPORTANT
Please make certain that the person who is
to use this equipment carefully reads and
understands these instructions before
starting operations.
The Model and Serial No. plate is located on the main
housing of the tool. Record these numbers in the
spaces below and retain for future reference.
Model No._______________________________________
Type No. ________________________________________
Serial No. _______________________________________
®
Part No. 902452 - 02-02-05

Advertisement

Table of Contents
loading

Related Manuals for Porter-Cable PORTA-BAND 7724

Summary of Contents for Porter-Cable PORTA-BAND 7724

  • Page 1 PORTA-BAND Band Saw MODEL 7724 IMPORTANT Please make certain that the person who is To learn more about Porter-Cable to use this equipment carefully reads and visit our website at: understands these instructions before http://www.porter-cable.com starting operations. The Model and Serial No. plate is located on the main housing of the tool.

  • Page 2: Table Of Contents

    Improper operation, maintenance or modification of tools or equipment could result in serious injury and property damage. There are certain applications for which tools and equipment are designed. Porter-Cable strongly recommends that this product NOT be modified and/or used for any application other than for which it was designed.

  • Page 3: Safety Guidelines

    SAFETY GUIDELINES - DEFINITIONS It is important for you to read and understand this manual. The information it contains relates to protecting YOUR SAFETY and PREVENTING PROBLEMS. The symbols below are used to help you recognize this information. indicates an imminently hazardous situation which, if not avoided, will result in death or serious injury.

  • Page 4: General Safety Rules

    GENERAL SAFETY RULES Read all instructions. Failure to follow all instructions listed below may result in electric shock, fire and/or serious injury. The term "power tool" in all of the warnings listed below refers to your mains-operated (corded) power tool or battery-operated (cordless) power tool.
  • Page 5 GENERAL SAFETY RULES continued d) Remove any adjusting key or wrench before turning the power tool on. A wrench or a key left attached to a rotating part of the power tool may result in personal injury. e) Do not overreach. Keep proper footing and balance at all times. This enables better control of the power tool in unexpected situations.

  • Page 6: Additional Specific Safety Rules

    ADDITIONAL SPECIFIC SAFETY RULES Hold tool by insulated gripping surfaces when performing an operation where the cutting tool may contact hidden wiring or its own cord. Contact with a “live” wire will make exposed metal parts of the tool “live” and shock the operator.
  • Page 7 SYMBOL DEFINITION ......volts ......amperes ......hertz ......watts ......kilowatts ......farads µF ......microfarads ......litres ......grams ......kilograms ......bars ......pascals ......hours ......minutes ......seconds ......no-load speed …/min or …min ..Revolutions or reciprocations per minute or d.c.

  • Page 8: Carton Contents

    MOTOR Many Porter-Cable tools will operate on either D.C., or single phase 25 to 60 cycle A.C. current and voltage within plus or minus 5 percent of that shown on the specification plate on the tool. Several models, however, are designed for A.C.

  • Page 9: Assembly

    ASSEMBLY NOTE: This tool is shipped completely assembled. No assembly time or tools are required. OPERATION TO START AND STOP SAW Make sure power circuit voltage is the same as that shown on the specification plate on the saw. Connect machine to power circuit. Squeeze trigger switch (A) Fig.
  • Page 10 LIQUID COOLANTS CAN INCREASE THE RISK OF ELECTRIC SHOCK. Use only stick wax to lubricate the blade. Porter-Cable’s “Lube Wax” is available as an accessory and is recommended when cutting aluminum, brass and thick materials. Cast iron should be cut dry.
  • Page 11 ➡ DIRECTION OF BLADE TRAVEL POSITION OF TEETH ON ON LEFT SIDE OF MACHINE LEFT SIDE OF MACHINE Fig. 3 Fig. 4 TO ADJUST BLADE TRACKING This Band Saw is equipped with an adjustable Blade Tracking Mechanism. When properly adjusted: the back edge of the blade will run lightly against at least one of the back-up rollers, but will not press heavily against the roller.

  • Page 12: Troubleshooting

    SECURELY. Fig. 6 shows the proper cutting position for various shapes. TROUBLESHOOTING For assistance with your tool, visit our website at www.porter-cable.com for a list of service centers or call the Porter-Cable help line at 1-800-487-8665. MAINTENANCE KEEP TOOL CLEAN Remove wax and Periodically blow out all air passages with dry compressed air.

  • Page 13: Service

    All quality tools will eventually require servicing, or replacement of parts due to wear from normal use. For assistance with your tool, visit our website at www.porter-cable.com for a list of service centers or call the Customer Care Department at 1-800-487-8665. All repairs made by our service centers are fully guaranteed against defective material and workmanship.

  • Page 14: Warranty

    PORTER-CABLE LIMITED ONE YEAR WARRANTY Porter-Cable warrants its Professional Power Tools for a period of one year from the date of original purchase. We will repair or replace at our option, any part or parts of the product and accessories covered under this warranty which, after examination, proves to be defective in workmanship or material during the warranty period.

  • Page 15: Español

    Porter-Cable • Delta products should be obtained by contacting any Porter-Cable • Delta Distributor, Authorized Service Center, or Porter-Cable • Delta Factory Service Center. If you do not have access to any of these, call 888-848-5175 and you will be directed to the nearest Porter-Cable •...
