- Page 2 Warning Improper installation, adjustment, alteration, service and maintenance can cause property damage, personal injury or loss of life. For more information about buying, using, and servicing of Rinnai appliances call: 0800 RINNAI (0800 746 624). Rinnai New Zealand Limited 105 Pavilion Drive, Mangere, Auckland...
-
Page 3: Table Of Contents
Installation checklist and Installer details....26 Purchase details ............27 Limited Warranty ............28 Gas appliances, like cars, require regular maintenance and servicing. For reliable operation Rinnai Energysavers, in residential applications, should be serviced every two years, including inspection of the flue system. -
Page 4: About Your Energysaver
About your Energysaver Congratulations on the purchase of your Rinnai Energysaver. We hope you love this product as much as we do, and on the off chance that something does go wrong, or if you need help, we’re only a phone call away. - Page 5 Override appliance will stop heating. If the temperature Temporarily changes operation from ON to then drops below 10 °C the heater will switch OFF or OFF to ON until the next programmed back on. setting is reached. 16-26 °C Timer 1 and Timer 2 Unit will modulate, and in some instances Displays which timer is operating.
-
Page 6: Safety
If odours persist turn the appliance off and Do not unplug the heater while it is still in use contact Rinnai. or while the fan is on. -
Page 7: Important
Important Clearances while the heater is operating Floor protection Energysavers discharge a large volume This appliance must not be installed where of warm air at a low level. Heat over curtains or other combustible materials could time may affect the appearance of some come into contact with it. -
Page 8: Setting The Clock
Setting the clock Temp On/O When the appliance is first plugged in or after a power failure the digital display will show --: --. ▲= UP button ▼= DOWN button Setting the clock (example - setting the clock to 6:00 am) 1. -
Page 9: Setting And Operating The Timers
Setting and operating the timers Before operating the timers the clock must be set. The timers can be programmed to operate for any two time periods in 24 hours. A timer start and finish time, and a set temperature must be set for the timers to work. The programmed time and temperature must be selected and locked-in within one minute of the indicators flashing for the information to be saved. -
Page 10: Additional Heater Information
Additional heater information Humidifier tray Vertical louvre adjustment Your heater is fitted with an enamel humidifier When the heater is turned off the direction of tray. To fill the tray, open the access panel as the warm air flow may be altered by carefully shown below. -
Page 11: Care And Maintenance
Before cleaning any part of the heater ensure it is turned off and has cooled down. All parts Rinnai has a maintenance, service and spare of the heater can be cleaned using a soft damp parts network with personnel who are fully cloth and mild detergent—do not use solvents. -
Page 12: Troubleshooting
Troubleshooting Check the following information before making a service call. If you are still unsure or concerned after reading this section, please contact Rinnai. Using the heater for the first time, or after a long period of non use The heater may not start the first time it is operated due to air in the gas pipes. If ignition does not occur within approximately one minute the heater will attempt to start again. -
Page 13: Error Codes
In all cases you may be able to clear the error by turning the heater off and on again. If the error code remains or returns when the heater is used again, contact Rinnai. Faults caused by insufficient gas supply, gas quality, installation or operation errors are not covered by the Rinnai warranty. -
Page 14: Installation
Installation Installation, servicing and repair shall be carried out only by authorised personnel. -
Page 15: Carton Contents And Item Checklist
Before installing the heater, check it is labelled for the correct gas type. Refer to the data label at the rear of the heater. The heater does not come supplied with flue components. These are purchased separately. Only Rinnai Energysaver flue components can be used with this appliance. Carton contents and item checklist, check you have: •... -
Page 16: Energysaver Specification Summary
Energysaver specification summary 309FT3 559FT3 561FT3 1005FT3 Colour White with grey White with grey White with grey White with grey louvres and rear louvres and rear louvres and rear louvres and rear panel panel panel panel Input* 5.8-13 MJ/h 9-23 MJ/h 9-23 MJ/h 15.5-37 MJ/h Output*... -
Page 17: Energysaver Dimensions (Mm)
Energysaver dimensions (mm) 309FT3 Gas inlet 559FT3 Gas inlet 561FT3 Gas inlet 114.5 1005FT3 inlet... -
Page 18: Positioning, Gas, And Electrical Supply
AS/NZS 5601.1:2013 and AS/NZS 3000 and other relevant local regulations. If the supply cord is damaged and requires replacing, it must be replaced by a licensed tradesperson. This must be a genuine replacement part available from Rinnai. -
Page 19: Energysaver Flueing Guidelines
Some guidelines to assist with flue design are in this guide. These must be read and modified as necessary with reference to the particular installation. All Rinnai Energysavers must be installed with an approved Rinnai flue system. Flue clearance to combustibles Flashings... -
Page 20: Energysaver Flueing Options (Most Common)
Energysaver flueing options (most common) Direct and direct extended flueing Direct through the wall flueing for walls Direct 75-385 mm thick. R1350: Mushroom flue kit for walls 75-115 mm R1351: Mushroom flue kit for walls 115-240 mm Flue can be extended if wall thickness is ESDFK : Straight horiz. -
Page 21: Installation
Installation 1. Remove the plastic protection cap from the threaded gas inlet located at the rear of the appliance. 2. Position the appliance gas inlet in line with the gas supply. 3. Attach the gas supply pipe to the appliance gas inlet and tighten (finger tight). 4. - Page 22 Installation continued Install flue Install the flue as per the instructions in the Energysaver flue installation guide. Return the Energysaver to its final position and connect to the flue. Connect the gas supply line and fully tighten the connection. Use a soapy solution to test all gas connections.
-
Page 23: Commissioning
It is the responsibility of the installer to check that all the flue gases are exhausted to the atmosphere and that there is no spillage of combustion gases into the room. If the appliance cannot be made to perform correctly, please contact Rinnai. Burning in period Advise the customer that during the initial burning in period of approximately two hours some vapour and smell may come from the heater, this is normal. -
Page 24: Wiring Diagram Rhfe-309, 559, 561Ft3
Wiring diagram RHFE-309, 559, 561FT3... -
Page 25: Wiring Diagram Rhfe-1005Ft3
Wiring diagram RHFE-1005FT3... -
Page 26: Installation Checklist And Installer Details
F All packaging and protective materials removed prior to operation F Appliance test point pressure correct for the installation, and flue config. adjusted if necessary F Only Rinnai Energysaver flue components used F Air inlet hose and flue connections secure... -
Page 27: Purchase Details
Purchase details Record your purchase details below ATTACH YOUR PROOF OF PURCHASE HERE: Retailer: Retailer address: Date of purchase: Product details: Please keep these details in a safe place for future reference. -
Page 28: Limited Warranty
Rinnai recommends that Energysavers are serviced every two years, including inspection of the flue system. 4. Servicing of the product is to be carried out by a Rinnai authorised service centre. 5. The warranty applies only to components supplied by Rinnai. It does not apply to components supplied by others, such as electrical switches, electrical cables, and fuses, but is not limited to these. - Page 29 8. Rinnai reserves the right to have installed product returned to the factory for inspection. 9. Where the heater is installed outside the metropolitan area or further than 40 km from a Rinnai authorised service centre, travel costs shall be the owner’s responsibility.
- Page 30 Register your appliance online at www.rinnai.co.nz/register/. You’ll need to know the model, and also the serial number—shown on the data plate on the lower right hand side of the heater. Warranty claim To make a warranty claim, contact Rinnai on 0800 RINNAI (0800 746 624) or email info@rinnai.co.nz.
