Summary of Contents for BIXOLON Bixolon SRP-770IIE
- Page 1 User's Manual SRP-770II/770IIE Label Printer Rev. 1.16 http://www.bixolon.com...
-
Page 2: Table Of Contents
3-3 Paper Installation ······································································································12 3-4 LED Display ··············································································································13 3-5 Test printing ··············································································································14 4. Self-Test························································································································15 5. Detailed features ··········································································································16 5-1 Printer Settings with Dip switches·············································································16 5-2 Pause/Restart ···········································································································17 5-3 Gap Sensor Auto-Calibration ····················································································18 5-4 Gap Sensor Manual-Calibration ···············································································19 5-5 The Peel-Off ·············································································································20 5-6 Using Fan-Fold Paper·······························································································22... -
Page 3: Manual Information & Usage Precautions
A4-sized original copy data to 4-inch size. 4. Programming (SLCS) Manual This manual provides information on label printer commands. 5. True Font Downloader Manual This manual provides information on the usage of the font downloader that can download True Fonts and facilitate their usage as Device Fonts. -
Page 4: Safety Precautions
PROHIBIT Do not pull the cable to unplug. • This can damage the cable, which is the origin of a fire or a breakdown of the printer. PROHIBIT Do not plug in or unplug with your hands wet. • You can be electrocuted. - Page 5 • After the disappearance of the smoke, call your dealer to repair it. TO UNPLUG PRINTER Install the printer on the stable surface. • If the printer falls down, it can be broken and you can hurt yourself. PRINTER PROHIBIT Do not let water or other foreign objects in the printer.
-
Page 6: Other Precautions
SRP-770II/770IIE ■ Other Precautions The copyright for this user manual and various other manuals is property of the BIXOLON Co., Ltd. Any copying or conversion into electronic firm and saving of this material without the express written permission of BIXOLON Co., Ltd. is strictly prohibited. Use of the information contained in this manual is not subject to any patent liability. -
Page 7: Content Confirmation
1. Content Confirmation The following items should all be contained in the printer package. Contact the dealer from which the purchase was made if any item is damaged and/or missing. SRP-770II/770IIE Power Cord Cleaning Pen ※ Optional items Rev. 1.16... -
Page 8: Product Part Names
SRP-770II/770IIE 2. Product Part Names Feed Button Power Switch Cover Peel-off Cover Lever Printer Head Paper Cover Paper Holder Paper Gap Sensor Paper Guide Peel-off Sensor - 8 - Rev. 1.16... - Page 9 SRP-770II/770IIE Fan-Fold RS-232C Receptacle Dip Switch Power Receptacle IEEE1284 Receptacle USB Receptacle Auto Cutter (Option) - 9 - Rev. 1.16...
-
Page 10: Installation & Usage
1) Turn off the printer power switch. 2) Check to see that the AC adapter voltage matches that of the power source. 3) Connect the AC adapter jack to the printer power connector. 4) Connect the power cord to the AC adapter. -
Page 11: Interface Cable Connection
LAN (Ethernet ) Cable 1) Turn off the power switch. 2) Connect the communication cable to the printer communication port to be used. - For a Serial cable, secure by tightening the screws on both sides. - For a Parallel cable, secure by fastening the clips on both sides. -
Page 12: Paper Installation
3-3 Paper Installation 1) Open the Paper Cover. 3) Keep note of paper printing direction. 5) Close the Paper Cover. Rev. 1.16 SRP-770II/770IIE 2) Spread the paper holder and insert paper as shown. 4) Adjust the paper guide to the width of the paper. -
Page 13: Led Display
- The printer waits for the data from Host (PC) in normal mode. 2) Orange LED on - It means paper gap sensing error. It becomes on when the printer fails to detect the paper or paper jam occurred. When fails to detect the paper correctly use Auto-Calibration function. -
Page 14: Test Printing
SRP-770II/770IIE 3-5 Test printing 3-5-1 Printing using Windows driver 1) Install the Windows driver. Refer to the “Windows driver manual” in the CD for the installation procedure. 2) Set the “port” of Windows driver to the appropriate interface to be used. Refer to the “Ethernet interface user’s manual”... -
Page 15: Self-Test
1) Make sure that the paper roll has been installed properly. 2) Turn on the power while holding down the FEED button. The self-test begins. 3) The self-test prints the current printer status, which provides the control ROM version and the DIP switch settings. -
Page 16: Detailed Features
Follow these steps when changing dip switch settings: 1) Turn the printer power switch off. 2) Remove the screw on the bottom of the printer and open the bracket. 3) Flip the dip switches using tweezers or another narrow-ended tool. -
Page 17: Pause/Restart
5-2 Pause/Restart Press FEED button to pause at the middle of labels printing. 1) Press FEED once. 2) Printer stops after on-going printing and Red LED becomes on. 3) Press FEED once again. It restarts printing in a queue. Rev. 1.16... -
Page 18: Gap Sensor Auto-Calibration
Gap sensor auto-calibration is used when the printer does not detect a gap on the label paper correctly. Generally a printer is set to detect most of gap types but sometimes it fails to detect and keep feeding the paper without a stop when special paper used. In such case, use gap sensor auto-calibration function for a proper detection. -
Page 19: Gap Sensor Manual-Calibration
2) Select the sensing type and input the label length by millimeter and click on “Check Sensing Value” tap. Then printer starts to calibrate. 3) Printer will print the scanned values after calibration and the values will appear on the Screen. -
Page 20: The Peel-Off
- When the peeler function is not required, turn the peeler switch off. Keeping the switch on may result in the printer not working correctly. - When the peeler switch has been changed, the printer should be turned off and back on. - Page 21 SRP-770II/770IIE 3) Adjust the paper guides and close the cover. ( O ) ( X ) 4) Turn the printer off and back on. - 21 - Rev. 1.16...
-
Page 22: Using Fan-Fold Paper
SRP-770II/770IIE 5-6 Using Fan-Fold Paper Insert paper through both the rear slot and guides. Adjust holders and guides to the width of the paper. 1) Open the Dust Cover and insert paper. Dust Cover 2) Adjust Paper Holders to the paper width 3) Adjust Paper Guides and close the Paper and fixed Paper Holders with fixing tool. -
Page 23: Auto Cutter (Option)
2. Put a paper roll into the printer and close the cover. ※ CAUTION (Partial cut) Once the printer cut the paper, remove the receipt in order for next printing. Otherwise the receipt could be back into the printer and the cutter would cut it again. Rev. 1.16 SRP-770II/770IIE... -
Page 24: Cleaning Head
3) Use a cloth moistened with an alcohol solution to clean the paper sensor are and remove any paper remnants and/or dust. 4) Insert paper into the printer 1~2 minutes after completing the cleaning process and close the printer cover. -
Page 25: Appendix
7. Appendix 7-1 Specifications Item Printing Method Dot Density Printer Printing Width Printing Speed Roll Paper Fan-Fold Type SMPS Input Voltage Frequency Adapter SMPS Output Voltage DC 24V Temperature Usage Conditions Humidity (except for paper) ※ Note - Printing speed can vary depending on the data transmission speed and combination of control commands. -
Page 26: Certification
• Europe: CE EMC,CB-Scheme:IEC60950-1, GS: EN60950-1: 2001 • North America: FCC rules parts 15B WARNING Use of an unprotected interface cable with this printer conflicts with EMC standards. Users should only use cables approved by BIXOLON. 2) CE Mark • EMC Directive 89/336/EEC •...
