Instructions – Parts List
55 Gallon, 20:1 King
Module Supply Units
1800 psi (124 bar) Maximum Working Pressure
* Model 970159, Tandem with Pneumatic Crossover (carbon steel pump)
* Model 288649, Tanden with Pneumatic Crossover (stainless steel pump)
Model 970160, Tandem with Electric Crossover
* Model 970163, Pneumatic Low Level Shutoff
* These models are CE certified.
Important Safety instructions
Read all warnings and instructions in this manual.
Save these instructions.
GRACO INC. P.O. BOX 1441 MINNEAPOLIS, MN 55440-1441
Copyright 2000, Graco Inc. is registered to I.S. EN ISO 9001
Model 970159 Tandem Shown
310334 rev.D
Advertisement
Table of Contents
Related Manuals for Graco 970159
Summary of Contents for Graco 970159
- Page 1 Module Supply Units 310334 rev.D 1800 psi (124 bar) Maximum Working Pressure * Model 970159, Tandem with Pneumatic Crossover (carbon steel pump) * Model 288649, Tanden with Pneumatic Crossover (stainless steel pump) Model 970160, Tandem with Electric Crossover * Model 970163, Pneumatic Low Level Shutoff * These models are CE certified.
-
Page 2: Table Of Contents
Maximum Fluid Maximum Pump Parts Part No. Pump Model Pump Model Ratio Working Pressure Air Input Pressure Page * 970159 Quiet Kingt Dura–Flowt 2400 20:1 125 bar, 13 MPa 6 bar, 0.6 MPa (carbon steel) (1800 psi) (90 psi) * 288649 Quiet Kingt Dura–Flowt 2400... -
Page 3: Warnings
D This equipment is for professional use only. D Read all instruction manuals, warnings, tags, and labels before operating the equipment. D Use the equipment only for its intended purpose. If you are uncertain about usage, call your Graco distributor. - Page 4 WARNING SKIN INJECTION HAZARD Spray from the spray gun, hose leaks, or ruptured components can inject fluid into your body and cause extremely serious injury, including the need for amputation. Splashing fluid in the eyes or on the skin can also cause serious injury. D Fluid injected into the skin might look like just a cut, but it is a serious injury.
- Page 5 WARNING MOVING PARTS HAZARD Moving parts, such as the ram follower plate/pump inlet can pinch fingers. D Do not operate the equipment with the guard removed. D Keep clear of all moving parts when starting or operating the equipment. D Keep hands and fingers away from the priming piston during operation and whenever the pump is charged with air.
-
Page 6: System Information
(Refer to the preceding WARNING ). When closed, System 970159 includes a dual 55 gallon supply unit the valve bleeds off all air in the ram and pump, and with pneumatic crossover for continuous material the ram slowly lowers. -
Page 7: Component Identification And Function
Component Identification and Function Pump Pump Air Bleed Valve Ball Valve Ram (two used on 970159 and 970160, (required, for pump) Ram Air Regulator one used on 970163) Air Line Filter Ram Director Valve Ram Plate Bleed-Type Air Valve Air Release Valve... -
Page 8: System Setup
(Y) into slot in lug (Z) and accessories. Contact your Graco distributor for help in tighten locknut securely. Connect other end of wire designing a system to suit your particular needs. - Page 9 This allows constant material flow and changing out of off. During operation, this position can be adjusted as material drums. desired. See Fig. 3. Pneumatic Crossover Setup (Model 970159) TI0388 Primary Valve Regulator 4–Way Piloted Air Valve...
- Page 10 System Setup Electrical Crossover Setup (Model 970160) The position of the empty level indicator kit (2) on the ram determines when the ram air motor is turned on and off. During operation, this position can be adjusted The electrical crossover is setup as shown in Fig. 4 as desired.
- Page 11 System Setup Low–Level Shutoff Setup (Model 970163) NOTE: The position of the air limit valve (2) on the ram determines when the ram air motor is turned on Setup the low–level shutoff as shown in Fig. 5. and off. During operation, this position can be adjusted During system operation, as the ram approaches the as desired.
-
Page 12: Operation
D or install or clean the dispense ball valve. WARNING Use fluids and solvents that are chemically compat- 1. Relieve system pressure to which Graco module ible with the equipment wetted parts. Refer to the supply units are attached. Technical Data sections of all the equipment manuals. - Page 13 Operation Model 970159 Tandem Ram Shown 05698B TI0361A Fig. 7 310334...
- Page 14 Operation Starting and Adjusting System Rams CAUTION To help avoid damage to equipment, do not use WARNING drums that have side bungs or large dents with this ram. Rough bung openings or large dents will dam- PRESSURIZED EQUIPMENT HAZARD age the wipers or stop the ram plate, resulting in a To reduce risk of injury or equipment runaway pump.
- Page 15 Operation Changing Drums 6. Inspect wiper plate and, if necessary, remove any remaining material or material build–up. WARNING Place full drum on ram base. MOVING PARTS HAZARD 8. Lower ram and adjust position of drum relative to Moving parts can pinch or amputate your ram plate, as explained under Starting and Ad- fingers.
- Page 16 Parts Models 970159 and 288649 Tandem with Pneumatic Crossover, 20:1 Ratio Quiet King Pump Includes items 1–7 2 REF Ref No. 3 Fluid Supply Hose Includes Items 4–7 TI0362A Part Part Description Description C59769 PUMP, ram–mounted 200 liter (55 gal.) C56995 HOSE ASSEMBLY, fluid supply;...
- Page 17 Parts Model 970160 Tandem with Electrical Crossover, 20:1 Ratio Quiet King Pump Includes items 1–7 Ref No. 2 Electrical Crossover Kit 7 6 5 4 Ref No. 3 Fluid Supply Hose Includes Items 4–7 TI0363 Part Part Description Description C59769 PUMP, ram–mounted 200 liter (55 gal.) 521973 .
- Page 18 Parts Model 970163 Supply Unit with Pneumatic Low Level Shut–Off, 20:1 Ratio Quiet King Pump Includes items 1–7 Ref No. 3 Fluid Supply Hose Includes Items 4–7 Part Part Description Description C59769 PUMP, ram–mounted 200 liter (55 gal.) 521973 . HOSE ASSEMBLY See 308027 for parts 521975 .
- Page 19 Ram Mounted Pump Clearance Dimensions Model 970159 Ram Shown 14.2 mm (0.56 in.) Diameter Holes Model (Raised) (Lowered) 2578 mm 1575 mm 533 mm 635 mm 965 mm 1067 mm 1111 mm (101.5 in.) (62 in.) (21 in.) (25 in.) (38 in.)
- Page 20 Notes 310334...
-
Page 21: Displacement
..........1/2 in. npt(f) Material outlets [for 970159 (2), 970160 (2), and 970163 (1)] .... - Page 22 Notes 310334...
- Page 23 Schematic Pneumatic Crossover Schematic Diagram (Model 970159 only) TI0389 Fig. 8 310334...
- Page 24 With the exception of any special, extended, or limited warranty published by Graco, Graco will, for a period of twelve months from the date of sale, repair or replace any part of the equipment determined by Graco to be defective.
