Summary of Contents for Samsung PPM42H3
-
Page 1: Video Wall
PDP-MONITOR LASMA ISPLAY ANEL Owner’s Instructions Before operating the unit, please read this manual thoroughly, and retain it for future reference. Intended for Commercial Use and Operation ON-SCREEN MENUS (PIP) ICTURE ICTURE VIDEO WALL ULTIPLE ISPLAY ONTROL... -
Page 2: Important Warranty Information Regarding Pdp Format Viewing
Be careful in the selection and duration of PDP formats used for viewing. Uneven PDP aging as a result of format selection and use, as well as burned-in images, are not covered by your Samsung limited warranty. -
Page 3: User Instructions
Remote Control/ AAA Batteries 1 Install CD Ferrite Cores for MDC Software (RS232C) Speaker Wire (2EA) The PPM42H3 model uses the same MDC program CD used for PPM50H3/PPM63H3 models. Power Cord Speaker Wires (2EA) PC Cable MDC Cable (RS232C) Stand-Base... -
Page 4: Table Of Contents
OREWORD Important Warranty Information Regarding PDP Format Viewing... User Instructions... ONNECTING AND Your New Plasma Display Panel... Becoming Familiar with the Remote Control ... Inserting the Batteries in the Remote Control... Assembling the Stand-Base ... Installing the Display on the Wall Attachment Panel ... Before Using the Video Wall and the Multiple Display Contol function ... -
Page 5: Your
Contents SING ISPLAY CONTINUED Locking the Control buttons... Setting the MDC (Multiple Display Control) ... Protecting the Screen Burning... Setting the Multiple Screen... Displaying the PC Information ... Displaying the Setting Information... Setting and Displaying the Current Time... Switching On and Off Automatically ... Setting the Film Mode... -
Page 6: Your New Plasma Display Panel
Your New Plasma Display Panel Front Panel Speaker SOURCE - External input selection. - Store your settings in the menu. - When the Main menu is displayed on screen, the Main menu is not operated with source key. MENU Menu display and exit. - VOL + - Volume adjustment. -
Page 7: Rear Panel
Your New Plasma Display Panel Rear Panel For further details about connection, refer to pages 35~37. a) RS232C - IN : Used for the MDC function when connecting PC or RS232C output of another PDP. - OUT : Used for the MDC function when connecting with RS232C input of another PDP. -
Page 8: Becoming Familiar With The Remote Control
The performance of the remote control may be affected by bright light. PDP OFF CURRENT TIME DISPLAY ZOOM/PANNING MENU DISPLAY (ONLY PC MODE) NEXT CHANNEL (NOT AVAILABLE FOR THIS MONITOR) EXTERNAL INPUT SELECTION PREVIOUS CHANNEL (NOT AVAILABLE FOR THIS MONITOR) INFORMATION DISPLAY EXIT FROM ANY DISPLAY... -
Page 9: Inserting The Batteries In The Remote Control
Assembling the Stand-Base Fit the Stand-Base into the guide hole on the bottom of the monitor and tighten the left and right sides using four screws for each side. Two or more people should carry the PDP. -
Page 10: Installing The Display On The Wall Attachment Panel
Installing the Display on the Wall Attachment Panel This wall mount bracket installation guide is for the WMN4230 model. This installation guide may be different from the PDP User’s manual. Please refer to the proper installation guide for your product. Installation Notes Do not install the PDP on any place other than vertical walls. - Page 11 Installing the Display on the Wall Attachment Panel The exterior of the PDP may be different than the picture. (Assembly and installation of the plastic hanger is the same.) Remove the screws from the back of the PDP. Use the screws and assemble the plastic hanger. Please ask the installers to install the wall mount bracket.
-
Page 12: Before Using The Video Wall And The Multiple Display Contol Function
For details about Multiple Display Control, refer to “Setting the MDC (Multiple Display Control)” on page 25 and the Help section in MDC program CD. The PPM42H3 model uses the same MDC program CD used for PPM50H3/PPM63H3 models. Do not install the PDP vertically. -
Page 13: Connecting Speakers
Connecting Speakers Remove the screws on the rear of the PDP. Hang the two “T” shaped hangers on the square holes on the rear of the PDP. Tighten the PDP and the speaker bracket using the screws removed from the PDP. When moving your PDP, do NOT hold the speaker connected to your PDP. - Page 14 Connecting Speakers Connect the speaker audio cable to the external speaker output jack on the rear of the PDP matching the “+” and “-” ends of the cable with the diagram on the PDP. The speakers MUST have to a power handling capability of 10 watts minimum (impedance 8Ω).
-
Page 15: Switching On And Off
Switching On and Off The mains lead is attached to the rear of your PDP. Plug the mains lead into an appropriate socket. Result: The Standby indicator on the front of the PDP lights up. The main voltage is indicated on the rear of the PDP and the frequency is 50 or 60Hz. -
Page 16: Selecting The Color System (Video Or S-Video Mode)
Selecting the Color System Picture œ œ AUTO √ √ Color System œ œ Dynamic √ √ Mode √ √ Adjust œ œ Normal √ √ Color Tone Size Wide œ œ Off √ √ Digital NR Move Sel. Changing the Picture Mode Picture œ... -
Page 17: Adjusting The Picture Settings
Adjusting the Picture Settings Your PDP has several settings which allow you to control picture quality. Press the MENU button. Result: The options available in the Picture group are displayed. Press the √ button. button to select Adjust. Press the √ button. Press the Result: The Adjust menu is displayed. -
Page 18: Adjusting The Picture Settings (Pc Or Dvi Mode)
Adjusting the Picture Settings Picture œ œ Custom √ √ Mode √ √ Adjust œ œ Custom √ √ Color Tone √ √ Color Adjust Size Wide Move Enter Adjust (Custom) Contrast Brightness Sharpness Move Adjust Picture œ œ Custom √ √ Mode √... -
Page 19: Selecting The Picture Size
Selecting the Picture Size You can select the picture size which best corresponds to your viewing requirements. Press the MENU button. Result: The options available in the Picture group are displayed. Press the √ button. button to select Size. Press the √ button. Press the Select the option by pressing the œ... -
Page 20: Freezing The Current Picture
Freezing the Current Picture Changing the Sound Mode Sound œ œ Custom √ √ Mode √ √ Equalizer œ œ Off √ √ Auto Volume œ œ Off √ √ Melody œ œ Off √ √ Pseudo Stereo œ œ Off √ √ Virtual Surround Move Sel. -
Page 21: Adjusting The Sound Settings
Adjusting the Sound Settings The sound settings can be adjusted to suit your personal preferences. Press the MENU button. Result: The main menu is displayed. Press the button to select Sound. Result: The options available in the Sound group are displayed. Press the √... -
Page 22: Extra Sound Settings
Extra Sound Settings Sound œ œ Custom √ √ Mode √ √ Equalizer œ œ Off √ √ Auto Volume œ œ Off √ √ Melody œ œ Off √ √ Pseudo Stereo œ œ Off √ √ Virtual Surround Move Sel. -
Page 23: Adjusting The Screen Position And Scale
Adjusting the Screen Position and Scale Press the MENU button. Result: The main menu is displayed. Press the button to select Setup. Result: The options available in the Setup group are displayed. Press the √ button. Result: The Screen Adjust is selected. Press the √... -
Page 24: Adjusting The Image Preferences (Pc Mode)
Adjusting the Image Preferences Setup √ √ Image Lock œ œ Off √ √ Key Lock √ √ Multi Control √ √ Burning Protection √ √ Video Wall √ √ Information Move Enter Image Lock Auto Adjustment Frequency Phase Position Zoom/Panning √... -
Page 25: Locking The Control Buttons
Locking the Control buttons This feature allows you to lock the PDP so that it cannot be switched on via the front panel. It can, however, still be switched on via the remote control. Thus, by keeping the remote control away from unauthorised users. -
Page 26: Protecting The Screen Burning
Protecting the Screen Burning Setup √ √ Screen Adjust œ œ Off √ √ Key Lock √ √ Multi Control √ √ Burning Protection √ √ Video Wall Move Enter Burning Protection √ √ Pixel Shift œ œ Off √ √ Signal Pattern œ... -
Page 27: Setting The Multiple Screen
Setting the Multiple Screen You can get the various display effect with many PDPs. Press the MENU button. Result: The main menu is displayed. Press the button to select Setup. Result: The options available in the Setup group are displayed. Press the √... -
Page 28: Displaying The Pc Information
Displaying the PC Information Setup √ √ Image Lock œ œ Off √ √ Key Lock √ √ Multi Control √ √ Burning Protection √ √ Video Wall √ √ Information Move Enter PC Information Resolution 1024x768 V Frequency H Frequency Return Displaying the Setting Information Mode... -
Page 29: Setting And Displaying The Current Time
Setting and Displaying the Current Time You can set the clock so that the current time is displayed. You must also set the time if you wish to use the automatic on or off timers. Press the MENU button. Result: The main menu is displayed. -
Page 30: Switching On And Off Automatically
Switching On and Off Automatically Time 11:35 Clock œ œ Off √ √ Clock Display œ œ Off √ √ Timer On Time Volume - - : - - On Time - - : - - Off Time œ œ √ √ Sel. Move Time Clock... -
Page 31: Setting The Film Mode
Setting the Film Mode When a video input source is from a film such as movies, this feature identifies the source and changes to the corresponding screen. Press the MENU button. Result: The main menu is displayed. Press the button to select Function. Result: The options available in the Function group are displayed. -
Page 32: Viewing The Picture In Picture (Pip)
Sound Sel. Move Sel. You can display a sub picture within the main picture. In this way you can monitor the video input from any connected devices while monitoring other video input. Press the MENU button. Result: The main menu is displayed. - Page 33 Viewing the Picture In Picture (PIP) Easy functions of remote control. Buttons Feature PIP ON Used to activate or deactivate the PIP feature directly. SIZE Used to select a size of sub picture (Large, Small, Double1, Double2). LOCATE Used to move the sub picture counterclockwise. SOURCE Used to assign a source of sub picture.
-
Page 34: Listening To The Sound Of The Sub Picture
Listening to the Sound of the Sub Picture œ œ On √ √ œ œ Video √ √ Sel. √ √ Swap œ œ Large √ √ Size œ œ Locate œ œ Sub √ √ Sound Sel. Move Sel. Viewing Pictures From External Sources AV Input Video... -
Page 35: Connecting To The Audio/Video Input
Connecting to the Audio/Video Input The "VIDEO IN" connectors are used for the equipment with an Composite Video output, such as video game devices or video disc players. Rear of the PDP (Input) The "VIDEO OUT" connectors are used for the equipment with an Composite Video input, such as a camcorder or VCR. -
Page 36: Connecting To The S-Video Input
Connecting to the S-Video Input The S-VIDEO and RCA (AUDIO-L/R) connectors are used for equipment with an S-Video output, such as a camcorder or VCR. Rear of the PDP To play picture and sound, both the S-VIDEO and RCA connectors must be used. Connecting to the DVD/DTV RECEIVER Input The “COMPONENT1 IN”... -
Page 37: Connecting To The Dvi Input
Connecting to the DVI Input The “DVI IN” (video) and “AUDIO” connectors are used for equipment with a DVI output. Rear of the PDP Connecting to the RGB(PC) Input The “RGB1(PC1) IN” (or “R(Pr)/G(Y)/B(Pb)/H/V”) and “AUDIO” connectors are used for interfacing with your PC. Rear of the PDP Personal Computer Personal Computer... -
Page 38: Setting Up Your Pc Software (Windows Only)
PC will probably be different, depending upon your particular version of Windows and your particular video card. But even if your actual screens look different, the same, basic set-up information will apply in almost all cases. (If not, contact your computer manufacturer or Samsung Dealer.) On the windows screen, select in the following... -
Page 39: Pin Configurations
Pin Configurations RGB(PC) Input Connector (15Pin) RGB(PC) IN Red (R) Green (G) Blue (B) Grounding Grounding (DDC) Red (R) Grounding Green (G) Grounding Blue (B) Grounding Reserved Sync Grounding Grounding Data (DDC) Horizontal sync. Vertical sync. Clock (DDC) RS232C Connector (9Pin) Signal Carrier Detect... -
Page 40: Input Mode (Pc/Dvi)
Input Mode (PC/DVI) Both screen position and size will vary depending on the type of PC monitor and its resolution. The table below shows all of the display modes that are supported: Resolution 640 x 350 640 x 400 720 x 400... -
Page 41: Power Saver (Pc1 Mode Only)
This monitor has a built-in power management system called Power Saver. This power management system saves energy by switching your monitor into a low-power mode when it has not been used for a certain amount of time. This power management system operates with a VESA DPMS compliant video card installed in your computer. -
Page 42: Troubleshooting: Before Contacting Service Personnel
Troubleshooting: Before contacting Samsung after-sales service, perform the following simple checks. If you cannot solve the problem using the instructions below, note the model and serial number of the PDP and contact your local dealer. No sound or picture Normal picture but no sound... -
Page 43: Technical Specifications
(H x V) Color systems Sound Audio output power Power supply Power consumption Video inputs Monitor outputs Audio inputs Audio outputs External control 1027 x 79 x 630.5 mm ; 40.43 x 3.11 x 24.82 inches 31kg 16:9 42 inch 1024 x 768 PAL, SECAM, NTSC (NT3.58/NT4.43) - Page 44 Memo...
- Page 45 Memo...
- Page 46 - AFTER SALES SERVICE - Do not hesitate to contact your retailer or service agent if a change in the performance of your product indicates that a faulty condition may be present. BN68-00589A-00...
