- Page 1 SIMATIC RTLS4030G Introduction Device description SIMATIC RTLS Installation & Operation Technical specifications Localization systems SIMATIC RTLS4030G Approvals Operating Instructions 05/2023 C79000-G8976-C515-10...
- Page 2 Note the following: WARNING Siemens products may only be used for the applications described in the catalog and in the relevant technical documentation. If products and components from other manufacturers are used, these must be recommended or approved by Siemens. Proper transport, storage, installation, assembly, commissioning, operation and maintenance are required to ensure that the products operate safely and without any problems.
-
Page 3: Table Of Contents
Mounting for ceiling holder with mounting plate ............... 20 Mounting for corner and pole mount ................. 21 Ethernet ..........................22 Operation .......................... 22 Cleaning and maintenance ....................22 Technical specifications ........................25 Approvals ............................. 27 SIMATIC RTLS4030G Operating Instructions, 05/2023, C79000-G8976-C515-10... - Page 4 Table of contents SIMATIC RTLS4030G Operating Instructions, 05/2023, C79000-G8976-C515-10...
-
Page 5: Introduction
You can find the complete documentation for all SIMATIC RTLS products at the following address: Link: (https://support.industry.siemens.com/cs/us/en/ps/25277/man) Trademarks The following and possibly other names not identified by the registered trademark sign ® registered trademarks of Siemens AG: SIMATIC RTLS SIMATIC RTLS4030G Operating Instructions, 05/2023, C79000-G8976-C515-10... - Page 6 Introduction Industry Online Support In addition to the product documentation, the comprehensive online information platform of Siemens Industry Online Support offers support at the following Internet address: (https://support.industry.siemens.com/cs/start?lc=en-US) Apart from news, there you will also find: • Project information: Manuals, FAQs, downloads, application examples etc.
- Page 7 Use of product versions that are no longer supported, and failure to apply latest updates may increase customer’s exposure to cyber threats. To ensure that you are always informed about product updates, subscribe to the Siemens Industrial Security RSS feed at: (https://www.siemens.com/cert) Note on firmware/software support Check regularly for new firmware/software versions or security updates and apply them.
- Page 8 Industrial Security (https://new.siemens.com/global/en/products/automation/topic-areas/industrial- security.html) website. • Inform yourself regularly about security recommendations published by Siemens ProductCERT (https://new.siemens.com/global/en/products/services/cert.html). • Evaluate your plant as a whole in terms of security. Use a cell protection concept with suitable products.
- Page 9 Do not dispose of the products at public disposal sites. For environmentally compliant recycling and disposal of your electronic waste, please contact a company certified for the disposal of electronic waste or your Siemens representative. Note the different national regulations.
- Page 10 Introduction SIMATIC RTLS4030G Operating Instructions, 05/2023, C79000-G8976-C515-10...
-
Page 11: Device Description
Device description Characteristics SIMATIC RTLS4030G Characteristics Design ① Status indicators (LEDs) ② Connection for power supply ③ Ethernet port; Alternative power supply using Power over Ethernet (PoE) General The gateway is the home location for localization in the RTLS localization system. -
Page 12: Order Data For Rtls4030G And Accessories
Device description 2.2 Order data for RTLS4030G and accessories Order data for RTLS4030G and accessories Table 2- 1 Order data RTLS4030G Article number SIMATIC RTLS4030G 6GT2701-5DB03 FCC/NOM/ANA 6GT2701-5DB13 CMIIT 6GT2701-5DB23 ISED 6GT2701-5DB33 Table 2- 2 Accessories order data (not included in scope of delivery) -
Page 13: Pin Assignment
• Sealing cover: PX0480 The pins are occupied as illustrated below: Description Supply voltage (red) 8 ... 30 V DC Digital output (brown) Switched input voltage, max. current 200 mA Grounding terminal (black) GND (0 V) SIMATIC RTLS4030G Operating Instructions, 05/2023, C79000-G8976-C515-10... -
Page 14: Led Status Indicator
Locating Manager LAN/SERVER LED Flashes blue once per second when the gateway has an Ethernet connection but no connection to the Locating Manager server LAN/SERVER LED Off when the gateway has no Ethernet connection SIMATIC RTLS4030G Operating Instructions, 05/2023, C79000-G8976-C515-10... -
Page 15: Dimension Drawing
Device description 2.5 Dimension drawing Dimension drawing Figure 2-2 Dimension drawing SIMATIC RTLS4030G - All dimensions specified in millimeters Troubleshooting Error detection Cause of the error Troubleshooting The gateway does not respond, all LEDs The gateway is not connected or... - Page 16 Device description 2.6 Troubleshooting SIMATIC RTLS4030G Operating Instructions, 05/2023, C79000-G8976-C515-10...
-
Page 17: Installation & Operation
Make sure that the ambient temperature does not exceed 50 °C and that the gateway is not installed in a location where it is exposed to direct sunlight. SIMATIC RTLS4030G Operating Instructions, 05/2023, C79000-G8976-C515-10... - Page 18 Make sure that the wiring is correct before you start up the gateway. Only use the cables described in the order data, supplied with the device or otherwise prescribed. Siemens AG is not liable for damage or functional limitations caused by the use of other cables.
- Page 19 2. Drill the holes with a suitable tool. 3. Insert the suitable anchors in the holes. 4. Mount the gateway to the wall using screws (M4). Figure 3-1 Drilling pattern - All dimensions specified in millimeters SIMATIC RTLS4030G Operating Instructions, 05/2023, C79000-G8976-C515-10...
-
Page 20: Mounting For Ceiling Holder With Mounting Plate
Figure 3-2 Gateway holder for ceiling installation - all dimensions specified in millimeters * Use this hole for mounting with the supplied plastic screw SIMATIC RTLS4030G Operating Instructions, 05/2023, C79000-G8976-C515-10... -
Page 21: Mounting For Corner And Pole Mount
Gateway holder for corner and mast mounting - all dimensions specified in millimeters Note If drilling is not possible, you can also fasten the gateway holder for corner and mast mounting to the given position using cable ties, for example. SIMATIC RTLS4030G Operating Instructions, 05/2023, C79000-G8976-C515-10... -
Page 22: Ethernet
Unauthorized opening of and improper repairs to the gateway may cause substantial risks to the user. As soon as the gateway has been opened without permission, warranty and liability of the Siemens AG are rendered null and void. Do not clean the enclosure with abrasive, alkaline or aggressive cleaning products or aids. - Page 23 Installation & Operation 3.6 Cleaning and maintenance SIMATIC RTLS4030G Operating Instructions, 05/2023, C79000-G8976-C515-10...
-
Page 25: Technical Specifications
Technical specifications Table 4- 1 Technical specifications of the gateway RTLS4030G 6GT2701-5DB03, 6GT2701-5DB13 6GT2701-5DB23, 6GT2701-5DB33 Product name SIMATIC RTLS4030G PULSE radio frequencies Wireless method IEEE 802.15.4-2015 UWB HRP PHY Transmission speed 850 kbps Operating frequency rated value 3993.6 MHz (UWB channel 2; CE, FCC/NOM/ANATEL) 6489.6 MHz (UWB channel 5;... - Page 26 Fixed mounting on walls, ceilings or masts Enclosure Plastic enclosure (ASA and PC), UV-resistant Color Titanium gray Power plug 3-pin plug-in connector with screw-type terminal Bulgin Buccaneer® PX0412/03P Ethernet RJ45 Ethernet with PoE Amphenol LTW RCP-00AMMA-TLM7001 SIMATIC RTLS4030G Operating Instructions, 05/2023, C79000-G8976-C515-10...
-
Page 27: Approvals
Declaration of conformity according to the technical regulations of the customs union (TR CU) USA (FCC) This device complies with part 15 of the FCC rules. Alternative: FCC ID: XXXXYYZZZZ IC: XXXXYYZZZZ Canada (ISED) This device complies with Industry Canada licence-exempt RSS standard(s). SIMATIC RTLS4030G Operating Instructions, 05/2023, C79000-G8976-C515-10... - Page 28 Para maiores informações, consulte o site da ANATEL (www.anatel.gov.br). ANATEL: XXXXYYZZZZ Importer UK: Siemens plc, Sir William Siemens House, Princess Road, Manchester M20 2UR Mexico (NOM) La operación de este equipo está sujeta a las siguientes dos condiciones: (1) es posible que este equipo o dispositivo no cause interferencia perjudicial y (2) este equipo o dispositivo debe aceptar cualquier interferencia, incluyendo la que pueda causar su operación...
- Page 29 Siemens plc, Manchester M20 2UR You can find the current UK Declaration of Conformity for these products on the Internet pages under Siemens Industry Online Support (https://support.industry.siemens.com/cs/en/en/view/109801531). The SIMATIC RTLS products described in this document meet the requirements of the following directives/regulation: •...
- Page 30 Electromagnetic compatibility of multimedia equipment – Emission requirements • EN 55035 Electromagnetic compatibility of multimedia equipment - Immunity requirements • EN 61000-6-1 Electromagnetic compatibility (EMC) - Part 6-1: Generic standards - Immunity for residential, commercial and light-industrial environments SIMATIC RTLS4030G Operating Instructions, 05/2023, C79000-G8976-C515-10...
- Page 31 3.2 of the Directive 2014/53/EU; Part 2: Requirements for UWB location tracking FCC information Siemens SIMATIC RTLS4030G (MLFB 6GT2701-5DB13); FCC ID SCF6032502 This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions:...
- Page 32 This equipment should be installed and operated with a minimum distance of 20 centimeters between the radiator and your body. ISED information Siemens SIMATIC RTLS4030G (MLFB 6GT2701-5DB33); IC ID 267X-4030G01 NOTICE (RSS-Gen Issue 5) This device complies with license-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and Economic Development Canada’s licence-exempt RSS standard(s).
- Page 33 61140 / EN 62368-1. • Le bloc d'alimentation de l'appareil doit être conforme à NEC Class 2 selon National Electrical Code (r) (ANSI/NFPA 70). The labeling of electrical equipment is as follows: LISTED E115352 SIMATIC RTLS4030G Operating Instructions, 05/2023, C79000-G8976-C515-10...
- Page 34 Approvals CMIIT Information Siemens SIMATIC RTLS4030G (MLFB 6GT2701-5DB23); CMIIT ID: 2020DJ2433 Radio Transmission Equipment Type Approval Certificate In accordance with the provisions on the Radio Regulations of the People's Republic of China, the following radio transmission equipment, after examination, conforms to the provisions with its CMIIT ID.
