Siemens SIMATIC RTLS4084T Operating Instructions Manual
Localization systems
Hide thumbs
Also See for SIMATIC RTLS4084T:
- Operating instructions manual (35 pages) ,
- System manual (204 pages)
Related Manuals for Siemens SIMATIC RTLS4084T
Summary of Contents for Siemens SIMATIC RTLS4084T
- Page 1 SIMATIC RTLS4084T Introduction Device description SIMATIC RTLS Installation & operation Technical specifications Localization systems SIMATIC RTLS4084T Approvals Operating Instructions 05/2023 C79000-G8976-C626-04...
- Page 2 Note the following: WARNING Siemens products may only be used for the applications described in the catalog and in the relevant technical documentation. If products and components from other manufacturers are used, these must be recommended or approved by Siemens. Proper transport, storage, installation, assembly, commissioning, operation and maintenance are required to ensure that the products operate safely and without any problems.
-
Page 3: Table Of Contents
Notes on installation ......................13 Replacing the battery pack ....................15 Cleaning and maintenance ....................15 Technical specifications ........................17 Technical specifications of the RTLS4084T ................17 Technical specifications of the battery pack ................ 18 Approvals ............................. 19 SIMATIC RTLS4084T Operating Instructions, 05/2023, C79000-G8976-C626-04... - Page 4 Table of contents SIMATIC RTLS4084T Operating Instructions, 05/2023, C79000-G8976-C626-04...
-
Page 5: Introduction
You can find the complete documentation for all SIMATIC RTLS products at the following address: Link: (https://support.industry.siemens.com/cs/us/en/ps/25277/man) Trademarks The following and possibly other names not identified by the registered trademark sign ® registered trademarks of Siemens AG: SIMATIC RTLS SIMATIC RTLS4084T Operating Instructions, 05/2023, C79000-G8976-C626-04... - Page 6 Introduction Industry Online Support In addition to the product documentation, the comprehensive online information platform of Siemens Industry Online Support offers support at the following Internet address: (https://support.industry.siemens.com/cs/start?lc=en-US) Apart from news, there you will also find: • Project information: Manuals, FAQs, downloads, application examples etc.
- Page 7 Use of product versions that are no longer supported, and failure to apply latest updates may increase customer’s exposure to cyber threats. To ensure that you are always informed about product updates, subscribe to the Siemens Industrial Security RSS feed at: (https://www.siemens.com/cert) Note on firmware/software support Check regularly for new firmware/software versions or security updates and apply them.
- Page 8 Do not dispose of the products at public disposal sites. For environmentally compliant recycling and disposal of your electronic waste, please contact a company certified for the disposal of electronic waste or your Siemens representative. Note the different national regulations.
-
Page 9: Device Description
Device description Characteristics SIMATIC RTLS4084T Characteristics Design ① L1 and L2 status indicators (LEDs) ② F1 and F2 function keys ③ Display General The transponder is a mobile device for localization in the RTLS localization system. It sends position data to gateways which transmit the data to the Locating Manager server. -
Page 10: Led Status Indicator, Display & Function Key
"low power" message is generated and LED 1 flashes red. Refer to the notes in the section "Installation & operation (Page 13)". SIMATIC RTLS4084T Operating Instructions, 05/2023, C79000-G8976-C626-04... -
Page 11: Dimension Drawing
Device description 2.4 Dimension drawing Dimension drawing Figure 2-1 Dimension drawing SIMATIC RTLS4084T - All dimensions are given in millimeters SIMATIC RTLS4084T Operating Instructions, 05/2023, C79000-G8976-C626-04... - Page 12 Device description 2.4 Dimension drawing SIMATIC RTLS4084T Operating Instructions, 05/2023, C79000-G8976-C626-04...
-
Page 13: Installation & Operation
Avoid contact with the battery fluid. Rinse skin that comes into contact with battery fluid with water. If fluid from the battery gets into your eye, seek medical attention. CAUTION Fires and burns Improper handling of batteries can lead result in fires and burns. SIMATIC RTLS4084T Operating Instructions, 05/2023, C79000-G8976-C626-04... - Page 14 Strong senders in close vicinity can interfere with the reception, even when they are located in neighboring frequency bands (de-sensing). This is true, for example, for the 2.4 GHz ISM band and PULSE in the UWB channel 5. SIMATIC RTLS4084T Operating Instructions, 05/2023, C79000-G8976-C626-04...
-
Page 15: Replacing The Battery Pack
Improper opening or repair of the transponder may result in serious risks for the user. Opening the transponder without permission renders the warranty of the Siemens AG null and void. Do not clean the enclosure with liquids or abrasive, caustic or flammable cleaning products. - Page 16 Installation & operation 3.3 Cleaning and maintenance SIMATIC RTLS4084T Operating Instructions, 05/2023, C79000-G8976-C626-04...
-
Page 17: Technical Specifications
Technical specifications Technical specifications of the RTLS4084T Table 4- 1 Technical specifications of the RTLS4084T transponder 6GT2700-7DC05, 6GT2700-7DC15 Product name SIMATIC RTLS4084T PULSE radio frequencies (localization) Wireless method IEEE 802.15.4-2015 UWB HRP PHY Transmission speed 850 Kbps Operating frequency rated value 3993.6 MHz (UWB channel 2;... -
Page 18: Technical Specifications Of The Battery Pack
During operation • -60 ... +85 °C • During storage • maximum +30 °C Dimensions (L x W x H) 57.9 x 53 x 14.8 mm (+/- 2 mm) Weight 74 g Color Blue SIMATIC RTLS4084T Operating Instructions, 05/2023, C79000-G8976-C626-04... -
Page 19: Approvals
Declaration of conformity according to the technical regulations of the customs union (TR CU) USA (FCC) This device complies with part 15 of the FCC rules. Alternative: FCC ID: XXXXYYZZZZ IC: XXXXYYZZZZ Canada (ISED) This device complies with Industry Canada licence-exempt RSS standard(s). SIMATIC RTLS4084T Operating Instructions, 05/2023, C79000-G8976-C626-04... - Page 20 Para maiores informações, consulte o site da ANATEL (www.anatel.gov.br). ANATEL: XXXXYYZZZZ Importer UK: Siemens plc, Sir William Siemens House, Princess Road, Manchester M20 2UR Mexico (NOM) La operación de este equipo está sujeta a las siguientes dos condiciones: (1) es posible que este equipo o dispositivo no cause interferencia perjudicial y (2) este equipo o dispositivo debe aceptar cualquier interferencia, incluyendo la que pueda causar su operación...
- Page 21 Siemens plc, Manchester M20 2UR You can find the current UK Declaration of Conformity for these products on the Internet pages under Siemens Industry Online Support (https://support.industry.siemens.com/cs/en/en/view/109801531). The SIMATIC RTLS products described in this document meet the requirements of the following directives/regulation: •...
- Page 22 Electromagnetic compatibility of multimedia equipment – Emission requirements • EN 55035 Electromagnetic compatibility of multimedia equipment - Immunity requirements • EN 61000-6-1 Electromagnetic compatibility (EMC) - Part 6-1: Generic standards - Immunity for residential, commercial and light-industrial environments SIMATIC RTLS4084T Operating Instructions, 05/2023, C79000-G8976-C626-04...
- Page 23 3.2 of the Directive 2014/53/EU; Part 2: Requirements for UWB location tracking FCC information Siemens SIMATIC RTLS4084T (MLFB 6GT2700-7DC15); FCC ID SCF6032702 This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions:...
