JETWAY MI23 Series User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Trademark:
* Specifications and Information contained in this documentation are furnished for information use only, and are
subject to change at any time without notice, and should not be construed as a commitment by manufacturer.
MI23 Series
User's Manual
NO. G03-MI23-F
Revision: 2.0
Release date: June 14, 2023

Advertisement

Table of Contents
loading

Related Manuals for JETWAY MI23 Series

Summary of Contents for JETWAY MI23 Series

  • Page 1 MI23 Series User’s Manual NO. G03-MI23-F Revision: 2.0 Release date: June 14, 2023 Trademark: * Specifications and Information contained in this documentation are furnished for information use only, and are subject to change at any time without notice, and should not be construed as a commitment by manufacturer.
  • Page 2 Environmental Protection Announcement Do not dispose this electronic device into the trash while discarding. To minimize pollution and ensure environment protection of mother earth, please recycle.

  • Page 3: Table Of Contents

    TABLE OF CONTENT ENVIRONMENTAL SAFETY INSTRUCTION..............iii USER’S NOTICE ......................iv MANUAL REVISION INFORMATION ................iv ITEM CHECKLIST ......................iv CHAPTER 1 INTRODUCTION OF THE MOTHERBOARD FEATURE OF MOTHERBOARD ................1 SPECIFICATION ....................2 LAYOUT DIAGRAM ....................4 CHAPTER 2 HARDWARE INSTALLATION JUMPER SETTING ....................

  • Page 4: Environmental Safety Instruction

    Environmental Safety Instruction  Avoid the dusty, humidity and temperature extremes. Do not place the product in any area where it may become wet.  0 to 40 centigrade is the suitable temperature. (The temperature comes from the request of the chassis and thermal solution) ...

  • Page 5: User's Notice

    USER’S NOTICE COPYRIGHT OF THIS MANUAL BELONGS TO THE MANUFACTURER. NO PART OF THIS MANUAL, INCLUDING THE PRODUCTS AND SOFTWARE DESCRIBED IN IT MAY BE REPRODUCED, TRANSMITTED OR TRANSLATED INTO ANY LANGUAGE IN ANY FORM OR BY ANY MEANS WITHOUT WRITTEN PERMISSION OF THE MANUFACTURER.

  • Page 6: Chapter 1 Introduction Of The Motherboard

    Chapter 1 Introduction of the Motherboard 1-1 Feature of Motherboard  ® Intel LGA1700 Socket supports 12 Gen. Core Processor (Max. 65W TDPs under 180A)  Support 2* DDR5 4800MHz SO-DIMM up to 64GB  MI23-Q670X/R680X series: total support up to 8* 2.5GbE RJ-45 LAN ports ...

  • Page 7: Specification

    1-2 Specification Spec Description  Mini-ITX form factor; 10-layers; Design  PCB size: 17.0x17.0cm  MI23-H610X Series: Intel H610E Chipset  Chipset MI23-Q670X Series: Intel Q670E Chipset  MI23-R680X Series: Intel R680E Chipset  Gen. Core™ i7 processors, Intel LGA 1700 Socket supports 12 Core™...
  • Page 8 5e UTP cable.  Graphics Intel UHD Graphics  BIOS AMI 256M Flash ROM Rear Panel I/O:  1* Power on/off button  1* Power LED & 1* HDD LED  1* RJ-45 RS232 COM port  MI23-Q670X/R680X: 2* USB 3.2 Gen.2 port & 2* USB 3.2 Gen.1 port ...

  • Page 9: Layout Diagram

    1-3 Layout Diagram Rear IO Diagram For MI23-Q670X / MI23-R680X Series: RJ-45 LAN Ports (2.5 GbE) USB 3.2 (Gen.1) RJ-45 RS232 Ports COM Port HDD LED Power Button USB 3.2 (Gen.2) Power LED Ports For MI23-H610X Series: RJ-45 LAN Ports (2.5 GbE) RJ-45 RS232 COM Port...
  • Page 10 Motherboard Internal Diagram-Front MI23-Q670X/R680X Series: ATX Main Power ATX 12V Connector Power Connector LGA1700 CPU Socket CPUFAN HDMI Header DDR5 SODIMM Slot x 2 *Rear IO Connector (Refer to Page-4) M.2 E-Key Slot M.2 M-Key Slot SMBUS Header (M2E1) (M2M1) M.2 B-Key Slot (M2B1 BATCON...
  • Page 11 Motherboard Internal Diagram-Front MI23-H610X Series: ATX Main Power ATX 12V Connector Power Connector LGA1700 CPU Socket CPUFAN HDMI Header DDR5 *Rear IO SODIMM Slot x 2 Connector (Refer to Page-4) M.2 E-Key Slot M.2 M-Key Slot SMBUS Header (M2E1) (M2M1) M.2 B-Key Slot (M2B1 SATAIII Ports...
  • Page 12 Motherboard Internal Diagram-Back *SIMCARDB1 *Note: 1. SIM card slot (only workable along with M.2 B-key slot); 2. PCIE2 sideway PCI Express Gen.4 x4 slot (only on MI23-Q670X/R680X) can be expanded to support up to 4* PCIe signal 4 by1 slots (At present, only supported by ETC4G adapter card series );...
  • Page 13 Motherboard Jumper Position JPCOM1 JPME_DIS COPEN JAT_ATX JP80P JBAT *Note: The diagrams in the manual are mostly taken from MI23-Q670X/R680X series unless otherwise stated.
  • Page 14 Connectors Connector Name RJ45_COM1 RJ-45 COM Port Connector for Console USB31 USB 3.2 (Gen.2) Port X2 MI23-Q670X/R680X: USB32 USB 3.2 (Gen.1) Port X2 Top: USB 2.0 Port MI23-H610X: USB32 Bottom: USB 3.2(Gen.1) Port LAN1-4 2.5 GbE RJ-45 LAN Port X4 MI23-Q670X/R680X: LAN5-8 2.5 GbE RJ-45 LAN Port X4...

  • Page 15: Chapter 2 Hardware Installation

    Jumper Jumper Name Description Pitch JPCOM1 RJ45_COM1 Port Pin-5 VCC Select 4-pin Block 2.0mm JPME_DIS ME Disabled 2-pin Block 2.0mm COPEN Case Open Message Display Function 2-pin Block 2.54mm JAT_ATX ATX Mode / AT Mode Select 3-pin Block 2.0mm JBAT Clear CMOS RAM Settings 3-pin Block 2.0mm...
  • Page 16 JPME_DIS(2-pin): ME Features Select JPME_DIS COPEN (2-pin): Case Open Message Display Function COPEN Pin 1-2 Short: When Case open function pin short to GND, the Case open function was detected. When Used, needs to enter BIOS and enable ‘Case Open Detect’ function. In this case if your...
  • Page 17 case is removed, next time when you restart your computer, a message will be displayed on screen to inform you of this. JAT_ATX (3-pin): AT Mode /ATX Mode Select JAT_ATX *ATX Mode Selected: Press power button to power on after power input ready; AT Mode Selected: Directly power on as power input ready.

  • Page 18: Connectors And Headers

    JP80P(2-pin): GPIO Header Function Select JP80P 2-2 Connectors and Headers 2-2-1 Connectors Rear I/O Back Panel Connectors Icon Name Function Power Button For user to power on/off the system. This connector is a RJ-45 COM port for console RJ-45 RSS232 COM Port function.
  • Page 19 To connect USB keyboard, mouse or other USB 2.0 Port devices compatible with USB 2.0 specification. To connect USB keyboard, mouse or other USB 3.2 (Gen.1) devices compatible with USB 3.2 (Gen.1) Port specification. Ports support up to 5Gbps data transfer rate.
  • Page 20 (2) 2.5 Gbps RJ-45 Ethernet LAN Port Connector LAN4 LAN2 LAN6 *LAN8 LAN3 *LAN7 LAN1 LAN5 LAN1/LAN2/ LAN3/LAN4/ LAN5/ LAN6/* LAN7/* LAN8 2.5Gbps RJ-45 LAN port LED Signals: ** There are two LED next to the LAN port. Please refer to the table below for the LAN port LED indications.
  • Page 21 (3) ATXPWR(24-pin block): Main Power Connector (4) ATX12V (4-pin block): 12V Internal Power Connector Pin1 Pin No. Definition +12V +12V...
  • Page 22 (5) SATA1/2/3/4 (7-pin): SATA III Port connector These are high-speed SATAIII port that supports 6 GB/s transfer rate. Pin No. Defnition (6) CPUFAN (4-pin): CPU FAN Connector CPUFAN Control Fan Speed +12V Fan Power Pin1...
  • Page 23 (7) SYSFAN (3-pin): System FAN Connector SYSFAN (8) BATCON (2-pin): Battery Connector BATCON...

  • Page 24: Headers

    2-2-2 Headers JW_FP (9-pin): Front Panel Header Pin 1 JW_FP HDMI1 (19-pin): HDMI Port Header HDMI1 HDMI_HPD HDMI_5V DDC_SDA DDS_SCL TMDS_CLKN TMDS_CLKP DATA0N DATA0P DATA1N DATA2N DATA1P DATA2P Pin1...
  • Page 25 FP_COM2/ FP_COM 3 (9-pin): RS232 Serial Port Header FP_COM2 FP_COM3 FP_USB21/ FP_USB22 (9-pin): USB 2.0 Port Headers Pin 1 FP_USB22 FP_USB21...
  • Page 26 LAN_LED1 (8-pin): LAN1 & LAN2& LAN3 & LAN4 Activity LED Header Pin1 LAN_LED1 Header LAN_LED1 LAN_LED2 (8-pin/4-pin): LAN5 & LAN6& LAN7 & LAN8 Activity LED Header MI23-Q670X/R680X Series: 8-pin LAN_LED2 Header; MI23-H610X Series: 4-pin LAN_LED2 Header (without Pin5/6/7/8 for LAN7/LAN8). Pin1 LAN_LED2 Header LAN_LED2...
  • Page 27 GPIO (10-pin): GPIO Header Pin1 GPIO PS2KBMS (6-pin): PS/2 Keyboard & Mouse Header PS2KBMS...

  • Page 28: Maximum Voltage & Current Limit

    SMBUS1 (5-Pin): SMBUS Header SMBUS1 2-3 Maximum Voltage & Current Limit Below is a list of maximum voltage & Current Limit specification for motherboard interface (including but not limited to slots, connectors and headers) for setup reference: Parts Working Voltage Current Support USB31 1.5A...

  • Page 29: Chapter 3 Introducing Bios

    Chapter 3 Introducing BIOS Notice! The BIOS options in this manual are for reference only. Different configurations may lead to difference in BIOS screen and BIOS screens in manuals are usually the first BIOS version when the board is released and may be different from your purchased motherboard.

  • Page 30: Bios Menu Screen

    3-2 BIOS Menu Screen The following diagram show a general BIOS menu screen: Menu Bar General Help Items Current Setting Value Menu Items Function Keys BIOS Menu Screen...

  • Page 31: Function Keys

    3-3 Function Keys In the above BIOS Setup main menu of, you can see several options. We will explain these options step by step in the following pages of this chapter, but let us first see a short description of the function keys you may use here: ...

  • Page 32: Menu Bar

    3-5 Menu Bars There are six menu bars on top of BIOS screen: Main To change system basic configuration Advanced To change system advanced configuration Chipset To change chipset configuration Security Password settings Boot To change boot settings Save & Exit Save setting, loading and exit options.

  • Page 33: Advanced Menu

    System Date Set the date. Please use [Tab] to switch between date elements. System Time Set the time. Please use [Tab] to switch between time elements. 3-7 Advanced Menu  Connectivity Configuration Press [Enter] to make settings for the following sub-item: CNVi Mode This option configures connectivity.
  • Page 34 sub-items: Hyper-Threading Use this item to enable or disable Hyper-Threading Technology The optional settings: [Disabled]; [Enabled]. Intel (VMX) Virtualization Technology When enabled, a VHM can utilize the additional hardware capabilities provided by Vanderpool Technology. The optional settings: [Disabled]; [Enabled]. Intel (R) SpeedStep ™ Use this item to Allows more than two frequency ranges to be supported.
  • Page 35 Use this item to designates this port as Hot Pluggable. The optional settings are: [Enabled]; [Disabled].  PCH-FW Configuration Use this item to configure Management engine technology parameters Press [Enter] to make settings for the following sub-items: TPM Device Selection Use this item to selects TPM device: PTT or dTPM.
  • Page 36 ACPI Settings ACPI Sleep State Use this item to select the highest ACPI sleep state the system will enter when the suspend button is pressed. The optional settings are: [Suspend Disabled]; [S3 (Suspend to RAM)]. ► Wake-up Function Settings Wake-up System With Fixed Time Use this item to enable or disable system wake on alarm event.
  • Page 37 function The optional settings: [Disabled]; [Enabled]. USB S5 Power Use this item to USB Power after system shutdown support only disable ERP function The optional settings: [Disabled]; [Enabled].  Super IO Configuration Press [Enter] to make settings for the following sub-items: Super IO Configuration ERP Support Use this item to energy-related products function.
  • Page 38  Serial Port 3 Configuration Press [Enter] to make settings for the following items: Serial Port Use this item to enable or disable serial port (COM). The optional settings: [Disabled]; [Enabled]. Change Settings Use this item to select an optimal setting for super IO device. The optional settings are: [IO=3E8h;...
  • Page 39 Press [Enter] to make settings for SmartFAN Configuration: SmartFAN Configuration CPUFAN/SYSFAN Smart Mode The optional settings: [Disabled]; [Enabled]. When set as [Enabled], the following sub-items shall appear: CPUFAN/SYSFAN Full-Speed Temperature Use this item to set CPUFAN/SYSFAN full speed temperature. Fan will run at full speed when above this pre-set temperature.
  • Page 40 The optional settings: [VT100]; [VT100Plus]; [VT-UTF8]; [ANSI]. [ANSI]: Extended ASCII char set; [VT100]: ASCII char set; [VT100Plus]: Extends VT100 to support color, function keys, etc.; [VT-UTF8]: Uses UTF8 encoding to map Unicode chars onto 1 or more bytes. Bits per second Use this item to select serial port transmission speed.
  • Page 41 The optional settings: [Disabled]; [Enabled]. Recorder Mode With this mode enable only text will be sent. This is to capture Terminal data. The optional settings: [Disabled]; [Enabled]. Resolution 100x31 Use this item to enable or disable extended terminal resolution. The optional settings: [Disabled]; [Enabled]. Putty KeyPad Use this item to select Function Key and KeyPad on Putty.
  • Page 42  Console Redirection Settings The settings specify how the host computer and the remote computer (which the user is using) will exchange data. Both computers should have the same or compatible settings. Press [Enter] to make settings for the following sub-items. Terminal Type EMS The optional settings: [VT100];...
  • Page 43 This is a workaround for OSes without XHCI hand-off support. The XHCI ownership change should be claimed by XHCI driver. The optional settings: [Enabled]; [Disabled]. USB Mass Storage Driver Support Use this item to enable or disable USB Mass storage driver support The optional settings: [Disabled];...
  • Page 44 boot option will not be created. The optional settings: [Disabled]; [Enabled]. Ipv6 PXE Support Use this item to enable IPv6 PXE Boot Support. When set as [Disabled], IPv6 PXE boot option will not be created. The optional settings: [Disabled]; [Enabled]. PXE boot wait time Use this item to set wait time to press [ESC] key to abort the PXE boot.

  • Page 45: Chipset Menu

    3-8 Chipset Menu  System Agent (SA) Configuration Press [Enter] to make settings for the following sub-items:  Memory Configuration Maximum Memory Frequency Use this item to maximum memory frequency selections in Mhz The optional settings are: [Auto]; [4000]; [4400]; [4800]. ...
  • Page 46 The optional settings: [128MB]; [256MB]; [512MB]; [1024MB] DVMT Pre-Allocated Use this item to select DVMT 5.0 Pre-Allocated (Fixed) graphics memory size used by the internal graphics device The optional settings: [32M]; [64M]; [128M] DVMT Total Gfx Mem Use this item to select DVMT 5.0 total graphic memory size used by the internal graphics device The optional settings: [128M];...
  • Page 47 Onboard Lan2 Controller Use this item to control the PCI Express root port.. The optional settings: [Disabled]; [Enabled]. Onboard Lan3 Controller Use this item to control the PCI Express root port.. The optional settings: [Disabled]; [Enabled]. Onboard Lan4 Controller Use this item to control the PCI Express root port.. The optional settings: [Disabled];...

  • Page 48: Security Menu

    3-9 Security Menu Security menu allow users to change administrator password and user password settings. Administrator Password If there is no password present on system, please press [Enter] to create new administrator password. If password is present on system, please press [Enter] to verify old password then to clear/change password.
  • Page 49 Secure Boot feature is Active if Secure Boot is Enabled, Platform Key(PK) is enrolled and the System is in User mode. The mode change requires platform reset. The optional settings: [Disabled]; [Enabled]. Secure Boot Mode Set UEFI Secure Boot Mode to Standard mode or Custom mode. This change is effective after save.
  • Page 50  Export Secure Boot variables Use this item to copy NVRAM content of Secure Boot variables to files in a root folder on a file system device. Secure Boot variable/Size/Keys/Key Source  Platform Key(PK)/Key Exchange Keys/Authorized Signatures/Forbidden Signatures/ Authorized TimeStamps/OsRecovery Signatures Use this item to enroll Factory Defaults or load certificates from a file: 1.

  • Page 51: Boot Menu

    3-10 Boot Menu Boot Configuration  Setup Prompt Timeout Use this item to set number of seconds to wait for setup activation key. 65535(0Xffff) means indefinite waiting  Bootup Numlock State Use this item to select keyboard numlock state. The optional settings are: [On]; [Off]. ...

  • Page 52: Save & Exit Menu

    3-11 Save & Exit Menu  Save Changes and Reset This item allows user to reset the system after saving the changes.  Discard Changes and Reset This item allows user to reset the system without saving any changes.  Restore Defaults Use this item to restore /load default values for all the setup options.

  • Page 53: Mebx

    3-12 MEBx  Intel(R) ME Password Use this item to MEBx Login.
