M-8460Se Printer
Standard Unit

Parts List

Page 1-1
P/N 9001090
Rev. B

Advertisement

Table of Contents
loading

Related Manuals for SATO M8460Se

Summary of Contents for SATO M8460Se

  • Page 1: Parts List

    ® M-8460Se Printer Standard Unit Parts List Page 1-1 P/N 9001090 Rev. B...

  • Page 2: Table Of Contents

    Cover Assembly ... 21 Cont PCB Assembly ... 24 Check PCB Assembly ... 25 Interface Option ... 26 Memory Option ... 27 Page 2 SATO Industrial Bar Code Printers Table of Contents SATO M-8460Se Printer Parts List Page Rev. B...

  • Page 3: Frame Assembly

    SATO Industrial Bar Code Printers Frame Assembly Rev. B Page 3 SATO M-8460Se Printer Parts List...
  • Page 4 SATO Industrial Bar Code Printers Frame Assembly Page 4 Rev. B SATO M-8460Se Printer Parts List...
  • Page 5 SATO Industrial Bar Code Printers Frame Assembly Rev. B Page 5 SATO M-8460Se Printer Parts List...
  • Page 6 PB0731600 ND0040030 PR1732600 MD4402022 PT8190064 PL1720100 MJ1400524 RH1730600 MC0401222 PB0731701 Page 6 SATO Industrial Bar Code Printers CODE DESCRIPTION ENGINE FRAME HEX NUT GUIDE POST PAN HEAD SCREW STAY HEX SOCKET BOLT GUIDE PLATE (HEAD BR) SPRING BRACKET PAN HEAD SCREW...
  • Page 7 Frame Assembly Rev. B SATO Industrial Bar Code Printers CODE DESCRIPTION PE8730100 GEAR PE8730300 PULLEY PT1112060 BALL SUPPORTER ND0040030 E-RING PT8150064 TIMING BELT PT8085048 TIMING BELT PA1730500 SHAFT BRACKET MC0401022 PAN HEAD SCREW MA0401622 PAN HEAD SCREW MT1400722 HEX NUT...

  • Page 8: Print Head Assembly

    SATO Industrial Bar Code Printers Print Head Assembly Page 8 Rev. B SATO M-8460Se Printer Parts List...
  • Page 9 SATO Industrial Bar Code Printers Print Head Assembly Rev. B Page 9 SATO M-8460Se Printer Parts List...
  • Page 10 Print Head Assembly Page 10 SATO Industrial Bar Code Printers CODE DESCRIPTION RH1731100 SEN5 CABLE MD3201221 PAN HEAD SCREW PR1733700 PRESSURE CAM ND0060030 E-RING PA2730800 HEAD FRAME MN0401024 HEX SOCKET BOLT PA1730300 PLATE (ADJUST) PL2720100 ADJUST COLLAR MN0400824 HEX SOCKET BOLT...

  • Page 11: Ribbon Assembly

    SATO Industrial Bar Code Printers Ribbon Assembly Rev. B Page 11 SATO M-8460Se Printer Parts List...
  • Page 12 Ribbon Assembly Page 12 SATO Industrial Bar Code Printers CODE DESCRIPTION RH1730400 SEN4 CABLE MA0300622 PAN HEAD SCREW PA3730200 SENSOR BRACKET(RIBBON) MC0301022 PAN HEAD SCREW PE6720100 DISK PLATE COVER MD4300622 PAN HEAD SCREW MD3300822 PAN HEAD SCREW MA0301022 PAN HEAD SCREW...
  • Page 13 Ribbon Assembly Rev. B SATO Industrial Bar Code Printers CODE DESCRIPTION PA0680400 DISK PC1730100 SPRING PE2730100 STOPPER COLLAR PB5730100 ADJUST SCREW MA0302522 PAN HEAD SCREW PR1734000 PULLEY PC0740200 SPRING (BACK) MH0300821 PAN HEAD P TITE SCREW SATO M-8460Se Printer Parts List...

  • Page 14: Platen Frame Assembly

    SATO Industrial Bar Code Printers Platen Frame Assembly Page 14 Rev. B SATO M-8460Se Printer Parts List...
  • Page 15 SATO Industrial Bar Code Printers Platen Frame Assembly Rev. B Page 15 SATO M-8460Se Printer Parts List...
  • Page 16 SATO Industrial Bar Code Printers Platen Frame Assembly Page 16 Rev. B SATO M-8460Se Printer Parts List...
  • Page 17 SATO Industrial Bar Code Printers Platen Frame Assembly Rev. B Page 17 SATO M-8460Se Printer Parts List...
  • Page 18 Platen Frame Assembly Page 18 SATO Industrial Bar Code Printers CODE DESCRIPTION MN0401024 HEX SOCKET BOLT MN0402024 HEX SOCKET BOLT PR4731601 PLATEN FRAME PB0730500 POST (LATCH) PA4730500 PLATE SPRING PB0733500 SHAFT (HOLDER) NB0040022 SPRING WASHER PR0730300 PLATEN ROLLER PT1109050 BALL SUPPORTER...
  • Page 19 Platen Frame Assembly Rev. B SATO Industrial Bar Code Printers CODE DESCRIPTION MC0300622 PAN HEAD SCREW MN0300624 HEX SOCKET BOLT PL1731300 PAPER LID BRACKET PB0735100 SHAFT (RIBBON) ND0020030 E-RING PC2730200 SPRING (OPEN) PA3738100 PAPER LID (BOTTOM) PA3731700 LATCH HANDLE PB0730900...
  • Page 20 Platen Frame Assembly PR1732800 PR1732900 MA1300822 PB0733601 PE2730600 PB2730100 MJ1300324 Page 20 SATO Industrial Bar Code Printers CODE DESCRIPTION PLATE (HOLDER) (F) PLATE (HOLDER) (R) FLAT HEAD SCREW SCREW (HOLDER) COLLAR COLLAR HEX SOCKET BOLT SATO M-8460Se Printer Parts List...

  • Page 21: Cover Assembly

    SATO Industrial Bar Code Printers Cover Assembly Rev. B Page 21 SATO M-8460Se Printer Parts List...
  • Page 22 SATO Industrial Bar Code Printers Cover Assembly Page 22 Rev. B SATO M-8460Se Printer Parts List...
  • Page 23 Cover Assembly Rev. B SATO Industrial Bar Code Printers CODE DESCRIPTION PH1731701 CLOSE COVER (A) PR7730301 POWER SUPPLY ASSY GA300161A POW SWITCH HD100311A FUSE RH1730500 POW/SW CABLE MC0301022 PAN HEAD SCREW MC0401022 PAN HEAD SCREW MC0301022 PAN HEAD SCREW MC0401022...

  • Page 24: Cont Pcb Assembly

    CONT PCB Assembly Page 24 SATO Industrial Bar Code Printers CODE DESCRIPTION RJ1733100 CONT PCB ASSY-B MD4300622 PAN HEAD SCREW PC9730100 SPRING(LOCK) PA3739900 CONNECTOR LOCK RH1727300 PITCH SENSOR RELAY RH1735100 SENSOR RELAY CODE RJ7770200 MEMORY PCB ASSY RJ7770300 4 MB FLASH MEMORY...

  • Page 25: Check Pcb Assembly

    Check PCB Assembly Rev. B SATO Industrial Bar Code Printers CODE DESCRIPTION RJ4731200 CHECK PCB SET RH4730000 CHECK CABLE SET PA3736601 PCB BRACKET (CHECK) MD4300822 PAN HEAD SCREW SATO M-8460Se Printer Parts List Page 25...

  • Page 26: Interface Option

    Interface Option CODE MD3300622 WCL404070 WCL404051 WCL404060 11S000158 11S000136 Page 26 SATO Industrial Bar Code Printers DESCRIPTION SCREW IEEE-1284 PARALLEL INTERFACE (OPTION) SERIAL INTERFACE (OPTION) USB INTERFACE (OPTION) ETHERNET INTERFACE (OPTION) CX/TX INTERFACE (OPTION) SATO M-8460Se Printer Parts List Rev. B...

  • Page 27: Memory Option

    Memory Option Rev. B SATO Industrial Bar Code Printers CODE DESCRIPTION RJ4770100 PC CARD PCB ASSY PT9770600 SPACER MD4300621 PAN SCREW PT9770700 SPACER MD4201621 PAN SCREW MT1200422 SATO M-8460Se Printer Parts List Page 27...
