Dear customer!
Thank you for choosing this quality product from ASKO.
We hope it will meet your expectations and fulfil your needs for many years to
come. Scandinavian design combines clean lines, everyday functionality and
high quality. These are key characteristics of all our products and the reason
they are greatly appreciated throughout the world.
To get the most out of your new dishwasher, we recommend that you read the
operating instructions before using the dishwasher. The operating instructions
also include information on how you can help protect the environment.
Operating instructions
Dishwasher
ASKO DWCFS5936
Read the instructions before using the appliance.

Advertisement

Table of Contents
loading

Related Manuals for Asko DWCFS5936

Summary of Contents for Asko DWCFS5936

  • Page 1 Dear customer! Thank you for choosing this quality product from ASKO. We hope it will meet your expectations and fulfil your needs for many years to come. Scandinavian design combines clean lines, everyday functionality and high quality. These are key characteristics of all our products and the reason they are greatly appreciated throughout the world.

  • Page 2: Table Of Contents

    Contents Front panel Care and cleaning Safety instructions Troubleshooting Before washing for the first time Technical information Loading the dishwasher Installation Using the dishwasher Service Settings Program chart Front panel To start the machine, press and hold the main power switch until the display lights up. 0:05 1.

  • Page 3: Safety Instructions

    Safety instructions General Installation Read the operating instructions and keep them in a safe place! Read the safety instructions before installing. See section Installation. Never use the dishwasher for any purpose other than that specified in these operating instructions. Child safety Do not load the dishwasher door, basket carriers or dishwasher baskets with anything other than dishes.

  • Page 4: Before Washing For The First Time

    Before washing for the first time Automatic dosing system WARNING! The dishwasher can be connected to an automatic dosing system Hard water leaves a white coating on dishes and the for commercial detergent and rinse aid which simplifies daily use dishwasher.

  • Page 5: Loading The Dishwasher

    Loading the dishwasher Top up with rinse aid Fragile dishes Add the rinse aid to the rinse aid compartment if the dishwasher Some cookware is not dishwasher safe. This can be for several is not connected to an automatic dosing system for commercial reasons.
  • Page 6 onto the dishwasher’s lower basket carrier. Check that the spray Upper basket carrier arms can rotate freely. Place dishes into a plastic dishwasher basket with dirty surfaces facing inwards and downwards. Place the dishwasher basket Cutlery onto the dishwasher’s upper basket carrier. Use adapted cutlery baskets.

  • Page 7: Using The Dishwasher

    Using the dishwasher Automatic dosing system NOTE! The dishwasher can be connected to an automatic dosing system Only use powder and liquid dishwasher detergent in the for commercial detergent and rinse aid which simplifies daily use dishwasher’s detergent compartment. Dishwasher tablets are and reduces the risk of overdosing.
  • Page 8 Program A / Program B / Program C Show dishwashing sequence Programs which can be adapted for specific needs. See “Create The current dishwashing sequence is shown on the display. program” in section Settings on page 9. Stopping or changing a program Starting the dishwasher A program should only be interrupted if it is absolutely necessary.

  • Page 9: Settings

    Settings 1. Betjeningsmenu Open the Function Menu: Button press Description Turn off the machine. Open the door. Press and hold the main power switch until the display lights up. Within 20 seconds; - press the button 2, 5 times. - press the button 3, 5 times. The display shows Function Menu.
  • Page 10 You can change the following settings in the Function Menu: Settings Alternatives 1. Language English/Svenska/Dansk/Norsk/ You can choose the language used for the display. Suomi/Français/Deutsch/Italiano/ Español/Nederlands/Русский 2. Temp. in last program The washing water’s highest temperature in the last run program is shown in the display.
  • Page 11 Settings Alternatives 12. Water connection Water connection: Single/Mix Select Single if the dishwasher is connected to cold or hot water. Select Mix if the dishwasher is connected to both cold and hot water. 13. Create program Design your own dishwashing program (Program A, Program B and Program C) according to your business’s specific needs.

  • Page 12: Care And Cleaning

    Care and cleaning 5. Lock the filter in place by turning the handle clockwise to the WARNING! stop position. The handle should point straight out from the dishwasher. The property’s main power switch must be switched off or power to the socket turned off while work is being carried out! Coarse filter The coarse filter traps larger food particles, which cannot get past the drainage pump.
  • Page 13 Cleaning the outside of the machine NOTE! Clean the outside of the machine and the program panel with a Do not forget to reinstall the fitted piece. mild cleaner. Do not use any solvents, as these can damage the machine. NOTE! Do not hose down the machine with water! Door...

  • Page 14: Troubleshooting

    Troubleshooting Front display Type of fault on the Action display Overfilling 1 Clear the drainage pump. See the chapter Care and cleaning. If the problem persists, call the service department. Water outlet fault See “Water remains in the dishwasher” in the table “Problem” below. If the problem persists, call the service department.
  • Page 15 Problem Possible causes Action The dishes are not clean. The spray arms do not rotate. Remove the arms and clean them. Check that the dishes are not blocking the spray arms. Spray arm holes or bearings blocked. Clean the spray arms. See the chapter Care and cleaning.
  • Page 16 Problem Possible causes Action Residue from the detergent remains in the The Function Menu is set incorrectly. Check that the Spray pressure setting under dishwasher. Automatic dosing system is set correctly. Check that the Spray pressure setting under Program A, Program B and Program C is set correctly.
  • Page 17 Problem Possible causes Action The dishes are not dry enough. The dishwasher is not fully loaded. Fully load the dishwasher. Rinse aid needs topping up or dosage is set Top up or increase the rinse aid dosage. See too low. section Before washing for the first time and “Rinse aid”...

  • Page 18: Technical Information

    Technical information Technical data Brand: ASKO Height: 847-902 mm Width: 600 mm Depth: 596 mm Weight: 67 kg Water pressure: 0.03–1.0 MPa 0.3–10 kp/cm 3–100 N/cm Electrical connection: See the serial number plate Rated power: See the serial number plate...

  • Page 19: Installation

    Installation 1235 [mm] *Remove rubber feet and locking nuts for an installed height of 850-861 mm. Safety instructions Transport protection for the door Connections to electricity, water and drainage must be Do not forget to remove the transport protection for the door when performed by a qualified professional.
  • Page 20 4. Check that there is an air gap of 10 mm between the underside Suggested machine installations of the worktop and the top edge of the dishwasher, as well as The dishwasher is intended for freestanding installation, but can behind the dishwasher. also be installed under a worktop.
  • Page 21 Attach the light shielding film Figure 2 Max. 3 m Mount the light shielding film (enclosed documents) above the touch buttons below the worktop. The purpose of the light shielding film is to get the touch buttons to function optimally, and to protect the worktop from moisture.
  • Page 22 Electrical connection during installation must be carried out by WARNING! the manufacturer’s service agent or someone with similar professional qualifications. Risk of contact with high voltage! The supplied protective caps must be fitted on the dishwasher’s cables for the automatic The dishwasher must be connected to residual current devices dosing system during installation and is the dosing system is as per the relevant safety regulations.

  • Page 23: Service

    Service Read chapter Troubleshooting before contacting the service department. Note down the details on the serial number plate positioned on the right inside the dishwasher. Note down the item number (1) and serial number (2). ART. NO. SERIAL NO.

  • Page 24: Program Chart

    Program chart...
  • Page 25 Quick guide ASKO DWCFS5936 Place the dishwasher baskets on the basket carriers Check that the plastic dishwasher baskets are placed within the edges of the basket carriers. Check that the spray arms can rotate freely Check/add detergent and rinse aid Check/add detergent and rinse aid to achieve good washing and drying results.
