- Page 1 PM351 Personal Monitor Station Owners Manual...
- Page 2 XLR Instrument Outputs. The instrument input connects to two independent XLR balanced outputs via real audio transformers. The PM351 is designed for performers who want to monitor their own sounds, such as their vocals and instruments, with the main mix via headphones or earphones.
- Page 3 "phantom power" the PM350. See the OPERATION section for details. DC IN 12 VDC: For connection to the external Rolls PS27 power adapter. HEADPHONE OUTPUTS:1/4" Stereo jack, and 1/8" stereo jack for connection to stereo headphones or earphones.
- Page 4 CONNECTION The diagram below shows an example of how to connect the PM351 for proper op- eration. • The LINE INPUT connects to either a 1/4" • The LINE INPUT connects to either a 1/4" stereo or mono plug. If this plug is Tip-Ring- stereo or mono plug.
