S-BP (Blank Panel) Installation Manual

This guide describes how to install S-BP (Blank Panel) in your S-4000S.

Before you attempt installation, please read this document carefully.

form without the written permission of ROLAND CORPORATION.

For the Purchaser — Please Read

When installing or detaching the S-BP, be sure to consult your RSS

Authorized Service Center.

For the Installer (Service Technician)

— Please Read

After installing the S-BP, please be sure to return this document to the

purchaser.

Cautions When Installing the S-BP

• Always turn the unit off and unplug the AC plug

before attempting installation of the S-BP.

• Remove only the specified screws.

• When the S-BP installation is complete,

double-check your work.

• Use a Philips screwdriver of the appropriate size to

avoid damaging the screw heads (a number of 2

screwdriver).

• Turn the screwdriver counter-clockwise to loosen

the screws-turn it clockwise to tighten them.

• Be careful not to let the screws drop inside the each

unit.

• Never leave a module uninstalled. Cover any

unused slots with S-BP blank panels.

• Be careful not to cut your hand on the edge of the

circuit board or the opening edge wile removing the

S-BP.

loosen

tighten

Page 1 S-BP (Blank Panel) Installation Manual This guide describes how to install S-BP (Blank Panel) in your S-4000S. Before you attempt installation, please read this document carefully. © 2006 Roland Corporation All rights reserved. No part of this publication may be reproduced in any form without the written permission of ROLAND CORPORATION.
Page 2 Installing the S-BP to the S-4000S Remove the two screws from each module (SI-AD4 or SO-DA4) installed in the S-4000S. Extract the module from the S-4000S. Install an S-BP in the opening left by the removed module. Secure the module in place using the two screws removed when detaching the module.
