- Page 1 INSTALLATION INSTRUCTIONS OPERATION MANUAL SHN79 Series NEMA 7/9 HAZARDOUS AREA Commercial and Industrial Door Operator UL325-2010 Compliant Continuous Duty Operators...
-
Page 2: Important Installation Instructions
10. Read and understand the wiring diagram of the operator and the control station and any other equipment to be connected to the operator. SHN79 Series REVISION # 0001 DATE: 08/01/2022... - Page 3 Before opening or unfastening the screws, use dry clean cloth to wipe out the dust to cleaning the cover joints. Alternatively, the cover joints can be blown clean with compressed air. SHN79 Series REVISION # 0001 DATE: 08/01/2022...
-
Page 4: Specifications
45 ft.). Use a sensing edge to provide entrapment protection on doors over 45 ft. wide. 2. A sensing edge can be used on all doors without size restriction. SHN79 Series REVISION # 0001 DATE: 08/01/2022... -
Page 5: Installation Instructions
Consult factory for any changes. (LS and RA mounting positions are LH operators, RS and LA positions are RH operators) Operators mounted in alternate positions (LA, RA) require a straight mounting plate in lieu of the standard bent plate. SHN79 Series REVISION # 0001 DATE: 08/01/2022... -
Page 6: Operator Mounting
The operator must be securely attached with the drive shaft parallel to the door shaft. It may be necessary to field brace the operator/bracket. Door Sprocket Operator Drive Sprocket Correct Incorrect SHN79 Series REVISION # 0001 DATE: 08/01/2022... -
Page 7: Drive Chain Adjustment
Note: The set screws on the operator base may be used to make the adjustment. (See figure - T1, T2 location). 2. Once the drive chain has been tightened and the base leg screws have been set, then tighten the operator set screws. Drive Chain Door Sprocket 1/4" Drive Sprocket SHN79 Series REVISION # 0001 DATE: 08/01/2022... - Page 8 HAND CHAIN ADJUSTMENT If the hand chain is too long, cut and reconnect the chain with the different color connecting link provided. Completely close the connecting link so it is properly aligned. Chain Holder Optional SHN79 Series REVISION # 0001 DATE: 08/01/2022...
-
Page 9: Typical Installation
Class I, Division 1, Groups C and D; Class II, Division 1, Group E, F and G Hazardous Location. End User/ Installer MUST follow applicable NEC requirements along with Local requirements for Hazardous Wiring. WARNING SHN79 Series REVISION # 0001 DATE: 08/01/2022... -
Page 10: Limit Switch Adjustment
It is recommended that the switch position be adjusted as low as possible without interfering with close limit switch function. NOTE: “C” is usually the open limit switch and “D” is usually the close limit switch. SHN79 Series REVISION # 0001 DATE: 08/01/2022... -
Page 11: Wiring Instructions
Failure to disable the locks could WARNING result in damage to the door or operator. SHN79 Series REVISION # 0001 DATE: 08/01/2022... -
Page 12: Control Wiring
Changing from left hand to right hand or vice versa could result in change WARNING of control wiring. Consult factory for details. 4. After installation, be sure that the operator, controls, and sensing edge or other entrapment protection devices have been tested and function properly. SHN79 Series REVISION # 0001 DATE: 08/01/2022... -
Page 13: Control Function
When the door is closing, pushing the “Open” or “Stop” button will stop the door from moving. When the door is closing, the radio control transmitter can stop and reverse the door at anytime. SHN79 Series REVISION # 0001... -
Page 14: Auxiliary Function
1. 1&2 Open limit dry contact 2. 3&4 Close limit dry contact Non-Monitored Sensing Devices (N.O. Dry Contact) 24VDC MAX 0.5A 24VDC MAX 0.5A B-2. B-2. Open door Open door Close door Close door Stop door Stop door SHN79 Series REVISION # 0001 DATE: 08/01/2022... -
Page 15: Timer Instruction
External timer disable switch connection – install a switch between “TIMER” wires in the IS junction box. When the switch is open and S10 switch is ON, all timers are enabled. When the switch is closed or S10 switch is OFF, all timers are disabled. SHN79 Series REVISION # 0001 DATE: 08/01/2022... - Page 16 Press to save setting. Without pressing, no adjustment is saved. Reclose Timer Max. 99 min 59 Sec Set the Max. 99 min 59 Sec desired time . Min. 1 Sec Min. 1 Sec SHN79 Series REVISION # 0001 DATE: 08/01/2022...
- Page 17 Max. 99 min 59 Sec Max. 99 min 59 Sec desired time . Min. 1 Sec Min. 1 Sec (5) To confirm timer value: Set Mode Select Time r Set Mode Set Mode SHN79 Series REVISION # 0001 DATE: 08/01/2022...
-
Page 18: Lcd Display Instruction
OFF: Sensing device circuit ok or not OPEN activated. CLOSE LED8 DEVICE Device light STOP ON: When the sensing device connected SAFE on terminal CN2 (E5,E6/P5,P6) is normal. OFF: Sensing device disconnected, failed LED30 or damaged. DEVICE SHN79 Series REVISION # 0001 DATE: 08/01/2022... - Page 19 All the input signals must be in the form of dry contact. I. S JUNCTION BOX OPEN OPEN CLOSE CLOSE STOP STOP 3-V-R-017 2022.03.03 Follow the instructions of the wire sleeves for external devices connections. SHN79 Series REVISION # 0001 DATE: 08/01/2022...
- Page 20 The values of Ca (or Co) and La (or Lo) determined by this method shall not be exceeded by the sum of all of Ci plus cable capacitances and the sum of all of the Li plus cable inductances in the circuit respectively. 3-V-R-017 2022.03.03 SHN79 Series REVISION # 0001 DATE: 08/01/2022...
-
Page 21: Non-Intrinsically Safe Connections
(Open, Close): Open & Close dry contact plug, which requires tightening torque of 57 ft-lbs (800 kg-cm). *Require additional holes, please specify in the order. Additional holes can be provided. Consult factory for details. SHN79 Series REVISION # 0001 DATE: 08/01/2022... - Page 22 INPUT POWER 115V 1 PHASE OPEN CLOSE STOP SHN79 Series REVISION # 0001 DATE: 08/01/2022...
- Page 23 STOP CLOSE OPEN INPUT POWER 115V 1 PHASE SHN79 Series REVISION # 0001 DATE: 08/01/2022...
- Page 24 INPUT POWER 230V 1 PHASE OPEN CLOSE STOP SHN79 Series REVISION # 0001 DATE: 08/01/2022...
- Page 25 STOP CLOSE OPEN INPUT POWER 230V 1 PHASE SHN79 Series REVISION # 0001 DATE: 08/01/2022...
- Page 26 NOTE : INPUT POWER ˙ 208V / 230V ˙ 3 PHASE OPEN CLOSE STOP SHN79 Series REVISION # 0001 DATE: 08/01/2022...
- Page 27 STOP CLOSE OPEN INPUT POWER 208V / 230V NOTE : 3 PHASE ˙ ˙ SHN79 Series REVISION # 0001 DATE: 08/01/2022...
- Page 28 INPUT POWER 460V 3 PHASE OPEN CLOSE STOP SHN79 Series REVISION # 0001 DATE: 08/01/2022...
- Page 29 STOP CLOSE OPEN INPUT POWER 460V 3 PHASE SHN79 Series REVISION # 0001 DATE: 08/01/2022...
- Page 30 INPUT POWER 575V 3 PHASE OPEN CLOSE STOP SHN79 Series REVISION # 0001 DATE: 08/01/2022...
- Page 31 STOP CLOSE OPEN INPUT POWER 575V 3 PHASE SHN79 Series REVISION # 0001 DATE: 08/01/2022...
-
Page 32: Important Safety Instructions
6. KEEP DOORS PROPERLY OPERATING AND BALANCED. See door manufacturer’s Operation and Maintenance Instructions. An improperly operating or unbalanced door could cause death or serious injury. Have trained door systems technicians make all necessary adjustments and repairs. SAVE THESE INSTRUCTIONS. SHN79 Series REVISION # 0001 DATE: 08/01/2022... -
Page 33: Emergency Manual Operation
Put the hand chain back into the chain bag, before operating the door again electrically. Turn off power to the operator before manually operating the door. WARNING Hand chain must be kept inside chain bag when operating electrically. WARNING SHN79 Series REVISION # 0001 DATE: 08/01/2022... -
Page 34: Maintenance Instructions
Do not place hands or tools in or near the operator when the power is connected or when testing control or sensing devices. Always disconnect WARNING power before servicing or adjusting the operator. SHN79 Series REVISION # 0001 DATE: 08/01/2022... - Page 35 APPENDIX 1 Wiring Change Instruction from 230V to 208V 3 Phase Operator Smart SHN79 Series SHN79-SB-3P-V01 REMOVE INSULATE (FACTORY INSTALLED FOR 230V) THE WIRE CONNECT (FOR 208V) 1. Unplug the red "230V" wire connector from the red "PWR" wire connector.
