NEO-RAY
™
GEO
14-DIP
D I R E C T- I N D I R E C T
• Direct-indirect light
distribution.
• The light is continuous and
unbroken.
• Discrete direct and indirect
lighting for 3 distinct
distributions (specify dual
switching).
• Die formed steel housing,
nominal illuminated sections
3', 4', 6' and 8'.
• Rigid 'U' shaped double
formed trim with 3/8"
regress soft lit edge.
• Housings may be special
ordered custom finished.
• Runs provided to the nearest
foot.
• Patterns are formed by
butting standard sections.
• Selection of 4 light diffuser
options.
726
COOPER LIGHTING
8-1/4"
[210mm]
6" [153mm]
Construction: 20-gauge steel housing. Nominal 3',
4', 6' or 8' illuminated sections.
Shielding: White bold baffle louver. White acrylic
diffuser. Prismatic acrylic lens. Parabolic baffle
shielding.
Electrical: 120, 277, 347 or Universal Voltage
electronic ballast. Fixtures and electrical
components certified to UL and CUL standards.
Finish: Durable, low gloss, white, powder coated
acrylic finish.
End Caps: 20-gauge steel construction.
Mounting: Pendant with single stem (standard) or
single cable. Canopy: Round 5-1/2" diameter.
M O U N T I N G
NOTES: For complete product data, refer to the Neo-Ray Specification Binder. Specifications and dimensions subject to change without notice. Products may be
modified for use in international markets. Please contact your Cooper Lighting Sales Representative for availability and ordering information.
ORDERING INFORMATION:
Sample number: 14DIP-21T8-ST40-1EB-SI-S58
Series
14=Geo
Light Output
18"
DIP=Direct-Indirect Pendant
[457mm]
MIN.
Number of Lamps Up
1=1 Lamp
Number of Lamps Down
1=1 Lamp
Lamp Type
T8
Pendant Type
SC=Single Cable
Run Length
Overall Nominal Run Length__ft. (Any combination of 8', 6', 4' and 3'
sections)
Voltage
1
1=120V
Ballast
EB=Electronic Ballast (Standard)
Switching
SI=Single Switching
Emergency
EM=Emergency Pack (Consult Factory)
Fusing
GLR
Shielding
S22=White Acrylic Diffuser
S72=White Bold Baffle
S58=KSH-12 Clear Acrylic Prismatic Lens
S79=Semi-Specular Aluminum Parabolic Baffle
1 Due to various constraints, some options may not be combined with others.
2 Available with 7° or earthquake 45° swivel canopy assembly.
(not included)
2=2 Lamps
(not included)
2=2 Lamps
T5
T5HO
ST=Single Stem
2
2=277V
3=347V
U=Universal
DB=Dimming Ballast
DU=Dual Switching
GMF
S22 Acrylic Diffuser
S58 Acrylic Lens
S72 Bold Baffle
S79 Parabolic Baffle
