Page 2: Power Module
PM250 SERIES POWER MODULE REGISTER YOUR PRODUCT ONLINE AT www.broan.com/register READ AND SAVE THESE INSTRUCTIONS INTENDED FOR DOMESTIC COOKING ONLY WARNING CAUTION TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR INJURY TO 1. For indoor use only. PERSONS, OBSERVE THE FOLLOWING: 2. To reduce risk of fire and to properly exhaust air, be sure to duct air 1. Use this unit only in the manner intended by the manufacturer. If you outside. Do not vent exhaust air into spaces within walls or ceilings have questions, contact the manufacturer at the address or telephone or into attics, crawl spaces, or garages. -
Page 3: Install The Ductwork
INSTALL THE DUCTWORK NOTE: To reduce the risk of fire, use only metal ductwork. 1. Decide where the ductwork will run between the hood and the outside (Refer to Figure 1). 2. A straight, short duct run will allow the hood to perform most efficiently. -
Page 4: Operation
OPERATION SERVICE PARTS Controls Light switch: turns the lamps on and off. KEY NO. PART NO. DESCRIPTION 97018550 Grid (Silver) Blower switch: makes it possible to select the motor operating 99010370 Grease Filter speed. B03295095 Upper Lampholder B03295094 Lower Lampholder 98010831 Metal Wire B02300280 Lampholder B03294757 Light Fitting 230 98010828 Controls Closing 236 99030347 Blower Switch (Black) 237 99030342 Light Switch (Black) 332 98010834 Cover Controls 415 99400048 Strain Relief Bushing... -
Page 5: Warranty
WARRANTY BROAN-NUTONE LLC ONE YEAR LIMITED WARRANTY Broan-NuTone LLC (Broan-NuTone) warrants to the original consumer purchaser of Broan products that such products will be free from defects in materials or workmanship for a period of one year from the date of original purchase. THERE ARE NO OTHER WARRANTIES, EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, IMPLIED WARRANTIES OR MERCHANT ABILITY OR FITNESS FOR A PARTICULAR PURPOSE. During this one-year period, Broan-NuTone will, at its option, repair or replace, without charge, any product or part which is found to be defective under normal use and service. THIS WARRANTY DOES NOT EXTEND TO FLUORESCENT LAMP STARTERS, TUBES, HALOGEN AND INCANDESCENT BULBS, FUSE, FILTERS, DUCTS, ROOF CAPS, WALL CAPS AND OTHER ACCESSORIES FOR DUCTING. This warranty does not cover (a) normal maintenance and service or (b) any products or parts which have been subject to misuse, negligence, accident, improper main- tenance or repair (other than by Broan-NuTone), faulty installation or installation contrary to recommended installation instructions. The duration of any implied warranty is limited to the one-year period as specified for the express warranty. Some states do not allow limitation on how long an implied warranty lasts, so the above limitation may not apply to you. BROAN-NUTONE’S OBLIGATION TO REPAIR OR REPLACE, AT BROAN-NUTONE’S OPTION, SHALL BE THE PURCHASER’S SOLE AND EXCLUSIVE REMEDY UNDER THIS WARRANTY. BROAN-NUTONE SHALL NOT BE LIABLE FOR INCIDENTAL, CONSEQUEN- TIAL OR SPECIAL DAMAGES ARISING OUT OF OR IN CONNECTION WITH PRODUCT USE OR PERFORMANCE. Some states do not allow the exclusion or limitation of incidental or consequential damages, so the above limitation or exclusion may not apply to you. This warranty gives you specific legal rights, and you may also have other rights, which vary from state to state. This warranty supersedes all prior warranties. To qualify for warranty service, you must (a) notify Broan-NuTone at the address stated below or telephone number stated below, (b) give the model number and part identification and (c) describe the nature of any defect in the product or part. At the time of requesting war- ranty service, you must present evidence of the original purchase date. In USA - Broan NuTone LLC, 926 W. State Street, Hartford, WI 53027 (800-558-1711) In Canada - Broan NuTone Canada, 550Lemire Blvd., Drummondville, QC J2C 7W9 (866-737-7770) www.Broan.com 99044715A...
