REFRIGERATOR
SERVICE MANUAL
CAUTION
BEFORE SERVICING THE UNIT,
READ THE SAFETY PRECAUTIONS IN THIS MANUAL.
√ Caution
In this manual, some parts can be changed for improving their performance without notice. So, If you need the latest parts
information, please visit and refer to PPL (Parts Price List) in Service Information Center.(http://webportal.daewoo-elec.com/sic)
MEXICO BUILT
TYPE
MODEL
111.72695120
111.72697120
4 DR
Better
111.72692120
111.72699120
KOREA BUILT
TYPE
MODEL
111.72695910~1
111.72697910~1
4 DR
Better
111.72692910~1
111.72699910~1
S/M No. RFP72695910
FACTORY MODEL
RFP83KETJ4E00-UEBX
RFP83KEBJ4E00-UEBX
RFP83KEWC4E00-UEBX
RFP83KEBC4E00-UEBX
FACTORY MODEL
RFP83KETJ4E00-UEBB
RFP83KEBJ4E00-UEBB
RFP83KEWC4E00-UEBB
RFP83KEBC4E00-UEBB
LAST UPDATED : Feb .2022
Color
STAINLESS
BLACK
STAINLESS
WHITE
BLACK
Color
STAINLESS
BLACK
STAINLESS
WHITE
BLACK

Advertisement

Table of Contents
loading

Related Manuals for Kenmore 111.72695120

Summary of Contents for Kenmore 111.72695120

  • Page 1 S/M No. RFP72695910 REFRIGERATOR SERVICE MANUAL CAUTION BEFORE SERVICING THE UNIT, READ THE SAFETY PRECAUTIONS IN THIS MANUAL. MEXICO BUILT TYPE MODEL FACTORY MODEL Color 111.72695120 RFP83KETJ4E00-UEBX STAINLESS BLACK 111.72697120 RFP83KEBJ4E00-UEBX STAINLESS 4 DR Better 111.72692120 RFP83KEWC4E00-UEBX WHITE 111.72699120 RFP83KEBC4E00-UEBX...
  • Page 2 Content 1. Warnings and 8-7. Refrigeration Failure … ....... 4 ..45 Precautions for Safety (Foods does not get cool or cold soon.) 2. Specifications ........... 5 8-8. Condensation ... 46 3. Sensor and Voltage ......... 7 8-9. Comp. Operation Noise ....... 47 4.

  • Page 3: Document History

    Content 10. Disassemble/Assemble Procedures 10-16. Freezer Sensor F Fan and ......69 Fan Motor 10-17. Freezer Defrost Sensor and ….. 70 Heater in the eva Assembly 10-18. Condenser Fan Motor …. 71 in Machine Room 10-19. Freezer, Pantry and R e f r i ge r at o r ..Door Switchs 10-20.

  • Page 4: General Information

    1. General Information Technician SAFETY Precautions Please observe the following safety precautions in order to use safely and correctly the refrigerator and to prevent accident and danger during repair ● To avoid electrical shock, disconnect power cord from wall outlet and wait for more than three minute before handling electronic components or capacitors.

  • Page 5: Specifications

    2. Specifications Model Name 111.7269**** Factory Model Name RFP83KE***** Total 29.53 Volume Freezer 8.93 AHAM 2008 Pantry 3.75 (Cu ft.) Refrigerator 16.84 External Dimension 35.86” x 70.11” x 38.26” (w/o Handle) (Width * Depth * Height) Rated Voltage 115~120V (60Hz) Weight (Kg) Gross (w/ Package)
  • Page 6 2. Specifications (continued) Model Name 111.7269**** Factory Model Name RFP83KE***** Defrost(F/D-SENSOR, R/D-SENSOR,I/M-D- In Evaporator Assembly, SENSOR) In Icemaker Evaporator Assembly Freezer(F-SENSOR) In Louver Assembly Refrigerator(R-SENSOR) In Multi Flow Duct Assembly Sensor RT(“RT-SENSOR” in Wiring Diagram) Between Top Cabinet and Top Cover Hinge Icemaker Room Temp.(ICE DUCT-SENSOR) In Fixture Geared Motor Assembly Pantry Drawer Temp.(PANTRY-SENSOR)

  • Page 7: Sensor / Voltage

    3. Sensor / Voltage (Table 1 of sensor resistance and measured voltage) R, Pantry, Ice Maker, F Defrost, R Defrost, I Defrost, RT SENSOR Resistance Resistance Resistance Temp( ℉ ) Temp( ℉ ) Temp( ℉ ) DC Volts DC Volts DC Volts (kΩ) (kΩ)
  • Page 8 3. Sensor / Voltage (Table 2 of sensor resistance and measured voltage) F, Ice Room SENSOR Resistance Resistance Resistance Temp( ℉ ) Temp( ℉ ) Temp( ℉ ) DC Volts DC Volts DC Volts (kΩ) (kΩ) (kΩ) - 22.0 39.652 3.04 14.9 14.712...
  • Page 9 4. Features 4-1. Exterior Front Control Panel LED, Touch Water and Ice Refrigerator Handle Dispenser Sticker written “R” inside handles for 1 Levers correct assembly Freezer Handle Sticker written “F” inside handle for correct assembly Included Parts Hex Wrench(2.5mm) in User Manual Bag, Standoff Screws on doors To avoid risk of electrical shock that can cause death or severe personal injury, 9 / 69...
  • Page 10 4. Features 4-2. Interior Filter Cover Water Filter Foldable Shelf fixed by magnet after folding Air Filter Cover Slid Away Split Icemaker Compartment Shelf Icemaker and Ice Bin Extra Bin Fixed Dairy Bin Fixed Shelves Gallon Bin Fixed Adjustable, Spill proof Gallon Bin Small Bin Fixed...
  • Page 11 4. Features 4-3. Others Refrigerator Sensor RT Sensor Refrigerator Door Switches Refrigerator Fan Motor Icemaker Pantry Door Sensor Room Sensor Pantry Door Switch Freezer Sensor Ice Type (Cubed/Crushed) Selector Water Tank Assembly Freezer Freezer Door Switch Fan Motor To avoid risk of electrical shock that can cause death or severe personal injury, 11 / 69 WARNING disconnect unit from power before servicing unless tests require power.
  • Page 12 4. Features 4-4. Machine Room Water Filter Inlet 1/4 “ Tube) Condenser Fan Connector(front) Step Valve Connector(back) Inverter Controller Signal Connector Hot Pipe (Outlet) Hot Pipe (Inlet) Flow Sensor Process Part in Valve Water Condenser in Compressor Step Valve Inverter Controller Dryer Valve Water...

  • Page 13: Flow Diagram

    5. Flow Diagram 5-1. Cold Air Flow Refrigerator Compartment Damper Control Air of Pantry Pantry` Compartment` Freezer Compartment To avoid risk of electrical shock that can cause death or severe personal injury, 13 / 69 WARNING disconnect unit from power before servicing unless tests require power.
  • Page 14 5. Flow Diagram 5-2. Water Flow RFP83* Water Water Tank Dispenser Water Main Water Valve Water Filter Icemaker Flow (R Room) Sensor □ Water Supply Pressure must be : Min 30psi (207kPa, 2.1kgf/㎠) Max 125psi (862Kpa, 8.8kgf/㎠) ※ If the water pressure exceeds 125psi, a pressure reducing valve must be installed. ※...
  • Page 15 5. Flow Diagram 5-3. Refrigerant Flow and Lokring Point Connecting Point POINTS Factory Service Copper Welding Lokring Lokring Lokring PIPE SVC (Process) Forced cool (short circuit) mode –[recommended for sealed system repair] With unit in normal operation (if just plugged in, wait for compressor to start) COMPRESSOR Lock Inner PCB While pressing the water filter and the icemaker...
  • Page 16 5. Flow Diagram 5-3. Refrigerant Flow and Lokring Point ST1,ST2,ST3 “PIPE CONN A1 AS”(connected from compressor discharge pipe to condenser inlet pipe) included in OD6mm Condenser Ass’y(“PIPE WICON AS”) Filter-drier Lokring Part Number Spec. Location Description Process Stub L13000654 8/6NRMS00 Discharge L13000630 6/5NRMS00...

  • Page 17: Wiring Diagram

    6. Wiring Diagram 6-1. Total View(1/2) To avoid risk of electrical shock that can cause death or severe personal injury, 17 / 69 WARNING disconnect unit from power before servicing unless tests require power.
  • Page 18 6. Wiring Diagram 6-1. Total View(2/2) To avoid risk of electrical shock that can cause death or severe personal injury, 18 / 69 WARNING disconnect unit from power before servicing unless tests require power.
  • Page 19 6. Wiring Diagram 6-2. Icemaker Circuit To avoid risk of electrical shock that can cause death or severe personal injury, 19 / 69 WARNING disconnect unit from power before servicing unless tests require power.
  • Page 20 6. Wiring Diagram Inner (User Interface) Board Connection Diagram Pantry PBA INNER PBA Dispenser PBA (User Interface) Main PBA Door hinge connectors not illustrated PANTRY PBA INNER PBA INNER PBA CN4 (5P) CN2A (5P) CN2A INNER PBA (6P) DISP PBA CN4 (4P) MAIN PBA CN12 (9P)
  • Page 21 6. Wiring Diagram Dispenser/ DV/ Icemaker Heater Operation 1. The “DISPNS HTR” is always on and located in the dispenser box. 2. The “DV HTR” is always on and located in the mullion bar. 3. The “R ICE AL PIPE HTR” cycles repeatedly, Under 21℉(-6℃) on and 25 ℉ (-4℃) off. It is located within the icemaker.
  • Page 22 6. Wiring Diagram CN 16 of PCB Main (Damper & Step Valve) Item Pin No Remarks Voltage(V) frequency(Hz) Voltage(V) frequency(Hz) Damper Heater Floating Damper Signal 3,4,5,6 Floating Step Motor 7,8,9,10 0~12V Swing Floating ※ Floating – pins 7, 8, 9, 10 are completed to circuit ground in sequence to operate the stepper valve Step Motor [Ω] CoilPOINT...
  • Page 23 6. Wiring Diagram CN 12 of PCB Main (Inner Control Panel) Item Pin No Remarks Voltage(V) frequency(Hz) Voltage(V) frequency(Hz) RX, TX 0~5V Swing Immeasurable Power Always on • This control panel is located inside the hinge cover. • On the SVC Parts list, it is stated as " A10 "COVER HI *T AS" •...

  • Page 24: Operation And Functions

    7. Operation and Functions 7-1. How to Use Control Panel 7-1-1. Dispenser Control Panel Button Item Display Description Default : Water LED on ① Dispenser Water LED ① Press ①button and “Water “LED on ② LED ② Press ②button and “Cubed Ice “LED on Dispenser Cubed Ice ③...
  • Page 25 7. Operation and Functions 7-1-3 Inner Control Panel ⓐ ⓖ ⓓ ⓔ ⓗ ⓘ ⓑ ⓒ ⓕ Button Item Display Description 88 LED Initial Temperature by power input Freezer : 0ºF / Refrigerator : 37ºF Press and hold ＂Water Filter” button for 3sec, “CHANGE” icon LED OFF LED ①...
  • Page 26 7. Operation and Functions 7-1-1. Inner Control Panel ⓖ ⓐ ⓓ ⓔ ⓗ ⓘ ⓑ ⓒ ⓕ Button Item Display Description ⓖ→ Switch Temperature Unit ºF ↔ ℃ LED ⑭ ⓓ and ⓔ ⓓⓔ In lock mode, press and hold buttons at the same time for 5sec 1.
  • Page 27 7. Operation and Functions 7-1. How to Use Control Panel (continued) ⓐ ⓑ ⓒ ⓓ ⓔ ⓕ ⓘ ⓗ ⓖ Button Item Display Description ⓐ & ⓑ ⓒ □ How to Start : While In lock mode, press and hold then press within 5seconds and release all.
  • Page 28 7. Operation and Functions 8-1-3. Inner Control Panel (continued) ⓐ ⓑ ⓒ ⓓ ⓔ ⓕ ⓗ ⓘ ⓖ Button Item Display Description ⓖ ⓑ & ⓒ □ How to Start : In lock mode, press 5 times, while pushing ⓑ & ⓒ once and hold for 5ecs □...
  • Page 29 7. Operation and Functions 7-2. Service Mode and Error Display □ How to Start : Preparation Work INPUT Water Dispenser Ice Maker “Lock” Mode ON Filter Light □ How to Proceed : • Pressing Freezer temp will advance forward (increasing step #), and Dispenser Light button will go backwards •...
  • Page 30 7. Operation and Functions Example Display STEP Content Description etc. F 88 R 88 etc. Error Code : Icemaker Room Sensor Error Code : Pantry Drawer Sensor The sensor is read as open or shorted. Check the wiring connections in each part and at Main PCB. Error Code : F Defrost Sensor Error Code...
  • Page 31 7. Operation and Functions 7-2. Service Mode and Error Display (continued) Example Display STEP Content Description etc. F 88 R 88 etc. Forced Defrost How to Force Defrost : Mode Display : Forced Defrost Ξ Ξ When the inner PCB is locked, while water filter (Only visible when Forced Defrost is active) and icemaker is pressed together, press smart grid 5 times...
  • Page 32 7. Operation and Functions • 7-5. Service Mode and Wifi Mode • How to Diagnose if not working : Enter Wifi test mode and check the current status of Wifi Module. To Enter Wifi Test mode : 1) Place User Interface into lock mode 2) Press and hold both “Ice Maker”...
  • Page 33 7. Operation and Functions 7-3. Compressor, Fan & Damper Output Icemaker Comp C FAN F FAN R FAN Pantry Damper Room FAN Freezer On/Off On/Off On/Off Refrigerator On/Off Pantry Drawer Open/Close Ice Harvest Condition On/Off & Step Valve Location F Door Open R Door Open Defrosting Mode Close...
  • Page 34 7. Operation and Functions 7-7 Fan Theory of Operation When the DC Fan motor is turned on There is RPM stabilization period for 30 seconds Afterwards, there is RPM error detection for 30 seconds consecutively (If no error is detected, item 3 is not executed) The fan turns off for 1 minute when/if RPM error is detected Fan motor restarts after 1 minute...
  • Page 35 7. Operation and Functions 7-8. Icemaker in the Icemaker Room 1) Icemaker Room Temperature Control : by IM Sensor On/Off • Icemaker Room Temp is controlled by IM Sensor on/off setting value. • In “Accela Ice” mode, the compress and icemaker room fan will turn on 24hr for Quick Icing. ※...
  • Page 36 7. Operation and Functions 7-8. Icemaker in the Icemaker Room (continued) 3) Icemaker Power OFF : □ How to Start : Preparation Work INPUT Maker Press power button of the icemaker for 3sec. □ How to Proceed : • Display : LED light of Icemaker will turn off. And “off” icon of the inner control panel will light up. •...
  • Page 37 7. Operation and Functions 7-9. Pantry Drawer Room • The Temp is controlled by Pantry Drawer Sensor, RT Sensor and Pantry Drawer Damper. • In case of Pantry Drawer Sensor error, the Pantry Drawer damper will repeat open and close every 5min. 7-9.
  • Page 38 7. Operation and Functions 7-10 Compensation of Refrigerator Sensor On/Off Temp □ R42 : R-SENSOR standard resistance in normal mode (31.4㏀) □ In case temperature of refrigerator compartment is week or insufficient, take the following action. • Cut J1 to increase the standard resistance by 2㏀ ⇒ 1.5℃ down (2.7 ºF down) •...
  • Page 39 7. Operation and Functions To avoid risk of electrical shock that can cause death or severe personal injury, 39 / 69 WARNING disconnect unit from power before servicing unless tests require power.

  • Page 40: How To Service

    8. How to Service 8-1. Faulty Start (F/M/R lights Off , F-PCB Power Off) Start Power input to Main PCB is ok? Check power connection from machine compartment to CN1 of Main PCB. Main PCB Fuse is disconnected? Change the fuse (AC250V 4A) on the Main PCB Voltage...
  • Page 41 8. How to Service 8-2. Freezing Failure . (Foods are not frozen/cold.) Start Refer to error display in operation and function Any error code on Front PCB? ■ How to check the inverter controller : 1) Empty the ice in the ice maker bucket 2) Run “Accella Ice”...
  • Page 42 8. How to Service 8-3. Ice Formation on F-Louver Start Condensation formed on the Gasket has a gap Remove the gap. gasket surface inside between cabinet ? F-compartment ? Door is hanged Reassemble the door. down ? Door is open and closed too frequently ? Explain not to open doors too frequently.
  • Page 43 8. How to Service 8-4. Disconnection / Breaking of Freezer Lights Ass’y Start Power of F Lamp Is OK ? (DC12V) Connection of F door switch is OK ? Change the Lamp Ass’y. Repair the F door switch. Check the power connection? (From Main PCB to F Lamp) ■...
  • Page 44 8. How to Service 8-5. Disconnection / Breaking of Pantry Lights Ass’y Start Power of Pantry Lamp Is OK ? (DC12V) Connection of Pantry door switch is OK ? Change the Lamp Ass’y. Repair the Pantry door switch. Check the power connection? (From Main PCB to Pantry Lamp) ■...
  • Page 45 8. How to Service 8-6. Disconnection / Breaking of Refrigerator Lights Ass’y Start Power of R Lamp Is OK ? (DC12V) Connection of R door switch is OK ? Change the Lamp Ass’y. Repair the R door switch. Check the power connection? (From Main PCB to R Lamp) ■...
  • Page 46 8. How to Service 8-7. Refrigeration Failure (Foods does not get cool or cold soon.) Start Any error mode on Front PCB? Solve error code problem, if any. Change R-Fan R-Fan motor the R-Fan motor. works ok ? is ok? Wiring connection Change the Main PCB.
  • Page 47 8. How to Service 8-8. Condensation on Refrigerator Compartment Start Condensation formed Gasket has Repair to eliminate the gap. on the gasket inside Any gap ? R-compartment? Door is Reassemble the doors. hanged down ? Door is open too long ? Explain not to open doors too long.
  • Page 48 8. How to Service 8-9. Comp. Operation Noise Start Refrigerator is leveled ? Level the refrigerator by adjusting wheels. ☞ Refer to User’s Guide and SVC Manual. Front cover or door gasket is assembled wrong ? Set it right. Absorber comp is distorted or aged ? Change the absorber comp.
  • Page 49 8. How to Service 8-10. Refrigerant Flow Sound Start Water flowing or hiss sounds from the refrigerator ? Attach an absorber gum on the capillary tube. Refrigerant sound of hiss or sizzling sound when comp. starts ? Apply a gum on the accumulator.
  • Page 50 8. How to Service 8-11. Fan Noise Start Fan is damaged or transformed ? Change the fan. Fan is touching the surround ? Set it right not to touch. Fan-motor assembly is moving or shaking ? Set it right not to move. Motor has its own noise or vibration when working ? Change the motor...
  • Page 51 8. How to Service 8-12. Pipe Noise Start Pipes are touching in the machine compartment ? Separate the touching pipes, if any. Tray drip makes noise by Condenser shaking ? Apply cushion material between Comp. base and Tray drip. Pipe itself is shaking much ? Move or change the points of vibration absorber rubbers on...
  • Page 52 8. How to Service 8-13. Door opening alarm continues though the door is closed. Start Check if F,M,R Lamp is ON. Is the switch activated? Attach a thin pad on the door liner or change the door assembly. Door switch is soaked with water or there is water in the switch ? Change the door switch.

  • Page 53: Sealed System Repair

    9. Sealed System Repair Technician SRC 111 R600a SS Repair Guide The following is in addition to or serves as a reminder of the established and prescribed company service procedures for R600a sealed system diagnosis & repair. 1. This refrigerator contains flammable refrigerant. Follow all relative company, federal, and local safety guidelines 2.
  • Page 54 10. Disassemble/Assemble Procedures 10-1. Holder Water Filter Assembly ※ Follow the reverse order when assembling. Step Description Step Description Remove a screw Turn off the main water supply to the appliance. Separate the tube fixture on the upper left side cabinet back face. Pull down the Holder Assembly and tubes gently to remove.
  • Page 55 10. Disassemble/Assemble Procedures 10-2. Water Tank and Cover Vegetable Assembly ※ Follow the reverse order when assembling. Step Description Step Description Remove Cover case. Turn off the main water supply to the appliance. Remove two screws. Remove two vegetable cases Take off the front cover from the water tank assembly to see the water storage...
  • Page 56 10. Disassemble/Assemble Procedures 10-2. Water Tank and Cover Vegetable Assembly (continued) ※ Follow the reverse order when assembling. Step Description Water Tank Assembly (tank + tubes + cover + …) Separate the fixture to protect 5/16”(the big one) tube from Water bending damage.
  • Page 57 10. Disassemble/Assemble Procedures 10-3. Hose Ice Maker Tube Assembly ※ Follow the reverse order when assembling. Step Description Step Description Separate the cover Remove the icemaker water icemaker Water tube tube cover. on the top of cabinet Using (-) driver. Pull the water outlet parts.
  • Page 58 10. Disassemble/Assemble Procedures 10-4. cover Icemaker ※ Follow the reverse order when assembling. Step Description Hold the bottom of the bucket and then pull it straight out. Unscrew and remove the wires cover. Disconnect the connector of icemaker. Remove the icemaker. □...
  • Page 59 10. Disassemble/Assemble Procedures 10-5. Fixture Geared Motor ※ Follow the reverse order when assembling. Step Description Disconnect the connector of the Fixture Geared Motor assembly. GOOD Separate wires from hooks gently. Pull a hook to the right to remove. GOOD Remove the Fixture G/Motor.
  • Page 60 10. Disassemble/Assemble Procedures 10-6. Pantry Drawer Cover and Cover Multi-duct Assembly ※ Follow the reverse order when assembling. Step Description Step Description Disconnect one sensor Remove vegetable cases, connectors and the vegetable cover. Loosen two motor Connectors from screws from water tank back wall.
  • Page 61 10. Disassemble/Assemble Procedures 10-7. Refrigerator Sensor, Pantry Drawer Sensor, Dampers in Cover Multi-duct Assembly ※ Follow the reverse order when assembling. Step Description Separate the insulator from the multi-duct cover. Remove R sensor on the upper side of cover. □ Remark : To avoid risk of electrical shock that can cause death or severe personal injury, 60 / 69 WARNING...
  • Page 62 10. Disassemble/Assemble Procedures 10-8. Refrigerator Defrost Sensor and Heater in the Evaporator Assembly ※ Follow the reverse order when assembling. Step Description Step Description remove clamping parts. right Remove the (the left and right side three connectors. of Eva) Pull out the evaporator from Bend out the lower clamping shape on the back wall.
  • Page 63 10. Disassemble/Assemble Procedures 10-9. Cover Damper and Insu Damp Covr Assembly ※ Follow the reverse order when assembling. Step Description Step Description Remove the tape from Remove one screw the floor. Disconnect the damper Connectors from back wall. Grasp the tape with both hands and lift it to the top to remove it.
  • Page 64 10. Disassemble/Assemble Procedures 10-10. Defrost Sensor in the Ice Maker Evaporator Assembly ※ Follow the reverse order when assembling. Step Description Remove eight screw attached to the cover. And remove cover. Straighten the 4 bent positions of the cover plate. Swing the cover plate to the right Cut the sensor wire and remove the defrost sensor on the right side of the evaporator.
  • Page 65 10. Disassemble/Assemble Procedures 10-11. Defrost Heater in the Ice Maker Evaporator Assembly ※ Follow the reverse order when assembling. Step Description Step Description Remove 8 screws Properly recover the R600a refrigerant and remove cover Disconnect Cut both copper harnesses tubes just above and as close to the brazed joint as possible...
  • Page 66 10. Disassemble/Assemble Procedures 10-12. Panel M Pcb Assembly. ※ Follow the reverse order when assembling. Step Description Remove one Panel with a thin flat tool. Separate the Panel M Pcb assemble. Disconnect one connectors from top wall. □ Remark : To avoid risk of electrical shock that can cause death or severe personal injury, 65 / 69 WARNING...
  • Page 67 10. Disassemble/Assemble Procedures 10-13. Supporter M Draw Rail Assembly. ※ Follow the reverse order when assembling. Step Description Step Description Separate the Case assemble. Pull a door to the top to remove release the right Pull a hook to the Rail Gear as right to remove.
  • Page 68 10. Disassemble/Assemble Procedures 10-13. Supporter M Draw Rail Assembly. ※ Follow the reverse order when assembling. Step Description Press the right fixing hook of the rail system. Holding the top of the Rail, pull it out a little to release. Remove one screw Disconnect two connectors from...
  • Page 69 10. Disassemble/Assemble Procedures 10-14 Freezer Louver Assembly ※ Follow the reverse order when assembling. Step Description Step Description Disconnect the connectors of F fan motor and F sensor. Remove freezer drawers. Fixture F Rail *M (Material : steel bar) Gear F rail *M Press the left fixing hook of the rail system.
  • Page 70 10. Disassemble/Assemble Procedures 10-16. Freezer Sensor, F Fan and Fan Motor ※ Follow the reverse order when assembling. Step Description Step Description Remove the tape to separate wires of F-sensor and F Fan motor. Remove Three Tape. And remove F Fan motor assembly from the Louver. Remove three screws.
  • Page 71 10. Disassemble/Assemble Procedures 10-17. Freezer Defrost Sensor and Heater in the Evaporator Assembly ※ Follow the reverse order when assembling. Step Description Step Description Remove two temp left and right fuses of defrost heater. Remove the three connectors. remove clamping parts. (the left and right side of Eva) Pull out the evaporator from 2 hooks on the back wall.
  • Page 72 10. Disassemble/Assemble Procedures 10-18. Condenser Fan Motor in the Machine Room ※ Follow the reverse order when assembling. Step Description Step Description Disconnect the connector of C Fan Motor. Break the shaft(plastic) of fan blade. Do not use the old fan again. Be careful not to damage the shaft of motor if the motor is used again.
  • Page 73 10. Disassemble/Assemble Procedures 10-19. Freezer, Pantry and Refrigerator Door Switches ※ Follow the reverse order when assembling. Step Description Step Description Remove the F door switch with flat-blade screwdriver. Loosen 5 screws and remove the top hinge cover. Disconnect the connector.
  • Page 74 10. Disassemble/Assemble Procedures 10-20. Front Control Panel Dispenser in the Left Refrigerator Door ※ Follow the reverse order when assembling. Step Description Grip the bottom side of the FCP with two hands and lift and pull it forward to remove. Disconnector the connector.
  • Page 75 10. Disassemble/Assemble Procedures 10-21. Box Dispenser ※ Follow the reverse order when assembling. Step Description Step Description Remove the Front Loosen 2 screws. Control Panel. Loosen 4 screws to remove the Box Dispenser Ice Shutter Assembly. Pull and remove the assembly.
  • Page 76 10. Disassemble/Assemble Procedures 10-22. Lever Dispenser ※ Follow the reverse order when assembling. Step Description Step Description Grip the bottom side of Remember how to the lever with hands arrange the spring and lift and pull it assemble. forward to remove. Separate the spring which is assembled to lever.
  • Page 77 10. Disassemble/Assemble Procedures 10-23 Mullion Bar Assembly ※ Follow the reverse order when assembling. Step Description ※ Assemble Procedures at Middle Hinge Part Align the 2 screw holes on the door with the mounting holes on the middle hinge of mullion bar after fitting two Loosen 2 screws.
  • Page 78 10. Disassemble/Assemble Procedures 10-24. Interior F/M/R Lamp ※ Follow the reverse order when assembling. Step Description Step Description Disconnect the r lamp connector. Remove the F lamp with flat-blade screwdriver. Disconnect the F lamp connector.. Remove the F lamp with flat-blade screwdriver. Push a hook to the right to remove..
  • Page 79 10. Disassemble/Assemble Procedures 10-25. Wifi Modules. ※ Follow the reverse order when assembling. Step Description Step Description Make sure power to the Refrigerator is OFF and power cable is unplugged. Remove 5 philps screws from the top display and door hinge cover. Carefully flip the display controller.
