7.
2.2

Unpacking the device

When unpacking the device, do the following:
1.
2.
3.
Note
If any item is missing or damaged, contact Siemens for assistance.
2.3

Mounting the Device

The RUGGEDCOM RSG909R is designed for maximum mounting and display
flexibility. It can be equipped with adapters that allow it to be attached to a DIN rail
or panel.
Note
Heat generated by the device is channeled outwards from the enclosure. As such, it
is recommended that 2.5 cm (1 in) of space be maintained on all open sides of the
device to allow for some convectional airflow.
Forced airflow is not required. However, any increase in airflow will result in a
reduction of ambient temperature and improve the long-term reliability of all
equipment mounted in the rack space.
Note
For detailed dimensions of the device with either DIN rail or panel hardware installed,
refer to "Dimension Drawings" (Page 33).
2.3.1

Mounting the Device on a DIN Rail

The RUGGEDCOM RSG909R can be ordered with a DIN rail adapter preinstalled on the
back of the chassis. Use the adapter to mount the device to a standard 35 mm (1.4
in) by 15 mm (0.6 in) IEC/EN 60715 or TS35 DIN rail.
DIN rail mounting is not recommended for constant vibration environments.
RUGGEDCOM RSG909R
Installation Manual, 04/2023, C79000-G8976-1388-17
Configure the device.
For more information, refer to "Configuring the Device" (Page 26).
Inspect the package for damage before opening it.
Visually inspect each item in the package for any physical damage.
Verify all items are included.
NOTICE
Installing the Device
2.2 Unpacking the device
