IT IS IMPORTANT TO READ THIS INSTRUCTION BOOK PRIOR TO USING YOUR NEW PRODUCT FOR THE FIRST TIME. ES IMPORTANTE LEER ESTE MANUAL ANTES DE USAR POR VEZ PRIMERA SU EQUIPO. US Cover RP5010 RP5012 1/21/02, 10:05 AM...
Page 3
T H E L I G H T N I N G FLASH AND ARROW- HEAD WITHIN THE T R I A N G L E I S W A R N I N G ALERTING YOU OF " D A N G E R O U S VOLTAGE"...
FCC information FCC Information This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Contents General controls---------2-3 The display-------------------4 Display messages---------5 Before you begin ---------6 Setting the time-----------7 Basic operation------------8 Recording mode-----------9 RP5010 Recording quality condition--------------------10 Other functions-----------11 Erasing file / folder------12 Advanced operation----13 Troubleshooting tips---14 More information-------15 Warranty----------------16-18 8/9/02, 6:00 PM...
Note: Auto power off- the unit will turn off automatically without key activation in 3 minutes. RP5010 Recording indicator external microphone jack VOL UP: volume up DIGITAL VOICE RECORDER ERASE MENU VOLUME DOWN: volume down Built-in speaker 8/9/02, 6:00 PM...
Page 7
General controls REC: starts/ pauses recording STOP: stops playback/ recording. Turns off the unit. PLAY: turns the unit on. Starts/ pauses playback. FORWARD: skips and searches forward. Selects/Browses under menu mode REVERSE: skips and searches backward. Selects/Browses under menu mode RP5010 Connects headphones...
The display The Display Folder Number (1-4) Current File Number FOLDER Total Number of files in a folder REMAIN Total Remaining Time for recording Play/ Record RP5010 Battery level indicator Lock Time/ Date/ recorded time Playback mode: DICT CONF Play one Play all Recording Conditions...
Display messages APPEND CUT-E CUT-S DELETE MM/DD 12 HOUR TIME INSERT INTRO SEN 07 TONE NO TONE VOL 15 YEAR LOCKED * ( )- You can find the mentioned displays as you set/ operate them. RP5010 ALL= Select all (Introductory Play back & Erasing All Files) APPEND= Appendix (Adding Appendix) CUT-E= Cut End (Cutting)
Before you begin Power supply This unit can be operated by 2 AAA batteries or 3V DC power supply. Installing Batteries (not included) 1. Slide the battery compartment door to the bottom and lift up the door to open. 2. Insert 2 AAA batteries with polarities matching indications.
Setting the time Year/Date/12/24/Time Setting With this function, you can always read on the display the recording date and time of your recorded messages. Follow the steps below for time setting. You can still use this unit for normal recording without setting the time. However, no correct recording date and time can be referred for your recorded messages and the display will...
Basic operation Manual recording 1. In STOP mode, select folder (1-4). 2. Press RECORD to start recording. (recording time will be displayed once you press RECORD) 3. To pause recording, you can press RECORD once, press again to resume recording. 4.
Recording mode Setting Recording Mode You can select between two recording modes - manual recording and AVR (automatic voice recording). 1. Manual Recording Please refer to page 8. 2. AVR (Automatic Voice Recording) This feature allows the unit to sense sound and to record only when you are speaking into the microphone.
Default is SP. Definition • SP (Standard Play) - allows about 160 min recording on RP5010, 320 min on RP5012. • HQ (High Quality) - allows about 60 min recording on RP5010, 120 min on RP5012. 1. Press MENU...
Other functions IntroScan This feature allows playback of the beginning 3 seconds of each file in a folder. 1. Select folder (1-4). 2. Press REVERSE or FORWARD until ALL shows on display. 3. Press PLAY to start introductory playback, INTRO shows on display.
Erasing file / folder Erasing selected file You can delete a file by the folowing steps: 1. Select folder (1-4) 2. Select file. 3. Press ERASE once and DELETE will blink on the screen. 4. Press and hold ERASE to confirm deleting.
Advanced operation CAUTION • The edit function does not operate when battery power is too low. • After editing a message, “WAIT” will be displayed. Do not power off the device until “WAIT” disappears. Insert You can insert new segments into a file without erasing previously recorded content.
Troubleshooting tips Unit doesn’t turn on • Check that batteries are properly inserted and not exhausted. • Make sure battery compartment door is properly closed. • Make sure LOCK function is not activated. Display keeps flashing when unit is • You may not have set the time. Refer to section on Time Setting.
More information Precautions for the Unit • Do not use the unit immediately after transportation from a cold place to a warm place; condensation problem may be resulted. • Avoid shock to the unit especially during recording. Recorded data can be damaged.
Page 20
US limited warranty What your warranty covers: • Defects in materials or workmanship. For how long after your purchase: • One year from date of purchase. The warranty period for rental units begins with the first rental or 45 days from date of shipment to the rental firm, whichever comes first.
US limited warranty Limitation of Warranty: • THE WARRANTY STATED ABOVE IS THE ONLY WARRANTY APPLICABLE TO THIS PRODUCT. ALL OTHER WARRANTIES, EXPRESS OR IMPLIED (INCLUDING ALL IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE) ARE HEREBY DISCLAIMED. NO VERBAL OR WRITTEN INFORMATION GIVEN BY THOMSON MULTIMEDIA INC., ITS AGENTS OR EMPLOYEES SHALL CREATE A GUARANTY OR IN ANY WAY INCREASE THE SCOPE OF THIS WARRANTY.
Page 22
Canadian limited warranty Thomson multimedia Ltd. warrants to the purchaser or gift recipient that if any manufacturing defect becomes apparent in this product within 1 year from the original date of purchase, it will be replaced free of charge, including return transportation. This warranty does not include damage to the product resulting from accidents, misuse or leaking batteries.
